Opening a Locked Decklid
It is possible for the decklid to become locked if a
convertible top system malfunction occurs. If the top is
manually moved to the full up or full down position
when the hydraulic pressure is relieved, the decklid
should unlock.
WHAT TO DO IN EMERGENCIES 201
6

MAINTAINING YOUR VEHICLE
CONTENTS

3.2L Engine..........................205

Onboard Diagnostic System (OBD II).......206

Emissions Inspection And Maintenance
Programs
............................207

Replacement Parts.....................208

Dealer Service........................208

Maintenance Procedures.................209
▫Engine Oil..........................209
▫Ignition Wiring System.................215
▫Crankcase Emission Control System........215
▫Maintenance-Free Battery................215
▫Air Conditioner......................216▫Power Steering Fluid...................217
▫Chassis Lubrication....................218
▫Body Lubrication.....................218
▫Windshield Wiper Blades................219
▫Windshield Wiper Blade Replacement.......219
▫Windshield Washer Reservoir.............220
▫Exhaust System......................221
▫Cooling System.......................222
▫Hoses And Vacuum/Vapor Harnesses.......225
▫Brakes.............................225
▫Automatic Transmission................228
7

▫Manual Transmission..................229
▫Appearance Care And Protection From
Corrosion...........................230

Convertible Top Care...................234
▫Washing............................235
▫General Cleaning.....................235
▫Weather Strip Care....................236

Fuses...............................237
▫Underhood Accessory Fuse Block Fuses.....237
▫Relay Control Module Fuses.............241
▫Interior Fuses........................242

Replacement Bulbs.....................243
▫Interior Light Bulbs....................243
▫Exterior Light Bulbs...................243

Exterior Light Bulb Service...............244▫Headlights..........................244
▫Front Turn Signal And Parking/Standing
Lights.............................245
▫Front And Rear Sidemarker Lights.........245
▫Tail, Stop, Back Up And Turn Signal Lights . . . 245
▫License Plate Light....................246
▫Headlight Aiming.....................246

Vehicle Storage........................247

Specifications.........................249

Fluid Capacities.......................251

Recommended Fluids, Lubricants And
Genuine Parts
.........................252
▫Engine.............................252
▫Chassis............................253
▫Body..............................254
204 MAINTAINING YOUR VEHICLE

3.2L ENGINE
MAINTAINING YOUR VEHICLE 205
7

ONBOARD DIAGNOSTIC SYSTEM (OBD II)
To meet new government regulations and promote
cleaner air, your Crossfire is equipped with a sophisti-
cated onboard diagnostic system called OBD II. This
system monitors the performance of the emissions and
engine control systems. When these systems are operat-
ing properly, your vehicle will provide excellent perfor-
mance and fuel economy, as well as engine emissions
well within current government regulations.
If any of these systems require service, the OBD II system
will turn on the CHECK ENGINE Light. It will also store
diagnostic codes and other information to assist your
service technician in making repairs. Although your
vehicle will usually be drivable and not need towing, see
your authorized dealer for service as soon as possible.CAUTION!
Prolonged driving with the CHECK ENGINE light
on could cause further damage to the emission
control system. It could also affect fuel economy and
drivability. The vehicle must be serviced before any
state emissions tests can be performed.
If the CHECK ENGINE light is flashing, severe catalytic
converter damage and power loss will soon occur. Im-
mediate service is required.
If the gas cap is not tightened properly, the CHECK
ENGINE light may come on. Be sure the gas cap is
tightened every time you add fuel. Tighten the cap until
you hear it “click” once.
206 MAINTAINING YOUR VEHICLE

EMISSIONS INSPECTION AND MAINTENANCE
PROGRAMS
In some localities, it may be a legal requirement to pass
an inspection of your vehicle’s emissions control system.
Failure to pass could prevent vehicle registration.
For states which have an I/M (Inspection and
Maintenance) requirement, this check verifies
the following: the CHECK ENGINE Light is functioning
and is not on when the engine is running, and that the
OBD (Onboard Diagnostic) system is ready for testing.
Normally, the OBD system will be ready. The OBD
system maynotbe ready if your vehicle was recently
serviced, if you recently had a dead battery, or a battery
replacement. If the OBD system should be determined
not ready for the I/M test, your vehicle may fail the test.
Your vehicle has a simple ignition key actuated test
which you can use prior to going to the test station. To
check if your vehicle’s OBD system is ready, you must do
the following:
1. Insert your ignition key into the ignition switch.2. Turn the ignition to the ON/RUN position, but do not
crank or start the engine.
3. If you crank or start the engine, you will have to start
this test over.
4. As soon as you turn your key to the ON/RUN
position, you will see your CHECK ENGINE light come
on as part of a normal bulb check.
5. Approximately 15 seconds later, one of two things will
happen:
a. The CHECK ENGINE light will flash for about 10
seconds and then return to being fully illuminated
until you turn off the ignition key or start the
engine. This means that your vehicle’s OBD system
isnot readyand you shouldnotproceed to the I/M
station.
b. The CHECK ENGINE light will not flash at all
and will remain fully illuminated until you turn off
the ignition key or start the engine. This means that
your vehicle’s OBD system isreadyand you can
proceed to the I/M station.
MAINTAINING YOUR VEHICLE 207
7

If your OBD system isnot ready,you should see your
authorized dealer or repair facility. If your vehicle was
recently serviced or had a battery failure or replacement,
you may need to do nothing more than drive your
vehicle as you normally would in order for your OBD
system to update. A recheck with the above test routine
may then indicate that the system is now ready.
Regardless of whether your vehicle’s OBD system is
ready or not ready, if the CHECK ENGINE light is
illuminated during normal vehicle operation, you should
have your vehicle serviced before going to the I/M
station. The I/M station can fail your vehicle because the
CHECK ENGINE light is on with the engine running.REPLACEMENT PARTS
Use of genuine Moparparts for normal/scheduled
maintenance and repairs is highly recommended to in-
sure the designed performance. Damage or failures
caused by the use of non-Moparparts for maintenance
and repairs will not be covered by the warranty offered
by DaimlerChrysler Corporation.
DEALER SERVICE
Your dealer has the qualified service personnel, special
tools and equipment to perform all service operations in
an expert manner. Service Manuals are available which
include detailed service information for your Crossfire.
Refer to these manuals before attempting any procedure
yourself.
NOTE:Intentional tampering with emissions control
systems can result in civil penalties being assessed
against you.
208 MAINTAINING YOUR VEHICLE

WARNING!
You can be badly injured working on or around a
motor vehicle. Do only that service work for which
you have the knowledge and the proper equipment.
If you have any doubt about your ability to perform
a service job, take your vehicle to a competent
technician.
MAINTENANCE PROCEDURES
The pages that follow contain the maintenance service
recommended by the engineers who designed your ve-
hicle.
Besides the maintenance items for which there are fixed
maintenance intervals, there are other items that should
operate satisfactorily without periodic maintenance.
However, if a malfunction of these items does occur, it
could adversely affect the engine or vehicle performance.
These items should be inspected if a malfunction is
observed or suspected.
Engine Oil
Checking Oil Level
To assure proper engine lubrication, the engine oil must
be maintained at the correct level. Check the oil level at
regular intervals, such as every fuel stop.
You can check the oil level using the procedure described
in Checking Engine Oil Level in the Understanding Your
Instrument Panel section, or by checking the engine oil
dipstick.
MAINTAINING YOUR VEHICLE 209
7

The best time to check the engine oil level is about 5
minutes after a fully warmed engine is shut off, or before
starting the engine after it has sat overnight.
Checking the oil while the vehicle is on level ground will
improve the accuracy of the oil level readings. Maintain
the oil level between the MIN and MAX markings on the
dipstick. Adding 1 quart of oil when the reading is at the
MIN mark will result in a MAX reading on this engine.
