CHRYSLER 300 2006 1.G Owners Manual

WARNING!
Adjusting a seat while the vehicle is moving is
dangerous. The sudden movement of the seat could
cause you to lose control. The seat belt might not be
properly adjusted and you could be injured. Adjust
the seat only while the vehicle is parked.
CAUTION!
Do not place any article under a power seat as it may
cause damage to the seat controls.
Power Reclining Seats
The recliner control for both front seats is located on the
outboard side of the seat.
WARNING!
Do not ride with the seatback reclined so that the
shoulder belt is no longer resting against your chest.
In a collision you could slide under the seat belt and
be seriously or even fatally injured. Use the recliner
only when the vehicle is parked.
Power Seat Recline Switch
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 91
3

Lumbar Support
This feature allows you to increase or decrease the
amount of lumbar support. Turn the control lever for-
ward to increase and rearward to decrease the desired
amount of lumbar support.
Heated Seats—If Equipped
Heated seats, which are available only with leather
upholstery, provide comfort and warmth on cold days
and can help soothe sore muscles and backs. The heaters
provide the same heat level for both cushion and back.The front driver’s and passenger seats are heated. The
controls for each heater are located near the bottom
center of the instrument panel. After turning on the
ignition, you can choose from High, Off, or Low heat
settings. Amber LEDs in the top portion of each switch
indicate the level of heat in use. Two LEDs are illumi-
nated for high, one for low, and none for off. Pressing the
switch once will select high-level heating.
Lumbar Support Control Lever
Heated Seat Switch
92 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Pressing the switch a second time will select low-level
heating. Pressing the switch a third time will shut the
heating elements off.
When high-temperature heating is selected, the heaters
provide a boosted heat level during the first four minutes
of operation after heating is activated. The heat output
then drops to the normal high-temperature level. If
high-level heating is selected, the system will automati-
cally switch to the low level after two hours of continu-
ous operation. At that time, the number of illuminated
LEDs changes from two to one, indicating the change.
Operation on the low setting also turns off automatically
after two hours.
NOTE:Once a heat setting is selected, heat will be felt
within two to five minutes.
WARNING!
Persons who are unable to feel pain to the skin
because of advanced age, chronic illness, diabetes,
spinal cord injury, medication, alcohol use, exhaus-
tion or other physical condition must exercise care
when using the seat heater. It may cause burns even
at low temperatures, especially if used for long
periods of time.
Do not place anything on the seat that insulates
against heat, such as a blanket or cushion. This may
cause the seat heater to overheat.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 93
3

Head Restraints
Head restraints can reduce the risk of whiplash injury in
the event of impact from the rear. Adjustable restraints
should be adjusted so that the upper edge is as high as
practical.
The head restraints have a locking button which must be
pushed in to lower the head restraint. The restraints may
be raised without pushing in the button.
Folding Rear Seat
The rear seatbacks can be folded forward to provide an
additional storage area. Pull on the loops shown in the
illustration to fold down either or both seatbacks. These
loops can be tucked away when not in use.
When the seat back is folded to the upright position make
sure it is latched by strongly pulling on the top of the seat
back above the seat strap.
Adjustable Head Restraint
Folding Rear Seats
94 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

WARNING!
The cargo area in the rear of the vehicle (with the
rear seatbacks in the locked-up or folded down
position) should not be used as a play area by
children when the vehicle is in motion. They could
be seriously injured in an accident. Children should
be seated and using the proper restraint system.
DRIVER MEMORY SEAT
This feature allows the driver to store up to two different
memory profiles for easy recall through a memory
switch. Each memory profile contains desired driver seat,
side mirror, adjustable pedals (if equipped), and power
tilt and telescopic steering column (if equipped) position
settings, and a set of desired radio station presets.
The memory switch is located on the driver’s door panel.
The switch contains an (S) button to activate the memory
save function. It also contains a rocker switch labeled
with the number (1) and the number (2). The rockerswitch allows the driver to recall either of two pre-
programmed memory profiles by pressing the appropri-
ate side of the switch.
To Set The Memory Feature Follow These Steps:
NOTE:Saving a new memory profile will erase an
existing profile from memory.
Memory Switch
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 95
3

1. Adjust all memory profile settings to desired prefer-
ences (i.e. seat, side mirror, adjustable pedals [if
equipped], power tilt and telescopic steering column [if
equipped], and radio station presets).
2. Press and release the Set (S) button on the memory
switch, then press the side of the rocker switch labeled (1)
within 5 seconds. The Electronic Vehicle Information
Center (EVIC)—if equipped will display which memory
position is being set.
If desired, a second memory profile can be stored into
memory as follows:
1. Adjust all memory profile settings to desired prefer-
ences (i.e. seat, side mirror, adjustable pedals [if
equipped], power tilt and telescopic steering column [if
equipped], and radio station presets).
2. Press and release the Set (S) button on the memory
switch, then press the side of the rocker switch labeled (2)
within 5 seconds. The Electronic Vehicle Information
Center (EVIC)—if equipped will display which memory
position is being set.NOTE:Memory profiles can be set without the vehicle
in Park, but the vehicle must be in Park to recall a
memory profile.
NOTE:The Recall Memory with Remote Key Unlock
feature can be enabled through the Electronic Vehicle
Information Center (EVIC)—if equipped. Refer to
“Personal Settings (Customer Programmable Features)”
under“Electronic Vehicle Information Center (EVIC)”in
Section 4 of this manual for details.
Programming the Remote Keyless Transmitter for
the Memory Feature
Your Remote Keyless Entry Transmitters can be pro-
grammed to recall one of two pre-programmed memory
profiles by pressing the UNLOCK button on the Remote
Keyless Entry Transmitter.
To program your transmitters, perform the following:
1. Remove key from ignition.
2. Select desired memory profile 1 or 2.
96 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

3. Press and release the Set (S) button on the memory
switch, then press and release the side of the rocker
switch labeled 1 or 2 accordingly.Memory Profile Set”(1
or 2) will display in the instrument cluster on vehicles
equipped with the Electronic Vehicle Information Center
(EVIC).
4. Press and release the LOCK button on the transmitter
within 10 seconds.
NOTE:Your transmitters can be unlinked to your
memory settings by pressing the Set (S) button followed
by the UNLOCK button on the transmitter in Step 4
above.
Easy Entry/Exit Seat (Available with Memory Seat
Only)
This feature provides automatic driver seat positioning
which will enhance driver mobility out of and into the
vehicle.
The distance the seat is moved is dependent on the
driver’s seat location once the key is removed from the
ignition.
•The seat cushion will move rearward about 2.4 inches
(60 mm) if the starting position of the seat is greater
than or equal to 3.5 inches (90 mm) forward of the rear
seat stop when the key is removed from the ignition
switch. The seat will return to its previously set
position when the key is placed into the ignition and
turned out of the LOCK position.
•The seat will move to the position located 1.2 inches
(30 mm) forward of the rear stop if the starting
position is between 2.4 inches to 3.5 inches (60 mm to
90 mm) forward of the rear stop when the key is
removed from the ignition switch. The seat will return
to its previously set position when the key is placed
into the ignition and turned out of the LOCK position.
The Easy Entry/Easy Exit feature will be automatically
disabled if the seat is already positioned closer than 2.4
inches (60 mm) forward of the rear stop. At this position
there is no benefit to the driver by moving the seat for
Easy Exit or Easy Entry.
Each stored memory setting will have an associated Easy
Entry and Easy Exit position.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 97
3

NOTE:The Easy Entry/Easy Exit feature is disabled
when the vehicle is delivered from the factory. The Easy
Entry/Easy Exit feature can be enabled or disabled
through the programmable features in the Electronic
Vehicle Information Center (EVIC). Refer to“Automati-
cally Move Seat Back on Exit”under“Personal Settings
(Customer Programmable Features)”under“Electronic
Vehicle Information Center (EVIC)”in Section 4 of this
manual for details.
ADJUSTABLE PEDALS—IF EQUIPPED
This feature allows both the brake and accelerator pedal
to move toward or away from the driver to provide
improved position with the steering wheel. The adjust-
able pedal system is designed to allow a greater range of
driver comfort for steering wheel tilt and seat position.
The switch is located on the front side of the driver’s seat
cushion side shield.Press the switch forward to move the pedals forward
(toward the front of the vehicle).
Press the switch rearward to move the pedals rearward
(toward the driver).
•The pedals can be adjusted with the ignition OFF.
•The pedals can be adjusted while driving.
Adjustable Pedal Switch
98 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

•The pedalscannotbe adjusted when the vehicle is in R
(Reverse) or when the Speed Control is ON. One of the
following message will display in the Electronic Ve-
hicle Information Center (EVIC)—if equipped if a
pedal adjustment is attempted when the system is
locked out:“Adjustable Pedal Disabled—Cruise
Control Engaged”or“Adjustable Pedal Disabled—
Vehicle In Reverse.”
NOTE:For vehicles equipped with Driver Memory Seat,
you can use your remote keyless entry transmitter or the
memory switch on the driver’s door panel to return the
adjustable pedals to pre-programmed positions. Refer to
“Driver Memory Seat”in this section for details.
CAUTION!
Do not place any article under the adjustable pedals
or impede its ability to move as it may cause damage
to the pedal controls. Pedal travel may become
limited if movement is stopped by an obstruction in
the adjustable pedal’s path.
TO OPEN AND CLOSE THE HOOD
Two latches must be released to open the hood. First, pull
the hood release lever located under the left side of the
instrument panel.
Hood Release Lever
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 99
3

Next, move to the outside of the vehicle and push the
safety catch to the left. The safety catch is located under
the center front edge of the hood.
Use the hood prop rod (if equipped) to secure the hood in
the open position.
To prevent possible damage, do not slam the hood to
close it. Lower the hood until it is open approximately 6
inches (15 cm) and then drop it. This should secure both
latches. Never drive your vehicle unless the hood is fully
closed, with both latches engaged.WARNING!
If the hood is not fully latched, it could fly up when
the vehicle is moving and block your forward vision.
You could have a collision. Be sure all hood latches
are fully latched before driving.
LIGHTS
Overhead Console Map/Reading Lights
These lights are mounted between the sun visors on the
overhead console. Each light is turned ON by pressing
the lens. Press the lens a second time to turn the light
OFF. The lights also turn on when a door is opened or the
dimmer control is turned fully upward, past the second
detent.
Hood Safety Catch
100 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
