CHRYSLER ASPEN HYBRID 2008 2.G Warranty Booklet

❏Change the engine oil and engine oil filter.
❏ Rotate tires.
Perform Maintenance Every
110,000 km or 66 Months
Odometer Reading
Date
Repair Order No.
DAIMLERCHRYSLER
RETAILERSTAMP
Signature of authorized DaimlerChrysler Canada Retailer
................................................................................................

Perform Maintenance Every
110,000 km or 66 Months
❏ Change the engine oil and engine oil filter.
❏ Rotate tires.Perform Maintenance
Every
66 Months or
110,000 km
Odometer Reading
DateRetailer Copy
Remove and attach to Repair Order
................................................................................................

❏Change the engine oil and engine oil filter.
❏ Rotate tires.
❏ Inspect the brake linings, replace if necessary.
❏ Replace the engine air cleaner filter.
❏ Inspect the transfer case fluid.
❏ Replace the top row of spark plugs on 4.7L engines. **
❏ Replace the spark plugs on 3.7L and 5.7L engines.
❏ Change the automatic transmission fluid and main sump filter, if using your
vehicle for any of the following: police, taxi, fleet, snow plowing, or frequent
trailer towing (3.7L, 4.7L, and 5.7L engines only).
❏ Change the transfer case fluid if using your vehicle for any of the following:
police, taxi, fleet, off-road or frequent trailer towing.
❏ Change the manual transmission fluid if using your vehicle for any of the fol-
lowing: trailer towing, snowplowing, heavy loading, taxi, police, delivery ser-
vice (commercial service), off-road, desert operation or more then 50% of your
driving is at sustained high speeds during hot weather, above 32C°.
** Vehicles built with the 4.7L engine are equipped with sixteen spark plugs, one
set is located on the top of the engine under the coils and the second set is lo-
cated on the side of the engine. The spark plugs located under the coils are a stan-
dard plug and must be change every 50,000 kilometres. The spark plugs located
on the side of the engine are a premium plug and must be changed every
170,000 kilometres.
Perform Maintenance Every
100,000 km or 60 Months
Odometer Reading
Date
Repair Order No.
DAIMLERCHRYSLER
RETAILERSTAMP
Signature of authorized DaimlerChrysler Canada Retailer
................................................................................................

Perform Maintenance Every
100,000 km or 60 Months
❏ Change the engine oil and engine oil filter.
❏ Rotate tires.
❏ Inspect the brake linings, replace if necessary.
❏ Replace the engine air cleaner filter.
❏ Inspect the transfer case fluid.
❏ Replace the top row of spark plugs on 4.7L engines. **
❏ Replace the spark plugs on 3.7L and 5.7L engines.
❏ Change the automatic transmission fluid and main sump filter, if using your vehicle for any of
the following: police, taxi, fleet, snow plowing, or frequent trailer towing (3.7L, 4.7L, and 5.7L
engines only).
❏ Change the transfer case fluid if using your vehicle for any of the following: police, taxi, fleet,
off-road or frequent trailer towing.
❏ Change the manual transmission fluid if using your vehicle for any of the following: trailer
towing, snowplowing, heavy loading, taxi, police, delivery service (commercial service),
off-road, desert operation or more then 50% of your driving is at sustained high speeds during
hot weather, above 32C°.
** Vehicles built with the 4.7L engine are equipped with sixteen spark plugs, one set is located on the top of the
engine under the coils and the second set is located on the side of the engine. The spark plugs located under the
coils are a standard plug and must be change every 50,000 kilometres. The spark plugs located on the side of the
engine are a premium plug and must be changed every 170,000 kilometres.
Perform Maintenance
Every
60 Months or
100,000 km
Odometer Reading
DateRetailer Copy
Remove and attach to Repair Order
................................................................................................

❏Change the engine oil and engine oil filter.
❏ Rotate tires.
❏ Inspect the front & rear axle fluid, change if using your
vehicle for police, taxi, fleet, off-road or frequent trailer
towing.
Perform Maintenance Every
90,000 km or 54 Months
Odometer Reading
Date
Repair Order No.
DAIMLERCHRYSLER
RETAILERSTAMP
Signature of authorized DaimlerChrysler Canada Retailer
................................................................................................

Perform Maintenance Every
90,000 km or 54 Months
❏ Change the engine oil and engine oil filter.
❏ Rotate tires.
❏ Inspect the front & rear axle fluid, change if using your vehicle for police, taxi,
fleet, off-road or frequent trailer towing.Perform Maintenance
Every
54 Months or
90,000 km
Odometer Reading
DateRetailer Copy
Remove and attach to Repair Order
................................................................................................

❏Change the engine oil and engine oil filter.
❏ Rotate tires.
❏ If using your vehicle for any of the following: Dusty or
off-road conditions. Inspect the engine air cleaner filter,
replace if necessary.
❏ Inspect the brake linings, replace if necessary.
❏ Inspect the CV joints.
❏ Inspect the exhaust system.
❏ Inspect the front suspension, tie rod ends and boot seals,
replace if necessary.
Perform Maintenance Every
80,000 km or 48 Months
Odometer Reading
Date
Repair Order No.
DAIMLERCHRYSLER
RETAILERSTAMP
Signature of authorized DaimlerChrysler Canada Retailer
................................................................................................

Perform Maintenance Every
80,000 km or 48 Months
❏ Change the engine oil and engine oil filter.
❏ Rotate tires.
❏ If using your vehicle for any of the following: Dusty or off-road conditions. Inspect
the engine air cleaner filter, replace if necessary.
❏ Inspect the brake linings, replace if necessary.
❏ Inspect the CV joints.
❏ Inspect the exhaust system.
❏ Inspect the front suspension, tie rod ends and boot seals, replace if necessary.Perform Maintenance
Every
48 Months or
80,000 km
Odometer Reading
DateRetailer Copy
Remove and attach to Repair Order
................................................................................................

❏Change the engine oil and engine oil filter.
❏ Rotate tires.
Perform Maintenance Every
70,000 km or 42 Months
Odometer Reading
Date
Repair Order No.
DAIMLERCHRYSLER
RETAILERSTAMP
Signature of authorized DaimlerChrysler Canada Retailer
................................................................................................

Perform Maintenance Every
70,000 km or 42 Months
❏ Change the engine oil and engine oil filter.
❏ Rotate tires.Perform Maintenance
Every
42 Months or
70,000 km
Odometer Reading
DateRetailer Copy
Remove and attach to Repair Order
................................................................................................
