CHRYSLER CROSSFIRE 2006 1.G Owners Manual

TOWING A DISABLED VEHICLE
We recommend that the vehicle be transported using flat
bed equipment. This method is preferable to other types
of towing.
CAUTION!
Important! If towing the vehicle, please note the
following: With the automatic central locking acti-
vated and the key in the ignition switch turned to the
ON/RUN position, the vehicle doors lock if the left
front wheel and the right rear wheel are turning at
vehicle speeds of approximately 9 mph (15 km/h) or
more. To prevent the vehicle door locks from lock-
ing, deactivate the automatic central locking.
CAUTION!
If the vehicle is towed with the front wheels raised,
the engine must be shut off (key in the ignition
switch turned to the OFF/LOCK or ACC positions).
Otherwise, the ESP will immediately be engaged
and will apply the rear wheel brakes. Switch off the
tow-away alarm as well as the automatic central
locking system.
Towing restrictions for vehicles with automatic transmis-
sion: The vehicle may be towed with all wheels on the
ground and the transmission selector lever in the Neutral
position for distances up to 30 miles (48 km) and at a
speed not to exceed 30 mph (48 km/h). The key must be
turned to the ON/RUN position in the ignition. To be
certain to avoid a possibility of damage to the transmis-
sion, however, we recommend the drive shaft be discon-
nected at the rear axle drive flange for any towing
beyond a short tow to a nearby garage.
Always comply with applicable state or local towing
ordinances.
WHAT TO DO IN EMERGENCIES 191
6

CAUTION!
•Do not attempt to tow this vehicle from the front
with sling-type towing equipment. Damage to the
front fascia will result.
•Always use wheel lift equipment when towing
from the front. The only other approved method
of towing is with a flatbed truck.
•Do not tow the vehicle from the rear. Damage to
the rear sheet metal and fascia will occur.
•Do not push or tow this vehicle with another
vehicle as damage to the bumper fascia and trans-
mission may result.
Towing Eyes
The vehicle is equipped with front and rear towing eyes
to allow towing with the wheels on the ground or to
allow the vehicle to be easily drawn up on a flatbed tow
truck. The rear towing eye is located on the right side of
the vehicle below the rear fascia. The front hook islocated behind the lower grille in the fascia. For access, a
snap-in grille must be removed using the multifunction
tool from the glovebox.
192 WHAT TO DO IN EMERGENCIES

Insert the tool (or similar sized screwdriver) into the slot
in the grille as shown (the tool must be inserted far
enough to engage the clip on the left side of the grille).
Push the tool to the left to disengage the clip and detach
the grille. The front towing eye is now accessible.
WHAT TO DO IN EMERGENCIES 193
6

Tow-Away Alarm
Once the alarm system has been armed, the exterior
vehicle lights will flash and an alarm will sound when
anyone attempts to raise the vehicle for towing. The
alarm will last approximately three minutes in the form
of flashing exterior lights. At the same time, an alarm will
sound for 30 seconds. The alarm will stay on even if the
vehicle is immediately lowered. To cancel the alarm,
insert the key in the ignition switch or press the transmit
button on the key fob.To prevent triggering the tow-away alarm feature, press
the tow-away alarm switch to turn off the tow-away
alarm before towing the vehicle, or when parking on a
surface subject to movement, such as a ferry or auto train.
To do so, turn the key in the ignition switch to the
OFF/LOCK or ACC positions, or remove key from the
ignition switch. Press the upper half of the tow-away
alarm switch. The indicator light will illuminate briefly.
Then, exit the vehicle and lock with a key or the remote
control. The tow-away alarm remains switched off until
the vehicle is locked again with a key or the remote
control, at which time it is automatically reactivated.
194 WHAT TO DO IN EMERGENCIES

CONVERTIBLE TOP EMERGENCY OPERATION
If the convertible top cannot be closed using the convert-
ible top switch, check the following:
•Is the decklid closed properly?
•Is there sufficient battery voltage? Start the engine if
necessary.
•Is the rear cargo compartment divider secured in the
vertical position?
If the power convertible top operation does not function
properly, you can close the convertible top manually.
NOTE:The multifunction tool from the glovebox is
required for this job.CAUTION!
Manually closing the convertible top is a compli-
cated and technically demanding procedure. Closing
the convertible top manually should be performed
with great care by two people. Close the convertible
top manually in emergency cases only. Otherwise,
visit an authorized DaimlerChrysler Dealer.
WHAT TO DO IN EMERGENCIES 195
6

Relieving Hydraulic Pressure
NOTE:
The hydraulic pressure must be relieved before
the top can manually be raised or lowered.
1. Turn the ignition to the “ON” position.
2. Push down on the convertible top switch and hold in
that position.
3. Turn the ignition “OFF” and continue to push down
on the switch for 5 seconds.
4. After 5 seconds the hydraulic system pressure will be
relieved.
WARNING!
It is important that a second person assist you to
close the convertible top manually to prevent inju-
ries.
1. Lower the windows and open the doors.
2. Turn the ignition key off.
CAUTION!
Ensure that the decklid is closed while raising the
convertible top manually to prevent the possibility
of contact between the decklid and the tonneau
cover.
WARNING!
Do not place your hands near the convertible top
frame, upper windshield area, or the convertible top
storage compartment while the convertible top is
being raised and locked. Serious personal injury
may occur.
196 WHAT TO DO IN EMERGENCIES

3. Unlock the storage compartment by placing the tool
on the bolt between the backrest and the tonneau cover.
Turn the wrench in the direction of the arrow to its stop
and remove the tool.
4. Open the tonneau cover and secure it in the upright
position.5. Pull up hard on the upper section of the convertible
top to move it out of its storage compartment.
NOTE:Do not let go of the convertible top as it may fall
back into the convertible top storage compartment.
WHAT TO DO IN EMERGENCIES 197
6

6. Move the convertible top toward the windshield
header.
WARNING!
Do not place your hands in the convertible top frame
areas. Serious personal injury may occur.
7. Do not place the convertible top frame onto wind-
shield header.8. Place the rear window section of the convertible top in
its vertical position.
9. Close the tonneau cover by placing hands near the
edges (arrows) and slowly lowering it. The tonneau cover
must lock in the first notch of the compartment cover
catch.
198 WHAT TO DO IN EMERGENCIES

10. Lock the convertible top storage compartment by
placing the tool on the bolt between the backrest and the
tonneau cover. Turn the wrench in the direction of the
arrow to its stop and remove the tool.11. Lower the rear window section of the convertible top
down and lock into the tonneau cover.
WHAT TO DO IN EMERGENCIES 199
6

12. Fold down the locking latch handle.
13. Turn the latch handle just past one quarter turn
clockwise and pull the convertible top frame carefully
down until it meets the windshield header attachment
points.
14. Turn the latch handle counterclockwise to the stop in
order to lock the convertible top.15. Fold the latch handle up.
The convertible top is now locked onto the windshield
header.
NOTE:Have the convertible top operation checked at
your authorized DaimlerChrysler Dealer as soon as pos-
sible.
200 WHAT TO DO IN EMERGENCIES
