automatic transmission fluid CHRYSLER 300 2022 Owners Manual

6
VEHICLE MAINTENANCE .................................... 217 Engine Oil ...................................................... 217Engine Oil Filter ............................................. 218
Engine Air Cleaner Filter .............................. 218Air Conditioner Maintenance ....................... 218
Accessory Drive Belt Inspection ................... 220
Body Lubrication............................................ 221
Windshield Wiper Blades .............................. 221Exhaust System ............................................. 222
Cooling System ............................................. 224
Brake System ............................................... 226
Automatic Transmission .............................. 227All Wheel Drive (AWD) — If Equipped .......... 228
Rear Axle ........................................................ 228Fuses.............................................................. 228
Bulb Replacement ......................................... 238
TIRES ..................................................................... 242
Tire Safety Information ................................ 242
Tires — General Information ........................ 250
Tire Types ....................................................... 253
Spare Tires — If Equipped ............................. 254
Wheel And Wheel Trim Care ........................ 256
Snow Traction Devices .................................. 257
Tire Rotation Recommendations ................ 258
DEPARTMENT OF TRANSPORTATION UNIFORM
TIRE QUALITY GRADES ...................................... 259
Treadwear ...................................................... 259Traction Grades ............................................. 259
Temperature Grades ..................................... 259 VEHICLE STORAGE .............................................. 260
BODYWORK ......................................................... 260
Protection From Atmospheric Agents .......... 260
Body And Underbody Maintenance.............. 260Preserving The Bodywork ............................. 260
INTERIORS .......................................................... 261
Seats And Fabric Parts ................................. 261
Plastic And Coated Parts .............................. 262Leather Surfaces ........................................... 262Glass Surfaces ............................................. 262
TECHNICAL SPECIFICATIONS
VEHICLE IDENTIFICATION NUMBER (VIN) ........ 263
BRAKE SYSTEM .................................................. 263
WHEEL AND TIRE TORQUE SPECIFICATIONS .. 263
Torque Specifications ................................... 263
FUEL REQUIREMENTS ........................................ 264
3.6L Engine ................................................... 264
5.7L Engine ................................................... 264
Reformulated Gasoline ................................ 265Materials Added To Fuel ............................... 265
Gasoline/Oxygenate Blends ......................... 265

Do Not Use E-85 In Non-Flex Fuel Vehicles ....265

CNG And LP Fuel System Modifications ...... 265Methylcyclopentadienyl Manganese
Tricarbonyl (MMT) In Gasoline...................... 266Fuel System Cautions ................................... 266 FLUID CAPACITIES .............................................. 267
ENGINE FLUIDS AND LUBRICANTS .................. 268
CHASSIS FLUIDS AND LUBRICANTS ................. 269
CUSTOMER ASSISTANCE
SUGGESTIONS FOR OBTAINING SERVICE FOR
YOUR VEHICLE .................................................... 270
Prepare For The Appointment ...................... 270
Prepare A List ................................................ 270
Be Reasonable With Requests..................... 270
IF YOU NEED ASSISTANCE ................................ 270
FCA US LLC Customer Center....................... 270
FCA Canada Inc. Customer Center .............. 270
Mexico............................................................ 271
Puerto Rico And US Virgin Islands ............... 271
Customer Assistance For The Hearing Or
Speech Impaired(TDD/TTY) .......................... 271
Service Contract ........................................... 271
WARRANTY INFORMATION ................................ 272
MOPAR® PARTS ................................................. 272
REPORTING SAFETY DEFECTS .......................... 272
In The 50 United States And
Washington, D.C............................................ 272
In Canada ...................................................... 272
PUBLICATION ORDER FORMS .......................... 273
GENERAL INFORMATION.................................... 273

22_LX_OM_EN_USC_t.book Page 6

80GETTING TO KNOW YOUR INSTRUMENT PANEL
If the ABS light does not turn on when the ignition
is placed in the ON/RUN or ACC/ON/RUN position,
have the brake system inspected by an authorized
dealer.
Electronic Stability Control (ESC) Active
Warning Light — If Equipped
This warning light will indicate when the
Electronic Stability Control system is
Active. The ESC Indicator Light in the
instrument cluster will come on when
the ignition is placed in the ON/RUN or ACC/ON/
RUN position, and when ESC is activated. It should
go out with the engine running. If the ESC Indicator
Light comes on continuously with the engine
running, a malfunction has been detected in the
ESC system. If this warning light remains on after
several ignition cycles, and the vehicle has been
driven several miles (kilometers) at speeds greater
than 30 mph (48 km/h), see an authorized dealer
as soon as possible to have the problem
diagnosed and corrected.
The ESC OFF Indicator Light and the ESC Indi -
cator Light come on momentarily each time the
ignition is placed in the ON/RUN or ACC/ON/
RUN position.
The ESC system will make buzzing or clicking
sounds when it is active. This is normal; the
sounds will stop when ESC becomes inactive.
This light will come on when the vehicle is in an
ESC event.
Electronic Stability Control (ESC) OFF
Warning Light — If Equipped
This warning light indicates the ESC is
off.
Each time the ignition is turned to ON/
RUN or ACC/ON/RUN, the ESC system
will be on, even if it was turned off previously.
Service LaneSense Warning Light —
If Equipped
This warning light will illuminate when
the LaneSense system is not operating
and requires service. Please see an
authorized dealer.
LaneSense Warning Light — If Equipped
The LaneSense system provides the
driver with visual and steering torque
warnings when the vehicle starts to drift
out of its lane unintentionally without
the use of a turn signal.
When the LaneSense system senses a lane drift
situation, the LaneSense indicator changes
from solid green to solid yellow.
When the LaneSense system senses the lane
has been approached and is in a lane departure
situation, the LaneSense indicator changes
from solid white/green to flashing yellow
Ú page 114.
Low Fuel Warning Light
When the fuel level reaches
approximately 1.9 gal (7.13 L), this light
will turn on and a single chime will
sound.
Low Washer Fluid Warning Light —
If Equipped
This warning light will illuminate when
the windshield washer fluid is low
Úpage 216.
Engine Check/Malfunction Indicator
Warning Light (MIL)
The Engine Check/Malfunction
Indicator Light (MIL) is a part of an
Onboard Diagnostic System called OBD
II that monitors engine and automatic
transmission control systems. This warning light
will illuminate when the ignition is in the ON/RUN
position before engine start. If the bulb does not
come on when turning the ignition switch from OFF
to ON/RUN, have the condition checked promptly.

22_LX_OM_EN_USC_t.book Page 80

STARTING AND OPERATING89
COLD WEATHER OPERATION
(BELOW –22°F OR −30°C)
To ensure reliable starting at these temperatures,
use of an externally powered electric engine block
heater (available from an authorized dealer) is
recommended.
AFTER STARTING
The idle speed is controlled automatically, and it
will decrease as the engine warms up.
ENGINE BLOCK HEATER — IF EQUIPPED
The engine block heater warms the engine, and
permits quicker starts in cold weather. Connect the
cord to a standard 110-115 Volt AC electrical
outlet with a grounded, three-wire extension cord.
The engine block heater must be plugged in at
least one hour to have an adequate warming effect
on the engine.
The engine block heater cord is routed under the
hood on the driver side of the vehicle. It has a
removable cap that is located near the air box.
ENGINE BREAK-IN RECOMMENDATIONS
A long break-in period is not required for the
drivetrain (engine, transmission, and rear axle) in
your new vehicle.
Drive moderately during the first 300 miles
(500 km). After the initial 60 miles (100 km),
speeds up to 50 or 55 mph (80 or 90 km/h) are
desirable.
While cruising, brief full-throttle acceleration within
the limits of local traffic laws contributes to a good
break-in. However, wide-open throttle acceleration
in low gear can be detrimental and should be
avoided.
The engine oil, transmission fluid, and axle
lubricant installed at the factory are high-quality
and energy-conserving. Oil, fluid, and lubricant
changes should be consistent with anticipated
climate and conditions under which vehicle
operations will occur. For the recommended
viscosity and quality grades Ú page 268.
WARNING!
Never pour fuel or other flammable liquid into
the throttle body air inlet opening in an
attempt to start the vehicle. This could result
in flash fire causing serious personal injury.
Do not attempt to push or tow your vehicle to
get it started. Vehicles equipped with an auto -
matic transmission cannot be started this
way. Unburned fuel could enter the catalytic
converter and once the engine has started,
ignite and damage the converter and vehicle.
If the vehicle has a discharged battery,
booster cables may be used to obtain a start
from a booster battery or the battery in
another vehicle. This type of start can be
dangerous if done improperly Ú page 201.
CAUTION!
To prevent damage to the starter, do not
continuously crank the engine for more than 10
seconds at a time. Wait 10 to 15 seconds before
trying again.
WARNING!
Remember to disconnect the engine block
heater cord before driving. Damage to the
110-115 Volt electrical cord could cause
electrocution.
CAUTION!
Never use Non-Detergent Oil or Straight Mineral
Oil in the engine or damage may result.
4

22_LX_OM_EN_USC_t.book Page 89

SERVICING AND MAINTENANCE227
(Continued)
reservoir. With disc brakes, fluid level can be
expected to fall as the brake pads wear. However,
low fluid level may be caused by a leak and a
checkup may be needed.
Use only brake fluid that has been recommended
by the manufacturer, and has been kept in a tightly
closed container to avoid contamination from
foreign matter or moisture Ú
page 269.
AUTOMATIC TRANSMISSION
Special Additives
The manufacturer strongly recommends against
using any special additives in the transmission.
Automatic Transmission Fluid (ATF) is an
engineered product and its performance may be
impaired by supplemental additives. Therefore, do
not add any fluid additives to the transmission.
Avoid using transmission sealers as they may
adversely affect seals.
Fluid Level Check
The fluid level is preset at the factory and does not
require adjustment under normal operating
conditions. Routine fluid level checks are not
required; therefore the transmission has no
dipstick. An authorized dealer can check your
transmission fluid level using special service tools.
If you notice fluid leakage or transmission
malfunction, visit an authorized dealer
immediately to have the transmission fluid level
checked. Operating the vehicle with an improper
fluid level can cause severe transmission damage.WARNING!
Use only manufacturer's recommended brake
fluid Úpage 269. Using the wrong type of
brake fluid can severely damage your brake
system and/or impair its performance. The
proper type of brake fluid for your vehicle is
also identified on the original factory installed
hydraulic master cylinder reservoir.
To avoid contamination from foreign matter or
moisture, use only new brake fluid or fluid that
has been in a tightly closed container. Keep
the master cylinder reservoir cap secured at
all times. Brake fluid in an open container
absorbs moisture from the air resulting in a
lower boiling point. This may cause it to boil
unexpectedly during hard or prolonged
braking, resulting in sudden brake failure. This
could result in a collision.
Overfilling the brake fluid reservoir can result
in spilling brake fluid on hot engine parts,
causing the brake fluid to catch fire. Brake
fluid can also damage painted and vinyl
surfaces, care should be taken to avoid its
contact with these surfaces.
Do not allow petroleum based fluid to contam -
inate the brake fluid. Brake seal components
could be damaged, causing partial or
complete brake failure. This could result in a
collision.
WARNING!CAUTION!
Do not use chemical flushes in your
transmission as the chemicals can damage your
transmission components. Such damage is not
covered by the New Vehicle Limited Warranty.
CAUTION!
If a transmission fluid leak occurs, visit an
authorized dealer immediately. Severe
transmission damage may occur. An authorized
dealer has the proper tools to adjust the fluid
level accurately.
8

22_LX_OM_EN_USC_t.book Page 227

TECHNICAL SPECIFICATIONS269
CHASSIS FLUIDS AND LUBRICANTS
CAUTION!
Mixing of engine coolant (antifreeze) other than specified Organic Additive Technology (OAT) engine coolant (antifreeze), may result in engine damage and
may decrease corrosion protection. Organic Additive Technology (OAT) engine coolant is different and should not be mixed with Hybrid Organic Additive Tech -
nology (HOAT) engine coolant (antifreeze) or any “globally compatible” coolant (antifreeze). If a non-OAT engine coolant (antifreeze) is introduced into the
cooling system in an emergency, the cooling system will need to be drained, flushed, and refilled with fresh OAT coolant (conforming to MS.90032), by an
authorized dealer as soon as possible.
Do not use water alone or alcohol-based engine coolant (antifreeze) products. Do not use additional rust inhibitors or antirust products, as they may not be
compatible with the radiator engine coolant and may plug the radiator.
This vehicle has not been designed for use with propylene glycol-based engine coolant (antifreeze). Use of propylene glycol-based engine coolant (antifreeze)
is not recommended.
Component Fluid, Lubricant, Or Genuine Part
Automatic Transmission Use only Mopar® ZF 8 & 9 Speed ATF Automatic Transmission Fluid, or
equivalent. Failure to use the correct fluid may affect the function or
performance of your transmission.
Brake Master Cylinder We recommend using Mopar® DOT 3 and SAE J1703.
Front Axle – AWD (If Equipped) We recommend using Mopar® Synthetic Gear Lubricant SAE 75W90
(API GL-5).
Rear Axle We recommend using Mopar® OD Synthetic Gear Lubricant SAE 75W85
(API GL-5).
Transfer Case – AWD (If Equipped) We recommend using Mopar® Transfer Case Lubricant for BorgWarner
44–40.
9

22_LX_OM_EN_USC_t.book Page 269

274
INDEX
A
About Your Brakes......................................... 263
Adaptive Cruise Control (ACC) (Cruise Control)..100
Adding Engine Coolant (Antifreeze)............... 225Adding Fuel.................................................... 118Adding Washing Fluid.................................... 216Additives, Fuel............................................... 265AdjustForward....................................................... 32Rearward..................................................... 32Air Bag........................................................... 168Advance Front Air Bag............................... 168Air Bag Operation...................................... 170Air Bag Warning Light................................ 168Driver Knee Air Bag................................... 170Enhanced Accident Response......... 174, 209Event Data Recorder (EDR)....................... 209Front Air Bag............................................. 168If Deployment Occurs................................ 173Knee Impact Bolsters................................ 170Maintaining Your Air Bag System.............. 175Maintenance............................................. 175Redundant Air Bag Warning Light.............168Side Air Bags............................................. 170Transporting Pets...................................... 189
Air Bag Light.................................. 77, 168, 190
Air Cleaner, Engine (Engine Air Cleaner Filter)... 218
Air Conditioner Maintenance........................ 218Air Conditioner Refrigerant.................. 218, 219Air Conditioner System...........................52, 218Air Conditioning Filter..............................55, 219Air Conditioning, Operating Tips....................... 55Air Filter........................................................ 218Air PressureTires......................................................... 250AlarmArm The System................................... 19, 20Rearm The System...................................... 20Security Alarm............................... 19, 20, 79Alarm SystemSecurity Alarm............................................. 19All Wheel DriveTowing...................................................... 209All Wheel Drive (AWD)................................... 228Alterations/ModificationsVehicle........................................................... 8Antifreeze (Engine Coolant)................. 224, 267Disposal................................................... 225Anti-Lock Brake System (ABS)...................... 145Anti-Lock Warning Light................................... 79
Arming SystemSecurity Alarm.............................................19Assist, Hill Start............................................. 150Audio Systems (Radio).................................. 128Auto Down Power Windows..............................62Automatic Door Locks......................................25Automatic Headlights.......................................46Automatic High Beams.....................................45Automatic Temperature Control (ATC)..............54Automatic Transmission...................................92Adding Fluid..................................... 228, 269Fluid And Filter Change............................. 228Fluid Change............................................. 228Fluid Level Check...................................... 227Fluid Type........................................ 228, 269Special Additives...................................... 227
Automatic Transmission Limp Home Mode...25, 95
AutoPark..........................................................87AutostickOperation.....................................................96AUX Cord..........................................................58Auxiliary Electrical Outlet (Power Outlet)..........60AWDTowing...................................................... 209Axle Fluid....................................................... 269Axle Lubrication............................................ 269

22_LX_OM_EN_USC_t.book Page 274

275
B
Back-Up
......................................................... 116Battery.................................................... 78, 216Charging System Light................................. 78Keyless Key Fob Replacement.................... 13Location.................................................... 216Belts, Seat..................................................... 189Body Mechanism Lubrication........................ 221B-Pillar Location............................................. 247Brake Assist System...................................... 146Brake Control System.................................... 146Brake Fluid.......................................... 226, 269Brake System...................................... 226, 263Fluid Check..................................... 226, 269Master Cylinder......................................... 226Parking........................................................ 90Warning Light..................................... 77, 263Brake/Transmission Interlock......................... 92Break-In Recommendations, New Vehicle....... 89Brightness, Interior Lights................................ 49Bulb Replacement......................................... 238Bulbs, Light.......................................... 191, 238
C
Camera, Rear................................................ 116Capacities, Fluid............................................ 267Caps, Filler Oil (Engine)................................................ 214Radiator (Coolant Pressure)...................... 225
Car Washes................................................... 260Carbon Monoxide Warning................... 191, 192CargoVehicle Loading........................................ 119Cargo Area Cover............................................. 67Cargo Compartment........................................ 67Cellular Phone.............................................. 144Certification Label......................................... 119Chains, Tire................................................... 257Chart, Tire Sizing........................................... 243Check Engine Light
(Malfunction Indicator Light)............................ 85Checking Your Vehicle For Safety................. 189Checks, Safety.............................................. 189Child Restraint.............................................. 176Child RestraintsBooster Seats........................................... 179Child Seat Installation.............................. 187How To Stow An unused ALR Seat Belt.... 184Infant And Child Restraints....................... 178Lower Anchors And Tethers For Children.. 181Older Children And Child Restraints......... 178Seating Positions...................................... 180Child Safety Locks........................................... 25Clean Air Gasoline......................................... 265CleaningWheels..................................................... 256Climate Control................................................ 52Automatic.................................................... 52Coin Holder...................................................... 57
Cold Weather Operation...................................89Compact Spare Tire...................................... 254ConsoleFloor............................................................57Contract, Service........................................... 271Cooling Pressure Cap (Radiator Cap)............ 225Cooling System............................................. 224Adding Coolant (Antifreeze)...................... 225Coolant Capacity....................................... 267Coolant Level................................... 224, 226Disposal Of Used Coolant......................... 225Drain, Flush, And Refill............................. 224Inspection................................................. 226Points To Remember................................ 226Pressure Cap............................................ 225Radiator Cap............................................. 225Selection Of Coolant (Antifreeze)......................... 224, 267, 268Corrosion Protection..................................... 260Cruise Control (Speed Control)............... 98, 100Cruise Light............................................... 82, 83Customer Assistance.................................... 270Cybersecurity................................................ 128
D
Daytime Running Lights...................................45Dealer Service............................................... 217Deck LidPower Release.............................................65Defroster, Windshield................................... 190
11

22_LX_OM_EN_USC_t.book Page 275

282
Towing Behind A Motorhome
......................... 126Traction......................................................... 126Traction Control............................................. 151Trailer Towing................................................ 120Hitches...................................................... 122Minimum Requirements............................ 123Tips........................................................... 125Trailer And Tongue Weight........................ 123Wiring........................................................ 124Trailer Towing Guide...................................... 122Trailer Weight................................................ 122Transfer Case Fluid................................................ 228, 269Maintenance............................................. 228Transmission................................................... 92Automatic........................................... 92, 227Fluid.......................................................... 269Maintenance............................................. 227Shifting........................................................ 91Transporting Pets.......................................... 189Tread Wear Indicators................................... 252Trunk Lid (Deck Lid)......................................... 65Trunk Release Remote Control........................ 65Turn Signals.............................................. 47, 83
U
UconnectUconnect Settings
..............................18, 129
Uconnect 4C/4C Nav With 8.4-Inch Display.... 129
Uconnect Settings
Customer Programmable Features.. 18, 23, 129
Passive Entry Programming......................... 23Uniform Tire Quality Grades.......................... 259Universal Garage Door Opener
(Homelink®)
b
............................................. 40Unleaded Gasoline....................................... 264Untwisting Procedure, Seat Belt................... 164USB.................................................................. 58
V
Vanity Mirrors.................................................. 37Vehicle Certification Label............................ 119Vehicle Identification Number (VIN).............. 263Vehicle Loading.......................... 119, 120, 247Vehicle Maintenance.................................... 217Vehicle Modifications/Alterations...................... 8Vehicle Security Alarm..................................... 19Vehicle Storage.......................................55, 260Voice Command............................................... 27Voice Recognition System (VR)........................ 27
W
Warning Flashers, Hazard............................. 193Warning Lights
(Instrument Cluster Descriptions)....................80Warranty Information.................................... 272Washer Adding Fluid.............................................. 216Washers, Windshield.................................... 216Washing Vehicle............................................ 260WaterDriving Through........................................ 127Wheel And Wheel Tire Care........................... 256Wheel And Wheel Tire Trim........................... 256Wind Buffeting.................................................63Window Fogging...............................................55Windows..........................................................61Power...........................................................61Reset Auto-Up..............................................62Windshield Defroster.................................... 190Windshield Washers........................................50Fluid.......................................................... 216Windshield Wiper Blades.............................. 221Windshield Wipers...........................................50Wipers Blade Replacement........................... 221Wipers, Rain Sensitive.....................................51

22_LX_OM_EN_USC_t.book Page 282
