Position 4 (Vertical)
Insert the front outboard corners of the shelf panel into
the vertical guides behind the rear seatbacks near the
floor and slide downward. Push the shelf panel forward
to lock it into place.WARNING!
When in the vertical position, the rear shelf panel
should not be used as a barrier for large objects in
the cargo area when the seatbacks folded down. In
an accident objects could strike the seatbacks or
occupants causing serious or fatal injury.
Position 5 (table)
With the liftgate open the rear shelf panel can be moved
rearward to act as a serving counter.
1. Install the front corners of the shelf panel into the top
rear guides. Press down on the shelf panel to lock it into
place.
Rear Shelf Panel Position 4
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 211
3

2. Twist the knob on the underside of the panel and
lower the shelf leg.
3. Install the shelf leg into the liftgate latch area as
labeled on the rear scuff plate.
WARNING!
Do not load objects over 100 lbs (45 kg) in position 5
(table). Failure to follow this warning could cause
the shelf to collapse resulting in personal injury.
Rear Shelf Leg Release Knob
Rear Shelf Panel Position 5
212 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

ROOF LUGGAGE RACK Ð IF EQUIPPED
The crossbars and siderails are designed to carry the
weight on vehicles equipped with a luggage rack. The
load must not exceed 150 lbs (68 kg), and should be
uniformly distributed over the luggage rack crossbars.
Use both adjustable crossbars assemblies to support the
load and distribute the load as evenly as possible.
To adjust the crossbars with latch style releases, release
the latches on the inboard side of the crossbar supports
on each side of the vehicle, then move the crossbars to the
desired position. Once the crossbar is in the desired
position, return both latches to the locked position.
To adjust the crossbars with botton style releases, depress
the button and slide the crossbar to the next locking
position. Alternate sides until the crossbars are posi-
tioned correctly for your cargo and the stanchions are
locked square to the slide rails.External racks do not increase the total load carrying
capacity of the vehicle. Be sure that the total occupant
and luggage load inside the vehicle, plus the load on the
luggage rack, do not exceed the rated vehicle capacity.
NOTE:When the luggage rack is not in use, place the
crossbars together at the rear of the vehicle. In this
position they are designed to improve the vehicle aero-
dynamics and reduce wind noise.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 213
3

CAUTION!
To avoid damage to the roof rack and vehicle, do not
exceed the maximum roof rack load capacity of 150
lbs (68 kg). Always distribute heavy loads as evenly
as possible and secure the load appropriately.
Long loads which extend over the windshield, such
as wood panels or surfboards, should be secured to
both the front and rear of the vehicle.
Travel at reduced speeds and turn corners carefully
when carrying large or heavy loads on the roof rack.
Wind forces, due to natural causes or nearby truck
traffic, can add sudden upward loads. This is espe-
cially true on large flat loads and may result in
damage to the cargo or your vehicle.
WARNING!
Cargo must be securely tied before driving your
vehicle. Improperly secured loads can fly off the
vehicle, particularly at high speeds, resulting in
personal injury or property damage. Follow the roof
rack ªCautionsº when carrying cargo on your roof
rack.
214 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

REAR WINDOW FEATURES
Electric Rear Window Defroster
The push-button is located at the center of the
instrument panel, below the radio. Press this but-
ton to turn on the rear window defroster, and the
optional electric remote control heated mirrors. An amber
light shows that the defroster is on.
NOTE:The defroster turns off automatically after 10
minutes of operation. Each following activation of the
defroster will last for five minutes.
CAUTION!
To avoid damaging the electrical conductors, do not
use scrapers, sharp instruments, or abrasive window
cleaners on the interior surface of the rear window.
Labels can be peeled off after soaking with warm
water.
Rear Wiper/Washer Switch Ð If Equipped
A switch on the right side of the steering column controls
operation of the rear wiper/washer function. Rotating
the center of the switch forward to the ON position will
activate the wiper. Rotating the center of the switch all
the way forward will turn on the wash function. The
wash pump will continue to operate as long as the button
is pressed. Upon release, the wipers will cycle two times
before returning to the set position.
Rear Defroster Switch
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 215
3

If the rear wiper is operating when the ignition is turned
OFF, the wiper will automatically return to the ªParkº
position if power accessory delay is active. Power acces-
sory delay can be cancelled by opening the door, if this
happens the rear wiper will stop at its current position
and will not go to park.
Adding Washer Fluid
The fluid reservoir for the windshield washers and the
rear window washer (If Equipped) is shared. It is located
in the rear of the engine compartment on the passenger
side and should be checked for fluid level at regular
intervals. Fill the reservoir with windshield washer sol-
vent (not radiator antifreeze) and operate the system for
a few seconds to flush out the residual water.
Rear Wiper Switch
216 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

UNDERSTANDING YOUR INSTRUMENT PANEL
CONTENTS
mInstrument Panel Features.................220
mInstrument ClusterÐBase.................221
mInstrument ClusterÐPremium..............222
mInstrument ClusterÐTurbo................223
mInstrument Cluster Descriptions............224
mElectronic Vehicle Information Center (EVIC)±
If Equipped...........................231
NEVIC Functions.......................233
NCompass/Temperature/Audio............233NAverage Fuel Economy.................234
NDistance To Empty (DTE)...............234
NElapsed Time........................234
NPersonal Settings
(Customer Programmable Features)........234
mSetting The Analog Clock.................240
mRadio General Information................241
NRadio Broadcast Signals.................241
NTwo Types Of Signals..................2414

NElectrical Disturbances..................241
NAM Reception.......................241
NFM Reception........................241
mSales Code REF Ð AM/FM/CD (Single Disc)
Radio With Optional Satellite Radio And Hands
Free Phone Capability...................242
NOperating Instructions - Radio Mode.......242
NOperation Instructions - CD Mode.........246
NOperation Instructions - Auxiliary Mode.....248
NOperating Instructions - Hands Free Phone Ð
If Equipped.........................249
NOperating Instructions - Satellite Radio Ð
If Equipped.........................250mSales Code RAQ ± AM/FM/CD (6-Disc) Radio With
Optional Satellite Radio, Hands Free Phone, And
Vehicle Entertainment Systems (VES)
Capabilities...........................250
NOperating Instructions - Radio Mode.......250
NOperation Instructions -
(CD Mode For CD Audio Play)...........256
NLoad/Eject Button
(CD Mode For CD Audio Play)...........257
NNotes On Playing MP3 Files.............259
NOperation Instructions -
(CD Mode For MP3 Audio Play)..........262
NLoad/Eject Button (CD Mode For MP3 Play) . . 262
mSatellite Radio Ð If Equipped..............264
NSystem Activation.....................264
218 UNDERSTANDING YOUR INSTRUMENT PANEL

NElectronic Serial Number/Sirius Identification
Number (ESN/SID)....................264
NSelecting Satellite Mode In REF, And RAQ,
Radios.............................265
NSelecting a Channel....................266
NStoring And Selecting Pre-Set Channels......266
NUsing The PTY (Program Type) Button
(If Equipped)........................266
NPTY Button9Scan9.....................267NPTY Button9Seek9.....................267
NSatellite Antenna......................267
NReception Quality.....................267
mCD/DVD Disc Maintenance...............268
mRadio Operation And Cellular Phones........268
mClimate Controls.......................269
NClimate Controls......................269
NOperating Tips.......................274
UNDERSTANDING YOUR INSTRUMENT PANEL 219
4

INSTRUMENT PANEL FEATURES
220 UNDERSTANDING YOUR INSTRUMENT PANEL
