CHRYSLER PACIFICA 2007 1.G Owners Manual

Miles 21, 000 24, 000 27, 000 30, 000 33, 000 36, 000
(Kilometers) (34 000) (38 000) (43 000) (48 000) (53 000) (58 000)
Change engine oil and engine oil filter.XXXXX X
Rotate TiresXX X
Inspect the brake linings.XX
Inspect the engine air cleaner filter, replace if
necessary. *XXX X X
Replace theengine air cleaner filter. X
Inspect the tie rod ends and boot seals. (Front &
Rear)X
Inspect thePCV valveand replace as necessary.*X
Change the All Wheel Drive (AWD) power
transfer unit fluid. (See note at the end of this
chart)X
Change the All Wheel Drive (AWD) rear carrier
fluid. (See the note at the end of this chart)X
Replace the air conditioning filter.XX
SCHEDULE “B” 421
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 39, 000 42, 000 45, 000 48, 000 51, 000 54, 000
(Kilometers) (62 000) (67 000) (72 000) (77 000) (82 000) (86 000)
Change engine oil and engine oil filter.XXXXX X
Rotate TiresXX X
Inspect the brake linings.XX
Inspect the engine air cleaner filter, replace if
necessary. *XX XX X
Replace theengine air cleaner filter.*X
Change the All Wheel Drive power transfer
unit fluid. (See the note at the end of this
chart.)X
Change the All Wheel Drive (AWD) rear car-
rier fluid. (See note at the end of this chart)X
Replace the air conditioning filter.X
422 SCHEDULE “B”
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 57, 000 60, 000 63, 000 66, 000 69, 000 72, 000
(Kilometers) (91 000) (96 000) (101 000) (106 000) (110 000) (115 000)
Change engine oil and engine oil filter.XXXXXX
Rotate TiresXXX
Inspect the brake linings.XX
Inspect the engine air cleaner filter, replace if necessary. *X XXXX
Replace theengine air cleaner filter. X
Inspect the tie rod ends and boot seals. (Front & Rear)X
Inspect thePCV valve
and replace if necessary.*X
Inspect the serpentine drive belt, replace if necessary. ‡X
Change the automatic transmission fluid and filter.X
Change the All Wheel Drive (AWD) power transfer unit
fluid. (See note at the end of this chart)XX
Change the All Wheel Drive (AWD) rear carrier fluid.
(See note at the end of this chart)X
Replace the air conditioning filter.XX
SCHEDULE “B” 423
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 75, 000 78, 000 81, 000 84, 000 87, 000 90, 000
(Kilometers) (120 000) (125 000) (130 000) (134 000) (139 000) (144 000)
Change engine oil and engine oil filter.XXXXXX
Rotate TiresXXX
Inspect the brake linings.XX
Inspect the engine air cleaner filter, replace if necessary. *XXXX
Replace theengine air cleaner filter X X
Replace thespark plugs. X
Inspect the tie rod ends and boot seals. (Front & Rear)X
Check thePCV valve
and replace if necessary. Not re-
quired if previously changed.*X
Inspect the serpentine drive belt, replace if necessary. ‡XX
Change the All Wheel Drive power transfer unit fluid.
(See the note at the end of this chart.)XX
Change the All Wheel Drive (AWD) rear carrier fluid.
(See note at the end of this chart)X
Replace the air conditioning filter.X
424 SCHEDULE “B”
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 93, 000 96, 000 99, 000 100, 000 102, 000 105, 000
(Kilometers) (149 000) (154 000) (158 000) (160 000) (163 000) (168 000)
Change engine oil and engine oil filter.XXX XX
Rotate TiresXX
Inspect the brake linings.X
Inspect the engine air cleaner filter, replace if necessary. *XXX X
Replace theengine air cleaner filter
*X
Replace engine timing belt.X
Change the All Wheel Drive (AWD) power transfer unit
fluid. (See note at the end of this chart)X
Change the All Wheel Drive (AWD) rear carrier fluid.
(See note at the end of this chart)X
Inspect the serpentine drive belt, replace if necessary. ‡X
Flush and replace the engine coolant.X
Replace the air conditioning filter.X
Engine Coolant — Flush and replace at 5 years of 100,000
miles whichever occurs first.X
SCHEDULE “B” 425
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 108, 000 111, 000 114, 000 117, 000 120, 000
(Kilometers) (173 000) (178 000) (182 000) (187 000) (192 000)
Change engine oil and engine oil filter.X XXXX
Rotate TiresXXX
Inspect the brake linings.XX
Inspect the engine air cleaner filter, replace if neces-
sary. *X XXX
Replace theengine air cleaner filter.X
Inspect the tie rod ends and boot seals. (Front &
Rear)X
Inspect thePCV valveand replace as necessary.*X
Inspect the serpentine drive belt, replace if neces-
sary. ‡X
Change the automatic transmission fluid and filter.X
Change the All Wheel Drive (AWD) power transfer
unit fluid. (See note at the end of this chart)X
Replace the air conditioning filter.XX
426 SCHEDULE “B”
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 123, 000 126, 000 129, 000 132, 000 135, 000
(Kilometers) (197 000) (202 000) (206 000) (211 000) (216 000)
Change engine oil and engine oil filter.XXXX X
Rotate TiresXX
Inspect the brake linings.XX
Inspect the engine air cleaner filter, replace if neces-
sary. *XXXX
Replace theengine air cleaner filter. X
Inspect the serpentine drive belt, replace if neces-
sary. ‡X
Change the All Wheel Drive (AWD) power transfer
unit fluid. (See note at the end of this chart)X
Change the All Wheel Drive (AWD) rear carrier
fluid. (See note at the end of this chart)X
Replace the air conditioning filter.X
SCHEDULE “B” 427
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 138, 000 141, 000 144, 000 147, 000 150, 000
(Kilometers) (221 000) (226 000) (230 000) (235 000) (240 000)
Change engine oil and engine oil filter.XXXXX
Rotate TiresXXX
Inspect the brake linings.X
Inspect the engine air cleaner filter, replace if neces-
sary. *XXXX
Replace theengine air cleaner filter.X
Replace thespark plugs.X
Inspect the serpentine drive belt, replace if neces-
sary. ‡X
Inspect the tie rod ends and boot seals. (Front &
Rear)X
Inspect thePCV valveand replace as necessary.*X
Change the All Wheel Drive (AWD) power transfer
unit fluid. (See note at the end of this chart)X
428 SCHEDULE “B”
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 138, 000 141, 000 144, 000 147, 000 150, 000
(Kilometers) (221 000) (226 000) (230 000) (235 000) (240 000)
Change the All Wheel Drive (AWD) rear carrier
fluid. (See note at the end of this chart)X
Replace the air conditioning filter.X
* This maintenance is recommended by the manufacture
to the owner but is not required to maintain the emis-
sions warranty.
‡ This maintenance is not required if previously replaced.
Inspection and service should also be performed anytime
a malfunction is observed or suspected. Retain all re-
ceipts.NOTE:The AWD power transfer unit fluid and the
AWD rear carrier fluid must be changed at the more
frequent intervals shown in schedule B if the vehicle is
operated under any of the conditions noted by a dia-
mond () at the beginning of the schedule.
SCHEDULE “B” 429
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

SCHEDULE “A”
Miles 6, 000 12, 000 18, 000 24, 000 30, 000 36, 000
(Kilometers) (10 000) (19 000) (29 000) (38 000 ) (48 000) (58 000)
[Months] [6] [12] [18] [24] [30] [36]
Change engine oil and engine oil filter.XXXXXX
Rotate TiresXXXXXX
Inspect the brake linings.XX
Inspect the engine air cleaner filter, replace if
necessary. *XXXX X
Replace theengine air cleaner filter. X
Inspect the tie rod ends and boot seals. (Front
& Rear)X
Replace the air conditioning filter.XXX
430 SCHEDULE “A”
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S
