CHRYSLER PT CRUISER 2005 1.G Owners Manual

The Universal Transceiver light will flash slowly and
then rapidly when the programming is successful.
NOTE:When programming such a garage door opener
or gate, unplug the device to prevent possible damage to
the garage door or gate motor.
Operation
Press and hold the desired button on the Universal
Transceiver until the garage door or other device begins
to operate. The light in the display shows that the signal
is being transmitted. The hand held transmitter may also
be used at any time.
Reprogramming A Single Button
1. Press and hold the Universal Transceiver button to be
reprogrammed. Do not release until step 4 has been
completed.2. When the indicator light begins to flash slowly (after
20 seconds) position the hand held transmitter one to
three inches away from the button to be trained.
3. Press and hold the hand held transmitter button.
4. The Universal Transceiver indicator light will begin to
flash, first slowly, then rapidly. When the indicator lights
begin to flash rapidly, release both buttons.
Security
If you sell your vehicle, be sure to erase the frequencies.
To erase all of the previously trained frequencies, hold
down both outside buttons until the indicator light
begins to flash.
This device complies with part 15 of FCC rules and with
RS-210 of Industry Canada. Operation is subject to the
following conditions:
1. This device may not cause harmful interference.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 111
3

2. This device must accept any interference that may be
received including interference that may cause undesired
operation.
NOTE:Changes or modifications not expressly ap-
proved by the party responsible for compliance could
void the user’s authority to operate the equipment.
HomeLinkis a trademark owned by Johnson Controls,
Inc.
ELECTRICAL POWER OUTLETS
These three outlets include tethered caps, labeled with a
key symbol or battery symbol, indicating power source.
All outlets are protected by a single 20 Amp fuse.
The outlet that is located in the front of the center floor
console is a conventional cigar lighter outlet.It will accept a cigar lighter unit, which is part of the
optional Smokers Package. To preserve the heating ele-
ment of the cigar lighter unit, do not hold the lighter in
the heating position. As a child safety precaution, this
outlet is powered by the ignition switch, only when the
switch is in theONorACCESSORYpositions.
Power Outlet
112 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Another of the outlets is in the Accessory Switch Bank, in
the center of the instrument panel.This outlet is powered directly by the battery, regardless
of the ignition switch position. All accessories connected
to this outlet should be removed or turned off when the
vehicle is not in use, to protect the battery against
discharge.
The third outlet is located in the right rear cargo area.
Power Outlet
Rear Power Outlet
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 113
3

Since this outlet is remote from the driver, it is powered
by the ignition switch, only when it is in theONor
ACCESSORYpositions, to protect the battery against
discharge. Note: Neither of the power outlets will accept
a cigar lighter unit. They are intended only for accessory
usage.Electrical Outlet Use With Engine Off
CAUTION!
•Many accessories that can be plugged in draw
power from the vehicle’s battery, even when not
in use (i.e. cellular phones, etc.). Eventually, if
plugged in long enough, the vehicle’s battery will
discharge sufficiently to degrade battery life
and/or prevent engine starting.
•Accessories that draw higher power (i.e. coolers,
vacuum cleaners, lights, etc.), will degrade the
battery even more quickly. Only use these inter-
mittently and with greater caution.
•After the use of high power draw accessories, or
long periods of the vehicle not being started (with
accessories still plugged in), the vehicle must be
driven a sufficient length of time to allow the
generator to recharge the vehicle’s battery.
114 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

CONSOLE FEATURES
The console has two front cup holders, a coin holder, 12
volt power outlet, and front and rear storage trays. There
are additional cup holders; one is molded in the center of
the console to hold large cups and the other is at the rear
of the console to serve passengers in the rear seat. The
floor console power outlet will also operate a conven-
tional cigar lighter unit (if equipped with an optional
Smoker’s Package).
Front Cupholders
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 115
3

CAUTION!
•Many accessories that can be plugged into the 12
volt power outlet, draw power from the vehicle’s
battery, even when not in use; i.e. cellular phones,
etc. Eventually, if plugged in long enough, the
vehicle’s battery will discharge sufficiently to
degrade battery life and/or prevent engine start-
ing.
•Accessories that draw higher power such as cool-
ers, vacuum cleaners, lights, etc., will discharge
the battery even more quickly. Only use these
intermittently and with greater caution.
•After the use of high power draw accessories, or
long periods of the vehicle not being started,
(with accessories still plugged in), the vehicle
must be driven a sufficient length of time to allow
the generator to recharge the vehicle’s battery.
STORAGE
Front Seat Storage Bin
The storage bin is located under the front passenger’s
seat. To openlift up on the handleand pull the storage
binforward.
Front Seat Storage Bin
116 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Storage Pockets
There are also Storage pockets located on each door trim
panel.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 117
3

UNDERSTANDING YOUR INSTRUMENT PANEL
CONTENTS

Instrument Panel Features.................123

Instrument Cluster......................124

Instrument Cluster—Turbo, With AutoStick....125

Instrument Cluster—Turbo, Without AutoStick . . 126

Instrument Cluster Descriptions............127

Electronic Digital Clock..................134
▫Clock Setting Procedure.................134

Radio General Information................135
▫Radio Broadcast Signals.................135▫Two Types Of Signals..................135
▫Electrical Disturbances..................135
▫AM Reception.......................135
▫FM Reception........................135

Sales Code RAZ—AM/ FM Stereo Radio With
Cassette Tape Player, CD Player And CD Changer
Controls.............................136
▫Operating Instructions—Radio...........136
▫Power Switch, Volume Control............136
▫Seek Button (Radio Mode)...............1364

▫Tuning.............................137
▫Radio Data System (RDS)...............137
▫PTY (Program Type) Button..............137
▫Balance............................139
▫Fade..............................139
▫Tone Control........................139
▫AM/FM Selection.....................139
▫Scan Button.........................139
▫To Set The Radio Push-Button Memory......140
▫To Change From Clock To Radio Mode......140
▫Operating Instructions—Tape Player.......140
▫Seek Button.........................140
▫Fast Forward (FF).....................141▫Rewind (RW)........................141
▫Tape Eject...........................141
▫Scan Button.........................141
▫Changing Tape Direction................141
▫Metal Tape Selection...................141
▫Pinch Roller Release...................142
▫Noise Reduction......................142
▫Operating Instructions—CD Player........142
▫Inserting The Compact Disc..............142
▫Seek Button.........................143
▫EJT CD (Eject) Button..................143
▫FF/Tune/RW........................144
▫Program Button 4 (Random Play)..........144
120 UNDERSTANDING YOUR INSTRUMENT PANEL
