can c CHRYSLER PACIFICA 2017 2.G Owners Manual

VEHICLES SOLD IN CANADA
With respect to any Vehicles Sold in Canada, the name FCA
US LLC shall be deemed to be deleted and the name FCA
Canada Inc. used in substitution therefore.
DRIVING AND ALCOHOL
Drunken driving is one of the most frequent causes of
accidents.
Your driving ability can be seriously impaired with blood
alcohol levels far below the legal minimum. If you are
drinking, don’t drive. Ride with a designated non-
drinking driver, call a cab, a friend, or use public trans-
portation.
WARNING!
Driving after drinking can lead to an accident.
Your perceptions are less sharp, your reflexes are
slower, and your judgment is impaired when you
have been drinking. Never drink and then drive.
This manual illustrates and describes the operation of
features and equipment that are either standard or op-
tional on this vehicle. This manual may also include a
description of features and equipment that are no longer
available or were not ordered on this vehicle. Please
disregard any features and equipment described in this
manual that are not on this vehicle.
FCA US LLC reserves the right to make changes in design
and specifications, and/or make additions to or improve-
ments to its products without imposing any obligation
upon itself to install them on products previously manu-
factured.
Copyright © 2015 FCA US LLC

GETTING TO KNOW YOUR VEHICLE
CONTENTS
KEYS ................................19
▫ RKEKeyFob .........................19
 IGNITION SWITCH ......................30
 REMOTE STARTING SYSTEM — IF
EQUIPPED ............................33
▫ Remote Start Cancel Message — If Equipped . . .33
▫ How To Use Remote Start ................34
▫ To Enter Remote Start Mode ...............35
▫ To Exit Remote Start Mode Without Driving The
Vehicle .............................35 ▫
To Exit Remote Start Mode And Drive The
Vehicle ..............................35
▫ Remote Start Comfort Systems — If
Equipped ...........................36
▫ Remote Start Windshield Wiper De–Icer
Activation — If Equipped ................36
▫ General Information ....................36
 SENTRY KEY ...........................37
 VEHICLE SECURITY ALARM — IF EQUIPPED . .38
▫ Rearming Of The System .................38
▫ To Arm The System ....................383

▫Opening Sunroof ..................... .154
▫ Closing Sunroof ...................... .155
▫ Wind Buffeting ...................... .155
▫ Power Sun Shade — If Equipped ..........156
▫ Pinch Protect Feature ...................157
▫ Sunroof Maintenance ...................157
▫ Ignition OFF Operation .................157
 HOOD ............................. .158
▫ Opening ........................... .158
▫ Closing ............................ .159
 LIFTGATE .......................... .160
▫ Opening .......................... .160
▫ Closing ........................... .162▫
Power Liftgate — If Equipped ............163
▫ Hands-Free Liftgate — If Equipped .........165
▫ Cargo Area Features ....................168
 GARAGE DOOR OPENER — IF EQUIPPED . . . .175
▫ Before You Begin Programming HomeLink . . .176
▫ Canadian/Gate Operator Programming ......180
▫ Using HomeLink .....................182
▫ Security ........................... .182
▫ Troubleshooting Tips ...................182
▫ General Information ....................183
 INTERNAL EQUIPMENT .................184
▫ Storage ............................ .184
▫ Illuminated Vanity Mirrors — If Equipped . . .192
3
GETTING TO KNOW YOUR VEHICLE 17

KEYS
The keyless ignition system consists of a Key Fob with
Remote Keyless Entry (RKE) transmitter (RKE Key Fob)
with a built in emergency key and a keyless push button
Ignition system.
RKE Key Fob
This system allows you to lock or unlock the doors and
liftgate, and activate the Panic Alarm, optional power
liftgate, left power sliding door, and right power sliding
door from distances up to approximately 66 ft (20 m)
using a hand-held RKE Key Fob. The RKE key fob does
not need to be pointed at the vehicle to activate the
system.NOTE:
The emergency key allows for entry into the
vehicle should the battery in the vehicle or the RKE Key
Fob go dead. The emergency key is also for locking/
unlocking the glove compartment. You can keep the
emergency key with you when valet parking.
Three Button RKE Key Fob
3
GETTING TO KNOW YOUR VEHICLE 19

General Information
The following regulatory statement applies to all radio
frequency (RF) devices equipped in this vehicle:
This device complies with Part 15 of the FCC Rules and
with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received,including interference that may cause undesired op-
eration.
NOTE: Changes or modifications not expressly approved
by the party responsible for compliance could void the
user ’s authority to operate the equipment.
To Unlock The Doors
NOTE: Uconnect Settings lets you program the system
to unlock either the driver’s side doors on the first push
(default) or unlock all doors on the first push of the
UNLOCK button on the RKE Key Fob. To change the
default setting, refer to “Uconnect Settings” in “Multime-
dia” for further information.
1st Push Of Key Fob Unlocks
Push and release the UNLOCK button on the RKE Key
Fob once to unlock the front and rear driver doors or
twice within five seconds to unlock all doors liftgate. The
hazard lights will flash to acknowledge the unlock signal.
The illuminated entry system will be activated.
22 GETTING TO KNOW YOUR VEHICLE

This feature lets you program the system to unlock either
the driver’s door or all doors on the first push of the
UNLOCK button on the RKE Key Fob. To change the
current setting, refer to “Uconnect Settings” in “Multime-
dia” for further information.
NOTE:If the vehicle is equipped with Passive Entry,
refer to “Keyless Enter-N-Go — Passive Entry” in “Get-
ting To Know Your Vehicle” for further information.
Emergency Key Feature
The RKE Key Fob also contains and an emergency key,
which stores in the bottom of the RKE Key Fob.
The emergency key allows for entry into the vehicle
should the battery in the vehicle or the RKE Key Fob go
dead. The emergency key is also for locking/unlocking
the glove compartment. You can keep the emergency key
with you when valet parking.
Mechanical Latch To Release Emergency Key
24 GETTING TO KNOW YOUR VEHICLE

To remove the emergency key, press the mechanical
button on the side of the RKE Key Fob with your thumb
and pull the emergency key out with your other hand
while pushing the mechanical button.
To Lock The Doors And Liftgate
Push and release the LOCK button on the RKE Key Fob
to lock all doors and liftgate. The hazard lights will flash
once and the horn will chirp once to acknowledge the
signal. Settings in radio can change to lights only, chirp
only, or both.
If the vehicle is equipped with Passive Entry, refer to
“Keyless Enter-N-Go — Passive Entry” in “Getting To
Know Your Vehicle” for further information.Key Fob With Remote Control And Integrated Vehicle
Key
If one or more doors are open, or the liftgate is open, the
doors will lock. This is signaled by a quick flash of the
turn signals.
Vehicles Equipped With Keyless Enter-N-Go — Passive
Entry
If one or more doors are open, or the liftgate is open, the
doors will lock. The doors will unlock again only if the
key is inside the passenger compartment.
3
GETTING TO KNOW YOUR VEHICLE 25

3. Remove the battery by turning the back cover over(battery facing downward) and tapping it lightly on a
solid surface such as a table or similar, then replace the
battery. When replacing the battery, match the + sign
on the battery to the + sign on the inside of the battery
clip, located on the back cover. Avoid touching the new battery with your fingers. Skin oils may cause
battery deterioration. If you touch a battery, clean it
with rubbing alcohol.
4. To assemble the RKE Key Fob case, snap the two halves together.
Programming Additional Transmitters
If you do not have a programmed RKE Key Fob, contact
your authorized dealer for details.
Request For Additional Remote Controls
NOTE: Only RKE Key Fobs that are programmed to the
vehicle electronics can be used to start and operate the
vehicle. Once a RKE Key Fob is programmed to a vehicle,
it cannot be programmed to any other vehicle.Separating The RKE Key Fob Case
3
GETTING TO KNOW YOUR VEHICLE 27

CAUTION!
•Always remove the Key Fobs from the vehicle and
lock all doors when leaving the vehicle unat-
tended.
• For vehicles equipped with Keyless Enter-N-Go,
always remember to place the ignition in the OFF
position.
At the time of purchase, the original owner is provided
with a four-digit Personal Identification Number (PIN).
Keep the PIN in a secure location. This number is
required for authorized dealer replacement of RKE Key
Fobs. Duplication of RKE Key Fobs may be performed at
an authorized dealer. This procedure consists of pro-
gramming a blank RKE Key Fob to the vehicle electron-
ics. A blank RKE Key Fob is one that has never been
programmed. NOTE:
When having the Sentry Key Immobilizer System
serviced, bring all vehicle keys with you to an authorized
dealer.
KeySense Features — If Equipped
This feature provides the vehicle owner with the ability
to identify a specific vehicle key for which a customized
category of vehicle settings can be applied to determine
the driving experience for other drivers of the vehicle.
The vehicle settings are protected by a unique 4-digit
PIN, which the vehicle owner creates when accessing the
specific settings for the first time.
This feature also has additional features that are always
enabled when the specific key is in use that cannot be set
by the vehicle owner. While this specific RKE Key Fob is
in use, the vehicle will respond accordingly to the cus-
tomized vehicle settings and mandatory features. This
includes enhanced driving assistance features, increased
driver alerts, and the locking of certain optional features.
28 GETTING TO KNOW YOUR VEHICLE

IGNITION SWITCH
This feature allows the driver to operate the ignition
switch with the push of a button, as long as the RKE Key
Fob is in the passenger compartment, and the drivers foot
on the brake pedal.
The Keyless Push Button Ignition has four operating
positions; three of which are labeled and will illuminate
when in position. The three positions are OFF, ACC, and
ON/RUN. The fourth position is START, during start
RUN will illuminate.The ignition can be placed in the following positions:
OFF
•The engine is stopped.
• Some electrical devices are available.
Keyless Push Button Ignition
30 GETTING TO KNOW YOUR VEHICLE
