Installation From Inside The Vehicle
1. Kneel on the rear seat and tuck the rear edge and side
edges of the top cover under the black molding near the
trunk.2. Insert both tabs located on the front of the top cover in
between the seatback and seatback bracket.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 51
3

3. Snap the top cover flaps to the inner trim panel snaps.
The side of the seat back cushion hides the snap.4. Press down on the forward portion of the top cover to
engage the hook and loop fasteners.
Top Cover FlapHook and Loop Fasteners
52 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Installation From Outside The Vehicle
1. Start on one side of the vehicle and tuck as much of the
top cover as possible under the black molding.2. Snap the top cover flap to the inner trim panel snap.
(The side of the seat back cushion hides the snap.)
Top Cover Flap
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 53
3

3. Tuck the top cover tab closest to you into the space
between the seatback and the seatback bracket.
4. Walk to the other side of the vehicle and finish tucking
the top cover under the black molding. Insert the remain-
ing tab between the seatback and the seatback bracket.5. Snap the remaining top cover flap to the inner trim
panel snap.
Top Cover Flap
54 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

6. Press down on the forward portion of the top cover to
engage the hook and loop fasteners.
Top Cover Removal
Unsnap the snaps and disengage the hook and loop
fasteners, slide the tabs from the rear seat and then from
the rear of the top storage area. Remove the top cover,
fold, and store in the trunk or a dry secure area.
CONSOLE FEATURES
The front console has two cup holders. An optional
removable ashtray may be located in the driver’s side cup
holder.
The center console/armrest has a pencil /tire gage holder
and a tissue holder mounted on the underside of the
cover. The bottom of the console bin also has built in
holders for compact discs or cassette tapes. The power
outlet is also mounted inside the center console (if
equipped). There are also two cup holders for rear seatHook and Loop Fasteners
Console Features
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 55
3

passengers and a rear courtesy lamp located directly in
back of the center console. The center console can be
locked using the “master” key.
Two coin holders are located toward the front of the
inside of the console bin. Both can also accommodate
various combinations of different types of coins, includ-
ing some international currencies. The slot on the far left
side is not for coins, but for an optional power outlet, if so
equipped.
MIRRORS
Inside Day/Night Mirror — If Equipped
Adjust the mirror to center on the view through the rear
window. A two point pivot system allows for horizontal
and vertical mirror adjustment. If the driver’s sunvisor
interferes with the mirror, the mirror can be moved to the
right to eliminate the interference.Annoying headlight glare can be reduced by moving the
small control under the mirror to the night position
(toward rear of vehicle). The mirror should be adjusted
while set in the day position (toward windshield).
Automatic Dimming Mirror — If Equipped
This mirror will automatically adjust for annoying head-
light glare from vehicles behind you. Push in the button
on the face of the mirror to activate the dimming feature.
Rearview Mirror
56 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

CAUTION!
To avoid damage to the mirror during cleaning,
never spray any cleaning solution directly onto the
mirror. Apply the solution onto a clean cloth and
wipe the mirror clean.
Electric Remote-Control Mirrors
Both of the outside mirrors can be adjusted by using the
remote controls mounted on the instrument panel located
to the left of the steering wheel.
NOTE:Place the mirror selector switch in the center
(neutral) position to prevent accidental movement of the
mirrors.
Automatic Dimming Mirror
Power Mirror Controls
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 57
3

Outside Mirror Adjustment — Driver’s Side
Adjust the outside mirror to center on the adjacent lane of
traffic, with a slight overlap of the view obtained on the
inside mirror.
Right Side Mirror Adjustment
Adjust the convex outside mirror so you can just see the
side of your vehicle in the part of the mirror closest to the
vehicle.
WARNING!
Vehicles and other objects seen in the right side
convex mirror will look smaller and farther away
than they really are. Relying too much on your right
side mirror could cause you to collide with another
vehicle or other object. Use your inside mirror when
judging the size or distance of a vehicle seen in this
convex mirror.
Illuminated Vanity Mirrors
An illuminated vanity mirror is on each sun visor. To use
the mirror, rotate the sun visor down and swing the
mirror cover upward. The lights will turn on automati-
cally. Closing the mirror cover turns off the lights.
Illuminated Vanity Mirror
58 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

SEATS
Manual Front Seat Adjustments
Forward/Rearward — If Equipped
The adjusting bar is at the front of the seats, near the
floor. Pull the bar up to move the seat to the desired
position.
Using body pressure, move forward and rearward on the
seat to be sure the seat adjusters have latched.
Reclining Bucket Seats
The recliner control is on the side of the seat. To recline,
lean forward slightly before lifting the lever, then lean
back to the desired position and release the lever. To
return the seat to the upright position, lean forward
slightly before lifting the lever, then lean forward to the
desired position and release the lever.
Manual Seat AdjusterManual Reclining Seat Control
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 59
3

WARNING!
•Adjusting a seat while the vehicle is moving is
dangerous. The sudden movement of the seat
could cause you to lose control. The seat belt
might not be properly adjusted and you could be
injured. Adjust the seat only while the vehicle is
parked.
•Do not ride with the seatback reclined so that the
shoulder belt is no longer resting against your
chest. In a collision you could slide under the seat
belt and be seriously or even fatally injured. Use
the recliner only when the vehicle is parked.
Lumbar Support — If Equipped
This feature allows you to increase or decrease the
amount of lumbar support. The control lever is located
on the inboard side of the driver’s seatback. Turn the
control lever forward to increase and rearward to de-
crease the desired amount of lumbar support.
Power Driver’s Seat
The power seat switches are on the outboard side of the
seat, near the floor. Use the forward switch to move the
front of the seat cushion up and down. Use the rear
switch to move the rear of the seat cushion up and down.
The middle switch will move either the entire seat
forward and rearward or the seat cushion up and down.
The rear lever controls the seatback reclining angle. The
seatback may have to be readjusted if the seat cushion
position is changed.
Power Driver’s Seat Switches
