CHRYSLER 300 2006 1.G Owners Manual

Ignition Off Operation
For vehicles not equipped with the Electronic Vehicle
Information Center (EVIC), the power sunroof switch
will remain active for 10 minutes after the ignition switch
is turned off. Opening either front door will cancel this
feature.
For vehicles equipped with the EVIC, the power sunroof
switch will remain active for up to 60 minutes after the
ignition switch is turned off. Opening either front door
will cancel this feature. The time is programmable
through the EVIC. Refer to“Delay Power Off to Acces-
sories Until Exit”under“Personal Settings (Customer
Programmable Features)”under“Electronic Vehicle In-
formation Center (EVIC)”in Section 4 of this manual for
details.
Sunroof Fully Closed
Press the switch forward and release to ensure that the
sunroof is fully closed.
ELECTRICAL POWER OUTLETS
There are two 12-volt electrical outlets on this vehicle.
Both of the outlets are protected by a fuse.
The 12 volt power outlet next to the ash receiver tray (if
equipped with an optional Smoker’s Package) has power
available only when the ignition is on. This outlet will
also operate a conventional cigar lighter unit.
WARNING!
Do not place ashes inside the cubby bin located on
the center console on vehicles not equipped with the
ash receiver tray. A fire leading to bodily injury
could result.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 131
3

NOTE:If desired, the power outlet next to the ash
receiver tray (if equipped) can be converted by your
authorized dealer to provide power with the ignition
switch in the LOCK position.The center console outlet is powered directly from the
battery (power available at all times). Items plugged into
this outlet may discharge the battery and/or prevent
engine starting.
Front Power OutletCenter Console Power Outlet
132 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Electrical Outlet Use With Engine Off
CAUTION!
•Many accessories that can be plugged in draw
power from the vehicle’s battery, even when not
in use (i.e. cellular phones, etc.). Eventually, if
plugged in long enough, the vehicle’s battery will
discharge sufficiently to degrade battery life
and/or prevent engine starting.
•Accessories that draw higher power (i.e. coolers,
vacuum cleaners, lights, etc.), will degrade the
battery even more quickly. Only use these inter-
mittently and with greater caution.
•After the use of high power draw accessories, or
long periods of the vehicle not being started (with
accessories still plugged in), the vehicle must be
driven a sufficient length of time to allow the
alternator to recharge the vehicle’s battery.
•Power outlets are designed for accessory plugs
only. Do not hang any type of accessory or acces-
sory bracket from the plug. Improper use of the
power outlet can cause damage.
CUP HOLDERS
Front Seat Cup Holders—Standard
The cup holders are located in the forward edge of the
center console.
Front Seat Cup Holders
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 133
3

Front Seat Cup Holders—300 Touring and 300C
Models
The cup holders are located in the forward edge of the
center console.
Push down on the cover as shown to expose the cup
holders. Close the cover when the cup holders are no
longer needed.
Rear Seat Cup Holders
The rear seat cup holders are located in the center armrest
between the rear seats. The cup holders are positioned
forward in the armrest and side-by-side to provide
convenient access to beverage cans or bottles while
maintaining a resting place for the rear occupants’el-
bows.
Front Seat Cup HoldersRear Seat Cup Holders
134 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

STORAGE
Console Features
The center console contains a large storage bin. The
storage bin contains a four-slot coin holder (designed to
hold various size coins) and a rubber mat at the bottom of
the bin for noise control. The bin is large enough to hold
a portable AC/DC converter to power laptops, games, or
other electrical equipment. Two slots at the top right side
of the bin provide clearance for power cords to pass
conveniently out of the bin with the lid closed. This
feature is ideal for games, laptops, cell phones, or other
electrical equipment. The console’s front-opening lid
allows for easy access to the storage bin for the both the
driver and the front passenger. The inside portion of the
arm rest lid contains a penholder, a tissue holder, and a
tire gauge holder.
In addition to the internal storage, the console contains
two shift bezel cubby bins with rubber mats for holding
small items. For vehicles not equipped with navigation
radio, the console also contains an extra storage bin
located below the climate control, which holds up to four
CD jewel cases.
Cargo Tie-Down Hooks
The tie-downs located on cargo area floor and on the rear
trim panels should be used to safely secure loads when
vehicle is moving.
WARNING!
•Cargo tie-down hooks are not safe anchors for a
child seat tether strap. In a sudden stop or colli-
sion a hook could pull loose and allow the child
seat to come loose. A child could be badly injured.
Use only the anchors provided for child seat
tethers.
•The weight and position of cargo and passengers
can change the vehicle center of gravity and
vehicle handling. To avoid loss of control result-
ing in personal injury, follow these guidelines for
loading your vehicle:
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 135
3

•Always place cargo evenly on the cargo floor. Put
heavier objects as low and as far forward as possible.
•Place as much cargo as possible in front of the rear
axle. Too much weight or improperly placed weight
over or behind the rear axle can cause the rear of the
vehicle to sway.
•Do not pile luggage or cargo higher than the top of the
seatback. This could impair visibility or become a
dangerous projectile in a sudden stop or collision.
WARNING!
To help protect against personal injury, passengers
should not be seated in the rear cargo area. The rear
cargo space is intended for load carrying purposes
only, not for passengers, who should sit in seats and
use seat belts.
LOAD LEVELING SYSTEM—IF EQUIPPED
The automatic load leveling system will provide a level
riding vehicle under most passenger and cargo loading
conditions.
A hydraulic pump contained within the shock absorbers
raises the rear of the vehicle to the correct height. It takes
approximately 1 mile (1.6 km) of driving for the leveling
to complete depending on road surface conditions.
If the leveled vehicle is not moved for approximately 15
hours, the leveling system will bleed itself down. The
vehicle must be driven to reset the system.
136 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

UNDERSTANDING YOUR INSTRUMENT PANEL
CONTENTS

Instruments And Controls................140

Standard Instrument Cluster..............141

Premium Instrument Cluster..............142

Instrument Cluster Descriptions...........143

Electronic Vehicle Information Center (EVIC). . 150
▫Electronic Vehicle Information Center (EVIC)
Displays............................151
▫Trip Functions.......................153
▫Compass Display.....................154
▫Telephone—If Equipped...............156
▫Navigation—If Equipped...............157▫Personal Settings (Customer Programmable
Features)...........................158

Setting The Analog Clock................162

Radio General Information...............163
▫Radio Broadcast Signals.................163
▫Two Types Of Signals..................163
▫Electrical Disturbances..................163
▫AM Reception.......................163
▫FM Reception........................163

Sales Code REF—AM/FM/CD (Single Disc)
Radio With Optional Satellite Radio And Hands
Free Phone Capability
...................164
4

▫Operating Instructions - Radio Mode.......165
▫Operation Instructions - CD Mode.........168
▫Operation Instructions - Auxiliary Mode.....169
▫Operating Instructions - Hands Free Phone—
If Equipped.........................170
▫Operating Instructions - Satellite Radio—
If Equipped.........................170

Sales Code RAK–AM/FM/Cassette/CD (6-Disc)
Radio With Optional Satellite Radio, Hands Free
Phone, Video, MP3, And WMA Capabilities
. . 171
▫Operating Instructions - Radio Mode.......171
▫Operating Instructions—Tape Player.......175
▫Seek Button.........................175
▫Fast Forward (FF).....................175
▫Rewind (RW)........................175
▫Tape Eject...........................175
▫Scan Button.........................175▫Changing Tape Direction................176
▫Metal Tape Selection...................176
▫Pinch Roller Release...................176
▫Noise Reduction......................176
▫Operation Instructions -
(CD Mode For CD Audio Play)...........176
▫Load/Eject Button
(CD Mode For CD Audio Play)...........177
▫Notes On Playing MP3 Files.............179
▫Operation Instructions -
(CD Mode For MP3 And WMA Audio Play) . . 181
▫Load/Eject Button
(CD Mode For MP3 And WMA Play).......181

Satellite Radio—If Equipped.............183
▫System Activation.....................183
▫Electronic Serial Number/Sirius Identification
Number (ESN/SID)....................183
▫Selecting Satellite Mode In REF, RAQ, And RAK
Radios.............................184
138 UNDERSTANDING YOUR INSTRUMENT PANEL

▫Selecting a Channel....................184
▫Storing And Selecting Pre-Set Channels......185
▫Using The PTY (Program Type) Button
(If Equipped)........................185
▫PTY ButtonScan.....................185
▫PTY ButtonSeek.....................185
▫Satellite Antenna......................185
▫Reception Quality.....................186

Video Entertainment System (Sales Code XRV)—
If Equipped
..........................186

Navigation System (Sales Code REC)—
If Equipped
..........................188
▫Clock Setting Procedure.................188

Remote Sound System Controls...........189
▫Radio Operation......................190
▫Tape Player Operation..................190
▫CD Player Operation...................190▫Satellite Radio Operation................191

Cassette Tape And Player Maintenance......191

CD/DVD Disc Maintenance..............192

Radio Operation And Cellular Phones.......192

Climate Controls......................192
▫Climate Controls—Manual..............192
▫Automatic Temperature Control—
If Equipped.........................196
▫Summer Operation....................201
▫Winter Operation.....................202
▫Vacation Storage......................202
▫Window Fogging.....................202
▫Outside Air Intake....................202
▫A/C Air Filter—If Equipped............202
▫Operating Tips.......................203
UNDERSTANDING YOUR INSTRUMENT PANEL 139
4

INSTRUMENTS AND CONTROLS
140 UNDERSTANDING YOUR INSTRUMENT PANEL
