CAUTION!
When replacing a blown fuse, it is important to use
only a fuse having the correct amperage rating. The
use of a fuse with a rating other than indicated may
result in a dangerous electrical system overload. If a
properly rated fuse continues to blow, it shows a
problem in the circuit that must be corrected.
VEHICLE STORAGE
If you will not be using your vehicle for more than 21
days you may want to take steps to preserve your battery.
You may:
•Disengage the mini fuse in the Power Distribution
Center labeled IOD (Ignition Off-Draw).
•Or, disconnect the negative cable from the battery.
REPLACEMENT BULBS
LIGHT BULBS—Inside Bulb No.
ABS Indicator.......................... LED
Airbag Indicator........................ LED
Brake System Warning Indicator............. LED
Center Console Floor Lamp................. T37
Climate Controls......................6233137
Console Gear Selector...................PC194
Cruise Indicator....................... VFD*
Deck Lid Ajar Indicator................... LED
Dome Light (Sport Bar Lights)..............T904
Door Ajar Indicator..................... VFD*
Front Fog Indicator...................... LED
High Beam Indicator....................... 74
Instrument Cluster Illumination.............. 74
Low Fuel Indicator....................... LED
Low Oil Pressure Indicator................. LED
Overhead Reading Light (Rearview Mirror).....T192
MAINTAINING YOUR VEHICLE 297
7

High Beam.........................97,129
High Beam/Low Beam Select Switch......... 97
Passing.............................. 97
Switch............................... 96
Heated Seats............................ 86
Homelink Transmitter.................... 106
Hood Release........................... 93
Hoses................................ 277
Ignition............................... 12
Key ................................. 12
Wiring System........................ 262
Immobilizer..........................14,26
Indicator, Traction Control...............131,132
Infant Restraint.......................... 50
Inside Rearview Mirror.................... 75
Instrument Cluster....................124,127
Instrument Panel and Controls.............. 123
Instrument Panel Cover................... 289Instrument Panel Lens Cleaning............. 289
Integrated Power Module.................. 292
Interior Appearance Care.................. 288
Interior Fuses.......................... 295
Interior Lights........................... 94
Intermittent Wipers....................... 99
Introduction............................. 4
Jack Location........................... 235
Jack Operation.......................235,238
Jump Starting.......................... 240
Key, Programming........................ 16
Key Release Button....................... 13
Key, Replacement........................ 16
Key, Sentry............................. 14
Key-In Reminder......................... 14
Keyless Entry System...................... 21
Keys................................. 12
