1. Wear eye protection and remove any metal jewelry
such as watch bands or bracelets that might make an
inadvertent electrical contact.
2. When boosting from a battery in another vehicle, park
that vehicle within booster cable reach but without
letting the vehicles touch. Set parking brake, place auto-
matic transaxle in PARK and turn ignition to OFF for
both vehicles.
WARNING!
Do not permit vehicles to touch each other as this
could establish a ground connection and personal
injury could result.
3. Turn off the heater, radio and all unnecessary electrical
loads.
4. Remove the protective cover over the remote jump-
start positive battery post(+)in the engine compartment.
Connect one end of the jumper cable to the positive
battery post. Connect the other end of the same cable tothe positive terminal of the booster battery. Refer to the
following illustration for jump-starting connections.
5. Connect the other cable, first to the negative terminal
of the booster battery andthen to the engine ground (-)
of the vehicle with the discharged battery.Make sure
you have a good contact on the engine ground. Refer to
the following illustration for jump-starting connections.
Jump-Starting Location
WHAT TO DO IN EMERGENCIES 281
6

6. If the vehicle is equipped with Sentry Key Immobi-
lizer, turn the ignition switch to the ON position for 3
seconds before moving the ignition switch to the START
position.
7. Start the engine in the vehicle that has the booster
battery, let the engine idle a few minutes, then start the
engine in the vehicle with the discharged battery.
8. When removing the jumper cables, reverse the se-
quence exactly. Be careful of the moving belts and fan.
9. Reinstall the protective cover over the remote jump-
start positive battery post.
WARNING!
•During cold weather when temperatures are be-
low freezing point, electrolyte in a discharged
battery may freeze. Do not attempt jump-starting
because the battery could rupture or explode. The
battery temperature must be brought up above
freezing point before attempting jump-start.
NOTE:To access the battery for service or replacement
refer to “Maintenance Procedures” in theMAINTAIN-
ING YOUR VEHICLEsection of this manual.
FREEING A STUCK VEHICLE
NOTE:
If your vehicle is equipped with Traction Con-
trol, turn the system OFF before attempting to “rock” the
vehicle.
If your vehicle becomes stuck in mud, sand or snow, it
can often be moved by a rocking motion. Turn your
steering wheel right and left to clear the area around the
front wheels. Then shift back and forth between Reverse
and First gear. Usually the least accelerator pedal pres-
sure to maintain the rocking motion without spinning the
wheels is most effective.
282 WHAT TO DO IN EMERGENCIES

WARNING!
Fast spinning tires can be dangerous. Forces gener-
ated by excessive wheel speeds may cause axle, tire
damage or failure. A tire could explode and injure
someone. Do not spin your vehicle’s wheels faster
than 30 mph (48 km/h) or for longer than 30 seconds
continuously without stopping when you are stuck.
And don’t let anyone near a spinning wheel, no
matter what the speed.
CAUTION!
Racing the engine or spinning the wheels too fast
may lead to transaxle overheating and failure. It can
also damage the tires. Do not spin the wheels above
30 mph (48 km/h). Do not spin the wheels continu-
ously for more than 30 seconds.
TOWING A DISABLED VEHICLE
With Ignition Key
Automatic And Manual Transaxle
Front-wheel-drive vehicles must have the front wheels
elevated; all-wheel-drive vehicles must be hauled on a
flatbed truck.
All Transaxles
CAUTION!
If the vehicle being towed requires steering, the
ignition switch must be in the ACCESSORY posi-
tion, not in the LOCK position.
Do not attempt to use sling type equipment when
towing. When securing vehicle to flat bed truck, do
not attach to front or rear suspension components.
Damage to your vehicle may result from improper
towing.
WHAT TO DO IN EMERGENCIES 283
6

If it is necessary to use the accessories while being towed
(wipers, defrosters, etc.), the key must be in the ON
position, not the ACCESSORY position. Make certain the
transaxle remains in NEUTRAL.
Without The Ignition Key
Special care must be taken when the vehicle is towed
with the ignition in the LOCK position. A dolly should be
used under the front wheels if the rear wheels are raised.
Proper towing equipment is necessary to prevent dam-
age to the vehicle.
Battery power is required to release the brake/
transmission interlock system. There is an override sys-
tem that allows you to shift out of Park in case of loss of
power. To activate the override system, remove the cup
holder liner, insert a key, screwdriver or finger into the
front hole and push the lever forward.
Towing This Vehicle Behind Another Vehicle (Flat
Towing With All Four Wheels On The Ground)
CAUTION!
DO NOT flat tow this vehicle. Damage to the driv-
etrain will result.
284 WHAT TO DO IN EMERGENCIES

MAINTAINING YOUR VEHICLE
CONTENTS

2.4L Engine Compartment...............287

2.7L Engine Compartment...............288

3.5L Engine Compartment...............289

Onboard Diagnostic System — OBD II......290
▫Loose Fuel Filler Cap Message............290

Emissions Inspection And
Maintenance Programs
..................291

Replacement Parts.....................292

Dealer Service........................292

Maintenance Procedures.................293
▫Engine Oil..........................293
▫Spark Plugs.........................297▫Catalytic Converter....................298
▫Crankcase Emission Control System........299
▫Fuel Filter..........................299
▫Air Cleaner Element (Filter)..............299
▫Maintenance-Free Battery................300
▫Air Conditioner Maintenance.............301
▫Power Steering — Fluid Check............302
▫Front Suspension Ball Joints..............302
▫Body Lubrication.....................303
▫Windshield Wiper Blades................303
▫Windshield Washer Reservoir.............304
7

▫Exhaust System......................304
▫Cooling System.......................305
▫Hoses And Vacuum/Vapor Harnesses.......309
▫Fuel System Connections................309
▫Brake System........................310
▫Automatic Transaxle...................312
▫Appearance Care And Protection
From Corrosion......................313
▫Cleaning The Center Console Cup Holders . . . 317

Fuses/Totally Integrated Power
Module (TIPM)
.......................318

Vehicle Storage........................321

Replacement Bulbs.....................321

Bulb Replacement......................322
▫Head Lamp Bulb Replacement............322
▫Fog Lamps..........................323
▫Tail Lamps, Rear Turn Signals And
Backup Lamps — Replacement...........324
▫License Plate Lamp — Rear..............326
▫Center High-Mounted Stop Lamp..........326

Fluids And Capacities...................327

Fluids, Lubricants, And Genuine Parts......328
▫Engine.............................328
286 MAINTAINING YOUR VEHICLE

2.4L ENGINE COMPARTMENT
2.4L Engine
MAINTAINING YOUR VEHICLE 287
7

2.7L ENGINE COMPARTMENT
2.7L Engine
288 MAINTAINING YOUR VEHICLE

3.5L ENGINE COMPARTMENT
3.5L Engine
MAINTAINING YOUR VEHICLE 289
7

ONBOARD DIAGNOSTIC SYSTEM — OBD II
Your vehicle is equipped with a sophisticated onboard
diagnostic system called OBD II. This system monitors
the performance of the emissions, engine, and automatic
transmission control systems. When these systems are
operating properly, your vehicle will provide excellent
performance and fuel economy, as well as engine emis-
sions well within current government regulations.
If any of these systems require service, the OBD II system
will turn on the “Malfunction Indicator Light.” It will
also store diagnostic codes and other information to
assist your service technician in making repairs. Al-
though your vehicle will usually be drivable and not
need towing, see your dealer for service as soon as
possible.CAUTION!
•Prolonged driving with the “Malfunction Indica-
tor Light” on could cause further damage to the
emission control system. It could also affect fuel
economy and driveability. The vehicle must be
serviced before any emissions tests can be per-
formed.
•If the “Malfunction Indicator Light” is flashing
while the engine is running, severe catalytic con-
verter damage and power loss will soon occur.
Immediate service is required.
Loose Fuel Filler Cap Message
After fuel is added, the vehicle diagnostic system can
determine if the fuel filler cap is loose or improperly
installed. A GASCAP message will be displayed in the
instrument cluster. Tighten the gas cap until aclicking
sound is heard. This is an indication that the gas cap is
properly tightened. Press the odometer reset button to
turn the message off. If the problem persists, the message
will appear the next time the vehicle is started. This
