CHRYSLER ASPEN HYBRID 2008 2.G Warranty Booklet
Manufacturer: CHRYSLER, Model Year: 2008, Model line: ASPEN HYBRID, Model: CHRYSLER ASPEN HYBRID 2008 2.GPages: 72, PDF Size: 1.4 MB
Page 61 of 72
❏Change the engine oil and engine oil filter.
❏ Rotate tires.
❏ If using your vehicle for any of the following: Dusty or
off-road conditions. Inspect the engine air cleaner filter,
replace if necessary.
❏ Inspect the brake linings, replace if necessary.
❏ Inspect the front & rear axle fluid, change if using your
vehicle for police, taxi, fleet, off-road or frequent trailer
towing.
Perform Maintenance Every
60,000 km or 36 Months
Odometer Reading
Date
Repair Order No.
DAIMLERCHRYSLER
RETAILERSTAMP
Signature of authorized DaimlerChrysler Canada Retailer
................................................................................................
Page 62 of 72
Perform Maintenance Every
60,000 km or 36 Months
❏ Change the engine oil and engine oil filter.
❏ Rotate tires.
❏ If using your vehicle for any of the following: Dusty or off-road conditions. Inspect
the engine air cleaner filter, replace if necessary.
❏ Inspect the brake linings, replace if necessary.
❏ Inspect the front & rear axle fluid, change if using your vehicle for police, taxi,
fleet, off-road or frequent trailer towing.Perform Maintenance
Every
36 Months or
60,000 km
Odometer Reading
DateRetailer Copy
Remove and attach to Repair Order
................................................................................................
Page 63 of 72
❏Change the engine oil and engine oil filter.
❏ Rotate tires.
❏ Replace the engine air cleaner filter.
❏ Inspect the transfer case fluid.
❏ Replace the top row of spark plugs on 4.7L engines. **
❏ Replace the spark plugs on 3.7L and 5.7L engines.
** Vehicles built with the 4.7L engine are equipped with sixteen spark plugs, one
set is located on the top of the engine under the coils and the second set is lo-
cated on the side of the engine. The spark plugs located under the coils are a stan-
dard plug and must be change every 50,000 kilometres. The spark plugs located
on the side of the engine are a premium plug and must be changed every
170,000 kilometres.
Perform Maintenance Every
50,000 km or 30 Months
Odometer Reading
Date
Repair Order No.
DAIMLERCHRYSLER
RETAILERSTAMP
Signature of authorized DaimlerChrysler Canada Retailer
................................................................................................
Page 64 of 72
Perform Maintenance Every
50,000 km or 30 Months
❏ Change the engine oil and engine oil filter.
❏ Rotate tires.
❏ Replace the engine air cleaner filter.
❏ Inspect the transfer case fluid.
❏ Replace the top row of spark plugs on 4.7L engines. **
❏ Replace the spark plugs on 3.7L and 5.7L engines.
** Vehicles built with the 4.7L engine are equipped with sixteen spark plugs, one set is located on the top of the
engine under the coils and the second set is located on the side of the engine. The spark plugs located under the
coils are a standard plug and must be change every 50,000 kilometres. The spark plugs located on the side of the
engine are a premium plug and must be changed every 170,000 kilometres.
Perform Maintenance
Every
30 Months or
50,000 km
Odometer Reading
DateRetailer Copy
Remove and attach to Repair Order
................................................................................................
Page 65 of 72
❏Change the engine oil and engine oil filter.
❏ Rotate tires.
❏ If using your vehicle for any of the following: Dusty or
off-road conditions. Inspect the engine air cleaner filter,
replace if necessary.
❏ Inspect the brake linings, replace if necessary.
❏ Inspect the CV joints.
❏ Inspect the exhaust system.
❏ Inspect the front suspension, tie rod ends and boot seals,
replace if necessary.
Perform Maintenance Every
40,000 km or 24 Months
Odometer Reading
Date
Repair Order No.
DAIMLERCHRYSLER
RETAILERSTAMP
Signature of authorized DaimlerChrysler Canada Retailer
................................................................................................
Page 66 of 72
Perform Maintenance Every
40,000 km or 24 Months
❏ Change the engine oil and engine oil filter.
❏ Rotate tires.
❏ If using your vehicle for any of the following: Dusty or off-road conditions. Inspect
the engine air cleaner filter, replace if necessary.
❏ Inspect the brake linings, replace if necessary.
❏ Inspect the CV joints.
❏ Inspect the exhaust system.
❏ Inspect the front suspension, tie rod ends and boot seals, replace if necessary.Perform Maintenance
Every
24 Months or
40,000 km
Odometer Reading
DateRetailer Copy
Remove and attach to Repair Order
................................................................................................
Page 67 of 72
❏Change the engine oil and engine oil filter.
❏ Rotate tires.
❏ Inspect the front & rear axle fluid, change if using your
vehicle for police, taxi, fleet, off-road or frequent trailer
towing.
Perform Maintenance Every
30,000 km or 18 Months
Odometer Reading
Date
Repair Order No.
DAIMLERCHRYSLER
RETAILERSTAMP
Signature of authorized DaimlerChrysler Canada Retailer
................................................................................................
Page 68 of 72
Perform Maintenance Every
30,000 km or 18 Months
❏ Change the engine oil and engine oil filter.
❏ Rotate tires.
❏ Inspect the front & rear axle fluid, change if using your vehicle for police, taxi,
fleet, off-road or frequent trailer towing.Perform Maintenance
Every
18 Months or
30,000 km
Odometer Reading
DateRetailer Copy
Remove and attach to Repair Order
................................................................................................
Page 69 of 72
❏Change the engine oil and engine oil filter.
❏ Rotate tires.
❏ If using your vehicle for any of the following: Dusty or
off-road conditions. Inspect the engine air cleaner filter,
replace if necessary.
❏ Inspect the brake linings, replace if necessary.
❏ Inspect the CV joints.
❏ Inspect the exhaust system.
Perform Maintenance Every
20,000 km or 12 Months
Odometer Reading
Date
Repair Order No.
DAIMLERCHRYSLER
RETAILERSTAMP
Signature of authorized DaimlerChrysler Canada Retailer
................................................................................................
Page 70 of 72
Perform Maintenance Every
20,000 km or 12 Months
❏ Change the engine oil and engine oil filter.
❏ Rotate tires.
❏ If using your vehicle for any of the following: Dusty or off-road conditions. Inspect
the engine air cleaner filter, replace if necessary.
❏ Inspect the brake linings, replace if necessary.
❏ Inspect the CV joints.
❏ Inspect the exhaust system.Perform Maintenance
Every
12 Months or
20,000 km
Odometer Reading
DateRetailer Copy
Remove and attach to Repair Order
................................................................................................
