ECU CHRYSLER PT CRUISER 2007 1.G Owners Manual

NTo Unlock The Doors And Liftgate..........24
NTo Lock The Doors And Liftgate
(If Equipped With Power Options)..........25
NUsing The Panic Alarm..................25
NTo Turn Off ªFlash Lights With Lockº........26
NProgramming Additional Transmitters........26
NGeneral Information....................28
NBattery Replacement....................28
mRemote Keyless Entry (Convertible)...........30
NTo Unlock The Doors...................30
NTo Lock The Doors.....................31
NTo Unlatch The Deck Lid.................32
NPanic Alarm..........................32NUsing The Panic Alarm..................32
NTo Turn Off ªFlash Lights With Lockº........32
NTo Program Additional Transmitters.........33
NGeneral Information....................34
NTransmitter Battery Service...............34
mSecurity Alarm System Ð If Equipped.........35
NTo Set The Alarm......................36
NTo Disarm The System...................36
NSecurity System Manual Override...........37
mLiftgate (Sedan).........................37
mDeck Lid (Convertible)....................39
NPower Deck Lid Release (Convertible)........40
mEmergency Seat Back Release (Sedan).........40
10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

NOTE:
²The Sentry Key Immobilizer System is not compatible
with remote starting systems. Use of these systems
may result in vehicle starting problems and loss of
security protection.
²Exxon/Mobil Speed Pass,Ÿ additional Sentry Keys, or
any other transponder equipped components on the
same keychain willnotcause a key-related (transpon-
der) fault unless the additional part isphysically held
against the ignition keybeing used when starting the
vehicle. Cell phones, pagers, or other RF electronics
will not cause interference with this system.
All of the keys provided with your new vehicle have
been programmed to the vehicle electronics.
Replacement Keys
NOTE:Only keys that have been programmed to the
vehicle electronics can be used to start the vehicle. Once
a Sentry Key has been programmed to a vehicle, it cannot
be programmed to any other vehicle.
At the time of purchase, the original owner is provided
with a four-digit PIN number. This number is required
for dealer replacement of keys. Duplication of keys may
be performed at an authorized dealer or by using the
Customer Key Programming procedure. This procedure
consists of programming a blank key to the vehicle
electronics. A blank key is one, which has never been
programmed.
NOTE: When having the Sentry Key Immobilizer
System serviced, bring all vehicle keys with you to the
dealer.
16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

WARNING!
For personal security, and safety in the event of an
accident, lock the vehicle doors as you drive as well
as when you park and leave the vehicle.
WARNING!
When leaving the vehicle always remove the key
from the ignition lock, and lock your vehicle. Do not
leave children unattended in the vehicle, or with
access to an unlocked vehicle. Unsupervised use of
vehicle equipment may cause severe personal inju-
ries and death.
CAUTION!
An unlocked vehicle is an invitation to thieves.
Always remove the key from the ignition and lock
all of the doors when leaving the vehicle unattended.Door Lock Plunger
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 19
2

NOTE:Pressing the LOCK button on the keyfob while
you are inside the vehicle will activate the Security
Alarm. Opening a door with the Security Alarm activated
will cause the alarm to sound. Press the UNLOCK button
to deactivate the Security Alarm.
5. If the desired programming was not achieved or to
reactivate this feature, repeat the above steps.
To lock the doors and liftgate (if equipped with
power options) :
Press and release the LOCK button on the transmitter to
lock all doors. The turn signal lights will flash and the
horn will chirp once to acknowledge the lock signal. If
desired, the ªSound Horn On Lockº and ªFlash Lamps
With Lockº feature can be turned on or off. On electronic
vehicle information center (EVIC) equipped vehicles re-
fer to ªPersonal Settingsº in the ªElectronic VehicleInformation Center (EVIC)º section of this manual. On
non EVIC ± equipped vehicles perform the following
steps:
1. Press the LOCK button for 4 to 10 seconds.
2. While the LOCK button is pressed (after 4 seconds),
press the PANIC button. Release both buttons.
The ªSound Horn On Lockº and ªFlash Lamps With
Lockº feature can be reactivated by repeating this proce-
dure.
Using The Panic Alarm:
To turn the panic alarm feature ON or OFF, press and
hold the PANIC button on the transmitter for at least one
second and release. When the panic alarm is on, the
headlights and park lights will flash, the horn will pulse
on and off and the interior lights will turn on.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 25
2

The panic alarm will stay on for 3 minutes unless you
turn it off by pressing the PANIC button a second time or
if the vehicle speed is 5 mph (8 km/h) or greater.
NOTE:When you turn off the panic alarm by pressing
the PANIC button a second time, you may have to be
closer to the vehicle due to the radio frequency noises of
the system.
To Turn Off ªFlash Lights With Lockº
NOTE:The Flash Lights With Lock feature can be
turned on or off. On Electronic Vehicle Information
Center (EVIC) equipped vehicles refer to9Personal Set-
tings9in the EVIC section of this manual. On non EVIC -
equipped vehicles perform the following steps:
1. Press the UNLOCK button for 4 to 10 seconds.
2. While the UNLOCK button is pressed, (after 4 sec-
onds) press the LOCK button. Release both buttons.3. Test the flash lamps with LOCK feature while outside
of the vehicle, by pressing the LOCK button on the key
fob with the ignition in the LOCK position, and the key
removed.
NOTE:Pressing the LOCK button on the key fob, while
you are in the vehicle, will activate the Security Alarm.
Opening a door with the Security Alarm activated will
cause the alarm to sound. Press the UNLOCK button to
deactivate the Security Alarm.
The ªFlash Lights On Lock/Unlockº feature can be
reactivated by repeating this procedure.
Programming Additional Transmitters
Vehicles will be shipped from the assembly plants with
two key fob transmitters programmed only for that
vehicle. A total of eight fobs can be programmed for your
vehicle. Additional fobs can be programmed to your
vehicle through the use of a currently programmed fob.
26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

The system can be programmed to unlock all the doors
upon the first UNLOCK button press by using the
following procedure:
1. Press and hold the LOCK button on a programmed
key fob.
2. Continue to hold the LOCK button at least 4 seconds,
but not longer than 10 seconds, then press and hold the
UNLOCK button. A single chime will sound to indicate
that this feature has changed.
3. Release both buttons at the same time.
4. Test the feature while outside of the vehicle, by
pressing the LOCK/UNLOCK button on the keyfob.
NOTE:Pressing the LOCK button on the keyfob while
you are inside the vehicle will activate the Security
Alarm. Opening a door with the Security Alarm activated
will cause the alarm to sound. Press the UNLOCK button
to deactivate the Security Alarm.5. If the desired programming was not achieved or to
reactivate this feature, repeat the above steps.
To lock the doors:
Press and release the LOCK button on the transmitter to
lock all doors. The turn signal lights will flash and the
horn will chirp once to acknowledge the lock signal. If
desired, the ªSound Horn On Lockº and ªFlash Lamps
With Lockº feature can be turned on or off. On electronic
vehicle information center (EVIC) equipped vehicles re-
fer to ªPersonal Settingsº in the ªElectronic Vehicle
Information Center (EVIC)º section of this manual. On
non EVIC ± equipped vehicles perform the following
steps:
1. Press the LOCK button for 4 to 10 seconds.
2. While the LOCK button is pressed (after 4 seconds),
press the PANIC button. Release both buttons.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 31
2

3. Test the flash lamps with LOCK feature while outside
of the vehicle, by pressing the LOCK button on the key
fob with the ignition in the LOCK position, and the key
removed.
NOTE:Pressing the LOCK button on the key fob, while
you are in the vehicle, will activate the Security Alarm.
Opening a door with the Security Alarm activated will
cause the alarm to sound. Press the UNLOCK button to
deactivate the Security Alarm.
The ªFlash Lights On Lock/Unlockº feature can be
reactivated by repeating this procedure.
To Program Additional Transmitters
NOTE:If vehicle is equipped with the optional Elec-
tronic Vehicle Information Center (EVIC) in the instru-
ment cluster, the transmitters may also be programmed
through the EVIC display.Up to 8 transmitters can be programmed to your vehicle.
To obtain additional transmitters, contact your autho-
rized dealer. To program a transmitter (within 23±50 feet
(7±15 meters) of the vehicle), perform the following
procedure:
1. Gather every transmitter that is to be used with the
vehicle including any transmitters that are currently
programmed.
2.Enter Program Mode:Turn the ignition to the ON
position, and using a currently programmed transmitter;
press and hold the9Unlock9button on the transmitter.
Continue to hold the ªUnlockº button, wait at least 4 but
no longer than 10 seconds, then press and hold the
PANIC button for at least 1 second. Release both buttons
simultaneously.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 33
2

2. Remove and replace the batteries. Avoid touching the
new batteries with your fingers. Skin oils may cause
battery deterioration. If you touch the battery, clean it
with rubbing alcohol.
3. Reassemble the transmitter case. Snap the halves
together and test transmitter operation.
SECURITY ALARM SYSTEM Ð IF EQUIPPED
The system monitors the doors, liftgate, and ignition
switch for unauthorized operation.
If something triggers the alarm, the system will signal for
about 18 minutes. For the first 3 minutes the horn will
sound and the headlights, park lights, tail lights and the
indicator light in the cluster will flash. Then the exterior
lights will flash for another 15 minutes.
If the monitored system, which triggered the alarm is
deactivated the alarm will continue to sound until 3
minutes of alarm time is reached. If the monitored
system, which triggered the alarm is deactivated after the
alarm has been on for 3 minutes the alarm will shut off
immediately.
Separating Transmitter Halves
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 35
2

Security System Manual Override
The system will not arm if you lock the doors using the
manual door lock plunger.
LIFTGATE (SEDAN)
NOTE:The key that is used to start the vehicle is also
used to lock or unlock the doors and open the liftgate (if
equipped). Rotate the key and pull the liftgate up.
To unlock the liftgate, insert the key into the lock and
turn to the right. If equipped, the liftgate can also be
unlocked using the remote keyless entry or by activating
the power door lock switches located on the front doors.
The central locking/unlocking feature (if equipped) can
also be activated from the liftgate key cylinder.
Door Lock Plunger
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 37
2

Power Deck Lid Release (Convertible)
You can open the deck lid by pressing the Remote
Keyless Entry Button or from inside the vehicle, using the
switch located inside the glove box. On vehicles
equipped with a manual transmission, the power deck
lid release switch is disabled if the doors are locked, or if
vehicle speed exceeds 0 mph (0 km/h), or when the
clutch pedal is depressed. On vehicles equipped with an
automatic transmission, the power deck lid release
switch is disabled if the doors are locked, or the trans-
mission is out of PARK.
EMERGENCY SEAT BACK RELEASE (SEDAN)
WARNING!
Do not allow children to have access to the liftgate
area with the rear shelf panel in position 1 (Top) or
position 2 (Middle), either by climbing into the
liftgate from outside, or through the inside of the
vehicle. Always close the liftgate when your vehicle
is unattended. Once in the liftgate area, young chil-
dren may not be able to escape, even if they entered
through the rear seat. If trapped in the liftgate,
children can die from suffocation or heat stroke.
As a security measure, a Seat Back Emergency Release
lever is built into the left side rear seat back latching
mechanism. In the event of an individual being locked
inside the liftgate area with the rear shelf panel in
position 1 (Top) or position 2 (Middle), the left side rear
40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
