CHRYSLER SEBRING COUPE 2005 2.G Owners Manual

WARNING!
²Any maintenance performed on or near the com-
ponents of the SRS should be performed only by
an authorized dealer. Do not permit anyone else to
do service, inspection, maintenance or repair on
any SRS components or wiring. Similarly, no part
of the SRS should ever be handled, removed or
disposed of by anyone except at an authorized
dealer.
Improper work on the SRS components or wiring
could result in an accidental air bag deployment
or could make the SRS inoperative. Either of these
situation could result in serious injury.
²Do not modify your steering wheel or any other SRS
components or related vehicle part. For example,
replacement of the steering wheel, or modifications
to the front bumper or body structure can negatively
affect SRS performance and may lead to possible
injury.
²If your vehicle has received any front-end dam-
age, you should have the SRS inspected by an
authorized dealer to make sure it is in proper
working order.
WARNING!
²On vehicles with side air bags, do not modify
your front seats, center pillar or center console.
Such modifications can adversely affect SRS per-
formance and may lead to possible injury.
Also, if you discover any tear or open seam in the
seat fabric near the side air bag, have the seat
inspected by an authorized dealer.
²On vehicles with side air bags, if your vehicle has
received any damage on either side, you should
have the SRS inspected by an authorized dealer to
make sure it is in proper working order.
NOTE:
²
When you transfer ownership of the vehicle to another
person, we urge you to alert the new owner that it is
equipped with the SRS and refer that owner to the
applicable sections in this owner 's manual.
SEATS, SEAT BELTS, CHILD RESTRAINTS AND AIR BAGS 101
3

²If you decide to junk or scrap your vehicle, we urge
you to first take it to an authorized dealer so that the
SRS can be made safe for disposal.
Caution label
Passenger restraint warning/caution labels for the SRS
are located in the vehicle as shown in the illustration.
Transporting Pets
Airbags deploying in the front seat could harm your pet.
An unrestrained pet will be thrown about and possibly
injured, or injure a passenger during panic braking or in
a collision.
Pets should be restrained in the rear seat in pet harnesses
or pet carriers that are secured by seat belts.
102 SEATS, SEAT BELTS, CHILD RESTRAINTS AND AIR BAGS

INSTRUMENTS AND CONTROLS
CONTENTS
mInstrument cluster......................106
NMeter cluster.........................106
NIndicator and warning light package........107
NSpeedometer.........................108
NTachometer..........................108
NFuel gauge..........................109
NOdometer/Trip odometer................110
NEngine coolant temperature gauge..........111
NTurn signal indicators/hazard warning lights . . 112
NHigh beam indicator...................112
NTheft-alarm indicator...................112
NDoor-ajar warning light and chime.........112NAnti-lock braking system warning light
(if so equipped).......................113
NCruise/speed control indicator............189
NLow-fuel warning light and chime..........113
NFront fog light indicator.................114
NCharging system warning light............114
NOil pressure warning light...............114
NMalfunction indicator light
(SERVICE ENGINE SOON)...............115
NSupplemental Restraint System (SRS)-air bag
warning light.........................116
NBrake warning light....................117
NSeat belt reminder/warning light...........118
4

NChanging the setting for warning operation . . . 118
NAutomatic transaxle indicator
(if so equipped).......................119
NTraction Control System warning light
(if so equipped).......................119
NWasher fluid level indicator..............119
mCombination headlights, dimmer and
turn signal lever
.......................120
NHeadlights..........................120
NLight auto-cutout feature
(headlights, fog lights, etc.)...............123
NWhen you want to keep the lights on
(time delay)..........................120
NHeadlight reminder chime...............121
NHeadlight flasher (high/low beam).........121
NDimmer (high/low beam change)..........122
NTurn signals..........................122
mFog light switch........................123
mHazard warning flasher switch............124
mInstrument panel light dimmer control.......125
mElectric rear window defroster.............125
mWindshield wipers......................126
mIntermittent wipers.....................127
mWindshield washer.....................128
mPrecautions to observe when using wipers
and washers
..........................128
mDome light...........................129
mLights (dome lights, etc.) auto-cutout
function
.............................130
mReading lights.........................131
mRear personal lights.....................132
mHorn switch..........................132
mGarage door opener (if so equipped)........132
NTraining the Universal Transceiver..........133
104 INSTRUMENTS AND CONTROLS

NCanadian Programming/Gate Programming . . . 135
NOperation...........................136NReprogramming a Signal Button...........136
INSTRUMENTS AND CONTROLS 105
4

INSTRUMENT CLUSTER
Meter cluster
1. Fuel gauge
2. Tachometer
3. Speedometer
4. Engine coolant temperature gauge
5. Odometer6. Trip odometer
7. Trip odometer reset button
D01A1960
106 INSTRUMENTS AND CONTROLS

Indicator and warning light package
1. Washer fluid level indicator!P. 1 1 9
2. Anti-lock braking system warning light
(if so equipped)!P. 1 1 3
3. Low-fuel warning light!P. 1 1 3
4. Brake warning light!P. 1 1 75. Supplemental Restraint System (SRS) - air bag
warning light!P. 1 1 6
6. Seat belt reminder/warning light!P. 1 1 8
7. Turn signal indicators/hazard warning light!P. 1 1 2
8. Trunk-ajar warning light!P113
9. Front fog light indicator!P. 1 1 4
10. Door-ajar warning light!P. 1 1 2
D50A439D
INSTRUMENTS AND CONTROLS 107
4

11. High beam indicator!P. 1 1 2
12. Cruise control indicator!P. 1 1 3
13. Theft-alarm indicator!P. 1 1 2
14. Malfunction indicator light
(SERVICE ENGINE SOON)!P. 1 1 5
15. Oil pressure warning light!P. 1 1 4
16. Charging system warning light!P. 1 1 4
17. Overheating warning light!P. 1 1 6
18. Traction control system warning light
(if so equipped)!P. 1 1 9
19. Automatic transaxle indicator
(Vehicles with Autostick automatic transaxle-if so
equipped)!P. 1 1 9
Speedometer
The speedometer indicates vehicle speed.
·The outer scale indicates miles per hour.
·The inner scale indicates kilometers per hour.
Tachometer
The tachometer indicates engine revolutions per minute.
This allows the driver to determine the most efficient
gear range and engine speed combinations.
D04A0500
2.4 liter
engine3.0 liter
engine
108 INSTRUMENTS AND CONTROLS

CAUTION!
The red zone indicates an engine speed in excess of
safe operation.
Select the correct gear to control engine speed so the
tachometer indicator does not enter the red zone.
Fuel gauge
The gauge shows the amount of fuel in the fuel tank
when the ignition key is turned to the ``on'' position.
The arrow A indicates that the fuel lid (fuel filler port) is
located on the right side of the vehicle. (Refer to ªFuel
fillerº on page 39.)
NOTE: Just after refueling, it takes a little time until the
correct fuel level is indicated after turning on the ignition
switch.
D05A0430
INSTRUMENTS AND CONTROLS 109
4

Odometer/Trip odometer
When the ignition switch is turned to the ªONº position,
an ªODOº or ªTRIPº indication is given.
Every time the reset button (3) is pressed lightly (less
than one second), the indicators will change from ªODOº
to ªTrip Aº to ªTrip Bº.
1. Odometer
2. Trip odometer3. Reset button
ODO --- Odometer
The odometer indicates the total distance the vehicle has
travelled.
TRIP --- Trip odometer
The trip odometer indicates the distance traveled during
a particular trip or period.
As a feature, there are two trip odometer displays:
and.
D03F0320D03F0120
110 INSTRUMENTS AND CONTROLS
