Page 75 of 360
MIRRORS
Inside Compass/Temperature Mirror
This manual day-night inside rearview mirror has an
integrated compass and outside temperature display,
along with dual map/courtesy lamps with switches for
independent operation. These lamps also turn on to-
gether with the dome lamp.
Adjust the mirror to center the view through the rear
window. A two point pivot system allows for horizontal
and vertical mirror adjustments.
Annoying headlight glare can be reduced by rotating the
small knob under the mirror in the clockwise direction,
so the knob points to the right (night position). The
mirror should be adjusted while set in the day position
(knob points towards rear of vehicle.)
Adjusting Rear View Mirror
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 75
3
Page 76 of 360
Lights
•
Briefly press the“Right”button to toggle the right
reading lamp“ON/OFF”. Repeat the key press to
cycle the light.
•Briefly press the“Left”button to toggle the left
reading lamp“ON/OFF”. Repeat the key press to
cycle the light.
NOTE:The light can be activated with the ignition off.
NOTE:The light(s) will automatically shut off after
seven minutes with ignition off.
Temperature
Press and hold the“Right”button for 5–10 seconds (until
°F/°C toggles in the display) then release the button.
Repeat the key press to cycle the°F/°C in the display.
Display ON/OFF
Press and hold the“Right”button for 10–15 seconds
(until display toggles ON/OFF) then release the button.
Repeat the key press to cycle the display ON/OFF.
NOTE:The display will default“ON”at each new
ignition cycle.
76 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
Page 77 of 360
Compass Variance
•
Find your current location and determine the correct
Zone number from the map.
•Press and hold the“Left”button for 5–10 seconds
(until“Zone”appears in the display), then release the
button. The number displayed is the current Zone
value.
•If a new Zone value is desired, briefly press the“Left”
button to increment the displayed value, (Range 1–15)
until you find your desired Zone number.
•No button activity for 4–5 seconds ends the Zone entry
mode. The display will return to normal operation and
the new Zone number will be set.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 77
3
Page 78 of 360
Compass Calibration
If“CAL”is not displayed, press and hold the“Left”
button for 10–15 seconds, until“CAL”appears in the
display, then release the button. The compass is now in
calibration mode.
The mirror can be calibrated in one of two ways
•
Drive the vehicle in circles at less then 5mph (8 km/h)
until“CAL”no longer appears in the display.
•Drive the vehicle under normal operating conditions.
Outside Mirror—Driver’s Side
Adjust the outside mirror to center on the adjacent lane of
traffic, with a slight overlap of the view obtained on the
inside mirror.
Outside Mirror—Passenger’s Side
Adjust the convex outside mirror so you can just see the
side of your vehicle in the part of the mirror closest to the
vehicle.
WARNING!
Vehicles and other objects seen in the passenger side
convex mirror will look smaller and farther away
than they really are. Relying too much on your
passenger side mirror could cause you to collide
with another vehicle or other object. Use your inside
mirror when judging the size or distance of a vehicle
seen in this convex mirror.
78 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
Page 111 of 360
The Universal Transceiver light will flash slowly and
then rapidly when the programming is successful.
NOTE:When programming such a garage door opener
or gate, unplug the device to prevent possible damage to
the garage door or gate motor.
Operation
Press and hold the desired button on the Universal
Transceiver until the garage door or other device begins
to operate. The light in the display shows that the signal
is being transmitted. The hand held transmitter may also
be used at any time.
Reprogramming A Single Button
1. Press and hold the Universal Transceiver button to be
reprogrammed. Do not release until step 4 has been
completed.2. When the indicator light begins to flash slowly (after
20 seconds) position the hand held transmitter one to
three inches away from the button to be trained.
3. Press and hold the hand held transmitter button.
4. The Universal Transceiver indicator light will begin to
flash, first slowly, then rapidly. When the indicator lights
begin to flash rapidly, release both buttons.
Security
If you sell your vehicle, be sure to erase the frequencies.
To erase all of the previously trained frequencies, hold
down both outside buttons until the indicator light
begins to flash.
This device complies with part 15 of FCC rules and with
RS-210 of Industry Canada. Operation is subject to the
following conditions:
1. This device may not cause harmful interference.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 111
3
Page 121 of 360
▫Mode..............................144
▫Tape CD Button......................144
▫Time Button.........................145
▫Scan Button.........................145
▫CD Changer Control Capability
—If Equipped.......................145
Sales Code RBB—AM/FM Stereo Radio With
Cassette Tape Player And CD Changer
Capability............................146
▫Operating Instructions..................147
▫Power Button........................147
▫Electronic Volume Control...............147
▫Seek..............................147
▫Tune ..............................148▫To Set The Push-Button Memory..........148
▫Balance............................148
▫Fade..............................148
▫Bass And Treble Tone Control............149
▫AM/FM Selection.....................149
▫Mode Button........................149
▫Cassette Player Features................149
▫CD Changer Control Capability
—If Equipped.......................151
▫Radio Display Messages................152
Sales Code RBK—AM/ FM Stereo Radio With
CD Player And CD Changer Controls........153
▫Radio Operation......................153
▫CD Player Operation...................155
UNDERSTANDING YOUR INSTRUMENT PANEL 121
4
Page 122 of 360
▫CD Changer Control Capability
—If Equipped.......................157
▫Radio Display Messages................158
Sales Code RBQ—AM/FM Stereo Radio With
6 - Disc CD Changer....................159
▫Radio Operation......................160
▫CD Player Operation...................162
Sales Code RB1—AM/FM Stereo Radio With
DVD/GPS Navigation System..............166Cassette Tape And Player Maintenance.......167
CD/DVD Disc Maintenance...............168
Radio Operation And Cellular Phones........168
Climate Controls.......................169
▫Air Conditioning.....................169
▫Operating Tips.......................174
Electric Rear Window Defroster.............176
122 UNDERSTANDING YOUR INSTRUMENT PANEL
Page 131 of 360
The light will also come on when the parking brake is
applied with the ignition switch in the ON position.
NOTE:This light shows only that the parking brake is
applied. It does not show the degree of brake application.
If the parking brake is off and the light remains on, have
the brake system inspected as soon as possible.
15. Trac Indicator—If Equipped
The TRAC Light will come on momentarily as a bulb
check when the ignition switch is first turned ON.
The light will flash when the Traction Control System is
controlling traction.
16. Door Ajar Indicator
This vacuum fluorescent display indicator illuminates
the word“DOOR”, when a door is not completely closed.
If the door is open for more than 8 minutes, the light will
turn off.17. Odometer/Trip Odometer
The odometer shows the total distance the vehicle has
been driven. The trip odometer shows the trip distance
since the last reset.
U.S. Federal regulations require that upon transfer of
vehicle ownership, the seller certify to the purchaser the
correct mileage that the vehicle has been driven. There-
fore, if the odometer reading changes during repair or
replacement, be sure to keep a record of the reading
before and after the service so the correct mileage can be
determined.
18. Trip Indicator
This vacuum fluorescent display indicator will illuminate
when the Trip Odometer is in use.
By pushing the trip button, located next to the instrument
cluster, the odometer will toggle between total distance
UNDERSTANDING YOUR INSTRUMENT PANEL 131
4
Page 134 of 360
25. AutoStick Gear Position—If Equipped
This vacuum fluorescent display indicator illuminates
when the gearshift lever is moved to the AutoStick
position and shows the current gear selection.
26. Fuel Door Reminder
This symbol is a reminder that the Fuel Filler Door is
located on the front passenger’s (right) side of the vehicle.
27. Odometer/Trip Odometer Reset Knob
Press the knob to switch between the odometer and trip
odometer. While the trip odometer is being displayed,
press and hold this knob for a few seconds to reset the
trip odometer to zero miles/kilometers.ELECTRONIC DIGITAL CLOCK
The clock and radio each use the display panel built into
the radio. A digital readout shows the time in hours and
minutes whenever the ignition switch is in the ON or
ACC position and the time button is pressed.
When the ignition switch is in the OFF position, or when
the radio frequency is being displayed, time keeping is
accurately maintained.
Clock Setting Procedure
1. Turn the ignition switch to the ON or ACC position
and press the time button. Using the tip of a ballpoint pen
or similar object, press either the hour (H) or minute (M)
buttons on the radio.
2. Press the H button to set hours or the M button to set
minutes. The time setting will increase each time you
press a button.
134 UNDERSTANDING YOUR INSTRUMENT PANEL
Page 136 of 360
remain active for up to 45 seconds after the ignition
switch has been turned off. Opening a vehicle front door
will cancel this feature.
SALES CODE RAZ—AM/ FM STEREO RADIO
WITH CASSETTE TAPE PLAYER, CD PLAYER
AND CD CHANGER CONTROLSOperating Instructions—Radio
NOTE:Power to operate the radio is controlled by the
ignition switch. It must be in the ON or ACC position to
operate the radio.
Power Switch, Volume Control
Press the ON/VOL control to turn the radio on. Turn the
volume control clockwise to increase the volume. The
volume will be displayed and continuously updated
while the button is pressed.
Seek Button (Radio Mode)
Press and release the Seek button to search for the next
station in either the AM or FM mode. Press the top of the
button to seek up and the bottom to seek down. Holding
the button will by pass stations until you release the
button.
RAZ Radio
136 UNDERSTANDING YOUR INSTRUMENT PANEL
