wiper fluid CHRYSLER PT CRUISER 2005 1.G Owners Manual

Satellite Radio — If Equipped..............177
▫System Activation.....................178
▫Electronic Serial Number/Sirius Identification
Number (ENS/SID)....................178
▫Selecting Satellite Mode In RBB, RAH And
RBK Radios.........................179
▫Selecting Satellite Mode In RBP, RBU, RAZ,
RB1 And RBQ Radios..................179
▫Selecting a Channel....................179
▫Storing And Selecting Pre-Set Channels......180
▫Using The PTY (Program Type) Button
(If Equipped)........................180
▫PTY ButtonScan.....................180
▫PTY ButtonSeek.....................180▫Satellite Antenna......................181
▫Reception Quality.....................181

Cassette Tape And Player Maintenance.......181

CD/DVD Disc Maintenance...............182

Radio Operation And Cellular Phones........183

Climate Controls.......................183
▫Air Conditioning.....................183
▫Operating Tips.......................188

Rear Window Features...................190
▫Electric Rear Window Defroster...........190
▫Rear Wiper/Washer Switch..............191
▫Adding Washer Fluid..................192
132 UNDERSTANDING YOUR INSTRUMENT PANEL

▫Air Conditioner Maintenance.............279
▫Power Steering — Fluid Check............280
▫Front Suspension Ball Joints..............280
▫Body Lubrication.....................281
▫Windshield Wiper Blades................281
▫Windshield Washer Reservoir.............282
▫Exhaust System......................283
▫Cooling System.......................284
▫Hoses And Vacuum/Vapor Harnesses.......289
▫Fuel System Connections................289
▫Brake System........................290
▫Automatic Transaxle...................293
▫Manual Transaxle.....................296▫Appearance Care And Protection From
Corrosion...........................297

Fuses...............................303
▫Underhood Fuses (Power Distribution
Center)............................303
▫Interior Fuses........................304

Vehicle Storage........................306

Replacement Bulbs......................306

Bulb Replacement......................308
▫Headlight Bulb Replacement.............308
▫Front Park/Turn Signal/Side Marker Lights . . 309
▫Front Fog Lights — If Equipped...........309
▫Tail/Stop, And Rear Turn Signal Lights......309
▫Back Up Light Bulb....................310
262 MAINTAINING YOUR VEHICLE

Body Lubrication
Locks and all body pivot points, including such items as
seat tracks, doors,liftgate and hood hinges, should be
lubricated periodically to assure quiet, easy operation
and to protect against rust and wear. Prior to the appli-
cation of any lubricant, the parts concerned should be
wiped clean to remove dust and grit; after lubricating
excess oil and grease should be removed. Particular
attention should also be given to hood latching compo-
nents to insure proper function. When performing other
underhood services, the hood latch, release mechanism
and safety catch should be cleaned and lubricated.
The external lock cylinders should be lubricated twice a
year, preferably in the fall and spring. Apply a small
amount of a high quality lubricant such as MoparLock
Cylinder Lubricant directly into the lock cylinder.
Windshield Wiper Blades
Clean the rubber edges of the wiper blades and the
windshield periodically with a sponge or soft cloth and a
mild non abrasive cleaner or use the washer solvent. This
will remove accumulations of salt, waxes or road film
and help reduce streaking and smearing.
Operation of the wipers on dry glass for long periods
may cause deterioration of the wiper blades. Always use
washer fluid when using the wipers to remove salt or dirt
from a dry windshield. Avoid using the wiper blades to
remove frost or ice from the windshield. make sure that
they are not frozen to the glass before turning them on to
avoid damaging the blade. Keep the blade rubber out of
contact with petroleum products such as engine oil,
gasoline, etc.
Windshield Wiper Blade Replacement
1. Lift the wiper arm away from the glass.
MAINTAINING YOUR VEHICLE 281
7

2. Push the release tab shown in the illustration and slide
the wiper blade assembly down along the arm. Gently
place the wiper arm on the windshield.
3. Install the new blade assembly onto the wiper arm tip
until it locks in place.Windshield Washer Reservoir
The washer fluid reservoir is located in the rear of the
engine compartment on the passenger side and should be
checked for fluid level at regular intervals. Fill the
reservoir with windshield washer solvent (not radiator
antifreeze).
Washer Fluid Reservoir
282 MAINTAINING YOUR VEHICLE

Parking Brake.......................... 209
Passing Light........................... 98
Pets.................................. 60
Phone, Cellular.......................... 70
Phone, Hands-Free....................... 70
Placard, Tire and Loading Information......... 221
Power
Distribution Center..................... 303
Door Locks........................... 19
Outlet.............................. 117
Steering..........................213,280
Steering, Checking..................... 280
Sunroof............................. 114
Windows............................. 31
Power Steering Fluid..................... 313
Pregnant Women and Seat Belts.............. 43
Preparation for Jacking.................... 250
Pretensioners
Seat Belts............................. 42Programmable Electronic Features.........106,110
Programming Transmitters............24,106,110
Radial Ply Tires......................... 228
Radio Broadcast Signals................... 144
Radio Operation...................146,163,183
Radio, Satellite.......................... 177
Radio (Sound Systems)...........146,152,163,169
Rear Liftgate............................ 28
Rear Seat, Folding......................87,88
Rear Seat Removal........................ 91
Rear Shelf Panel........................ 122
Rear Window........................... 32
Rear Window Defroster................... 190
Rear Window Features.................... 190
Rear Wiper/Washer...................... 191
Reclining Front Seats...................... 84
Recommended Fluids, Lubricants and Genuine
Parts............................... 312
360 INDEX

Warning, Door Ajar...................... 141
Warning Lights (Instrument Cluster Description) . 137
Warnings and Cautions..................... 6
Warranty Information..................... 343
Washer, Adding Fluid..................... 192
Washer, Rear........................... 191
Washers, Windshield...................... 99
Washing Vehicle......................... 298
Wheel Alignment and Balance............... 232Wheel and Wheel Trim Care................ 299
Wind Buffeting.......................33,117
Window Fogging........................ 189
Windows.............................. 31
Windshield Washers....................98,99
Windshield Wipers.....................98,281
Wiper Blade Replacement.................. 281
Wiper, Rear............................ 191
Wipers, Intermittent...................... 100
INDEX 365
10
