CHRYSLER 300 2017 2.G Warranty Booklet

Perform Maintenance At 64,000 km or 48 Months
❏Inspect the front suspension components, tie rod ends and boot seals; replace if necessary.
❏ Inspect the rear axle fluid. Inspect the front axle fluid. (AWD)
❏ Inspect the manual transmission fuid, add if necessary. (if equipped)
❏ Inspect the brake linings; replace if necessary.
❏ Adjust the parking brake on vehicles equipped with four-wheel disc brakes.
❏ Replace the cabin air filter.
Odometer Reading
Date
Repair Order No.
Signature of authorized FCA Retailer
FCA
R
ETAILERSTAMP
Perform Maintenance At 80,000 km or 60 Months
❏ Change the manual transmission fluid if using your vehicle for any of the following: Most of
your driving is at sustained high speeds during hot weather, above 32°C (90°F), driving in
dusty conditions, or stop and go driving. (if equipped)
❏ Change the rear axle fluid and on models equipped with All Wheel Drive (AWD) also change
the front axle fluid if using your vehicle for any of the following: police, taxi, fleet, off-road, or
frequent trailer towing.
Odometer Reading
Date
Repair Order No.
Signature of authorized FCA Retailer
FCA
R
ETAILERSTAMP
19

Perform Maintenance At 96,000 km or 72 Months
❏Inspect the CV joints.
❏ Inspect the front suspension components, tie rod ends and boot seals; replace if necessary.
❏ Inspect the rear axle fluid. Inspect the front axle fluid. (AWD)
❏ Inspect the manual transmission fuid, add if necessary. (if equipped)
❏ Inspect the brake linings; replace if necessary.
❏ Adjust the parking brake on vehicles equipped with four-wheel disc brakes.
❏ Replace the engine air filter.
❏ Replace the cabin air filter.
❏ Inspect the transfer case fluid. Change the transfer case fluid if using your vehicle for any of
the following: police, taxi, fleet, off-road, or frequent trailer towing. (AWD)
❏ Change the automatic transmission fluid and filter. (Charger - police vehicle only)
Odometer Reading
Date
Repair Order No.
Signature of authorized FCA Retailer
FCA
R
ETAILERSTAMP
Perform Maintenance At 128,000 km or 96 Months
❏ Inspect the front suspension components, tie rod ends and boot seals; replace if necessary.
❏ Inspect the rear axle fluid. Inspect the front axle fluid. (AWD)
❏ Inspect the manual transmission fuid, add if necessary. (if equipped)
❏ Inspect the brake linings; replace if necessary.
❏ Adjust the parking brake on vehicles equipped with four-wheel disc brakes.
❏ Replace the cabin air filter.
Odometer Reading
Date
Repair Order No.
Signature of authorized FCA Retailer
FCA
R
ETAILERSTAMP
20

Perform Maintenance At 144,000 km or
108 Months
❏Inspect the CV joints.
❏ Inspect the transfer case fluid. (AWD)
❏ Replace the engine air filter.
Odometer Reading
Date
Repair Order No.
Signature of authorized FCA Retailer
FCA
R
ETAILERSTAMP
Perform Maintenance At 160,000 km or
120 Months
❏ Inspect the front suspension components, tie rod ends and boot seals; replace if necessary.
❏ Inspect the rear axle fluid. Inspect the front axle fluid. (AWD)
❏ Change the manual transmission fluid if using your vehicle for any of the following: Most of
your driving is at sustained high speeds during hot weather, above 32°C (90°F), driving in
dusty conditions, or stop and go driving. (if equipped)
❏ Inspect the manual transmission fuid, add if necessary. (if equipped)
❏ Inspect the brake linings; replace if necessary.
❏ Adjust the parking brake on vehicles equipped with four-wheel disc brakes.
❏ Replace the cabin air filter.
❏ Replace the spark plugs. **
❏ Flush and replace the engine coolant at 10 years or 240,000 kilometres, whichever comes first.
❏ Change the rear axle fluid and on models equipped with All Wheel Drive (AWD) also change
the front axle fluid if using your vehicle for any of the following: police, taxi, fleet, off-road, or
frequent trailer towing.
❏ Inspect the PCV valve; replace if necessary.
** The spark plug change interval is metrage based only, monthly intervals do not apply.
Odometer Reading
Date
Repair Order No.
Signature of authorized FCA Retailer
FCA
R
ETAILERSTAMP
21

Perform Maintenance At 192,000 km or
144 Months
❏Inspect the CV joints.
❏ Inspect the front suspension components, tie rod ends and boot seals; replace if necessary.
❏ Inspect the rear axle fluid. Inspect the front axle fluid. (AWD)
❏ Inspect the manual transmission fuid, add if necessary. (if equipped)
❏ Inspect the brake linings; replace if necessary.
❏ Adjust the parking brake on vehicles equipped with four-wheel disc brakes.
❏ Replace the engine air filter.
❏ Replace the cabin air filter.
❏ Inspect the transfer case fluid. Change the transfer case fluid if using your vehicle for any of
the following: police, taxi, fleet, off-road, or frequent trailer towing. (AWD)
❏ Change the automatic transmission fluid and filter. (Charger - police vehicle only)
Odometer Reading
Date
Repair Order No.
Signature of authorized FCA Retailer
FCA
R
ETAILERSTAMP
Perform Maintenance At 224,000 km or
168 Months
❏ Inspect the front suspension components, tie rod ends and boot seals; replace if necessary.
❏ Inspect the rear axle fluid. Inspect the front axle fluid. (AWD)
❏ Inspect the manual transmission fuid, add if necessary. (if equipped)
❏ Inspect the brake linings; replace if necessary.
❏ Adjust the parking brake on vehicles equipped with four-wheel disc brakes.
❏ Replace the cabin air filter.
Odometer Reading
Date
Repair Order No.
Signature of authorized FCA Retailer
FCA
R
ETAILERSTAMP
22

Perform Maintenance At 240,000 km or
180 Months
❏Inspect the CV joints.
❏ Change the manual transmission fluid if using your vehicle for any of the following: Most of
your driving is at sustained high speeds during hot weather, above 32°C (90°F), driving in
dusty conditions, or stop and go driving. (if equipped)
❏ Inspect the transfer case fluid. (AWD)
❏ Replace the engine air filter.
❏ Flush and replace the engine coolant at 10 years or 240,000 kilometres, whichever comes first.
❏ Change the rear axle fluid and on models equipped with All Wheel Drive (AWD) also change
the front axle fluid if using your vehicle for any of the following: police, taxi, fleet, off-road, or
frequent trailer towing.
Odometer Reading
Date
Repair Order No.
Signature of authorized FCA Retailer
FCA
R
ETAILERSTAMP
23

SCHEDULED
MAINTENANCE
NON-SRT 6.4L ENGINES
24

MAINTENANCE SCHEDULE
Scheduled maintenance must be completed to provide the best vehicle performance and reliability.
The limited warranties in the warranty booklet DO NOT COVER repairs required due to improper
maintenance. We strongly suggest you keep track of scheduled maintenance and keep receipts or other
documents. Use only recommended Mopar® Lubricants and genuine Mopar® Parts. In the event that
a condition arises between maintenance intervals, please contact your retailer.AVOID PRO-
LONGED PERIODS OF IDLING.
NOTE: WHERE TIME AND METRAGE ARE INDICATED, FOLLOW THE INTERVAL THAT OCCURS FIRST.
Your vehicle is equipped with an automatic oil change indicator system. The oil change indicator
system will remind you that it is time to take your vehicle in for scheduled maintenance. Based on
engine operation conditions, the oil change indicator message will illuminate. This means that service
is required for your vehicle. Operating conditions such as frequent short-trips, trailer tow and
extremely hot or cold ambient temperatures will influence when the “Change Oil” message is
displayed. Severe operating conditions can cause the change oil message to illuminate as early as
5,600 kilometres since last reset. Have your vehicle serviced as soon as possible, within the next 800
kilometres.
NOTE: UNDER NO CIRCUMSTANCES SHOULD OIL CHANGE INTERVALS EXCEED 10,000 KILOMETRES OR SIX MONTHS, WHICHEVER COMES FIRST.
THE OIL CHANGE INDICATOR MESSAGE WILL NOT MONITOR THE TIME
SINCE THE LAST OIL CHANGE. CHANGE YOUR VEHICLE’S OIL IF IT HAS
BEEN SIX MONTHS SINCE YOUR LAST OIL CHANGE, EVEN IF THE OIL
CHANGE INDICATOR MESSAGE IS NOT ILLUMINATED.
CHANGE YOUR ENGINE OIL MORE OFTEN IF YOU DRIVE YOUR VEHICLE
OFF-ROAD FOR AN EXTENDED PERIOD OF TIME.
AT EACH STOP FOR FUEL:
• Check engine oil level.
• Check windshield washer fluid level.
ONCE A MONTH
• Check the tire inflation pressures and look for unusual wear or damage.
• Inspect battery and clean and tighten terminals as required.
• Check the fluid levels of the coolant reservoir, brake master cylinder and power steering. Fill as
needed.
• Check function of all interior and exterior lights.
• Check and clean wiper blades. Replace if required.
AT EACH OIL CHANGE
• Change engine oil and filter. Oil changes prompted by the oil change indicator system can be
recorded in the oil change log section.
• Inspect brake pads hoses and lines.
REQUIRED MAINTENANCE
Refer to the Maintenance Schedules on the following pages for required maintenance.
WARNING!
• The performance of all scheduled service work is required to maintain your vehicle in good
operating condition. FCA Canada Inc. reserves the right to deny warranty coverage if the
vehicle has not been properly maintained. While we do not insist that such work be
performed by factory authorized retailers, we strongly recommend that an authorized FCA
Retailer perform this work.
25

•You can be badly injured working on or around a motor vehicle. Do only service work for
which you have the knowledge and the right equipment. If you have any doubt about your
ability to perform a service job, take your vehicle to a competent mechanic.
• Failure to properly inspect and maintain your vehicle could result in a component
malfunction and effect vehicle handling and performance. This could cause an accident.
26

Perform Maintenance At 10,000 km or 6 Months
❏Change the engine oil and engine oil filter.
❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before scheduled
maintenance.
Odometer Reading
Date
Repair Order No.
Signature of authorized FCA Retailer
FCA
R
ETAILERSTAMP
Perform Maintenance At 20,000 km or 12 Months
❏ Change the engine oil and engine oil filter.
❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before scheduled
maintenance.
❏ Inspect the engine air filter if using your vehicle in dusty or off-road conditions; replace if nec-
essary.
❏ Inspect the brake linings; replace if necessary.
❏ Inspect the CV joints.
❏ Inspect the exhaust system.
❏ Inspect the front suspension components, tie rod ends and boot seals; replace if necessary.
❏ Replace the cabin air filter.
Odometer Reading
Date
Repair Order No.
Signature of authorized FCA Retailer
FCA
R
ETAILERSTAMP
27

Perform Maintenance At 30,000 km or 18 Months
❏Change the engine oil and engine oil filter.
❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before scheduled
maintenance.
❏ Inspect the manual transmission fluid, add if necessary. (if equipped)
❏ Inspect the rear axle fluid.
Odometer Reading
Date
Repair Order No.
Signature of authorized FCA Retailer
FCA
R
ETAILERSTAMP
Perform Maintenance At 40,000 km or 24 Months
❏ Change the engine oil and engine oil filter.
❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before scheduled
maintenance.
❏ Inspect the engine air filter if using your vehicle in dusty or off-road conditions; replace if nec-
essary.
❏ Inspect the brake linings; replace if necessary.
❏ Inspect the CV joints.
❏ Inspect the exhaust system.
❏ Inspect the front suspension components, tie rod ends and boot seals; replace if necessary.
❏ Replace the cabin air filter.
Odometer Reading
Date
Repair Order No.
Signature of authorized FCA Retailer
FCA
R
ETAILERSTAMP
28
