CHRYSLER PT CRUISER 2005 1.G Owners Manual

Your leather upholstery can be best preserved by regular
cleaning with a damp soft cloth. Small particles of dirt
can act as an abrasive and damage the leather upholstery
and should be removed promptly with a damp cloth.
Stubborn soils can be removed easily with a soft cloth
and Mopar Total Clean. Care should be taken to avoid
soaking your leather upholstery with any liquid. Please
do not use polishes, oils, cleaning fluids, solvents, deter-
gents, or ammonia based cleaners to clean your leather
upholstery. Application of a leather conditioner is not
required to maintain the original condition.
WARNING!
Do not use volatile solvents for cleaning purposes.
Many are potentially flammable, and if used in
closed areas they may cause respiratory harm.
Cleaning Headlights
Your vehicle has plastic headlights that are lighter and
less susceptible to stone breakage than glass headlights.
Plastic is not as scratch resistant as glass and therefore
different lens cleaning procedures must be followed.
To minimize the possibility of scratching the lenses and
reducing light output, avoid wiping with a dry cloth. To
remove road dirt, wash with a mild soap solution fol-
lowed by rinsing.
Do not use abrasive cleaning components, solvents, steel
wool or other aggressive material to clean the lenses.
MAINTAINING YOUR VEHICLE 301
7

Glass Surfaces
All glass surfaces should be cleaned on a regular basis
with any commercial household-type glass cleaner.
Never use an abrasive type cleaner. Use caution when
cleaning inside rear windows equipped with electric
defrosters. Do not use scrapers or other sharp instru-
ments which may scratch the elements.
Instrument Panel Cover
The instrument panel cover has a low glare surface which
minimizes reflections in the windshield. Do not use
protectants or other products which may cause undesir-
able reflections. Use soap and warm water to restore the
low glare surface.
Cleaning Plastic Instrument Cluster Lenses
The lenses in front of the instruments in the vehicle are
molded in clear plastic. When cleaning the lenses, care
must be taken to avoid scratching the plastic.1. Clean with a wet soft rag. A mild soap solution may be
used, but do not use high alcohol content of abrasive
cleaners. If soap is used, wipe clean with a clean damp
rag.
2. Dry with a soft tissue.
Seat Belt Maintenance
Do not bleach, dye or clean the belts with chemical
solvents or abrasive cleaners. This will weaken the fabric.
Sun damage will also weaken the fabric.
If the belts need cleaning, use a mild soap solution or
lukewarm water. Do not remove the belts from the
vehicle to wash them.
Replace the belts if they appear frayed or worn or if the
buckles do not work properly.
302 MAINTAINING YOUR VEHICLE

FUSES
Underhood Fuses (Power Distribution Center)
A Power Distribution Center is located in the engine
compartment; next to the air cleaner filter. A label iden-
tifying the components and circuits is located on the
underside of the cover.
MAXI
FUSEAmp/Color Items Fused
1 30 Amp/Pink Ignition Start
2 40 Amp/Green Anti-Lock Brake (ABS)
Pump
3 40 Amp/Green Ignition Run
4 30 Amp/Pink Heated Seats
5 40 Amp/Green Radiator Fan (Lo Speed
Turbo Only)
6 50 Amp/Red High Speed Radiator Fan
(Turbo Only)
7 30 Amp/Pink Anti-Lock Brake (ABS)
Solenoid
8 40 Amp/Green Electric Back Light (EBL)
9 Spare
10 40 Amp/Green IP Fuseblock
Power Distribution Center Location
MAINTAINING YOUR VEHICLE 303
7

MINI
FUSEAmp/Color Items Fused
11 10 Amp/Red Air Conditioning (A/C)
12 15 Amp/Blue Stop Lights
13 20 Amp/
YellowFuel Pump/Auto Shut
Down (ASD)
14 15 Amp/Blue Horn
15 20 Amp/
YellowElectronic Automatic
Transaxle (ETAX)
16 15 Amp/Blue Hi Beam
17 20 Amp/
YellowIOD
18 15 Amp/Blue Hazard Flasher
19 20 Amp/
YellowPower Outlet
20 Spare
21 20 Amp/
YellowFog Lights (Build-Up Ex-
port Only)22 Spare
Interior Fuses
The fuse access panel is on the left side of the instrument
panel next to the steering column. To remove the panel,
pull it out, as shown. A label identifying the components
and circuits is located on the inside of the cover.
Interior Fuse Panel
304 MAINTAINING YOUR VEHICLE

FUSE Amp/Color Items Fused
1 25 Amp/
NaturalHeadlamp Switch
2 15 Amp/Blue Exterior Lighting
3 20 Amp/
YellowRKE/Door Locks
4 20 Amp/
YellowPower Height Adjust
5 10 Amp/Red Airbag Run Only
6 10 Amp/Red B/U Electric Back Light
(EBL) NEU SAF
7 25 Amp/
NaturalHVAC Blower
8 15 Amp/Blue Fog Lamp (Domestic
Only)
9 10 Amp/Red Airbag Run-ST
10 10 Amp/Red Cluster/RKE/SKIM11 10 Amp/Red Engine Module/ABS-
TRAC
12 10 Amp/Red PDC Relays/LDP
13 10 Amp/Red Interior Lighting
14 20 Amp/
YellowSunroof/Overhead
Console/Radio
15 20 Amp/
YellowWipers/Comb. FLS
16 10 Amp/Red Auto Stick/Ignition Off/
Run
17 15 Amp/Blue Heated Seats
18 10 Amp/Red Heated Mirrors
19 10 Amp/Red Rt Headlamp
20 10 Amp/Red Lt Headlamp
MAINTAINING YOUR VEHICLE 305
7

CAUTION!
When replacing a blown fuse, it is important to use
only a fuse having the correct amperage rating. The
use of a fuse with a rating other than indicated may
result in a dangerous electrical system overload. If a
properly rated fuse continues to blow, it shows a
problem in the circuit that must be corrected.
VEHICLE STORAGE
If you will not be using your vehicle for more than 21
days you may want to take steps to preserve your battery.
You may:
•Disengage the mini fuse in the Power Distribution
Center labeled IOD (Ignition Off-Draw).
•Or, disconnect the negative cable from the battery.
REPLACEMENT BULBS
LIGHT BULBS — Inside Bulb No.
ABS Indicator.......................... LED
Airbag Indicator........................ LED
Brake System Warning Indicator............. LED
Center Console Floor Lamp................. T37
Climate Controls......................6233137
Console Gear Selector...................PC194
Cruise Indicator....................... VFD*
Dome Light............................T579
Door Ajar Indicator..................... VFD*
Front Fog Indicator...................... LED
High Beam Indicator....................... 74
Instrument Cluster Illumination.............. 74
Liftgate Ajar Indicator.................... LED
Low Fuel Indicator....................... LED
Low Oil Pressure Indicator................. LED
306 MAINTAINING YOUR VEHICLE

Overhead Reading Light (Overhead Console). . . T1037
Overhead Reading Light (Rearview Mirror).....T192
Rear Cargo............................T906
Seat Belt Indicator....................... LED
Security Alarm Indicator................... LED
Malfunction Indicator Light................ LED
Temperature Indicator.................... LED
Trac (Active) Indicator................... VFD*
TRAC OFF Indicator..................... LED
Trip Indicator......................... VFD*
Turn Signal Indicator...................... 103
Visor Vanity.........................6501966
Voltage Indicator........................ LED
NOTE:* Vacuum Fluorescent Display
All the inside bulbs are brass or glass wedge base.
Aluminum base bulbs are not approved and should not
be used for replacement.LIGHTS BULBS — Outside Bulb No.
Low Beam Headlight...................9006XS
High Beam Headlight...................9005XS
Front Park/Turn Signal/Side Marker
Light............................4157NAKX
Front Fog Light.........................9006
Center High Mounted Stop Light
(CHMSL).........................921–W16W
Rear Tail/Stop/Turn Signal Light......3157–P27/7W
Backup Light.....................3157-P27/7W
License Light........................... 168
MAINTAINING YOUR VEHICLE 307
7

BULB REPLACEMENT
Headlight Bulb Replacement
CAUTION!
Do not touch the new headlight bulb with your
fingers. Oil contamination will severely shorten
bulb life.
1. Remove the headlight access cover splash shield,
located in the front wheel well opening.
2. Disconnect the electrical connector.3. Rotate the socket to the left one quarter turn and
replace the bulb.
308 MAINTAINING YOUR VEHICLE

Front Park/Turn Signal/Side Marker Lights
1. Remove the headlight access cover splash shield,
located in the front wheel well opening.
2. Rotate the socket to the left one quarter turn to replace
and replace the bulb.
Front Fog Lights — If Equipped
1. Remove the fasteners attaching the lower splash
shield to gain access to the fog light.
2. Twist and remove the bulb from the fog light housing.
3. Disconnect the electrical connector and replace bulb.
Tail/Stop, and Rear Turn Signal Lights
1. Remove the screw attaching the tail light housing and
remove the housing from the vehicle.
MAINTAINING YOUR VEHICLE 309
7

2. Twist the bulb socket 1/4 turn to remove it from the
housing.
3. Pull the bulb out of the socket and replace.Back Up Light Bulb
1. Remove the screws attaching the back up light to the
rear fascia and remove the housing.
2. Remove the socket from the housing.
3. Pull the bulb out of the socket and replace.
Center High Mounted Stop Light
1. Open the liftgate and remove the liftgate CHMSL
cover.
2. Remove CHMSL lens from the housing by unlatching
the two side latches.
3. Pull the bulb out of the socket and replace.
310 MAINTAINING YOUR VEHICLE
