FLUIDS AND CAPACITIES
EngineU.S. Metric
Fuel (approximate)
All Engines 16.9 gallons 64 liters
Engine Oil with Filter
2.4L Engine (SAE 5W-20, API Certified) 4.5 quarts 4.26 liters
2.7L Engine (SAE 5W-20, API Certified) 5.5 quarts 5.2 liters
3.5L Engine (SAE 10W-30, API Certified) 5.5 quarts 5.2 liters
Cooling System *
2.4L Engine (MopartAntifreeze/Coolant 5 Year/100,000 Mile For-
mula) or equivalent.7.7 quarts. 7.3 liters
2.7L Engine (MopartAntifreeze/Coolant 5 Year/100,000 Mile For-
mula) or equivalent.9.8 quarts. 9.3 liters
3.5L Engine (MopartAntifreeze/Coolant 5 Year/100,000 Mile For-
mula) or equivalent.11.6 quarts. 11.0 liters
* Includes heater and coolant recovery bottle filled to MAX level.
