5. DOT Street Legal Competition Tires
P Zero Trofeo and P Zero Corsa tire lines use special tire construction and
compounds to achieve their distinctive performance in dry conditions. As
a result of that, their performance in cold temperatures, heavy rain or
standing water will be decreased. Use extreme caution and drive slowly
on wet roads.
The minimum tread depth will be reached earlier than normal road tires,
resulting in reduced tread life.
6. Winter Tires
The standard Pirelli tires may be effective in light snow conditions.
However, for winter use, you may wish to install winter tires. During
winter use, Pirelli strongly recommends the fitment of 4 winter tires.
Please check your vehicle owner ’s manual concerning winter tire size
recommendation. If the winter tires have a lower speed rating than the
original equipment tires, vehicle handling may be affected, and the
vehicle maximum speed must be reduced to the winter tire speed rating.
Pirelli requires that studded tires be installed on all four positions.
Installing studded tires only on the drive positions of any vehicle,
including a front wheel drive vehicle, may cause adverse handling
characteristics.
7. Run Flat Tires
Always refer to the vehicle owners’ manual with respect to specific safety
and operating information relating to the vehicle. Damaged Run Flat tires
or Run Flat tires that have experienced a loss of pressure should
immediately be replaced with another Run Flat tire of identical size and
Service Description (Load Index and Speed Symbol).
Run Flat tires have been developed based on the specifications of the
vehicles on which they are mounted. Accordingly, Run Flat tires should
only be mounted on vehicles specifically manufactured to accommodate
Run Flat tires.
Run Flat tires must be mounted in conjunction with a functional Tire
Pressure Monitoring System (TPMS).
The mounting of tires and installation of the Tire Pressure Monitoring
System (TPMS) should be carried out by a specialized dealer.
PIRELLI TIRES
210

8. Tire Replacement
The tires fitted to your vehicle as original equipment were tested and
approved by the vehicle manufacturer and the tire manufacturer and take
into account all aspects of the vehicle’s operation. Changes in the tire size,
type or construction should not be made without seeking advice from the
vehicle or tire manufacturer or an authorized Pirelli dealer since unap-
proved tires on your vehicle could adversely affect steering, handling,
braking and traction. The tire information (tire size, load index and speed
symbol) as found on the vehicle placard or in the owner ’s manual should
always be followed when replacing tires.
It is strongly recommended that Pirelli tires be mounted in sets of four
with the same tread type. Pirelli tires should not be mixed with other tire
brands. It is necessary to follow this procedure because different tire
constructions have different handling characteristics. Tires on the same
axle must be the same manufacturer, brand, tire size, load index, speed
rating and Pirelli part number.
When changing only two tires on a vehicle which is homogeneously
fitted (four tires of the same tire size), fit the new tires on the rear axle.
This applies to all vehicles regardless of their drive axle. (Front or Rear
Drive).
On all wheel drive or four wheel drive vehicles the tires must always be
replaced in sets of four.
When replacing tires on light truck vehicles, you should always follow
the vehicle manufacturer ’s recommendations. Passenger and light truck
tires are not interchangeable, due to differences in their pressures and
load carrying capacity.
P-Metric and Euro-metric Interchangeability: Euro-metric (Example: 225/
45R17) tires have a load index which is equal to or greater than that of the
same size P-metric (Example: P225/45R17) tire. Therefore, they have the
same or higher load carrying capacity at the maximum rated inflation
pressure. Always check with your tire dealer or Pirelli Tire Consumer
Affairs to be sure of the exact interchangeability to maintain proper
vehicle dynamics.
Please be aware that it is important that, before fitting the suggested tires,
the fitment is allowed by the technical specifications of the vehicle, the
vehicle manufacturer and the relevant homologations. Pirelli Tire does
not express any view as to the compatibility of the wheel/tire combina-
tion with the technical specifications for the chassis and vehicle.
PIRELLI TIRES
211

TO MAINTAIN PROPER VEHICLE DYNAMICS AND LOAD CARRY-
ING CAPACITY, REPLACEMENT TIRES MUST ALWAYS HAVE A
LOAD INDEX AND SPEED SYMBOL EQUAL TO OR GREATER THAN
THOSE FITTED AS ORIGINAL EQUIPMENT.
When making plus size fitments, you should consult with the dealer
regarding any suspension or braking system modifications which may be
recommended for the vehicle.
9. Tire Inspection
As a minimum, tires (including the spare tire) should be examined and air
pressure checked monthly and always prior to long trips. They should also
be examined if you strike any unusual object on the road. Tires showing
bulges, cracks, cuts, penetrations or uneven wear must be dismounted and
examined by an authorized Pirelli tire dealer and replaced if necessary.
Pirelli tires have treadwear indicators in the tread grooves, which show up
when the tread has worn to 2/32” remaining. At this point, your tires must
be replaced because they are illegal and dangerous.
The mere passage of time (age) does not cause tires to deteriorate, but
rather exposure to outside forces. Such outside forces can include, but are
not limited to: road hazards, punctures, improper repairs, misalignment,
under inflated operation, over inflated operation, excessive heat caused
by over deflected operation, excessive exposure to ozone, improper
storage conditions, etc. Tire companies can only have an impact on a few
of these exposures. Tire companies add antiozinants and anti-oxidants
(anti-degradation compounds) to minimize degradation. Pirelli believes
that since there is no way to accurately predict what outside forces a tire
will be exposed to there is no scientifically supportable age limit that can
be set for tires.
To avoid cosmetic damage, use a mild soap solution to clean sidewalls
and rinse off with low-pressure tap water. Never apply cleaners or
dressings to enhance sidewall appearance to avoid removal of antioxi-
dants, which are intended to prevent ozone degradation. The removal of
anti-oxidants may degrade the rubber and can lead to sidewall cracking.
Use of high-pressure sprayers may cause sidewall damage.
WARNING!
Driving on a damaged tire is dangerous, as the tire can suddenly fail,
which can lead to an accident and serious personal injury or death.
PIRELLI TIRES
212

10. Tire Rotation
Pirelli recommends that you follow the tire rotation procedure as defined
in your vehicle owner ’s manual. If there is no procedure, PTI recom-
mends tire rotation every 8,000 to 11,000 kilometers to optimize your tire
wear.
11. Tire Repair
Punctures, nail holes or cuts located in the tread area of Pirelli radial tires
may be repaired if the diameter does not exceed 6 mm. The repair
material used must seal the innerliner and fill the injury to be considered
a permanent repair. Tire and Rubber Association of Canada and industry
approved repair methods include a combination of plug and patch;
chemical or hot vulcanizing patches, and head type plugs, all applied
from inside the tire. A self-vulcanizing plug repair may be used only in
conjunction with a patch repair, but not by itself. Plugs may cause further
damage to the tire, they are not always airtight and the plug may fail. If
a tire puncture exceeds 6 mm or is located in the shoulder or sidewall
deflection areas, the tire must be replaced. Never resort to tubes (in
tubeless tires) or sleeves or large thick patches, which can upset the
balance and may result in a sudden failure at highway speeds and high
operating temperatures.
WARNING!
Driving on an improperly repaired tire is dangerous, as the tire can
suddenly fail, which can lead to an accident and serious personal
injury or death.
PIRELLI TIRE DOES NOT ENDORSE:
•The use of tire sealants in Pirelli tires to repair, even temporarily, a
puncture;
•The repairing of V, W, Y or Z Speed Rated tires;
•The repairing of Run Flat tires.
PIRELLI TIRES
213

12. Storage
Should you need to store tires after removal from a vehicle (as in the case
of winter tires), they should be stored in a cool, dry place. To protect your
tires from damage related to: heat, water, ozone and direct sunlight, it is
suggested you place them in opaque, waterproof containers (e.g., plastic
trash bags).
13. Tubes in Tubeless Tires
Under no circumstances are tubes to be used in Pirelli tires marked
“Tubeless”. This includes tires that have been repaired. If the tire’s
pressure retention ability has been affected, so as to necessitate a tube
being installed, the tire must be replaced.
14. Tire Valves
Whenever new tires are installed on your wheels, new tire valves of the
correct type must be installed. During your routine tire inspection, verify
that all your valves have proper valve caps. Replace as necessary, since
the valve cap is also a seal against pressure loss.
15. Tire Demounting and Mounting
Tire fitting is best left to professionals who have the proper tools and
equipment to perform the task properly and safely. Your tires should be
mounted or demounted, using Tire and Rubber Association of Canada
procedures or the vehicle manufacturers’ recommendations. Your wheels
should be in good, clean condition. Wheels should be inspected for
distortion, dents, cracks, rust and foreign matter, and be replaced as
necessary. NEVER EXCEED 40 PSI WHEN SEATING BEADS.
PIRELLI TIRES
214

16. Tire/Wheel Alignment and Balancing
Tire/Wheel alignment specifications are issued by your vehicle manu-
facturer and your vehicle must be kept within these tolerances. You
should have your alignment checked annually or whenever you notice
any irregular wear or vibrations. Tire/ Wheel assemblies should be
balanced each time a tire is fitted to a wheel. Tire/Wheel alignment and
balancing are important for safety and maximum performance and
mileage from your tires.
For more information or service regarding Pirelli tires, please contact
your nearest Authorized Pirelli Dealer. To locate an authorized Pirelli
Dealer in your area, refer to the Dealer Locator section on the Pirelli web
site at www.ca.pirelli.com.
P ZERO, P ZERO CORSA, P ZERO ROSSO, P ZERO NERO, CINTU-
RATO, SCORPION, SCORPION ZERO, SCORPION VERDE, P3000, P1,
P4, P5, P6, P7 are trademarks of Pirelli Tyre S.p.A.
“Confidence
Program” is a trademark of Pirelli Tire Inc.
1111 D r. F rederik-Philips Blvd, Suite 506
St-Laurent (Quebec) H4M 2X6
Eastern Canada1-800-363-0583
Ontario1-800-828-2585
Western Canada1-800-663-0148
www.ca.pirelli.comPIRELLI TIRES
215

NOTES
PIRELLI TIRES
216

TOYO TIRES – LIMITED
WARRANTY
LIMITED WARRANTY FOR ORIGINAL EQUIPMENT TOYO TIRES
WHAT IS COVERED AND FOR HOW LONG?
This Limited Warranty covers all Toyo brand passenger car, light truck
and temporary spare tires installed as original equipment on vehicles that
are sold and used within the United States.
Eligible Tires
Your tires are covered under this Limited Warranty if all of the following
criteria are met:
•The tire was installed on your vehicle at the factory as an original
equipment part.
•You are the original purchaser of the vehicle.
•You purchased the vehicle after November 2011*.
•You have always used the tires with this vehicle.
•The tires have been used for normal street driving.
•The vehicle has not been used for commercial service.
•You properly maintained and used the tire (See “Tire Safety and
Maintenance Information” section below).
•The tires are not subject to an exclusion (See “What is Not Covered?”
section below).
•You fulfill the warranty claim procedure (See “How to Make a Claim”
section below).
Eligible Tires are covered under this Limited Warranty for a period of up
to 5 years from the date you purchased your new vehicle. Toyo Tires will
replace it with a comparable new Toyo brand tire in the manner
explained in the “What Toyo Tires Will Do” section below.
* Vehicles purchased before November 2011 may be covered by an earlier
warranty. See your Toyo Tires retailer or contact Toyo Tires for more
information.
TOYO TIRES – LIMITED WARRANTY
217

WHAT IS NOT COVERED?
This Limited Warranty does not cover the following categories of claims:
Rapid Treadwear: Original equipment tires are not guaranteed to last a
specified number of miles.
Damage from road hazards (not limited to cuts, snags, bruises, impact
breaks, bulges, punctures, stone drills, chips, and scales), fire, theft, or
collision.
Conditions arising from improper tire/vehicle maintenance or use, not
limited to:
•Irregular or excessive treadwear due to: Incorrect inflation; overload-
ing; vehicle misalignment; failure to rotate tires; and poor or defective
mechanical condition of brakes, shocks, and wheels; or other factors
attributable to the vehicle or wheel.
•Any tire which has been run with low air pressure or while flat.
•Damage due to abuse; vandalism; tire alteration; tire spinning; racing;
or other competitive activities.
•Damage, corrosion, or deterioration from using oil-based chemicals,
water-based sealers, balancing substances, or flammable gases.
•Damage from improper use of tire chains.
Tires with the DOT identification number removed or rendered illegible.
Improper mounting, balancing or repair, not limited to:
•Improper tire mounting, or tire/wheel assembly imbalance.
•Damage from incorrect mounting or dismounting of the tire, incorrect
wheel size, water or other material trapped inside the tire during
mounting, or failure to keep the tires balanced.
•Damage resulting from improper repair materials or procedures.
TOYO TIRES – LIMITED WARRANTY
218

Failure to meet conditions of this Limited Warranty, not limited to:
•Any tire that is not an Eligible Tire.
•Any tire for which mileage and tire rotation records are not available
or verifiable.
•Any tire not presented and available for Toyo Tires’ inspection.
•Any tire worn beyond the treadwear indicators (less than 2/32” of
remaining tread).
•Uniformity issues after the first 25% of treadwear.
Temporary spare tires that are used at speeds over 50 miles per hour.
Nothing in this Limited Warranty is intended to be a representation that
tire failures cannot occur.
WHAT TOYO TIRES WILL DO
For every Eligible Tire, Toyo Tires will do the following:
Regular OE Tires
1. If less than 25% Worn: Toyo Tires will replace, free of charge, any
Eligible Tire when the original usable tread is worn by 25% or less, and
within 5 years from the date you purchased the vehicle new. If you
cannot provide a copy of the new vehicle registration or vehicle
purchase receipt, the manufacture date of the tire, as indicated by the
tire DOT code, will be used instead to determine if a tire is within the
warranty period. Tire mounting and balancing costs are covered by
Toyo Tires.You are responsible for taxes and all other costs, fees and
expenses.
2. If more than 25% Worn: Toyo Tires will replace any Eligible Tire when
the original usable tread is worn by more than 25%, and within 5 years
from the date you purchased the vehicle new. If you cannot provide a
copy of the new vehicle registration or vehicle purchase receipt, the
manufacture date of the tire, as indicated by the tire DOT code, will be
used instead to determine if a tire is within the warranty period.Yo u
are responsible for the pro-rated cost of a replacement tire, mount-
ing and balancing costs, taxes and all other costs, fees and expenses.
TOYO TIRES – LIMITED WARRANTY
219
