2. Twist the knob on the underside of the panel and
lower the shelf leg.
3. Install the shelf leg into the liftgate latch area as
labeled on the rear scuff plate.
WARNING!
Do not load objects over 100 lbs (45 kg) in position 5
(table). Failure to follow this warning could cause
the shelf to collapse resulting in personal injury.
Rear Shelf Leg Release Knob
Rear Shelf Panel Position 5
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 211
3

ROOF LUGGAGE RACK — IF EQUIPPED
The crossbars and siderails are designed to carry the
weight on vehicles equipped with a luggage rack. The
load must not exceed 150 lbs (68 kg), and should be
uniformly distributed over the luggage rack crossbars.
Use both adjustable crossbars assemblies to support the
load and distribute the load as evenly as possible.
To adjust the crossbars with latch style releases, release
the latches on the inboard side of the crossbar supports
on each side of the vehicle, then move the crossbars to the
desired position. Once the crossbar is in the desired
position, return both latches to the locked position.
To adjust the crossbars with botton style releases, depress
the button and slide the crossbar to the next locking
position. Alternate sides until the crossbars are posi-
tioned correctly for your cargo and the stanchions are
locked square to the slide rails.External racks do not increase the total load carrying
capacity of the vehicle. Be sure that the total occupant
and luggage load inside the vehicle, plus the load on the
luggage rack, do not exceed the rated vehicle capacity.
NOTE:When the luggage rack is not in use, place the
crossbars together at the rear of the vehicle. In this
position they are designed to improve the vehicle aero-
dynamics and reduce wind noise.
212 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

CAUTION!
To avoid damage to the roof rack and vehicle, do not
exceed the maximum roof rack load capacity of 150
lbs (68 kg). Always distribute heavy loads as evenly
as possible and secure the load appropriately.
Long loads which extend over the windshield, such
as wood panels or surfboards, should be secured to
both the front and rear of the vehicle.
Travel at reduced speeds and turn corners carefully
when carrying large or heavy loads on the roof rack.
Wind forces, due to natural causes or nearby truck
traffic, can add sudden upward loads. This is espe-
cially true on large flat loads and may result in
damage to the cargo or your vehicle.
WARNING!
Cargo must be securely tied before driving your
vehicle. Improperly secured loads can fly off the
vehicle, particularly at high speeds, resulting in
personal injury or property damage. Follow the roof
rack “Cautions” when carrying cargo on your roof
rack.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 213
3

UNDERSTANDING YOUR INSTRUMENT PANEL
CONTENTS

Instrument Panel Features.................218

Instrument Cluster—Base.................219

Instrument Cluster—Premium..............220

Instrument Cluster—Turbo................221

Instrument Cluster Descriptions............222

Electronic Vehicle Information Center (EVIC)–If
Equipped............................229
▫EVIC Functions.......................231
▫Compass/Temperature/Audio............231▫Average Fuel Economy.................232
▫Distance To Empty (DTE)...............232
▫Elapsed Time........................232
▫Personal Settings (Customer Programmable
Features)...........................232

Setting The Analog Clock.................238

Radio General Information................239
▫Radio Broadcast Signals.................239
▫Two Types Of Signals..................2394

▫Electrical Disturbances..................239
▫AM Reception.......................239
▫FM Reception........................239

Sales Code REF — AM/FM/CD (Single Disc)
Radio With Optional Satellite Radio And
Hands Free Phone Capability..............240
▫Operating Instructions - Radio Mode.......240
▫Operation Instructions - CD Mode.........244
▫Operation Instructions - Auxiliary Mode.....246
▫Operating Instructions - Hands Free
Phone — If Equipped..................247
▫Operating Instructions - Satellite
Radio — If Equipped..................248
Sales Code RAQ – AM/FM/CD (6-Disc) Radio
With Optional Satellite Radio, Hands Free
Phone, And Vehicle Entertainment
Systems (VES) Capabilities................248
▫Operating Instructions - Radio Mode.......248
▫Operation Instructions - (CD Mode For
CD Audio Play)......................254
▫Load/Eject Button (CD Mode For
CD Audio Play)......................255
▫NotesOnPlayingMP3Files .............257
▫Operation Instructions - (CD Mode For
MP3 Audio Play).....................259
▫Load/Eject Button (CD Mode For MP3 Play) . . 259

Satellite Radio — If Equipped..............261
▫System Activation.....................262
216 UNDERSTANDING YOUR INSTRUMENT PANEL

▫Electronic Serial Number/Sirius Identification
Number (ESN/SID)....................262
▫Selecting Satellite Mode In REF, And RAQ,
Radios.............................263
▫Selecting a Channel....................263
▫Storing And Selecting Pre-Set Channels......264
▫Using The PTY (Program Type) Button
(If Equipped)........................264
▫PTY ButtonScan.....................264
▫PTY ButtonSeek.....................264
▫Satellite Antenna......................265▫Reception Quality.....................265

CD/DVD Disc Maintenance...............265

Radio Operation And Cellular Phones........266

Climate Controls.......................266
▫Climate Controls......................266
▫Operating Tips.......................271

Rear Window Features...................273
▫Electric Rear Window Defroster...........273
▫Rear Wiper/Washer Switch — If Equipped . . . 274
▫Adding Washer Fluid..................275
UNDERSTANDING YOUR INSTRUMENT PANEL 217
4

INSTRUMENT PANEL FEATURES
218 UNDERSTANDING YOUR INSTRUMENT PANEL

INSTRUMENT CLUSTER—BASE
UNDERSTANDING YOUR INSTRUMENT PANEL 219
4

INSTRUMENT CLUSTER—PREMIUM
220 UNDERSTANDING YOUR INSTRUMENT PANEL
