Page 92 of 292
5. Tachometer
The red area of the scale shows the maximum permissible
engine revolutions-per-minute (rpm x 1000) for each gear
range. Before reaching the red area (over 6,500 rpm), ease
up on the accelerator to prevent engine over speed.
6. Turn Signal Indicators
The arrows will flash in unison with the exterior turn
signal, when using the turn signal lever.
7. High Beam Indicator
This light shows that the headlights are on high
beam. Pull the turn signal lever toward the
steering wheel to switch the headlights from high or
low beam.
8. Speedometer
Shows the vehicle speed in miles-per-hour and
kilometers-per-hour.
9. Charging System Light
This light shows the status of the electrical
charging system. The light should come on
briefly when the ignition is first turned on and remain
on briefly as a bulb check. If the light stays on orcomes on while driving, turn off some of the vehicle’s
electrical devices, such as the Fog Lights or Rear
Defroster. If the Charging System Light remains on, it
means that the vehicle is experiencing a problem with
the charging system. Obtain SERVICE IMMEDI-
ATELY. See your local authorized dealer.
10. Malfunction Indicator Light
This light is part of an onboard diagnostic
system called OBD that monitors engine and
automatic transmission control systems. The
light will illuminate as long as the key is in the ON
position, prior to engine start up. Approximately 15
seconds later the MIL may blink for 10 seconds then
resume to full illumination. (See“EMISSIONS IN-
SPECTION AND MAINTENANCE PROGRAMS”in
the“MAINTAINING YOUR VEHICLE”section of
your Owner Manual for more details). If the bulb does
not come on when turning the key from OFF to ON,
have the condition checked promptly.
Certain conditions such as a loose or missing gas cap or
poor fuel quality may illuminate the light after engine
start. The vehicle should be serviced if the light stays on
92 UNDERSTANDING YOUR INSTRUMENT PANEL
Page 200 of 292
▫Appearance Care And Protection
From Corrosion......................229
Convertible Top Care...................234
▫Washing............................234
▫General Cleaning.....................235
▫Cloth Top Additional Cleaning Procedure....235
▫Cloth Top Protection...................236
▫Weather Strip Care....................236
Fuses...............................236
▫Underhood Fuses (Power
Distribution Center)...................236
▫Interior Fuses........................237
Vehicle Storage........................239
Replacement Light Bulbs................239
Bulb Replacement......................240
▫Headlight Bulb Replacement.............240
▫Park, Turn Signal, Sidemarker
Bulb Replacement.....................242
▫Fog Light Bulb Replacement.............243
▫Center Stoplight Bulb Replacement.........244
▫Rear Light Bulb Replacement.............244
▫License Plate Bulb Replacement...........245
▫Headlight Aiming.....................245
Fluids And Capacities...................246
Recommended Fluids, Lubricants And Genuine
Parts
...............................247
▫Engine.............................247
▫Chassis............................248
200 MAINTAINING YOUR VEHICLE
Page 239 of 292
VEHICLE STORAGE
If you are leaving your vehicle dormant for more than 21
days you may want to take steps to protect your battery.
You may:
•Disconnect the negative cable from the battery.
•Anytime you store your vehicle, or keep it out of
service (i.e. vacation) for two weeks or more, run the
air conditioning system at idle for about five minutes
in the fresh air and high blower setting. This will
insure adequate system lubrication to minimize the
possibility of compressor damage when the system is
started again.
REPLACEMENT LIGHT BULBS
LIGHT BULBS—Interior Bulb Number
Instrument Cluster..................... PC194
ABS Indicator........................ PC161
Fog Indicators........................ PC161
Floor Console, Courtesy Light, Door
Courtesy Light, Trunk Light................. 562
Climate Control Light...................... 37
Traction Control Light...................PC161
LIGHT BULBS—Exterior Bulb Number
Headlight.............................9007
Park/Turn Signal (Front).................3157A
Side/Marker (Front)...................... 168
Turn Signal (Rear)......................3757A
Fog Light.............................880L
Center Stop Light (CHMSL)......Dealer Service Item
Tail/Stop.............................3157
Tail Light.........................W3W/2821
Back Up Light.....................W16W/921
License Light......................W5W/2825
MAINTAINING YOUR VEHICLE 239
7
Page 240 of 292
BULB REPLACEMENT
Headlight Bulb Replacement
1. Open the hood and remove the two headlight mount-
ing screws.2. Remove the push-in fasteners by prying under the
head of the fasteners with a flat bladed tool.
240 MAINTAINING YOUR VEHICLE
Page 241 of 292
3. Gently pry the headlight assembly away from the
fender as shown in the picture. This will free the ball stud
from its retainer in the fender. Pull the headlight assem-
bly away from the vehicle.
4. Turn the retaining ring counterclockwise and remove
the bulb and socket assembly.5. Pull the bulb out of the socket and replace the bulb.
CAUTION!
Do not touch the new bulb with your fingers. Oil
contamination will severely shorten bulb life.
6. If the bulb comes in contact with any oily surface,
clean the bulb with rubbing alcohol.
MAINTAINING YOUR VEHICLE 241
7
Page 242 of 292
7. Reinsert the bulb and socket assembly and turn the
retaining ring clockwise to secure the bulb.
8. Reinstall the headlight assembly.
Park, Turn Signal, Sidemarker Bulb Replacement
1. Open the hood and remove the two headlight assem-
bly mounting screws. Pull the headlight assembly away
from the vehicle.2. Gently pry the headlight assembly away from the
fender as shown in the picture. This will free the ball stud
from its retainer in the fender. Pull the headlight assem-
bly away from the vehicle.
242 MAINTAINING YOUR VEHICLE
Page 243 of 292
3. Turn the bulb socket counterclockwise and remove the
bulb and socket assembly.
4. Pull the bulb out of the socket, replace the bulb, and
reinstall the bulb and socket to the headlight assembly.
Reinstall the headlight assembly.Fog Light Bulb Replacement
1. Remove the screw securing the light assembly to the
front fascia.
2. Pull the bulb and socket assembly away from the
vehicle to expose the bulb and socket assembly.
3. Disconnect the wiring connector from the bulb and
socket assembly.
MAINTAINING YOUR VEHICLE 243
7
Page 245 of 292
2. Disconnect the wiring connector as shown and re-
move the plastic retainers. Remove the light housing
from the vehicle.
3. Turn the bulb socket counterclockwise to remove it
from the housing. Remove the bulb and reinstall the bulb
and socket assembly.
4. Reinstall the light housing and reconnect the wiring
connector. Push the trunk liner back into place.
License Plate Bulb Replacement
1. Locate both small slots on the outboard side of the
license lamp. Using a small screwdriver, remove the
entire housing.
2. Turn the bulb socket counterclockwise to remove it
from the housing. Pull the bulb out of the socket. Replace
the bulb and snap it back into place on the housing of the
chrome appliqué.
Headlight Aiming
The headlights on your new vehicle were aimed at the
factory. The factory setting was made at a no load setting.
A great increase in weight will change the aiming and it
may be necessary to readjust the headlights if carrying an
excessive amount of weight in the trunk, rear seats or
pulling a trailer. To readjust the headlights first mark the
position of the headlights on a wall prior to loading the
vehicle. Load the vehicle and then readjust the headlights
to the original position. If any further adjustments are
necessary contact your manufacturer’s dealer. A detailed
service procedure is contained in the manufacturer’s
Service Manual. Information on purchasing a Service
Manual can be found at the back of this Owner’s Manual.
MAINTAINING YOUR VEHICLE 245
7
Page 283 of 292
Additives........................... 176
Clean Air........................... 175
Ethanol............................. 181
Filler Cap........................... 177
Filter.............................. 211
Gasoline............................ 174
Gauge.............................. 91
Hoses.............................. 227
Light............................... 96
Octane Rating........................ 247
Requirements.....................174,246
Tank Capacity........................ 246
Fueling.............................. 177
Fuses................................ 236
Garage Door Opener..................... 77
GasCap .............................. 177
Gas Gauge (Fuel Gauge).................. 91
Gasoline............................. 174
Gasoline, Clean Air..................... 175
Gasoline, Reformulated.................. 175
Gasoline/Oxygenate Blends............... 175Gauges
Coolant Temperature................... 93
Fuel................................ 91
Speedometer......................... 92
Tachometer.......................... 92
Voltmeter............................ 92
Gearshift............................. 149
General Information...................12,18
Glass Cleaning......................... 233
Hazard Warning Flasher.................. 186
Head Restraints......................... 65
Headlights............................ 240
Aiming............................. 245
Automatic........................... 70
Bulb Replacement..................... 240
Cleaning............................ 233
High Beam.........................71,92
High Beam/Low Beam Select Switch....... 71
Passing............................. 71
Switch.............................. 69
Time Delay........................70,71
Heater............................128,134
INDEX 283
10
Page 285 of 292
Bulb Replacement..................... 239
Check Engine......................... 92
Daytime Running...................... 70
Dimmer Switch, Headlight.............69,71
Engine Temperature Warning............. 93
Exterior Check........................ 45
Fog ...........................70,93,243
Front Replacement.................242,243
Headlight Switch...................... 69
Headlights........................... 69
High Beam........................... 71
Illuminated Entry...................... 12
Instrument Cluster..................... 69
Interior.............................. 67
License............................. 245
Lights On Reminder.................... 70
Low Fuel............................ 96
Malfunction Indicator................... 92
Map Reading......................... 67
Oil Pressure.......................... 94
Park............................... 242
Reading............................. 67
Rear Servicing....................... 244Seat Belt Reminder..................... 96
Security Alarm........................ 20
Service..........................239,240
Service Engine Soon (Malfunction Indicator) . . 92
Theft Alarm.......................... 96
Traction Control...................... 156
Turn Signal......................69,70,92
Voltage.............................. 92
Loading Vehicle........................ 179
Capacities........................... 179
Tires ............................... 160
Locks
Central.............................. 14
Door............................... 12
Ignition.............................. 9
Lower Anchors and Tether for
CHildren (LATCH)....................38,40
Lubricants............................ 216
Lubrication, Body....................... 216
Luggage/Cargo Capacity................. 179
Lumbar Support........................ 62
Maintenance Free Battery................. 213
INDEX 285
10
