▫Express Down Window Feature —
If Equipped......................... 25
▫Using The Panic Alarm................. 25
▫Programming Additional Transmitters...... 26
▫Battery Replacement................... 26
▫General Information................... 27
Remote Starting System — If Equipped....... 28
▫How To Use Remote Start............... 28
Door Locks........................... 30
▫Manual Door Locks................... 30
▫Power Door Locks.................... 31
Windows............................ 33
▫Power Windows...................... 33▫Wind Buffeting....................... 36
Trunk Lock And Release................. 36
Trunk Safety Warning................... 37
▫Trunk Internal Emergency Release......... 38
Occupant Restraints..................... 38
▫Lap/Shoulder Belts.................... 40
▫Lap/Shoulder Belt Untwisting Procedure.... 44
▫Seat Belt Pretensioners................. 45
▫Enhanced Seat Belt Reminder System
(BeltAlert) ......................... 46
▫Automatic Locking Mode............... 47
▫Seat Belts And Pregnant Women.......... 48
▫Seat Belt Extender..................... 48
10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

To Arm The System:
1. Remove the keys from the ignition switch and get out
of the vehicle.
2. Lock the door using either the power door lock switch
(one door must be open) or the LOCK button on the
Remote Keyless Entry (RKE) transmitter (doors can be
open or closed), and close all doors.
NOTE:The system will not arm if you lock the doors
with the manual door lock plungers.
3. The Vehicle Security Light in the instrument cluster
will flash rapidly for 16 seconds. This shows that the
system is arming. During this period, if a door is opened,
the ignition switch is turned ON, or the power door locks
are unlocked in any manner, the system will automati-
cally disarm. After 16 seconds, the indicator light will
flash slowly. This shows that the system is fully armed.NOTE:•During the 16 second arming period, if a door is
opened or the ignition switch is turned ON, the system
will automatically disarm.
•Once armed, the Vehicle Security Alarm system dis-
ables the unlock switch on the driver door trim panel
and passenger door trim panel, the trunk release
button on the instrument panel, and the HomeLink/
Garage Door Opener (if equipped).
To Disarm The System
Either press the UNLOCK button on the RKE transmitter
or insert a valid Sentry Keyinto the ignition lock
cylinder and turn the key to the ON/START position.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 19
2

2. Release both buttons at the same time.
3. Test the feature while outside of the vehicle, by
pressing the LOCK button on the RKE transmitter with
the ignition in the LOCK position, and the key removed.
4. Repeat these steps if you want to return this feature to
its previous setting.
NOTE:Pressing the LOCK button on the RKE transmit-
ter while you are in the vehicle will activate the Vehicle
Security Alarm. Opening a door with the Vehicle Security
Alarm activated will cause the alarm to sound. Press the
UNLOCK button to deactivate the Vehicle Security
Alarm System.
Convertible Top Operation Button — If Equipped
Refer to “Convertible Top Operation” under “Under-
standing The Features Of Your Vehicle” in Section 3 of
this manual.
To Unlatch the Trunk
Press the TRUNK button on the RKE transmitter two
times to unlatch the trunk.
Express Down Window Feature — If Equipped
This feature allows you to remotely lower both door and
rear quarter windows at the same time. To use this
feature, press and release the UNLOCK button on the
RKE transmitter and then immediately press and hold
the UNLOCK button until the windows lower to the level
desired or until they lower completely.
Using the Panic Alarm
To turn the Panic Alarm feature on or off, press and hold
the PANIC button on the RKE transmitter for at least one
second and release. When the Panic Alarm is on, the
headlights and park lights will flash, the horn will pulse
on and off, and the Illuminated Entry system (if
equipped) will turn on.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 25
2

Wind Buffeting
Wind buffeting can be described as the perception of
pressure on the ears or a helicopter type sound in the
ears. Your vehicle may exhibit wind buffeting with one
window down in certain open or partially open posi-
tions. This is a normal occurrence and can be minimized.
If the buffeting occurs with one window open, then open
both windows together to minimize the buffeting.
TRUNK LOCK AND RELEASE
To unlatch the trunk lid from inside the vehicle, press and
release the TRUNK RELEASE Button located on the
instrument panel to the left of the steering wheel.
NOTE:The convertible top must be either closed and
latched or open and latched.The trunk release button on the
dash will be disabled if the vehicle
is locked by pressing the power
door lock switch or by pressing
the LOCK button on the Remote
Keyless Entry (RKE) transmitter.
The trunk release button will be
enabled when the vehicle is un-
locked by the RKE or if the key is
inserted into the ignition and
turned to ON or START.
NOTE:This provides a locked area in the vehicle even
if the convertible top is open.
To unlatch the trunk lid from outside the vehicle, press
and release the TRUNK RELEASE button on the RKE
transmitter two times.
Trunk Release
Button
36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

Trunk Internal Emergency Release
As a security measure, a Trunk Internal Emergency Release
lever is built into the trunk latching mechanism. In the event
of an individual being locked inside the trunk, the trunk can
be simply opened by pulling on the glow-in-the-dark handle
attached to the trunk latching mechanism.
OCCUPANT RESTRAINTS
Some of the most important safety features in your
vehicle are the restraint systems. The following safety
features are standard on your vehicle:
•Three point lap and shoulder belts for all seating
positions
•Pretensioning and load-limiting retractors for the front
seat belts
•Advanced dual-stage driver and front passenger air-
bags
•New active-vent front passenger airbags
•Knee bolsters/blockers for front seat occupants
•An energy absorbing steering column and steering
wheel
•Supplemental seat side (Thorax) airbagsTrunk Internal Emergency Release
38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

CAUTION! (Continued)
Failure to follow these cautions can cause damage to
the convertible top components, trunk contents, and
the vehicle interior.
CAUTION!
•Do not operate the power top with the hydraulic
pump valve open.
•Do not allow the top to remain in the suspended
position. After approximately 10 minutes in the
suspended position, the hydraulic pressure will
release, which will allow the top and the trunk lid
to lower. Pressing the power top switch will cancel
this operation.
(Continued)
CAUTION! (Continued)
•Always use a normal ice scraper to remove snow or
ice from the rear window. Use of a sharp object or
other tools could scratch the fabric or panels when
removing snow or ice.
•Always close the top when leaving your vehicle so
as not to leave the interior exposed to potentially
damaging outdoor conditions.
•Do not leave the top lowered for several weeks at
a time. Close it occasionally to prevent discolora-
tion in the folds of the fabric and to allow the
creases to smooth out. This is especially important
if the top was stowed when not completely dry.
Failure to follow these cautions can cause damage
to the convertible top components, trunk contents,
and the vehicle interior.
84 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

INSTRUMENT PANEL FEATURES
1 — Air Outlet 6 — Radio 11 — Hazard Switch
2 — Side Window Demister Outlet 7 — Passenger Airbag 12 — Storage Compartment
3 — Instrument Cluster 8 — Glove Box 13 — Climate Control
4 — Ignition Switch 9 — Heated Seat Switch – If Equipped 14 — Trunk Release Switch
5 — Analog Clock 10 — Electronic Stability Program Off Button
– If Equipped15 — Power Top Switch 178 UNDERSTANDING YOUR INSTRUMENT PANEL

NOTE:You must apply the brakes before shifting from
PARK.
14. Odometer/Trip Odometer
The odometer shows the total distance the vehicle has
been driven. U.S. federal regulations require that upon
transfer of vehicle ownership, the seller certify to the
purchaser the correct mileage that the vehicle has been
driven. Therefore, if the odometer reading is changed
during repair or replacement, be sure to keep a record of
the reading before and after the service so that the correct
mileage can be determined.
The two trip odometers show individual trip mileage. To
switch from odometer to trip odometers, press and
release the Trip Odometer button. To reset a trip odom-
eter, display the desired trip odometer to be reset then
push and hold the button until the display resets (ap-
proximately 2 seconds). Refer to “Trip Odometer Button”
for additional information.Vehicle Warning Messages
When the appropriate conditions exist, “door,” “deck,”
“LoW TirE,” “CHAngE OIL,” “GASCAP” or “HOTOIL”
will display in the odometer.
NOTE:If the instrument cluster is equipped with the
optional Electronic Vehicle Information Center (EVIC),
then all warnings including ”Low Tire,” “Door Ajar” and
“Trunk Ajar” will only display in the EVIC. (Refer to
“Electronic Vehicle Information Center (EVIC)” in this
section for specific messages).
LoW TirE
When the appropriate condition exists the odometer
display will toggle between LoW and TirE for three
cycles.
HOTOIL
When this message is displayed there is an engine
over-temperature condition.
184 UNDERSTANDING YOUR INSTRUMENT PANEL

Oil (Engine).......................... 376
Power Steering........................ 282
Disabled Vehicle Towing................... 365
Disposal
Antifreeze (Engine Coolant)............... 392
Engine Oil........................... 379
Door Locks............................. 30
Door Locks, Automatic.................... 31
Door Opener, Garage..................... 158
Driver’s Seat Back Tilt.................... 140
Driving
On Slippery Surfaces.................... 279
Through Flowing, Rising, or Shallow
Standing Water........................ 280
E-85 Fuel............................. 330
Electric Rear Window Defrost............... 173
Electric Remote Mirrors................... 100
Electrical Power Outlets................... 164Electronic Speed Control (Cruise Control)...... 155
Electronic Stability Program (ESP)............ 294
Electronic Vehicle Information Center (EVIC).... 193
Emergency Deck Lid Release................ 37
Emergency, In Case of
Hazard Warning Flasher................. 352
Jacking............................. 354
Jump Starting......................... 361
Overheating.......................... 352
Towing............................. 365
Emergency Trunk Release................... 37
Emission Control System Maintenance......373,424
Engine..........................369,370,371
Air Cleaner.......................... 380
Block Heater......................... 270
Break-In Recommendations................ 72
Checking Oil Level..................... 376
Coolant (Antifreeze).................388,421
Cooling............................. 388
456 INDEX

Deck Lid Release....................... 36
Door Locks........................... 31
Mirrors............................. 100
Outlet (Auxiliary Electrical Outlet).......... 164
Seats............................... 135
Steering............................. 282
Windows............................. 33
Pregnant Women and Seat Belts.............. 48
Preparation for Jacking.................... 354
Pretensioners
Seat Belts............................. 45
Programmable Electronic Features............ 200
Programming Transmitters
(Remote Keyless Entry).................... 21
Radial Ply Tires......................... 309
Radiator Cap (Coolant Pressure Cap).......... 391
Radio Operation........................ 250
Radio Remote Controls.................... 248Radio, Satellite.......................... 243
Rear Cupholder......................... 169
Rear Window Defroster................... 173
Rear Window Features.................... 173
Recorder, Event Data...................... 60
Recreational Towing...................... 349
Reformulated Gasoline.................... 327
Refrigerant............................ 382
Release, Hood.......................... 142
Reminder, Lights On..................... 146
Reminder, Seat Belt....................... 46
Remote Control
Security Alarm......................... 18
Starting System........................ 28
Remote Keyless Entry (RKE)................. 21
Remote Sound System (Radio) Controls........ 248
Remote Starting System.................... 28
Remote Trunk Release..................... 36
Replacement Bulbs....................... 411
INDEX 465
10
