remote start CHRYSLER PT CRUISER 2006 1.G User Guide

LIFTGATE (SEDAN)
NOTE:The key that is used to start the vehicle is also
used to lock or unlock the doors and open the liftgate (if
equipped). Rotate the key and pull the liftgate up.
To unlock the liftgate, insert the key into the lock and
turn to the right. If equipped, the liftgate can also be
unlocked using the remote keyless entry or by activating
the power door lock switches located on the front doors.
The central locking/unlocking feature (if equipped) can
also be activated from the liftgate key cylinder.
Once unlocked, the liftgate can be opened or closed
without using the key. To open the liftgate, squeeze the
liftgate release touch pad located on the backside of the
liftgate handle and pull the liftgate open with one fluid
motion (if equipped).NOTE:In the event of a power malfunction, or the
remote transmitter is inoperative, insert the key into the
liftgate lock cylinder and turn to the right. Using the
liftgate handle, pull the liftgate open with one fluid
motion.
Liftgate Handle
38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

WARNING!
•Driving with the liftgate open can allow poison-
ous exhaust gases into your vehicle. You and your
passengers could be injured by these fumes. Keep
the liftgate closed when you are operating the
vehicle.
•If you are required to drive with the liftgate open,
make sure that all windows are closed, and the
climate control blower switch is set at high speed.
DO NOT use the recirculation mode.
Gas props support the liftgate in the open position.
However, because the gas pressure drops with tempera-
ture, it may be necessary to assist the props when
opening the liftgate in cold weather.
DECK LID (CONVERTIBLE)
NOTE:The key that is used to start the vehicle is also
used to lock or unlock the doors and open the deck lid.
To open the deck lid, insert the key into the lock and turn
to the right. The deck lid can also be opened using the
remote keyless entry or by using the power deck lid
release switch located in the glove box.
WARNING!
•Driving with the deck lid open can allow poisonous
exhaust gases into your vehicle. You and your pas-
sengers could be injured by these fumes. Keep the
deck lid closed when you are operating the vehicle.
•If you are required to drive with the deck lid
open, make sure that all windows are closed, and
the climate control blower switch is set at high
speed. DO NOT use the recirculation mode.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 39
2

Gas props support the deck lid in the open position.
However, because the gas pressure drops with tempera-
ture, it may be necessary to assist the props when
opening the deck lid in cold weather.
Power Deck Lid Release
You can open the deck lid by pressing the Remote
Keyless Entry Button or from inside the vehicle, using the
switch located inside the glove box. On vehicles
equipped with a manual transmission, the power deck
lid release switch is disabled if the doors are locked, or if
vehicle speed exceeds 0 mph (0 km/h), or when the
clutch pedal is depressed. On vehicles equipped with an
automatic transmission, the power deck lid release
switch is disabled if the doors are locked, or the trans-
mission is out of PARK.
EMERGENCY SEAT BACK RELEASE (SEDAN)
WARNING!
Do not allow children to have access to the liftgate
area with the rear shelf panel in position 1 (Top) or
position 2 (Middle), either by climbing into the
liftgate from outside, or through the inside of the
vehicle. Always close the liftgate when your vehicle
is unattended. Once in the liftgate area, young chil-
dren may not be able to escape, even if they entered
through the rear seat. If trapped in the liftgate,
children can die from suffocation or heat stroke.
As a security measure, a Seat Back Emergency Release
lever is built into the left side rear seat back latching
mechanism. In the event of an individual being locked
inside the liftgate area with the rear shelf panel in
position 1 (Top) or position 2 (Middle), the left side rear
40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

The front airbag system consists of the following:
•Occupant Restraint Controller
•Side Remote Acceleration Sensors (If equipped)
•Airbag Warning Light
•Driver Airbag
•Passenger Airbag
•Front Seat Mounted Side Airbags (If equipped)
•Steering Wheel and Column
•Instrument Panel
•Interconnecting Wiring
•Knee Impact Bolsters
•Driver Inflatable Knee Blocker
•Front Acceleration Sensors
•Driver and Front Passenger Seat Belt Pretensioners
•Occupant Classification System (OCS) for the Front
Passenger Seat
Occupant Classification Module
Passenger Airbag Disable (PAD) Indicator Light
Weight Sensors
How The Airbag System Works
•
TheOccupant Restraint Controller (ORC)determines
if a frontal collision is severe enough to require the
airbags to inflate. The front airbag inflators are de-
signed to provide different rates of airbag inflation
from direction provided by the ORC. The ORC may
also modify the rate of inflation based on the occupant
size provided by the Occupant Classification Module.
The ORC will not detect roll over.
60 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

The front airbag system consists of the following:
•Occupant Restraint Controller
•Side Remote Acceleration Sensors (If Equipped)
•Airbag Warning Light
•Driver Airbag
•Passenger Airbag
•Front Seat Mounted Side Airbags (If equipped)
•Steering Wheel and Column
•Instrument Panel
•Interconnecting Wiring
•Knee Impact Bolsters
•Driver Inflatable Knee Blocker
•Front Acceleration Sensors
•Driver and Front Passenger Seat Belt Pretensioners
•Occupant Classification System (OCS) for the Front
Passenger Seat
Occupant Classification Module
Passenger Airbag Disable (PAD) Indicator Light
Weight Sensors
How The Airbag System Works
•
TheOccupant Restraint Controller (ORC)determines
if a frontal collision is severe enough to require the
airbags to inflate. The front airbag inflators are de-
signed to provide different rates of airbag inflation
from direction provided by the ORC. The ORC may
also modify the rate of inflation based on the occupant
size provided by the Occupant Classification Module.
The ORC will not detect roll over.
94 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
