Page 64 of 360
1. Turn the ignition key to the ON position.
2. Release the top from the windshield header by pulling
down on the latch handle and turning the latch handle
clockwise until it stops.3. Press the Power Top Switch to disengage the top pins
from the header, turn the handle counterclockwise and
raise the handle to the stowed position.
NOTE:The Power Top Switch has two detent positions
for lowering the convertible top. Pressing and holding
the Power Top Switch lightly in the first detent position
will lower the windows slightly and the convertible top
to the full down position. Pressing and holding the
switch in the second detent position will lower all four
windows completely and the top to the full down posi-
tion.
Releasing Convertible Top Latches
64 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
Page 66 of 360
To Raise The Top:
CAUTION!
To avoid damage to the convertible top or its com-
ponents, your vehicle is equipped with a feature that
prevents convertible top operation at speeds over 10
mph (16 km/h).
CAUTION!
To fully insure that no damage occurs, be sure that
the vehicle is at a complete stop with the gear
selector in the Park position (automatic transaxle) or
in the Neutral position (manual transaxle) before
lowering or raising the top.
1. Remove the convertible top boot cover, if equipped.
Refer to Convertible Top Boot Cover Removal and Stor-
age, in this section.
2. Turn the ignition to the ON position.
3. Press the Power Top Switch to raise the top. Before the
top reaches the windshield, open the latch handle and
turn the handle clockwise to open the latches. Press the
switch again to continue raising the top until the two pins
seat themselves in the windshield header.
NOTE:If the top is not latched right away, it may be
necessary to press the power top switch,“UP”or
“DOWN”quickly, to align the pins to the windshield
header.
4. Pull down on the latch handle and rotate it counter-
clockwise to engage the latches.
66 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
Page 74 of 360
2. Turn the screw counterclockwise until the screw stops.
This will relieve the hydraulic pressure and allow the
convertible top to be raised manually.
3. Using the latch handle raise the top until the two pins
seat themselves in the windshield header.
4. Rotate the latch handle clockwise to open the latches.5. Pull down and rotate the handle counterclockwise to
engage the latches.
6. Raise the handle into the stowed position.
7. Close the convertible top motor bleeder screw by
turning the screw clockwise until it stops.
Bleeder Screw
Engaging Convertible Top Latches
74 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
Page 75 of 360
MIRRORS
Inside Compass/Temperature Mirror
This manual day-night inside rearview mirror has an
integrated compass and outside temperature display,
along with dual map/courtesy lamps with switches for
independent operation. These lamps also turn on to-
gether with the dome lamp.
Adjust the mirror to center the view through the rear
window. A two point pivot system allows for horizontal
and vertical mirror adjustments.
Annoying headlight glare can be reduced by rotating the
small knob under the mirror in the clockwise direction,
so the knob points to the right (night position). The
mirror should be adjusted while set in the day position
(knob points towards rear of vehicle.)
Adjusting Rear View Mirror
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 75
3
Page 99 of 360
CAUTION!
In cold weather, always turn off the wiper switch
and allow the wipers to return to the park position
before turning off the engine. If the wiper switch is
left on and the wipers freeze to the windshield,
damage to the wiper motor may occur when the
vehicle is restarted.
Windshield Wiper Operation
Move the lever upward to the second detent for Low
speed wiper operation, or to the third detent for High
speed operation.
Intermittent Wiper System
Use the intermittent wiper when weather conditions
make a single wiping cycle, with a variable pause be-
tween cycles, desirable. Move the lever to the DEL
position, then select the delay interval by turning the end
of the lever. Rotate the knob upward (clockwise) to
decrease the delay time and downward (counterclock-
wise) to increase the delay time. The delay can be
regulated from a maximum of approximately 18 seconds
between cycles, to a cycle every second.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 99
3
Page 119 of 360
UNDERSTANDING YOUR INSTRUMENT PANEL
CONTENTS
Instrument Panel Features.................123
Instrument Cluster......................124
Instrument Cluster—Turbo, With AutoStick....125
Instrument Cluster—Turbo, Without AutoStick . . 126
Instrument Cluster Descriptions............127
Electronic Digital Clock..................134
▫Clock Setting Procedure.................134
Radio General Information................135
▫Radio Broadcast Signals.................135▫Two Types Of Signals..................135
▫Electrical Disturbances..................135
▫AM Reception.......................135
▫FM Reception........................135
Sales Code RAZ—AM/ FM Stereo Radio With
Cassette Tape Player, CD Player And CD Changer
Controls.............................136
▫Operating Instructions—Radio...........136
▫Power Switch, Volume Control............136
▫Seek Button (Radio Mode)...............1364
Page 120 of 360
▫Tuning.............................137
▫Radio Data System (RDS)...............137
▫PTY (Program Type) Button..............137
▫Balance............................139
▫Fade..............................139
▫Tone Control........................139
▫AM/FM Selection.....................139
▫Scan Button.........................139
▫To Set The Radio Push-Button Memory......140
▫To Change From Clock To Radio Mode......140
▫Operating Instructions—Tape Player.......140
▫Seek Button.........................140
▫Fast Forward (FF).....................141▫Rewind (RW)........................141
▫Tape Eject...........................141
▫Scan Button.........................141
▫Changing Tape Direction................141
▫Metal Tape Selection...................141
▫Pinch Roller Release...................142
▫Noise Reduction......................142
▫Operating Instructions—CD Player........142
▫Inserting The Compact Disc..............142
▫Seek Button.........................143
▫EJT CD (Eject) Button..................143
▫FF/Tune/RW........................144
▫Program Button 4 (Random Play)..........144
120 UNDERSTANDING YOUR INSTRUMENT PANEL
Page 134 of 360
25. AutoStick Gear Position—If Equipped
This vacuum fluorescent display indicator illuminates
when the gearshift lever is moved to the AutoStick
position and shows the current gear selection.
26. Fuel Door Reminder
This symbol is a reminder that the Fuel Filler Door is
located on the front passenger’s (right) side of the vehicle.
27. Odometer/Trip Odometer Reset Knob
Press the knob to switch between the odometer and trip
odometer. While the trip odometer is being displayed,
press and hold this knob for a few seconds to reset the
trip odometer to zero miles/kilometers.ELECTRONIC DIGITAL CLOCK
The clock and radio each use the display panel built into
the radio. A digital readout shows the time in hours and
minutes whenever the ignition switch is in the ON or
ACC position and the time button is pressed.
When the ignition switch is in the OFF position, or when
the radio frequency is being displayed, time keeping is
accurately maintained.
Clock Setting Procedure
1. Turn the ignition switch to the ON or ACC position
and press the time button. Using the tip of a ballpoint pen
or similar object, press either the hour (H) or minute (M)
buttons on the radio.
2. Press the H button to set hours or the M button to set
minutes. The time setting will increase each time you
press a button.
134 UNDERSTANDING YOUR INSTRUMENT PANEL
Page 136 of 360
remain active for up to 45 seconds after the ignition
switch has been turned off. Opening a vehicle front door
will cancel this feature.
SALES CODE RAZ—AM/ FM STEREO RADIO
WITH CASSETTE TAPE PLAYER, CD PLAYER
AND CD CHANGER CONTROLSOperating Instructions—Radio
NOTE:Power to operate the radio is controlled by the
ignition switch. It must be in the ON or ACC position to
operate the radio.
Power Switch, Volume Control
Press the ON/VOL control to turn the radio on. Turn the
volume control clockwise to increase the volume. The
volume will be displayed and continuously updated
while the button is pressed.
Seek Button (Radio Mode)
Press and release the Seek button to search for the next
station in either the AM or FM mode. Press the top of the
button to seek up and the bottom to seek down. Holding
the button will by pass stations until you release the
button.
RAZ Radio
136 UNDERSTANDING YOUR INSTRUMENT PANEL
Page 140 of 360
To Set The Radio Push-button Memory
When you are receiving a station that you wish to
commit to push-button memory, press the SET button.
SET 1 will show in the display window. Select the
push-button you wish to lock onto this station and press
and release that button. If a station is not selected within
5 seconds after pressing the SET button, the station will
continue to play but will not be locked into push-button
memory.
You may add a second station to each push-button by
repeating the above procedure with this exception: Press
the SET button twice and SET 2 will show in the display
window. Each button can be set for SET 1 and SET 2 in
both AM and FM. This allows a total of 10 AM and 10 FM
stations to be locked into memory. You can recall the
stations stored in SET 2 memory by pressing the push-
button twice.
To Change From Clock To Radio Mode
Press the Time button to change the display between
radio frequency and time.
Operating Instructions—Tape Player
Insert the cassette with the exposed tape side toward the
right and the mechanical action of the player will gently
pull the cassette into the play position.
NOTE:When subjected to extremely cold temperatures,
the tape mechanism may require a few minutes to warm
up for proper operation. Sometimes poor playback may
be experienced due to a defective cassette tape. Clean and
demagnetize the tape heads at least twice a year.
Seek Button
Press the SEEK button up for the next selection on the
tape and down to return to the beginning of the current
selection.
140 UNDERSTANDING YOUR INSTRUMENT PANEL
