CHRYSLER PT CRUISER 2005 1.G Owners Manual

This device complies with part 15 of FCC rules and with
RS-210 of Industry Canada. Operation is subject to the
following conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference that may be
received including interference that may cause undesired
operation.
NOTE:Changes or modifications not expressly ap-
proved by the party responsible for compliance could
void the user’s authority to operate the equipment.
HomeLinkis a trademark owned by Johnson Controls,
Inc.OVERHEAD CONSOLE — IF EQUIPPED
This feature has a compass/temperature display and two
map lamps. The overhead console is located on the
headliner between the sun visors.
Overhead Console
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 111
3

Compass/Temperature Display
This display provides the outside temperature and one of
eight compass readings to indicate the direction the
vehicle is facing.
WARNING!
Even if the display still reads a few degrees above
32°F ( 0°C), the road surface may be icy, particularly
in woods or on bridges. Drive carefully under such
conditions to prevent an accident and possible per-
sonal injury or property damage.
STEP Button Functions:
1. US
2. Metric
3. Off
4. Magnetic Zone Selection
5. Manual Compass Calibration
Step Button
112 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Automatic Compass Calibration
The automatic calibrating feature of the compass elimi-
nates the need to calibrate the compass due to normal
varying conditions.
Compass Variance Selection
Variance is the difference between magnetic North and
geographic North. For proper compass function, the
correct variance zone must be set. Refer to the variance
map for the correct variance zone. To check the variance
zone, the ignition switch must be on and the compass/
temperature displayed. Press and hold the STEP button
for about 5 to 10 seconds until ZONE and the number
appears in the display. The number displayed is the
variance zone used by the compass. To change the zone,
press the STEP button to scroll through numbers 1
through 15.
When the correct variance is selected release the step
button and the Compass/Temperature display will re-
turn to normal after approximately 15 seconds.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 113
3

Manual Compass Calibration
If the compass appears erratic, inaccurate, abnormal or
the vehicle is new, you may calibrate the compass. Prior
to calibrating the compass make sure the proper zone is
selected. Refer to “Magnetic Zone Selection”.Find an
open area away from large metal objects. With the vehicle
running, press and hold the STEP button for (about 10 to
15 seconds). The display will illuminate the CAL indica-
tor. Drive slowly (about 5 mph) in 3 complete 360 circles.
The CAL indicator will turn off and the compass will be
calibrated.
NOTE:
•The compass needs to go through a manual calibration
to insure proper operation when taking vehicle deliv-
ery.
•The STEP button must be pressed for 10 to 15 seconds
to place the compass into CAL mode. Regardless of
whether the CAL indicator is already illuminated.
Outside Temperature
Because engine temperature can increase the displayed
temperature, temperature readings are not updated
when the vehicle is not moving.
If the display shows
49°F (
45°C) or 140°F (60°C), see
your authorized dealer for repair.
POWER SUNROOF — IF EQUIPPED
The power sunroof control is located between the sun
visors on the overhead console.
114 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Press and hold the switch rearward to fully open the
sunroof. The sunroof can be stopped at any position
between closed and full open. Momentarily pressing the
switch rearward will activate the Express Open Feature,
causing the sunroof to open automatically.Press and hold the button in the center of the sunroof
switch to open the vent. The sunroof can be stopped at
any position between closed and full vent. To close the
sunroof from the vent position, press and hold the switch
forward. Releasing the switch will stop the movement of
the sunroof and the sunroof will remain in the partial
vent position until the switch is pushed forward again.
Express Open Feature
During the Express Open operation, any movement of
the switch will stop the sunroof and it will remain in a
partial open position. Again, momentarily pressing the
switch rearward will activate the Express Open Feature.
To close the sunroof, hold the switch in the forward
position. Again, any release of the switch will stop the
movement and the sunroof will remain in a partial open
condition until the switch is pushed forward again.
Power Sunroof Switch
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 115
3

The sunshade can be opened manually. It will also open
as the sunroof opens. The sunshade cannot be closed if
the sunroof is open.
WARNING!
Never leave children in a vehicle, with the keys in
the ignition switch. Occupants, particularly unat-
tended children, can become entrapped by the
power sunroof while operating the power sunroof
switch. Such entrapment may result in serious injury
or death.
WARNING!
In an accident, there is a greater risk of being thrown
from a vehicle with an open sunroof. You could also
be seriously injured or killed. Always fasten your
seat belt properly and make sure all passengers are
properly secured too.
Do not allow small children to operate the sunroof.
Never allow fingers or other body parts, or any
object to project through the sunroof opening. Injury
may result.
116 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Wind Buffeting
Wind buffeting can be described as the perception of
pressure on the ears or a helicopter type sound in the
ears. Your vehicle may exhibit wind buffeting with the
windows down, or the sunroof (if equipped) in certain
open or partially open positions. This is a normal occur-
rence and can be minimized. If the buffeting occurs with
the rear windows open, open the front and rear windows
together to minimize the buffeting. If the buffeting occurs
with the sunroof open, adjust the sunroof opening to
minimize the buffeting or open any window.
Sunroof Maintenance
Use only a non-abrasive cleaner and a soft cloth to clean
the glass panel.
ELECTRICAL POWER OUTLETS
The outlets include tethered caps, labeled with a key
symbol or battery symbol, indicating power source. All
outlets are protected by a single 20 Amp fuse.
The standard outlet in the front of the center floor console
is a conventional cigar lighter outlet.
Power Outlet
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 117
3

It will accept a cigar lighter unit, which is part of the
optional Smokers Package. To preserve the heating ele-
ment of the cigar lighter unit, do not hold the lighter in
the heating position. As a child safety precaution, this
outlet is powered by the ignition switch, only when the
switch is in theONorACCESSORYpositions.
There are two optional power outlets. One is in the
Accessory Switch Bank, in the center of the instrument
panel.
This outlet is powered directly by the battery, regardless
of the ignition switch position. All accessories connected
to this outlet should be removed or turned off when the
vehicle is not in use, to protect the battery against
discharge.
Power Outlet
118 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

The second is in the right rear cargo area.
Since this outlet is remote from the driver, it is powered
by the ignition switch, only when it is in theONor
ACCESSORYpositions, to protect the battery against
discharge. Note: Neither of the power outlets will accept
a cigar lighter unit. They are intended only for accessory
usage.Electrical Outlet Use With Engine Off
CAUTION!
•Many accessories that can be plugged in draw
power from the vehicle’s battery, even when not
in use (i.e. cellular phones, etc.). Eventually, if
plugged in long enough, the vehicle’s battery will
discharge sufficiently to degrade battery life
and/or prevent engine starting.
•Accessories that draw higher power (i.e. coolers,
vacuum cleaners, lights, etc.), will degrade the
battery even more quickly. Only use these inter-
mittently and with greater caution.
•After the use of high power draw accessories, or
long periods of the vehicle not being started (with
accessories still plugged in), the vehicle must be
driven a sufficient length of time to allow the
generator to recharge the vehicle’s battery.
Rear Power Outlet
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 119
3

CONSOLE FEATURES
The console has two front cup holders, a coin holder, 12
volt power outlet and a front storage tray. There are
additional cup holders; one is molded in the center of the
console to hold large cups and the other is at the rear of
the console to serve passengers in the rear seat. The floor
console power outlet will also operate a conventional
cigar lighter unit (if equipped with an optional Smoker’s
Package).
Front Cupholders
120 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
