CHRYSLER 300 SRT 2005 1.G Owners Manual

If the headlights are turned off before the ignition, they
will turn off in the normal manner.
NOTE:The lights must be turned off within 45 seconds
of turning the ignition off to activate this feature
The Headlamp delay time is programmable. Refer to
“Delay Turning Headlamps Off” in the Electronic Vehicle
Information Center section for details.
Fog Lights
The front fog light switch is on the headlamp
switch below the dimmer control. To activate the
front fog lights, turn on the parking lights or the
low beam headlights and press the fog lamp switch.
NOTE:The fog lights will operate with the low beam
headlights, or parking lights on. However, selecting the
high beam headlights will turn off the fog lights.
Turn Signals
Move the Multi-Function Lever up or down and the
arrows on each side of the instrument cluster flash to
show proper operation of the front and rear turn signal
lights. You can signal a lane change by moving the leverpartially up or down without moving beyond the detent.
Releasing the lever at the detent will provide 3 flashes.
If either light has a very fast flash rate, check for a
defective outside light bulb. If an indicator fails to light
when the lever is moved, it would suggest that the fuse
or indicator bulb is defective or there may be a circuit
failure.
NOTE:The message “Turn Signal On” will appear in
the electronic vehicle information center (EVIC), and a
continuous chime will be heard when the vehicle has
been driven more than 1 mile (1.6 km) with either turn
signal on.
Highbeam/Lowbeam Select Switch
Push the Multi-Function Lever away from you to switch
the headlights to HIGH beam. Pull the Lever towards
you to switch the headlights back to LOW beam.
Flash to Pass
You can signal another vehicle with your headlights by
lightly pulling the Multi-Function Lever toward you.
This will cause the headlights to turn on at high beam
and remain on until the lever is released.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 101
3

WINDSHIELD WIPERS AND WASHERS
The wipers and washers are operated by the
multi-function lever. The lever is located on the
left side of the steering column. Rotate the end of
the control lever to select the desired wiper speed.
CAUTION!
Turn the windshield wipers off when driving
through an automatic car wash. Damage to the
windshield wipers may result if the wiper switch is
left in any position other than OFF.
Windshield Washers
To use the front washer, push the lever in and hold while
spray is desired. If the lever is released while in the delay
range, the wiper will operate for two wipe cycles after the
lever is released, and then resume the intermittent inter-
val previously selected.
If the lever is pushed while in the OFF position, the
wipers will operate for two wipe cycles, then turn OFF.
Windshield Wiper/Washer Control
102 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Rain Sensing Wipers
This feature senses moisture on the windshield and
automatically activates the wipers for the driver. The
feature is especially useful for road splash or overspray
from the windshield washers of the vehicle ahead. Rotate
the end of the multi-function lever to one of six settings
to activate this feature.
The sensitivity of the system can be adjusted with the
multi-function lever. Wiper delay position 1 is the least
sensitive, and wiper delay position 6 is the most sensi-
tive. Settings 3-4 should be used for normal rain condi-
tions. Settings 2 or 1 can be used if the driver desires less
wiper sensitivity. Settings 5 and 6 can be used if the
driver desires more sensitivity. Place the wiper switch in
the OFF position when not using the system.
NOTE:
•
The rain sensing feature will not operate when the
wiper switch is in the LOW or HIGH speed position.
•The rain sensing feature may not function properly
when ice, or dried salt water is present on the wind-
shield.
•Use of Rain-Xor products containing wax or silicone
may reduce rain sensor performance.
•The rain sensing system will not operate when the
engine is running, the gear selector is in the PARK
position, and the outside temperature is below freez-
ing. This is done to protect the wiper blades from
damage. Place the gear selector in the DRIVE position
to allow the rain sensing feature to operate.
•A customer programmable feature in the Electronic
Vehicle Information Center (EVIC) allows the Rain
Sense feature to be turned off. Refer to “Personal
Settings” in the Electronic Vehicle Information Center
section of this manual for details.
Mist Feature
Push the wiper lever in to activate a single wipe to clear
off road mist or spray from a passing vehicle. As long as
the lever is pushed in, the wipers will continue to
operate.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 103
3

Headlamps On With Wipers
The headlights will turn on approximately 10 seconds
after the wipers are turned on if the headlight switch is
placed in the AUTO position. The headlights will also
turn off when the wipers are turned off if they were
turned on by this feature. This feature can be turned on or
off using the Electronic Vehicle Information Center
(EVIC). Refer to ”Headlamps On With Wipers” in the
Electronic Vehicle Information Center section of this
manual for details.
Windshield Wiper Operation
Rotate the end of the lever to the second detent for Low
speed wiper operation, or to the third detent for High
speed operation.
Intermittent Wiper System
Use the intermittent wiper when weather conditions
make a single wiping cycle, with a variable pause be-
tween cycles, desirable. Rotate the end of the lever to the
first detent position, then turn the end of the lever to
select the desired delay interval. There are 6 possibledelay wiper positions. The delay can be regulated from a
maximum of approximately 23 seconds between cycles,
to a cycle every second.
Adding Washer Fluid
The windshield washer fluid reservoir is located in the
front of the engine compartment on the passenger side
and should be checked for fluid level at regular intervals.
Fill the reservoir with windshield washer solvent (not
radiator antifreeze) and operate the system for a few
seconds to flush out the residual water.
Windshield Washer Fluid Reservoir
104 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

The washer fluid reservoir will hold a full gallon of fluid
when “Low Washer Fluid” appears in the Electronic
Vehicle Information Center.
Headlight Washers
This feature operates in combination with the windshield
washers. To use the headlight washers, turn the head-
lights ON and press in on the windshield washer control
knob while the engine is running.This will operate the windshield washers and direct a
timed high pressure spray onto the headlight lens.
NOTE:The headlamp washers will operate on the first
spray of the windshield washers, then every fourth spray
of the windshield washers after that.
Windshield Wiper/Washer Control
Headlamp Washer
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 105
3

Adding Washer Fluid
The headlamp washer system and windshield washer
system share the same fluid reservoir. The reservoir is
located in the front of the engine compartment on the
passenger side and should be checked for fluid level at
regular intervals. Fill the reservoir with windshield
washer solvent (not radiator antifreeze) and operate the
system for a few seconds to flush out the residual water.
POWER TILT/TELESCOPING STEERING COLUMN
The power tilt/telescoping steering column lever is located
below the multi-function lever on the steering column. To tilt
the column move the lever up or down as desired. To
lengthen or shorten the steering column pull the lever
toward you or push the lever away from you as desired.
NOTE:Your remote keyless entry transmitter or
memory buttons on the driver’s door panel can be used
to recall the steering column tilt and telescopic positions.
Refer to the “Seats”section for details.
Windshield Washer Fluid Reservoir
Power Tilt/Telescoping Steering
106 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

WARNING!
Moving the steering column while the vehicle is
moving is dangerous. Without a stable steering col-
umn you could lose control of the vehicle and have
an accident. Adjust the column only while the ve-
hicle is stopped.
TRACTION CONTROL SYSTEM (TCS)
WARNING!
TCS cannot prevent the natural laws of physics from
acting on the vehicle, nor can it increase the traction
afforded. The TCS cannot prevent accidents, includ-
ing those resulting from excessive speed in turns, or
hydroplaning. Only a safe, attentive, and skillful
driver can prevent accidents. The capabilities of a
TCS-equipped vehicle must never be exploited in a
reckless or dangerous manner which could jeopar-
dize the user’s safety or the safety of others.
The traction control system is part of the elec-
tronic stability program (ESP). The traction
control system (TCS) warning light is located in
the instrument cluster. The TCS light will flash
as soon as the tires lose traction and the wheels begin to
spin. This indicates that the TCS system is active. If the
TCS warning light begins to flash during acceleration,
ease up on the accelerator and apply as little throttle as
possible. Be sure to adapt your speed and driving to the
prevailing road conditions. When the TCS warning light
is illuminated continuously, the TCS is switched off. To
return to the enhanced vehicle stability offered by TCS,
press the electronic stability program switch (the TCS
warning light in the instrument cluster goes out). Avoid
spinning one drive wheel. This may cause serious dam-
age to the drive train.
The electronic stability program switch is located on the
center of the instrument panel. To turn the traction
control system OFF press the electronic stability program
switch until the traction control Indicator in the instru-
ment cluster lights up.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 107
3

To improve the vehicle’s traction when driving with
snow chains, or starting off in deep snow, sand or gravel,
switch off the TCS system by pressing the electronic
stability program switch.
To turn the system back ON, press the electronic stability
program switch a second time until the traction control
Indicator turns OFF.NOTE:
•
The traction control system comes on each time the
ignition switch is turned ON. This will occur even if
you used the switch to turn the system OFF.
•The Traction Control system will make buzzing or
clicking sounds when in operation.
BRAKE ASSIST SYSTEM (BAS)
The BAS is designed to optimize the vehicle’s braking
capability during emergency braking maneuvers. The
system applies optimum pressure to the brakes in emer-
gency braking conditions than might otherwise be af-
forded solely by the driver’s braking style. This can help
reduce braking distances. The BAS complements the
antilock brake system (ABS). Applying the brakes very
quickly results in the best BAS assistance. To receive the
benefit of the system, you must apply continuous brak-
ing power during the stopping sequence. Do not reduce
brake pedal pressure.
Electronic Stability Program Switch
108 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

WARNING!
BAS cannot prevent the natural laws of physics from
acting on the vehicle, nor can it increase braking
efficiency beyond that afforded by the condition of
the vehicle brakes and tires or the traction afforded.
The BAS cannot prevent accidents, including those
resulting from excessive speed in turns, following
another vehicle too closely, or hydroplaning. Only a
safe, attentive, and skillful driver can prevent acci-
dents. The capabilities of a BAS-equipped vehicle
must never be exploited in a reckless or dangerous
manner which could jeopardize the user’s safety or
the safety of others.
Once the brake pedal is released, the BAS is deactivated.
The malfunction indicator lamp for the ESP is
combined with the BAS. The yellow BAS mal-
function indicator light and the yellow ESP
warning light in the instrument cluster both
come on with the key in the ignition switch turned to the
“ON” position. They should go out with the enginerunning. If the BAS/ESP malfunction indicator light
comes on continuously with the engine running, a mal-
function has been detected in either the BAS or the ESP
system. If this light stays illuminated, have the BAS and
ESP checked at your authorized dealer as soon as pos-
sible.
ELECTRONIC STABILITY PROGRAM (ESP)
WARNING!
ESP cannot prevent the natural laws of physics from
acting on the vehicle, nor can it increase the traction
afforded. The ESP cannot prevent accidents, includ-
ing those resulting from excessive speed in turns, or
hydroplaning. Only a safe, attentive, and skillful
driver can prevent accidents. The capabilities of an
ESP-equipped vehicle must never be exploited in a
reckless or dangerous manner which could jeopar-
dize the user’s safety or the safety of others.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 109
3

The ESP enhances directional control and reduces driving
wheel spin of the vehicle under various driving condi-
tions. The system operates when the vehicle speed is
greater than 7.8 mph (12.6 km/h).
The ESP system corrects for over/understeering of the
vehicle by applying brakes to the appropriate wheel.
Engine torque is also limited.
The ESP warning light, located in the instru-
ment cluster, starts to flash as soon as the ESP
system sensor’s information varies from the
driver’s intended path. The ESP warning light
also flashes when traction control is activated. If the ESP
warning light begins to flash during acceleration, ease up
on the accelerator and apply as little throttle as possible.
Be sure to adapt your speed and driving to the prevailing
road conditions. When the ESP warning light is illumi-
nated continuously, the ESP is switched off. To return to
the enhanced vehicle stability offered by ESP, press the
ESP switch (the ESP warning light in the instrument
cluster goes out). Avoid spinning one drive wheel. This
may cause serious damage to the drive train.To improve the vehicle’s traction when driving with
snow chains, or starting off in deep snow, sand or gravel,
switch off the ESP system by pressing the ESP switch.
With the ESP system switched off, the engine torque
reduction feature is cancelled. Therefore, the enhanced
vehicle stability offered by ESP is unavailable. ESP al-
ways operates under braking, even with the switch in the
OFF position. When the ESP system is disabled (if one
drive wheel loses traction and begins to spin) the brake is
applied by the ESP system to control wheel slip. This
Electronic Stability Program Switch
110 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
