clock CHRYSLER PT CRUISER 2005 1.G User Guide

SALES CODE RBK—AM/ FM STEREO RADIO
WITH CD PLAYER AND CD CHANGER
CONTROLSRadio Operation
Power/Volume Control
Press the ON/VOL control to turn the radio on. Turn the
volume control clockwise to increase the volume.
NOTE:Power to operate the radio is supplied through
the ignition switch. It must be in the ON or ACC position
to operate the radio.
Seek
Press and release the SEEK button to search for the next
station in either the AM or FM mode. Press the top of the
button to seek up and the bottom to seek down. The
radio will remain tuned to the new station until you
make another selection. Holding the button in will by-
pass stations without stopping until you release it.
Tune
Press the TUNE control up or down to increase or
decrease the frequency. If you press and hold the button,
RBK Radio
UNDERSTANDING YOUR INSTRUMENT PANEL 153
4

Radio Operation
Power/Volume Control
Press the PWR/VOL control to turn the radio on. Turn
the volume control clockwise to increase the volume.
NOTE:Power to operate the radio is controlled by the
ignition switch. It must be in the ON or ACC position to
operate the radio.
Mode
Press the MODE button repeatedly to select between AM,
FM, the CD changer and Sirius Satellite Radio™(if
equipped). The display will show ST when a stereo
station is received.
To select Sirius Satellite Radio™(if equipped), press the
MODE button until the word SIRIUS appears. The fol-
lowing will be displayed in this order: After three sec-
onds, the current channel name and number will be
displayed for five seconds. The current program type andchannel number will then be displayed for five seconds.
The current channel name and number will then be
displayed until an action occurs. CD’s may remain in the
player while in the Satellite Radio mode.
Seek
Press and release the SEEK button to search for the next
station in either the AM or FM mode. Press the top of the
button to seek up and the bottom to seek down. The
radio will remain tuned to the new station until you
make another selection. Holding the button in will by-
pass stations without stopping until you release it.
Tune
Press the TUNE control up or down to increase or
decrease the frequency. If the button is pressed and held,
the radio will continue to tune until the button is
released. The frequency will be displayed and continu-
ously updated while the button is pressed.
160 UNDERSTANDING YOUR INSTRUMENT PANEL

CONVERTIBLE TOP MANUAL OVERRIDE
If your vehicle is experiencing electrical failure (low
battery, etc.) and it is necessary to raise the convertible
top, perform the following steps:
1. Locate the convertible top motor bleeder screw, which
is found in the trunk under the convertible top storage
area.
2. Turn the screw counterclockwise until the screw stops.
This will relieve the hydraulic pressure and allow the
convertible top to be raised manually.
3. Using the latch handle raise the top until the two pins
seat themselves in the windshield header.
4. Rotate the latch handle clockwise to open the latches.
Bleeder Screw
WHAT TO DO IN EMERGENCIES 247
6

5. Pull down and rotate the handle counterclockwise to
engage the latches.6. Raise the handle into the stowed position.
7. Close the convertible top motor bleeder screw by
turning the screw clockwise until it stops.
Engaging Convertible Top
248 WHAT TO DO IN EMERGENCIES

Cellular Phone.......................... 168
Center High Mounted Stop Light............ 301
Central Door Locks....................... 20
Chains, Tire............................ 219
Changing A Flat Tire..................... 235
Chart, Tire Sizing........................ 203
Check Engine Light (Malfunction Indicator Light) . 255
Child Restraint.......................... 49
Child Restraint Tether Anchors............... 53
Child Seat.............................. 54
Clean Air Gasoline....................... 222
Climate Control......................... 169
Clock................................ 134
Coin Holder........................... 115
Compact Disc Maintenance................. 168
Compact Disc Player..................136,142
Compact Spare Tire...................... 214
Compass.............................. 75
Compass Calibration...................... 78Compass Variance........................ 77
Console............................... 115
Contract, Service........................ 332
Convertible............................. 62
Convertible Boot.......................68,72
Convertible Top.......................... 62
Convertible Top Maintenance............... 290
Convertible Top Manual Override..........73,247
Cool Down, Turbo....................... 184
Coolant............................302,303
Coolant Pressure Cap..................... 275
Cooling System......................... 272
Adding Coolant (Antifreeze).............. 274
Coolant Level......................272,275
Disposal of Used Coolant................ 275
Drain, Flush, and Refill.................. 273
Inspection........................... 275
Points to Remember.................... 276
Pressure Cap......................... 275
342 INDEX

Seat Belts.............................. 30
And Pregnant Women................... 39
Child Restraint......................... 49
Cleaning............................ 290
Front Seat............................ 31
Pretensioners.......................... 39
Rear Seat............................. 31
Reminder............................ 129
Untwisting Procedure.................... 37
Seats................................. 80
Adjustment........................... 80
Head Restraints........................ 85
Heated.............................. 86
Height Adjustment...................... 81
Rear Folding........................87,88
Reclining............................. 82
Seatback Release.....................82,83
Tilting.............................82,83
Security Alarm (Theft Alarm)................ 25Sentry Key...........................14,26
Sentry Key Programming................... 16
Service and Maintenance.................. 306
Service Assistance....................330,331
Service Contract......................... 332
Service Manuals........................ 336
Setting the Clock........................ 134
Severe Service.......................... 309
Shift Speeds, Manual Transaxle.............. 194
Shoulder Belts........................... 31
Side Airbag............................. 46
Side Window Demisters................... 176
Slippery Surfaces, Driving On............... 243
Snow Tires............................ 219
Spare Tire.......................214,215,236
Spark Plugs............................ 262
Speed Control.......................103,132
Speedometer........................... 129
Speedometer and Odometer................ 124
INDEX 351
10
