CHRYSLER PT CRUISER 2006 1.G Owners Manual

Miles 72,000 78,000 84,000 90,000 96,000 102,000
(Kilometers) (120000) (130000) (140 000) (150 000) (160 000) (170 000)
[Months] [72] [78] [84] [90] [96] [102]
Change engine oil and engine oil filter. X X X X X X
Rotate tires. X X X X X X
Inspect the brake linings. X X
Replace theengine air cleaner filter.X
Replace thespark plugs.X
Inspect the tie rod ends and boot seals. X
Inspect thePCV valveand replace if necessary.
Not required if previously changed. * ‡X
Replace theMake-up air filter.X
Adjust the generator drive belt tension. X
Flush and replace the engine coolant, if not re-
placed at 60 months.X
SCHEDULE “A”—NON TURBO 431
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles108,000 114,000 120,000
(Kilometers) (180 000) (190 000) (200 000)
[Months] [108] [114] [120]
Change engine oil and engine oil filter. X X X
Rotate tires. X X X
Inspect thePCV valveand replace if necessary. * ‡ X
Replace theair cleaner filter.X
Replace theengine timing belt.*X
Flush and replace the engine coolant at 120 months, if not done at
102,000 miles.X
Replace thespark plugs and ignition cables.X
Replace theMake-up air filter.X
* This maintenance is recommended by the manufacturer
to the owner but is not required to maintain the emis-
sions warranty.
‡ This maintenance is not required if previously replaced.Inspection and service should also be performed anytime
a malfunction is observed or suspected. Retain all re-
ceipts.
432 SCHEDULE “A”—NON TURBO
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

SCHEDULE “A”—TURBO
Miles 5,000 10,000 15,000 20,000 25,000 30,000
(Kilometers) (8 000) (16 000) (24 000) (32 000) (40 000) (48 000)
[Months] [6] [12] [18] [24] [30] [36]
Change engine oil and engine oil filter. XXXXXX
Rotate tires. XXXXXX
Inspect the brake linings. X
Replace theengine air cleaner filter.X
Replace thespark plugs.X
Inspect the tie rod ends and boot seals. X
Replace theMake-up air filter.X
Adjust the generator drive belt tension. X
SCHEDULE “A”—TURBO 433
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 35,000 40,000 45,000 50,000 55,000
(Kilometers) (56 000) (64 000) (72 000) (80 000) (88 000)
[Months] [42] [48] [54] [60] [66]
Change engine oil and engine oil filter.XXXXX
Rotate tires.XXXXX
Inspect the brake linings. X
Flush and replace engine coolant at 60 months, if not
replaced at 100,000 miles.X
434 SCHEDULE “A”—TURBO
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 60,000 65,000 70,000 75,000 80,000 85,000
(Kilometers) (96 000) (104
000)(112
000)(120
000)(128
000)(136 000)
[Months] [72] [78] [84] [90] [96] [102]
Change engine oil and engine oil filter. X X X X X X
Rotate tires. X X X X X X
Inspect the brake linings. X X
Replace theengine air cleaner filter.X
Replace thespark plugs and ignition cables.X
Inspect the tie rod ends and boot seals. X
Inspect thePCV valveand replace if necessary. Not
required if previously changed. * ‡X
Replace theMake-up air filter.X
Adjust the generator drive belt tension. X
SCHEDULE “A”—TURBO 435
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 90,000 95,000 100,000 105,000
(Kilometers) (144 000) (156 000) (160 000) (168 000)
[Months] [108] [114] [120] [126]
Change engine oil and engine oil filter. X X X X
Rotate tires. X X X X
Inspect the brake linings.X
Replace theengine air cleaner filter.X
Replace thespark plugs.X
Adjust the generator drive belt tension. X
Inspect the tie rod ends and boot seals. X
Inspect thePCV valveand replace if necessary. Not required if
previously changed. * ‡X
Flush and replace the engine coolant if not done at 60 months. X
Replace theMake-up air filter.X
Replace theengine timing belt.X
436 SCHEDULE “A”—TURBO
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 110,000 115,000 120,000
(Kilometers) (177 000) (185 000) (193 000)
[Month] [132] [138] [144]
Change engine oil and engine oil filter. X X X
Rotate tires. X X X
Inspect thePCV Valveand replace if necessary. * X
Replace theengine air cleaner filter.X
Replace thespark plugs and ignition cables.X
* This maintenance is recommended by the manufacturer
to the owner but is not required to maintain the emis-
sions warranty.
‡ This maintenance is not required if previously replaced.
Inspection and service should also be performed anytime
a malfunction is observed or suspected. Retain all re-
ceipts.
WARNING!
You can be badly injured working on or around a
motor vehicle. Do only that service work for which
you have the knowledge and the right equipment. If
you have any doubt about your ability to perform a
service job, take your vehicle to a competent me-
chanic.
SCHEDULE “A”—TURBO 437
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

IF YOU NEED CONSUMER ASSISTANCE
CONTENTS

Suggestions For Obtaining Service For Your
Vehicle ..............................440
▫Prepare For The Appointment............440
▫Prepare A List........................440
▫Be Reasonable With Requests.............440

If You Need Assistance...................440

Warranty Information (U.S. Vehicles Only).....443

MoparParts.........................443
Reporting Safety Defects..................443
▫In Canada..........................443

Publication Order Forms..................444

Department Of Transportation Uniform Tire
Quality Grades........................445
▫Treadwear..........................445
▫Traction Grades......................445
▫Temperature Grades...................446
9

SUGGESTIONS FOR OBTAINING SERVICE FOR
YOUR VEHICLE
Prepare For The Appointment
If you’re having warranty work done, be sure to have the
right papers with you. Take your warranty folder. All
work to be performed may not be covered by the
warranty, discuss additional charges with the service
manager. Keep a maintenance log of your vehicle’s
service history. This can often provide a clue to the
current problem.
Prepare A List
Make a written list of your vehicle’s problems or the
specific work you want done. If you’ve had an accident,
or work done that is not on your maintenance log, let the
service advisor know.
Be Reasonable With Requests
If you list a number of items, and you must have your
vehicle by the end of the day, discuss the situation with
the service advisor and list the items in order of priority.
At many dealers you may obtain a rental vehicle at a
minimal daily charge. If you need a rental, it is advisable
to make these arrangements when you call for an ap-
pointment.
IF YOU NEED ASSISTANCE
The manufacturer and its dealers are vitally interested in
your satisfaction. We want you to be happy with our
products and services.
Warranty service must be done by an authorized
Chrysler, Dodge, or Jeep dealer. We strongly recommend
that you take your vehicle to your selling dealer. They
know you and your vehicle best, and are most concerned
that you get prompt and high quality service. The
manufacturer’s dealers have the facilities, factory-trained
440 IF YOU NEED CONSUMER ASSISTANCE
