CHRYSLER SEBRING 2005 2.G Warranty Booklet

2005 Passenger Car • Minivan • PacificaDealer Copy
Remove and attach to Repair Order 26-92-02-01 3N.
Maint enance Service
Sc hedule “B”
Odometer Reading
Date
221,0 00 km
Maint
enance Service Sc hedule “B”
221,0 00 km
Change engine oil and engine oil filter (or every 3 months).
Inspect and lubricate, as required, all steering and suspension componen\
ts.
Inspect the engine air cleaner filter and replace if necessary (Sebring\
, Pacifica
and Minivan only).
Rotate tires and check tire pressure.
INSPECT THE FOLLOWING:
Inspect the brake hoses.
Check the automatic transaxle fluid level.
Check the manual transaxle fluid level and fill-plug condition (SX 2.0,\
SRT-4
and PT Cruiser only, if equipped).
Check the coolant level, hoses and clamps.
Inspect the exhaust system.

DAIMLER CHR YSLER
D EALER STAMP
Signature of authorized DaimlerChrysler Canada dealer
2005 Passenger Car • Minivan • Pacifica
Odometer Reading
Date
Repair Order No.

Change engine oil and engine oil filter
(or every 3 months).
Inspect and lubricate, as required, all steering
and suspension components.
Inspect the engine air cleaner filter and replace if
necessary (Sebring, Pacifica and Minivan only).
Rotate tires and check tire pressure.
INSPECT THE FOLLOWING:
Inspect the brake hoses.
Check the automatic transaxle fluid level.
Check the manual transaxle fluid level and fill-plug
condition (SX 2.0, SRT-4 and PT Cruiser only,
if equipped).
Check the coolant level, hoses and clamps.
Inspect the exhaust system.
Maint enance Service Sc hedule “B”
221,0 00 km

2005 Passenger Car • Minivan • PacificaDealer Copy
Remove and attach to Repair Order 26-92-02-01 3N.
Maint enance Service
Sc hedule “B”
Odometer Reading
Date
225,0 00 km
Maint
enance Service Sc hedule “B”
225,0 00 km
Change engine oil and engine oil filter (or every 3 months).
Inspect and lubricate, as required, all steering and suspension componen\
ts.
Inspect the engine air cleaner filter and replace if necessary (Sebring\
, Pacifica
and Minivan only).
INSPECT THE FOLLOWING:
Inspect the brake hoses.
Check the automatic transaxle fluid level.
Check the manual transaxle fluid level and fill-plug condition (SX 2.0,\
SRT-4
and PT Cruiser only, if equipped).
Check the coolant level, hoses and clamps.
Inspect the exhaust system.

DAIMLER CHR YSLER
D EALER STAMP
Signature of authorized DaimlerChrysler Canada dealer
2005 Passenger Car • Minivan • Pacifica
Odometer Reading
Date
Repair Order No.

Change engine oil and engine oil filter (or every 3 months).
Inspect and lubricate, as required, all
steering and suspension components.
Inspect the engine air cleaner filter and replace if
necessary (Sebring, Pacifica and Minivan only).
INSPECT THE FOLLOWING:
Inspect the brake hoses.
Check the automatic transaxle fluid level.
Check the manual transaxle fluid level and fill-plug
condition (SX 2.0, SRT-4 and PT Cruiser only,
if equipped).
Check the coolant level, hoses and clamps.
Inspect the exhaust system.
Maint enance Service Sc hedule “B”
225,0 00 km

2005 Passenger Car • Minivan • PacificaDealer Copy
Remove and attach to Repair Order 26-92-02-01 3N.
Maint enance Service
Sc hedule “B”
Odometer Reading
Date
230,0 00 km
Maint
enance Service Sc hedule “B”
230,0 00 km
Change engine oil and engine oil filter (or every 3 months).
Inspect and lubricate, as required, all steering and suspension componen\
ts.
Inspect the engine air cleaner filter and replace if necessary (Sebring\
, Pacifica
and Minivan only).
Change the manual transaxle fluid (PT Cruiser only).***
Change the manual transaxle fluid (SRT-4 only).
Change the brake fluid if the vehicle is used for trailer towing (PT Cr\
uiser
and SRT-4 only).
Replace the air conditioning filter (Pacifica and Minivan if equipped)\
.
Rotate tires and check tire pressure.
INSPECT THE FOLLOWING:
Inspect the front and rear brakes and components (all models).
Inspect the brake hoses.
Check the automatic transaxle fluid level.
Check the coolant level, hoses and clamps.
Inspect the exhaust system.
***Change the manual transaxle fluid and filter every 77,000 km if the v\
ehicle is used for trailer tow,
taxi, police or other type of commercial service.

DAIMLER CHR YSLER
D EALER STAMP
Signature of authorized DaimlerChrysler Canada dealer
2005 Passenger Car • Minivan • Pacifica
Odometer Reading
Date
Repair Order No.

Change engine oil and engine oil filter
(or every 3 months).
Inspect and lubricate, as required, all steering
and suspension components.
Inspect the engine air cleaner filter and replace if
necessary (Sebring, Pacifica and Minivan only).
Change the manual transaxle fluid (PT Cruiser only).***
Change the manual transaxle fluid (SRT-4 only).
Change the brake fluid if the vehicle is used for trailer
towing (PT Cruiser and SRT-4 only).
Replace the air conditioning filter (Pacifica and Minivan
if equipped).
Rotate tires and check tire pressure.
INSPECT THE FOLLOWING:
Inspect the front and rear brakes and components
(all models).
Inspect the brake hoses.
Check the automatic transaxle fluid level.
Check the coolant level, hoses and clamps.
Inspect the exhaust system.
***Change the manual transaxle fluid and filter every 77,000 km
if the vehicle is used for trailer tow, taxi, police or other type of
commercial service.
Maint enance Service Sc hedule “B”
230,0 00 km

2005 Passenger Car • Minivan • PacificaDealer Copy
Remove and attach to Repair Order 26-92-02-01 3N.
Maint enance Service
Sc hedule “B”
Odometer Reading
Date
235,0 00 km
Maint
enance Service Sc hedule “B”
235,0 00 km
Change engine oil and engine oil filter (or every 3 months).
Inspect and lubricate, as required, all steering and suspension componen\
ts.
Inspect the engine air cleaner filter and replace if necessary (Sebring\
, Pacifica
and Minivan only).
Change the all-wheel-drive overrunning clutch and rear carrier fluid.*
INSPECT THE FOLLOWING:
Inspect the brake hoses.
Check the automatic transaxle fluid level.
Check the manual transaxle fluid level and fill-plug condition (SX 2.0,\
SRT-4
and PT Cruiser only, if equipped).
Check the coolant level, hoses and clamps.
Inspect the exhaust system.
*The all-wheel-drive power transfer unit fluid and overrunning clutch/re\
ar carrier fluid must be changed at
more frequent intervals than shown in schedule B if the vehicle is used \
for trailer tow, taxi, or other type of
commercial service.

DAIMLER CHR YSLER
D EALER STAMP
Signature of authorized DaimlerChrysler Canada dealer
2005 Passenger Car • Minivan • Pacifica
Odometer Reading
Date
Repair Order No.

Change engine oil and engine oil filter
(or every 3 months).
Inspect and lubricate, as required, all steering
and suspension components.
Inspect the engine air cleaner filter and replace if necessary
(Sebring, Pacifica and Minivan only).
Change the all-wheel-drive overrunning clutch
and rear carrier fluid.*
INSPECT THE FOLLOWING:
Inspect the brake hoses.
Check the automatic transaxle fluid level.
Check the manual transaxle fluid level and fill-plug
condition (SX 2.0, SRT-4 and PT Cruiser only,
if equipped).
Check the coolant level, hoses and clamps.
Inspect the exhaust system.
*The all-wheel-drive power transfer unit fluid and overrunning
clutch/rear carrier fluid must be changed at more frequent intervals
than shown in schedule B if the vehicle is used for trailer tow, taxi,
or other type of commercial service.
Maint enance Service Sc hedule “B”
235,0 00 km

Dealer Copy
Remove and attach to Repair Order 26-92-02-01 3N.
Maint enance Service
Sc hedule “B”
Odometer Reading
Date
240,0 00 km
Maint
enance Service Sc hedule “B”
240,0 00 km
Change engine oil and engine oil filter (or every 3 months).
Inspect and lubricate, as required, all steering and suspension componen\
ts.
Replace the engine air cleaner filter, if required. (All models).
Replace the Ignition cables (Minivan only).
Replace the Ignition cables (PT Cruiser, SRT-4, Sebring and SX 2.0 only\
).
Replace the spark plugs (PT Cruiser, SRT-4, Sebring and SX 2.0 only).
Replace the spark plugs (Pacifica and Minivan only).
Check and replace, if necessary, the PCV valve.
Inspect and replace, if required, the make-up air filter located inside \
the air cleaner
(PT Cruiser, SRT-4 and SX 2.0 only).
Inspect the serpentine drive belt, replace if necessary (Pacifica and M\
inivan only).
Adjust the generator belt tension (PT Cruiser, SX 2.0 and SRT-4 only).\
Inspect and adjust the power-steering pump belt tension (2.4L Sebring o\
nly).
Change the all-wheel-drive power transfer unit fluid.*
Rotate tires and check tire pressure.
INSPECT THE FOLLOWING:
Inspect the tie rod ends and boot seals (Pacifica, Minivan, PT Cruiser,\
SRT-4
and SX 2.0 only).
Inspect the brake hoses.
Check the automatic transaxle fluid level.
Check the manual transaxle fluid level and fill-plug condition (SX 2.0,\
SRT-4
and PT Cruiser only, if equipped).
Check the coolant level, hoses, and clamps.
Inspect the exhaust system.
*The all-wheel-drive power transfer unit fluid and overrunning clutch/re\
ar carrier fluid must
be changed at more frequent intervals than shown in schedule B if the ve\
hicle is used for trailer tow,
taxi, or other type of commercial service.

DAIMLER CHR YSLER
D EALER STAMP
Signature of authorized DaimlerChrysler Canada dealer
2005 Passenger Car • Minivan • Pacifica
Odometer Reading
Date
Repair Order No.

Change engine oil and engine oil filter (or every 3 months).
Inspect and lubricate, as required, all steering and suspension
components.
Replace the engine air cleaner filter, if required (All models).
Replace the Ignition cables (Minivan only).
Replace the Ignition cables (PT Cruiser, SRT-4, Sebring
and SX 2.0 only).
Replace the spark plugs (PT Cruiser, SRT-4, Sebring
and SX 2.0 only).
Replace the spark plugs (Pacifica and Minivan only).
Check and replace, if necessary, the PCV valve.
Inspect and replace, if required, the make-up air filter located
inside the air cleaner (PT Cruiser, SRT-4 and SX 2.0 only).
Inspect the serpentine drive belt, replace if necessary (Pacifica
and Minivan only).
Adjust the generator belt tension (PT Cruiser, SX 2.0
and SRT-4 only).
Inspect and adjust the power-steering pump belt tension
(2.4L Sebring only).
Change the all-wheel-drive power transfer unit fluid.*
Rotate tires and check tire pressure.
INSPECT THE FOLLOWING:
Inspect the tie rod ends and boot seals (Pacifica, Minivan,
PT Cruiser, SRT-4 and SX 2.0 only).
Inspect the brake hoses.
Check the automatic transaxle fluid level.
Check the manual transaxle fluid level and fill-plug condition
(SX 2.0, SRT-4 and PT Cruiser only, if equipped).
Check the coolant level, hoses, and clamps.
Inspect the exhaust system.
*The all-wheel-drive power transfer unit fluid and overrunning
clutch/rear carrier fluid must be changed at more frequent intervals
than shown in schedule B if the vehicle is used for trailer tow, taxi,
or other type of commercial service.
Maint enance Service Sc hedule “B”
240,0 00 km
