CHRYSLER PT CRUISER 2004 1.G Warranty Booklet

Odometer Reading
Date
Repair Order No.
DAIMLER CHR YSLER
D EALER STAMP
Signature of authorized DaimlerChrysler Canada dealer
l Change engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate, as required, all steering and suspension components.
l Inspect the engine air cleaner filter and replace if necessary(Sebring, Sebring Convertible, PT Cruiser, SRT-4, and SX 2.0only).
l Replace the engine air cleaner filter, if required (Pacifica, Minivan, Concorde, Intrepid, and 300M only).
l Inspect and replace, if required, the make-up air filter located inside the air cleaner (PT Cruiser and SX 2.0 only).
l Adjust the drive belt tension (Concorde, Intrepid, and 300M only).
l Check and retention power steering pump belt (2.4L Minivan only).
l Check the generator belt, replace if necessary (2.4L Minivan only)
l Change the all-wheel-drive power transfer unit fluid.*
INSPECT THE FOLLOWING: l Inspect the front and rear brake linings and components (Pacifica, Minivan, Concorde, Intrepid, 300M and SX 2.0 only).
l Inspect the brake hoses
l Check the automatic transaxle fluid level.
l Check the manual transaxle fluid level and fill plug condition (if equipped).
l Check the coolant level, hoses and clamps.
l Inspect the exhaust system.
*All-wheel-drive power transfer unit fluid and overrunning clutch/rear carrier fluid must be changed at more frequent intervals than shown in Schedule B if thevehicle is used for trailer tow, taxi, police or other types of commercial service.
Maint enance Service Sc hedule ÒBÓ
72,0 00 km
2004 Car_Minivan Maint Book 7/24/03 12:42 PM Page 60

Maintenance Service
Sc hedule ÒBÓ
Odometer Reading
Date
77,000 km
Dealer copy.
Remove and attach to Repair Order 26-92-16-01 3N.
Maint enance Service Sc hedule ÒBÓ
77 ,000 km
l Change engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate, as required, all steering and suspension components.
l Inspect the engine air cleaner filter and replace if necessary (Sebring, Sebring Convertible, Concorde, Intrepid, 300M, Pacifica, and Minivan only).
l Change the manual transaxle fluid. (PT Cruiser and SRT-4 only). *
l Replace the differential fluid (Concorde, Intrepid and 300M only).
lChange the brake fluid if the vehicle is used for trailer towing (PT Cruiser and SRT-4 only).l Replace the air conditioning filter (Pacifica and Minivan if equipped).
l Rotate tires and check tire pressure.
INSPECT THE FOLLOWING: l Inspect the front and rear brake linings and components (Sebring, Sebring Convertible, PT, and SRT-4 only).
l Inspect the brake hoses.
l Check the automatic transaxle fluid level.
l Check the manual transaxle fluid level and fill plug condition (SX 2.0 only, if equipped).
l Check the coolant level, hoses and clamps.
l Inspect the exhaust system.
* Change the manual transmission fluid and filter every 77,000 km if the vehicle is used for trailer tow, taxi, police or other types of commercial service.
2004 Car_Minivan Maint Book 7/24/03 12:42 PM Page 61

Odometer Reading
Date
Repair Order No.
DAIMLER CHR YSLER
D EALER STAMP
Signature of authorized DaimlerChrysler Canada dealer
l Change engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate, as required, all steering and suspension components.
l Inspect the engine air cleaner filter and replace if necessary(Sebring, Sebring Convertible, Concorde, Intrepid, 300M,Pacifica, and Minivan only).
l Change the manual transaxle fluid. (PT Cruiser and SRT-4 only). *
l Replace the differential fluid (Concorde, Intrepid and 300M only).
lChange the brake fluid if the vehicle is used for trailer towing(PT Cruiser and SRT-4 only).
l Replace the air conditioning filter (Pacifica and Minivan, if equipped).
l Rotate tires and check tire pressure.
INSPECT THE FOLLOWING: l Inspect the front and rear brake linings and components (Sebring, Sebring Convertible, PT, and SRT-4 only).
l Inspect the brake hoses.
l Check the automatic transaxle fluid level.
l Check the manual transaxle fluid level and fill plug condition (SX 2.0 only, if equipped).
l Check the coolant level, hoses and clamps.
l Inspect the exhaust system.
* Change the manual transmission fluid and filter every 77,000 km if the vehicle is
used for trailer tow, taxi, police or other types of commercial service.
Maint enance Service Sc hedule ÒBÓ
77 ,000 km
2004 Car_Minivan Maint Book 7/24/03 12:42 PM Page 62

Maintenance Service
Sc hedule ÒBÓ
Odometer Reading
Date
82,0 00 km
Dealer copy.
Remove and attach to Repair Order 26-92-17-01 3N.
Maint enance Service Sc hedule ÒBÓ
82,0 00 km
l Change engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate, as required, all steering and suspension components.
l Inspect the engine air cleaner filter and replace if necessary
(Sebring, Sebring Convertible,
Concorde, Intrepid, 300M, Pacifica, and Minivan only).
INSPECT THE FOLLOWING: l Inspect the brake hoses.
l Check the automatic transaxle fluid level.
l Check the manual transaxle fluid level and fill plug condition (if equipped).
l Check the coolant level, hoses and clamps.
l Inspect the exhaust system.
2004 Car_Minivan Maint Book 7/24/03 12:42 PM Page 63

Odometer Reading
Date
Repair Order No.
DAIMLER CHR YSLER
D EALER STAMP
Signature of authorized DaimlerChrysler Canada dealer
l Change engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate, as required, all steering and suspension components.
l Inspect the engine air cleaner filter and replace if necessary
(Sebring, Sebring Convertible, Concorde,
Intrepid, 300M, Pacifica, and Minivan only).
INSPECT THE FOLLOWING: l Inspect the brake hoses.
l Check the automatic transaxle fluid level.
l Check the manual transaxle fluid level and fill plug condition (if equipped).
l Check the coolant level, hoses and clamps.
l Inspect the exhaust system.
Maint enance Service Sc hedule ÒBÓ
82,0 00 km
2004 Car_Minivan Maint Book 7/24/03 12:42 PM Page 64

Maintenance Service
Sc hedule ÒBÓ
Odometer Reading
Date
86,0 00 km
Dealer copy.
Remove and attach to Repair Order 26-92-18-01 3N.
Maint enance Service Sc hedule ÒBÓ
86,0 00 km
l Change engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate, as required, all steering and suspension components.
l Inspect the engine air cleaner filter and replace if necessary
(Sebring, Sebring Convertible,
Concorde, Intrepid, 300M, Pacifica, and Minivan only).
l Rotate tires and check tire pressure.
INSPECT THE FOLLOWING: l Inspect the front and rear brake linings and components (Pacifica, Minivan, Concorde, Intrepid, 300M, and SX 2.0 only).
l Inspect the brake hoses.
l Check the automatic transaxle fluid level.
l Check the manual transaxle fluid level and fill plug condition (if equipped).
l Check the coolant level, hoses and clamps.
l Inspect the exhaust system.
2004 Car_Minivan Maint Book 7/24/03 12:42 PM Page 65

Odometer Reading
Date
Repair Order No.
DAIMLER CHR YSLER
D EALER STAMP
Signature of authorized DaimlerChrysler Canada dealer
l Change engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate, as required, all steering and suspension components.
l Inspect the engine air cleaner filter and replace ifnecessary (Sebring, Sebring Convertible, Concorde,Intrepid, 300M, Pacifica, and Minivan only).
l Rotate tires and check tire pressure.
INSPECT THE FOLLOWING: l Inspect the front and rear brake linings and components (Pacifica, Minivan, Concorde, Intrepid, 300M, and SX 2.0 only).
l Inspect the brake hoses.
l Check the automatic transaxle fluid level.
l Check the manual transaxle fluid level and fill plugcondition (if equipped).
l Check the coolant level, hoses and clamps.
l Inspect the exhaust system.Maint enance Service Sc hedule ÒBÓ
86,0 00 km
2004 Car_Minivan Maint Book 7/24/03 12:42 PM Page 66

Maintenance Service
Sc hedule ÒBÓ
Odometer Reading
Date
91,0 00 km
Dealer copy.
Remove and attach to Repair Order 26-92-19-01 3N.
Maint enance Service Sc hedule ÒBÓ
91,0 00 km
l Change engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate, as required, all steering and suspension components.
l Inspect the engine air cleaner filter and replace if necessary (Sebring, Sebring Convertible, Concorde, Intrepid, 300M, Pacifica, and Minivan only).
INSPECT THE FOLLOWING: l Inspect the brake hoses.
l Check the automatic transaxle fluid level.
l Check the manual transaxle fluid level and fill plug condition (if equipped).
l Check the coolant level, hoses and clamps.
l Inspect the exhaust system.
2004 Car_Minivan Maint Book 7/24/03 12:42 PM Page 67

Odometer Reading
Date
Repair Order No.
DAIMLER CHR YSLER
D EALER STAMP
Signature of authorized DaimlerChrysler Canada dealer
l Change engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate, as required, all steering and suspension components.
l Inspect the engine air cleaner filter and replace ifnecessary (Sebring, Sebring Convertible, Concorde,Intrepid, 300M, Pacifica, and Minivan only).
INSPECT THE FOLLOWING: l Inspect the brake hoses.
l Check the automatic transaxle fluid level.
l Check the manual transaxle fluid level and fill plug condition (if equipped).
l Check the coolant level, hoses and clamps.
l Inspect the exhaust system.Maint enance Service Sc hedule ÒBÓ
91,0 00 km
2004 Car_Minivan Maint Book 7/24/03 12:42 PM Page 68

Maintenance Service
Sc hedule ÒBÓ
Odometer Reading
Date
96,0 00 km
Dealer copy.
Remove and attach to Repair Order 26-92-20-01 3N.
Maint enance Service Sc hedule ÒBÓ
96,0 00 km
lChange engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate, as required, all steering and suspension components.
l Replace the engine air cleaner filter, if required (all models).
l Replace the ignition cables (PT Cruiser, SRT-4, Sebring, Sebring Convertible, SX 2.0, and 2.4L Minivan only).lReplace the spark plugs (PT Cruiser, SRT-4, Sebring, Sebring Convertible, SX 2.0, and 2.4L Minivan only).
l Check and replace, if necessary, the PCV valve.
l Inspect and replace, if required, the make-up air filter located inside the air cleaner (PT Cruiser and SX 2.0 only).
l Inspect the serpentine drive belt, replace if necessary (Pacifica and 3.3L/3.8L Minivan only).
l Replace drive belts (Concorde, Intrepid, and 300M only).
l Adjust the generator belt tension (PT Cruiser and SRT-4 only).
l Replace the drive belts (SX 2.0 only).
l Check and retention power steering pump belt (2.4L Minivan only).
l Check the generator belt, replace if necessary (2.4L Minivan only).
l Replace the accessory drive belts (2.7L Sebring, Sebring Convertible only).
l Replace power steering fluid (Concorde, Intrepid, and 300M only).
l Change the all-wheel-drive power transfer unit fluid.*
l Change the automatic transaxle fluid and filter. **
l Replace the air conditioning filter (Pacifica and Minivan, if equipped).
l Rotate tires and check tire pressure.
INSPECT THE FOLLOWING: l Inspect the tie rod ends and boot seals (Pacifica, Minivan, PT Cruiser, SRT-4, and SX 2.0 only).
l Inspect the front and rear brake linings and components (Sebring, Sebring Convertible, PT Cruiser, and SRT-4 only).
l Inspect the brake hoses.
l Check the manual transaxle fluid level and fill plug condition (if equipped).
l Check the coolant level, hoses, and clamps.
l Inspect the exhaust system.
* All-wheel-drive power transfer unit fluid and overrunning clutch/rear carrier fluid must be changed at more frequent intervals than shown in Schedule B if the vehicle is used for trailer tow, taxi, police or other types of commercial service.
** Change the automatic transmission fluid and filter every 96,000 km if the vehicle is used for trailer tow, taxi, police orother types of commercial service.
2004 Car_Minivan Maint Book 7/24/03 12:42 PM Page 69
