To return the rear seat to it’s upright latched position,
rotate the seat cushion rearward to latch the seat. Then
lift the seatback to its upright latched position.
NOTE:The elastic strap should be reinstalled in the clip
on the base of the seat cushion before returning the seat
to its normal position.
Tumbling Rear Seat (Convertible)
To provide additional storage area, each rear seat can be
tumbled forward.
CAUTION!
It is important that the front seats be pulled forward
to the midpoint of the seat track to avoid contact
between the rear seat and the front seatback. If the
front seat is not pulled forward the two seats will
make contact during the tumbling motion and cause
damage to the rear seat material. After the rear seat is
tumbled forward and secured the front seat can then
be repositioned to the preferred position.
To tumble the seat forward use the following procedure:
1. The seat back release knobs are located in the trunk
area. Pull the left side seatback release knob to fold down
Tumbling Seat Strap
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 171
3

the left side seatback. Pull the right side seatback release
knob to fold down the right side seatback.2. From inside the vehicle, fold the rear seat back down
flat.
Folding Rear Seat Release Knobs
Folding Rear Seat Back
172 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

3. Pull the release handle located at the bottom of the
folded seat back and tumble the seat forward.4. Attach the cinching tether strap, located at the side of
the seat cushion, onto the hook bar on the center trim
panel and tighten by pulling the cinching strap until the
seat is secure.
Tumbling Rear Seat
Cinching Tether Strap
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 173
3

To return the tumbling rear seat to the latched (normal)
position use the following procedure:
1. Loosen the strap by pushing rearward on the cinching
tether strap buckle.
2. Disconnect the cinching tether strap.NOTE:The strap should be reinstalled in the side
pocket on the seat cushion before returning the seat to the
latched (normal) position.
NOTE:Prior to rotating the seat cushions rearward, be
sure that the rear seat belt buckles are secured with the
straps, so that the buckles are accessible.
Releasing Cinching Tether Strap
Rear Seat Belt Buckle Straps
174 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

NOTE:Prior to lifting either seatback to the upright
position, be sure that the seat belt is brought forward to
avoid trapping it behind the seatback.
3. Rotate the seat cushion rearward to latch the seat.
Then lift the seatback to its upright latched position.
WARNING!
In an accident, you or others in your vehicle could be
injured if seats are not properly latched to their
attachments. Always be sure the seats are fully
latched.
Rear Seat Removal (Sedan)
The rear seats can be removed to provide more cargo
space.
•Push and hold the button on the seatback and fold
down the rear seatback.
Folding Rear Seat Button
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 175
3

•Pull the release lever located on the outboard side of
the seat. Lift up the seat and tumble the seat forward.
•Lift up the release levers to disengage the seat from the
floor attachments.
•Using the handle on the seat, the seat assembly can
now be lifted and removed from the vehicle.
NOTE:Small rollers on the bottom of the folded seat
and a handle at the top allow the seat to be easily moved
when removed from the vehicle.
Tumbling Seat Release Strap
Release Lever Location
176 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

To reinstall the rear seat, insert the seat into the floor
attachments. Lower the release levers of the seat to latch
the front floor attachments and rotate the seat rearward
to latch the seat. Lift the seat back to its upright latched
position.
WARNING!
In an accident, you or others in your vehicle could be
injured if seats are not properly latched to their floor
attachments. Always be sure the seats are fully
latched.
TO OPEN AND CLOSE THE HOOD
To open the hood, two latches must be released. First pull
the hood release lever located under the left side of the
instrument panel.
Hood Release Lever
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 177
3

Then move the safety catch located under the front edge
of the hood, near the center and slightly to the right, and
raise the hood.
Use the hood prop rod clipped to the driver’s side of the
engine compartment to secure the hood in the open
position. Place the hood prop at the location stamped into
the inner hood surface.
To prevent possible damage, do not slam the hood to
close it. Lower the hood until it is open approximately 20
cm (8 inches) and then drop it. This should secure both
latches. Never drive your vehicle unless the hood is fully
closed, with both latches engaged.WARNING!
If the hood is not fully latched it could fly up when
the vehicle is moving and block your forward vision.
You could have a collision. Be sure all hood latches
are fully latched before driving.
LIGHTS
Map/Reading Lights (Sedan)
These lights are mounted between the sun visors above
the rear view mirror. Each light is turned ON by pressing
the button. Press the button a second time to turn the
light OFF. The lights also come on when a door is opened
or the dimmer control is turned fully upward, past the
second detent.
178 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

NOTE:The lights will remain on until the switch is
pressed a second time, so be sure they have been turned
off before leaving the vehicle. They will not turn off
automatically.
Map/Reading Lights (Convertible)
When the ignition switch is in the ON position, these
lights, located under the rearview mirror can be turned
on by switches located at the base of the rearview mirror.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 179
3

NOTE:The lights will remain on until the switch is
pressed a second time, so be sure they have been turned
off before leaving the vehicle. They will not turn off
automatically.
Interior Lights
The interior lights come on when a door or deck lid
(convertible) is opened.
With the ignition key in the OFF position, the interior
lights will automatically turn off in about 10 minutes if a
door is left open or the dimmer control is left in the Dome
light position. The interior lights will remain on for only
90 seconds for all occurrences after that, until the engine
is turned on and off.
Dimmer Control
With the parking lights or headlights
on, rotating the dimmer control for the
interior lights on the Multi-Function
Control Lever upward will increase
the brightness of the instrument panel
lights.
Dome Light Position
Rotate the dimmer control completely
upward to the second detent to turn
on the interior lights. The interior
lights will remain on when the dim-
mer control is in this position. With the
ignition key in the OFF position, the
interior lights will automatically turn
off in about 10 minutes if the dimmer
