CHRYSLER PT CRUISER 2008 1.G Owners Manual

UNDERSTANDING THE FEATURES OF YOUR VEHICLE 161
3

North American English
Primary Alternate(s)
Zero
One
Tw o
Three
Four
Five
Six
Seven
Eight
Nine
Star (*)
Plus (+)
Pound (#)
Add Location
AllCall
Cancel
Confirmation Prompts
Continue
Delete
Dial
Edit
Emergency
English
Erase All
Espanol
Francais
Help
Home
Language
List names
List phones
162 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Mobile
Mute
Mute off
New entry
No
Pager
Pair a phone
Phone pairing Pairing
Phonebook Phone book
Previous
Record again
Redial
Return to main menu Return. Main menu
Select phone Select
Send
Set up Phone settings / Phone
set upTowing assistance
Transfer call
Try again
Voice training
Work
Ye s
General Information
This device complies with part 15 of the FCC rules and
RSS 210 of Industry Canada. Operation is subject to the
following conditions:
²This device may not cause harmful interference.
²This device must accept any interference received,
including interference that may cause undesired op-
eration.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 163
3

SEATS
FRONT SEAT ADJUSTMENT
The adjusting bar is at the front of the seats, near the
floor. Pull the bar up to move the seat to the desired
position.Using body pressure, move forward and rearward on the
seat to be sure the seat adjusters have latched.WARNING!
²Adjusting a seat while the vehicle is moving is
dangerous. The sudden movement of the seat
could cause you to lose control. The seat belt might
not be properly adjusted and you could be injured.
Adjust the seat only while the vehicle is parked.
²Do not ride with the seatback reclined so that the
shoulder belt is no longer resting against your
chest. In a collision you could slide under the seat
belt and be seriously or even fatally injured. Use
the recliner only when the vehicle is parked.
Manual Adjustment Bar
164 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

POWER SEAT ADJUSTER Ð IF EQUIPPED
WARNING!
Do not ride with the seatback reclined so that the seat
belt is no longer resting against your chest. In a
collision you could slide under the seat belt and be
seriously or even fatally injured. Use the recliner
only when the vehicle is parked.
Six-Way Power Seat with Manual Recliner
The seat switch is on the outboard side of the seat near
the floor. Use this switch to move the seat up or down,
forward or rearward, or to tilt the seat.
Power Seat Switch
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 165
3

This seat also has a manual recline lever located just to
the rear of the power seat switch. To recline, lean forward
slightly before lifting the lever, then lean back to the
desired position and release the lever. Lean forward and
lift the lever to return the seatback to its normal position.MANUAL LUMBAR Ð IF EQUIPPED
The Lumbar adjustment is located on the inboard side of
the driver's seat. To increase support, rotate the handle
down.
Recliner Control Lever
Lumbar Adjust Handle
166 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

FOLDING FRONT PASSENGER SEAT Ð IF
EQUIPPED
The passenger front seat may be folded fully forward to
provide additional cargo space.
To fold the seat forward pull up on the recliner lever
located on the outboard side of the seat.
DRIVER'S SEAT BACK TILT Ð IF EQUIPPED
How to operate the driver's seat:
1. Push the lever down until seat back releases.
2. Push the seat back forward.
3. To return seat to a sitting position, push seat back
rearward.
Folding Seat Control Lever
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 167
3

NOTE:The driver's front seat has a full recliner
memory, which will allow the seat back to return to its
original position.PASSENGER SEAT BACK TILT (EASY ENTRY
SYSTEM) Ð CONVERTIBLE
How to operate the passenger front seat:
1. Push the lever down until seat back releases.
2. Push seat back forward until it slides toward the
dashboard.
Driver's Seat Back Tilt Lever
Passenger Seat Back Tilt Lever
168 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

3. To return seat to a sitting position, rotate seat back
upright until it locks.
4. Push seat rearward until the track locks.
NOTE:The passenger front seat has a full recliner
memory, which will allow the seat back to returned to its
original position.
NOTE:The passenger front seat has a track memory,
which returns the seat to just past the half way point of
the track regardless of original position.
ADJUSTABLE HEAD RESTRAINTS
Head restraints can reduce the risk of whiplash injury in
the event of impact from the rear. Pull up or push down
on the head restraints so that the upper edge is as high as
practical. To raise the head restraint, pull up on the head
restraint. To lower the head restraint, push in the button
that is part of the head restraint rod guide, and push
down on the head restraint.
HEATED SEATS Ð IF EQUIPPED
WARNING!
Persons who are unable to feel pain to the skin
because of advanced age, chronic illness, diabetes,
spinal cord injury, medication, alcohol use, exhaus-
tion or other physical condition must exercise care
when using the seat heater. It may cause burns even
at low temperatures, especially if used for long
periods of time. Do not place anything on the seat
that insulates against heat, such as a blanket or
cushion. This may cause the seat heater to overheat.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 169
3

CAUTION!
Do not place anything on the seat that insulates
against heat, such as a blanket or cushion. This may
cause the seat heater to overheat. To avoid heated seat
surfaces coming in contact and potential seat over-
heating, ALWAYS ensure that the seat heater is in the
OFF position (amber lights are on for HIGH or LOW
and no amber lights for the OFF position) before
placing any of the seats into a folded flat position.
Heated seats provide comfort and warmth when needed
for the front driver's and passenger's seats. The heaters
provide the same average heat level for both seat and
back cushions. The controls for each heater are located
near the bottom center of the instrument panel.With the ignition switch in the on or run
position, you may choose from HIGH, LOW, or
OFF heat settings. Amber LEDs on the side of
each switch indicate the level of heat in use.
Two LEDs are illuminated for HIGH, one for LOW, and
none for OFF. Pressing the switch once will select the
HIGH setting. Pressing the switch a second time, will
select the LOW setting. Pressing the switch a third time,
will turn the heating elements OFF.
Heated Seat Switches
170 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
