²Pull the release handle located on the outboard side of
the seat. Lift up the seat and tumble the seat forward.²Attach the elastic strap, located at the base of the seat
cushion, onto the hook bar on the center trim panel to
hold the seat in place.
Folding Rear Seat ButtonTumbling Seat Release Strap
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 171
3

To return the rear seat to it's upright latched position,
rotate the seat cushion rearward to latch the seat. Then
lift the seatback to its upright latched position.
NOTE:The elastic strap should be reinstalled in the clip
on the base of the seat cushion before returning the seat
to its normal position.
Tumbling Rear Seat (Convertible)
To provide additional storage area, each rear seat can be
tumbled forward.
CAUTION!
It is important that the front seats be pulled forward
to the midpoint of the seat track to avoid contact
between the rear seat and the front seatback. If the
front seat is not pulled forward the two seats will
make contact during the tumbling motion and cause
damage to the rear seat material. After the rear seat is
tumbled forward and secured the front seat can then
be repositioned to the preferred position.
To tumble the seat forward use the following procedure:
1. The seat back release knobs are located in the trunk
area. Pull the left side seatback release knob to fold down
Tumbling Seat Strap
172 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

the left side seatback. Pull the right side seatback release
knob to fold down the right side seatback.2. From inside the vehicle, fold the rear seat back down
flat.
Folding Rear Seat Release Knobs
Folding Rear Seat Back
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 173
3

3. Pull the release handle located at the bottom of the
folded seat back and tumble the seat forward.
4. Attach the cinching tether strap, located at the side of
the seat cushion, onto the hook bar on the center trim
panel and tighten by pulling the cinching strap until the
seat is secure.To return the tumbling rear seat to the latched (normal)
position use the following procedure:
1. Loosen the strap by pushing rearward on the cinching
tether strap buckle.
Tumbling Rear Seat
Cinching Tether Strap
174 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

2. Disconnect the cinching tether strap.
NOTE:The strap should be reinstalled in the side
pocket on the seat cushion before returning the seat to the
latched (normal) position.NOTE:Prior to rotating the seat cushions rearward, be
sure that the rear seat belt buckles are secured with the
straps, so that the buckles are accessible.
NOTE:Prior to lifting either seatback to the upright
position, be sure that the seat belt is brought forward to
avoid trapping it behind the seatback.
Releasing Cinching Tether Strap
Rear Seat Belt Buckle Straps
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 175
3

3. Rotate the seat cushion rearward to latch the seat.
Then lift the seatback to its upright latched position.
WARNING!
In an accident, you or others in your vehicle could be
injured if seats are not properly latched to their
attachments. Always be sure the seats are fully
latched.
Rear Seat Removal (Sedan)
The rear seats can be removed to provide more cargo
space.
²Push and hold the button on the seatback and fold
down the rear seatback.
²Pull the release lever located on the outboard side of
the seat. Lift up the seat and tumble the seat forward.
Folding Rear Seat Button
176 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

²Lift up the release levers to disengage the seat from the
floor attachments.²Using the handle on the seat, the seat assembly can
now be lifted and removed from the vehicle.
NOTE:Small rollers on the bottom of the folded seat
and a handle at the top allow the seat to be easily moved
when removed from the vehicle.
Tumbling Seat Release StrapRelease Lever Location
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 177
3

To reinstall the rear seat, insert the seat into the floor
attachments. Lower the release levers of the seat to latch
the front floor attachments and rotate the seat rearward
to latch the seat. Lift the seat back to its upright latched
position.
WARNING!
In an accident, you or others in your vehicle could be
injured if seats are not properly latched to their floor
attachments. Always be sure the seats are fully
latched.
TO OPEN AND CLOSE THE HOOD
To open the hood, two latches must be released. First pull
the primary hood release lever located under the left side
of the instrument panel.
Primary Hood Release Lever
178 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Then move the secondary hood latch (safety latch) lo-
cated under the front edge of the hood, slightly to the
right of center, and raise the hood.Use the hood prop rod clipped to the driver's side of the
engine compartment to secure the hood in the open
position. Place the hood prop at the location stamped into
the inner hood surface.
To prevent possible damage, do not slam the hood to
close it. Lower the hood until it is open approximately 20
cm (8 inches) and then drop it. This should secure both
latches. Never drive your vehicle unless the hood is fully
closed, with both latches engaged.
WARNING!
If the hood is not fully latched it could fly up when
the vehicle is moving and block your forward vision.
You could have a collision. Be sure all hood latches
are fully latched before driving.
Secondary Hood Latch
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 179
3

LIGHTS
Map/Reading Lights (Sedan)
These lights are mounted between the sun visors above
the rear view mirror. Each light is turned ON by pressing
the button. Press the button a second time to turn the
light OFF. The lights also come on when a door is opened
or the dimmer control is turned fully upward, past the
second detent.
NOTE:The lights will remain on until the switch is
pressed a second time, so be sure they have been turned
off before leaving the vehicle. They will not turn off
automatically.
