CHRYSLER SEBRING COUPE 2005 2.G Owner's Guide

Using the panic alarm
If you are near your vehicle and feel threatened, you may
activate the alarm to call attention.
1. Press the PANIC button.
2. The headlights will blink on and off and the horn will
sound intermittently for about 3 minutes.
3. To turn off the alarm, press any button on the keyless
transmitter.
NOTE
1. The keyless entry system will not operate if the key is
in the ignition switch.
2. The keyless transmitter will operate within about 12 m
(39 ft) from the vehicle. However, the operating range
may change if the vehicle is located near a TV transmit-
ting tower, power station, or radio broadcasting station.
3. If the UNLOCK button is pressed when all doors are
closed and no door is opened within approximately 30
seconds, re-locking will automatically occur.
4. If the following conditions are observed after pressing
a keyless transmitter button, the battery in the keyless
transmitter may need to be replaced.
·The doors cannot be locked or unlocked.
·The trunk lid cannot be unlocked.
·The panic alarm cannot be operated.
5. Do not leave the keyless transmitter where it may be
exposed to heat caused by the direct rays of the sun.
6. If your transmitter is lost or damaged, please contact
an authorized dealer for a replacement.
F12D0360
PANIC
button
LOCKING AND UNLOCKING 31
2

7. If you wish to add another transmitter, contact an
authorized dealer. A maximum of 4 keyless transmitters
may be programmed for your vehicle.
CAUTION!
The keyless transmitter is a precision electronic
device. Therefore;
·Avoid impact to the transmitter.
·Keep the transmitter dry.
·Do not disassemble the transmitter.
Your keyless entry system operates on a radio frequency
subject to Federal Communications Commission (FCC)
Rules. This device complies with Part 15 of the FCC
Rules. Operation is subject to the following two condi-
tions.
·This device may not cause harmful interference.
·This device must accept any interference, including
interference that may cause undesired operation.
CAUTION!
Changes or modifications not expressly approved by
the manufacturer for compliance could void the
user's authority to operate the equipment.
Procedure for replacing keyless transmitter
battery
1. Remove the transmitter case mounting screw (A) and
gently pry open the case.
F12D0390T
32 LOCKING AND UNLOCKING

2. Remove the discharged battery from the panic button
side of the case half.
3. Install a new battery with its positive + side (2) down.
Coin type battery CR2032 used
4. Close the transmitter case firmly and tighten the
mounting screw.
5. Check the keyless entry system for operation.
NOTE
1. You may purchase a battery at any local store that sells
batteries.
2. Your authorized dealer can replace the battery for you
if necessary.
CAUTION!
When the transmitter is opened, be careful to keep
water, dust, etc. out. In addition, do not touch the
internal components.
F12D0280
+side
2
-side
LOCKING AND UNLOCKING 33
2

POWER DOOR LOCKS
Locking and unlocking with the door lock switch
All of the doors can be locked or unlocked by pressing
the power door lock switch on the driver's or the
passenger's door.
Rolling lock feature
If the vehicle's speed goes over 15 mph (25 km/h), all the
doors will lock automatically.
NOTE: The Rolling lock function can be turned ON or
OFF by the following procedures:
1. Insert the key in the ignition. Leave key in ªOFFº
position.
2. Close both the driver 's and passenger 's doors.
3. Press and hold the driver 's (central) door lock switch
until a chime sounds (10 seconds). The Rolling lock
feature will be switched to ON (if it is OFF) or OFF (if it
is ON).
If the chime sounds once, the Rolling lock feature is ON.
If the chime sounds twice, the Rolling lock feature is OFF.
F12B0850
Driver side switch Passenger side switch
Lock
UnlockLock
Unlock
34 LOCKING AND UNLOCKING

Locking and unlocking with key or inside lock
knob
Using the key to lock or unlock the driver 's door will
automatically lock or unlock all of the doors.
·Turn the key inserted in the driver 's door lock once in
the unlocking direction, and the front driver 's door
will be unlocked.
·Give another turn in the unlocking direction, and both
doors will be unlocked.
Locking by means of the inside lock knob
Place the inside lock knob of the driver's door in the
locked position, and both doors will be locked.
TRUNK LID
WARNING!
²It is dangerous to drive with the trunk lid open
since carbon monoxide (CO) gas can enter the
cabin. CO is an invisible, odorless gas that can
cause unconsciousness and even death.
²Do not allow children to have access to the trunk,
either by climbing into the trunk from outside or
through the inside of the vehicle. Always close the
trunk lid when your vehicle is unattended. If
trapped in the trunk, it is possible to escape from
the trunk by using the inside emergency trunk
release handle. (See ``Inside emergency trunk re-
lease'' on Page 37).
F12B0710
Lock Unlock
Lock
LOCKING AND UNLOCKING 35
2

CAUTION!
Do not stand behind the exhaust pipe when loading
and unloading luggage. Heat from the exhaust could
lead to burns.
To open the trunk lid
Press the TRUNK button twice within five seconds.
(Refer to ``Keyless entry system'' on page 29.)
The trunk lid will unlock and rise slightly.
Lift it to open.
To close the trunk lid
Lower the trunk lid and push down with both hands
until it is locked.
Trunk-ajar warning chime
When the vehicle is moving at more than 5 mph (8 km/h)
and the trunk lid is open, a chime will sound to inform
the driver that the trunk lid is not properly shut.
Remote trunk lid release
Pull the trunk lid release lever, located to the left of the
driver's seat, up to open the trunk lid.
CAUTION!
Do not operate the trunk lid release lever while the
vehicle is moving. If the trunk lid opened, luggage
could fall onto the road and cause an accident.
F15A1770
36 LOCKING AND UNLOCKING

Inside emergency trunk release
The emergency trunk release is designed to provide a way to
open the trunk lid from inside the trunk. It was developed to
help prevent death and serious heat-related injuries, includ-
ing brain damage, especially for children who might become
locked inside a vehicle trunk.
The illuminated9T9shaped yellow emergency trunk release
handle (see illustration) is mounted near the latch inside the
trunk lid. Velcro keeps the handle secure in its holder.The handle glows in the dark after exposure to sunlight.
You and your family should familiarize yourselves with the
location and operation of the emergency trunk release
handle. Children should be taught not to play in or around
vehicles.
WARNING!
²Children should never be left unsupervised in or
around vehicles.
²Unsupervised children could lock themselves in
an open vehicle or trunk.
²People trapped inside a vehicle, or trunk, even if
only for a short period of time, can quickly die
from suffocation or heat stroke, especially on hot
days. Interior temperatures in vehicles can rise in
minutes.
²Keep your vehicle doors locked and the trunk
closed when not in use. Keep your vehicle keys
away from children.
F15A2350
LOCKING AND UNLOCKING 37
2

To open the trunk from inside the trunk, tear off the
illuminated9T9handle from its holder by pulling in the
direction of the arrow (1). Then pull the handle in the
direction of the arrow (2). Push up on the trunk to exit.
CAUTION!
²When loading objects in the trunk, position them
so that they will not contact the emergency trunk
release handle when closing the trunk. This will
prevent damage to the handle that could render it
inoperable.
²Always keep the handle in its holder when oper-
ating the vehicle to prevent trunk cargo from
moving the handle that might result in the open-
ing of the trunk lid.
F15A2180
1. Tear off
2. PullHandle
Holder
38 LOCKING AND UNLOCKING

FUEL FILLERWARNING!
²Remove the fuel tank filler tube cap (gas cap)
slowly to prevent fuel spray from the filler neck
which may cause injury.
²The volatility of some gasolines may cause a build
up of pressure in the fuel tank that may increase
while you drive. This pressure can result in a
spray of gasoline and/or vapors when you remove
the cap from a hot vehicle. Removing the cap
slowly allows the pressure to vent and prevents
fuel spray.
²Never have any smoking materials lit in or near
the vehicle when the gas cap is removed or the
tank filled.
²Never add fuel when the engine is running. This
is in violation of most state and federal fire
regulations and will cause the malfunction indi-
cator light to turn on.
C20A1160
LOCKING AND UNLOCKING 39
2

The fuel filler is located on the right rear of the body.
Hook a finger behind the fuel filler door, and pull the
door toward you.
Remove the fuel tank filler tube cap slowly by turning it
counterclockwise.
To close, securely turn the fuel tank filler tube cap
clockwise until you hear clicking sounds, and gently
push the fuel filler tank door into the closed position.Low fuel warning chime
If a chime sounds when the low fuel warning light is on,
that means the fuel is low.
NOTE: If the low fuel warning light goes off, then comes
back on again, the chime will not sound.
Fuel tank capacity 62 L (16.4 gal)
CAUTION!
²As the fuel system may be under pressure, remove the
fuel tank filler tube cap slowly. Removing the cap
slowly relieves any pressure or vacuum that might have
built up in the fuel tank. If the cap is venting vapor or
if you hear a hissing sound, wait until it stops before
completely removing the cap. Otherwise, fuel may
spray out and injure you or others.
²If you need to replace the fuel tank filler tube cap,
use only a cap specified for your model vehicle.
²To avoid fuel spillage and overfilling, do not ªtop-offº
the fuel tank again and again after filling.
C20A1140
RemoveClose
