NLights-On Reminder...................187
NFog Lights Ð If Equipped...............188
NTurn Signals.........................188
NHighbeam/Lowbeam Select Switch.........189
NPassing Light........................190
mWindshield Wipers And Washers...........190
NWindshield Washers...................191
NMist Feature.........................191
NWindshield Wiper Operation.............192
NIntermittent Wiper System...............192
mTilt Steering Column....................193
mElectronic Speed Control Ð If Equipped......194
NTo Activate..........................194NTo Set At A Desired Speed...............195
NTo Deactivate........................195
NTo Resume Speed.....................195
NTo Vary The Speed Setting...............195
NManual Transaxle.....................196
NTo Accelerate For Passing...............196
mGarage Door Opener Ð If Equipped.........197
NProgramming HomeLinkt...............198
NGate Operator/Canadian Programming.....201
NUsing HomeLinkt.....................202
NReprogramming A Single HomeLinkt
Button.............................202
NSecurity............................202
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 121
3

NTroubleshooting Tips...................203
NGeneral Information...................203
mPower Sunroof (Sedan Only) Ð If Equipped....204
NExpress Open Feature..................204
NWind Buffeting.......................205
NSunroof Maintenance...................206
mElectrical Power Outlets..................206
NElectrical Outlet Use With Engine Off.......208
mConsole Features.......................208
mStorage..............................209
NCenter Console/Armrest Storage Bin.......209
NStorage Pockets.......................210mRear Shelf PanelÐ If Equipped.............210
NPosition 1 (Top)......................211
NPosition 2 (Middle)....................212
NPosition 3 (Floor).....................212
NPosition 4 (Vertical)....................212
NPosition 5 (Table).....................213
mRoof Luggage Rack Ð If Equipped..........215
mRear Window Features...................217
NElectric Rear Window Defroster...........217
NRear Wiper/Washer Switch (Sedan Models
Only) Ð If Equipped...................217
NAdding Washer Fluid..................218
122 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

CONVERTIBLE TOP OPERATION
WARNING!
The convertible top does not provide the structural
protection that a reinforced metal roof does, and the
fabric top cannot be expected to prevent the ejection
of the occupants of a vehicle in a collision. Therefore
it is important that all occupants wear their seat belts
at all times when riding in a convertible. Studies
have shown that it is generally safer to remain inside
a vehicle during a collision, than to be ejected from
the vehicle.
To Lower The Top:
NOTE:Thoroughly dry the convertible top and top
storage area, prior to leaving the top lowered for an
extended period of time. This will help prevent possible
mildew build-up.
CAUTION!
To avoid damage to the convertible top or its compo-
nents, your vehicle is equipped with a feature that
prevents convertible top operation at speeds over 10
mph (16 km/h).
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 123
3

CAUTION!
To fully insure that no damage occurs, be sure that
the vehicle is at a complete stop with the gear selector
in the Park position (automatic transaxle) or in the
Neutral position (manual transaxle) before lowering
or raising the top.
CAUTION!
Do not operate the convertible top with ice or snow
build-up on the top. Damage to the top may occur.
CAUTION!
To avoid damage to either the top or the rear window,
check the top storage area at the rear of the vehicle
interior to be sure that it is clear of debris or other
items. Be sure that child seat flip up bars are lowered.
Do not use the top storage area for other storage
purposes.
NOTE:When closing the convertible top all windows
will drop slightly from the full up position.
1. Turn the ignition key to the ON position.
2. Release the top from the windshield header by pulling
down on the latch handle and turning the latch handle
clockwise until it stops.
124 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

3. Press the Power Top Switch to lower the top just
enough to disengage the top pins from the header, turn
the handle counterclockwise and raise the handle to the
stowed position.
NOTE:The Power Top Switch has two detent positions
for lowering the convertible top. Pressing and holdingthe Power Top Switch lightly in the first detent position
will lower the windows slightly and the convertible top
to the full down position. Pressing and holding the
switch in the second detent position will lower all four
windows completely and the top to the full down posi-
tion.
Releasing Convertible Top Latches
Convertible Top Switch
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 125
3

4. Continue pressing the Power Top Switch until the
convertible top is lowered completely.
5. Install the Convertible Top Boot Cover, if equipped.
Refer to Convertible Top Boot Cover Installation±If
Equipped, in this section.
CAUTION!
Damage to the convertible top boot cover could result
if the latch handle is not completely closed when the
top is lowered. The convertible top boot cover cannot
be installed while the latch handle is open.
To Raise The Top:
CAUTION!
To avoid damage to the convertible top or its compo-
nents, your vehicle is equipped with a feature that
prevents convertible top operation at speeds over 10
mph (16 km/h).
CAUTION!
To fully insure that no damage occurs, be sure that
the vehicle is at a complete stop with the gear selector
in the Park position (automatic transaxle) or in the
Neutral position (manual transaxle) before lowering
or raising the top.
126 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

1. Remove the convertible top boot cover, if equipped.
Refer to Convertible Top Boot Cover Removal and Stor-
age, in this section.
2. Turn the ignition to the ON position.
3. Press the Power Top Switch to raise the top. Before the
top reaches the windshield, open the latch handle and
turn the handle clockwise to open the latches. Press the
switch again to continue raising the top until the two pins
seat themselves in the windshield header.
NOTE:If the top is not latched right away, it may be
necessary to press the power top switch, UP or DOWN
quickly, to align the pins to the windshield header.
4. Pull down on the latch handle and rotate it counter-
clockwise to engage the latches.5. Raise the latch handle into the stowed position.
Engaging Convertible Top Latches
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 127
3

CAUTION!
Car top carriers, ski racks, etc., should not be attached
to the convertible top mechanism as they will dam-
age the top. Do not place objects on the convertible
top, in the top well or on the sport bar. Damage to the
convertible top may occur.
Convertible Top Boot Cover Installation±If
Equipped
1. With the top down and the convertible top latch
handle in the stowed position, lay the unfolded boot
cover across the convertible top.Convertible Top Latch Handle
128 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

2. Install the rear edge of the boot, first tucking the rear
edge of the boot under the rear and both sides of the rails.
Boot Laying Across Convertible Top
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 129
3

3. Pull the right and left boot arms forward and engage
both boot arm snaps. Make sure both snaps are fully
engaged.
Tucking Boot Under Rail
Engaging Boot Arm Snaps
