CHRYSLER SEBRING SEDAN 2007 3.G Owners Manual

VEHICLE STORAGE
If you will not be using your vehicle for more than 21
days you may want to take steps to preserve your battery.
You may:
•Disengage the mini fuse in the Power Distribution
Center labeled IOD (Ignition Off-Draw).
•Or, disconnect the negative cable from the battery.
REPLACEMENT BULBS
All the inside bulbs are brass or glass wedge base.
Aluminum base bulbs are not approved and should not
be used for replacement.
LIGHT BULBS — Interior Bulb Number
Front Courtesy/Reading Lights..........578/W5W
Center Courtesy/Reading Lights.........578/W5W
Visor Vanity Lights.....................A6220
Glove Box Light......................... 194
Shift Indicator Light................. JKLE14140
Rear Compartment (Trunk) Light............. 579
NOTE:For lighted switches, see your dealer for re-
placement instructions.LIGHTS BULBS — Outside Bulb No.
Low Beam Headlight.....................9006
High Beam Headlight.....................9005
Front Park/Turn Signal/Side Marker Light. . . 3157AK
Front Fog Light.......9145//H10 (Serviced at Dealer)
Center High Mounted
Stop Light (CHMSL)............... LEDAssembly
Rear Tail/Stop..........................3057
Rear Turn Signal......................3157AK
Backup Light..................... W16W(921)
License Light........................... 168
MAINTAINING YOUR VEHICLE 321
7

BULB REPLACEMENT
Head Lamp Bulb Replacement
1. Open the hood and remove the two head lamp mount-
ing screws.
2. Remove the push-in fasteners by prying under the
head of the fasteners with a flat bladed tool.3. Gently pry the head lamp assembly away from the
fender as shown in the picture. This will free the ball stud
from its retainer in the fender. Pull the head lamp
assembly away from the vehicle.
4. Rotate bulb and connector
14turn counterclockwise.
5. Pull the bulb out of the socket and replace the bulb.Removing Head Lamp For Bulb Replacement
Gently Pry Out Head Lamp
322 MAINTAINING YOUR VEHICLE

CAUTION!
Do not touch the new bulb with your fingers. Oil
contamination will severely shorten bulb life.
6. If the bulb comes in contact with any oily surface,
clean the bulb with rubbing alcohol.
7. Reinsert the bulb and socket assembly and rotate
clockwise
14turn to secure.
8. Reinstall the head lamp assembly.
Fog Lamps
1. Access to the lamps through the lower fascia cutout is
limited.
2. We recommend you access the lamps by turning the
steering wheel to allow access and remove the inner
fender shield.3. Rotate bulb and connector
14turn counterclockwise.
4. Pull bulb off of connector and replace with a new one.
CAUTION!
Do not touch the new bulb with your fingers. Oil
contamination will severely shorten bulb life. If the
bulb comes in contact with an oily surface, clean the
bulb with rubbing alcohol.
MAINTAINING YOUR VEHICLE 323
7

Tail Lamps, Rear Turn Signals And Backup
Lamps — Replacement
The tail lamps are a two piece design. The turn signal,
brake and tail lamps are located in the rear corner body
panel housing. The back up and tail lamps are located in
the trunk lid housing.
Changing the Rear Corner Tail Lamp Bulbs
1. Open the trunk and gently pull back the trunk liner
behind the tail lamp
Split Tail Lamp Assembly
Pull Back Trunk Liner
324 MAINTAINING YOUR VEHICLE

2. Remove the two plastic wing nuts from the tail lamp
housing.
3. Grasp the tail lamp and pull firmly outward pushing
gently on the studs from inside to disengage the lamp
housing.
4. Twist and remove socket from lamp.
5. Remove bulb from socket and replace.Changing the Trunk Lid Tail Lamps
1. With the trunk lid open, unplug the lamp assembly.
2. Remove and replace the bulb.
3. Reinstall the lamp assembly locking in place.
Location Plastic Wing NutsTrunk Lid Tail Lamp
MAINTAINING YOUR VEHICLE 325
7

License Plate Lamp — Rear
1. Remove two retaining screws holding the lamp lens in
place.
2. Gently pry the lens loose.
3. Pull bulb from socket, replace and reattach the lamp
lens with the two retaining screws.
Center High-Mounted Stop Lamp
1. Open the trunk lid to find the centrally located high-
mounted stop lamp.
2. Twist and remove socket from lamp.
3. Replace the bulb and reinstall the lamp assembly
locking in place with a twist.
Location and Removal of Rear License Lamp LensHigh-mounted Stop Lamp Bulb Replacement
326 MAINTAINING YOUR VEHICLE

FLUIDS AND CAPACITIES
U.S. Metric
Fuel (approximate)
2.4L, 2.7L and 3.5 Liter Engine 16.9 gallons 64 liters
Engine Oil with Filter
2.4 Liter Engine (SAE 5W-20, API Certified) 4.5 quarts 4.26 liters
2.7 Liter Engine (SAE 5W-20, API Certified) 5.5 quarts 5.2 liters
3.5 Liter Engine (SAE 10W-30, API Certified) 5.5 quarts 5.2 liters
Cooling System *
2.4 Liter Engine (MoparAntifreeze/Coolant 5 Year/100,000 Mile For-
mula) or equivalent.7.7 quarts. 7.3 liters
2.7 Liter Engine (MoparAntifreeze/Coolant 5 Year/100,000 Mile For-
mula) or equivalent.9.8 quarts. 9.3 liters
3.5 Liter Engine (MoparAntifreeze/Coolant 5 Year/100,000 Mile For-
mula) or equivalent.11.6 quarts. 11.0 liters
* Includes heater and coolant recovery bottle filled to MAX level.
MAINTAINING YOUR VEHICLE 327
7

FLUIDS, LUBRICANTS, AND GENUINE PARTS
Engine
Component Fluids, Lubricants, and Genuine Parts
Engine Coolant MoparAntifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hybrid
Organic Additive Technology) or equivalent
Engine Oil (2.4 & 2.7 Liter) Use API Certified engine oil. SAE 5W-20 is recommended. Refer to the en-
gine oil fill cap for the correct SAE grade meeting DaimlerChrysler Mate-
rial Standard MS-6395.
Engine Oil (3.5 Liter) Use API Certified engine oil. SAE 10W-30 is recommended. Refer to the
engine oil viscosity chart for the correct SAE grade meeting
DaimlerChrysler Material Standard MS-6395.
Oil Filter (2.4 Liter) Mopar04884900AB or equivalent.
Oil Filter (2.7 & 3.5 Liter) Mopar05281090 or equivalent.
Spark Plugs Refer to the Vehicle Emission Control Information label in the engine com-
partment.
Fuel Selection (2.4 & 2.7 Liter) 87 Octane
Fuel Selection (3.5 Liter) 87 to 89 Octane
328 MAINTAINING YOUR VEHICLE

Chassis
Component Fluids, Lubricants and Genuine Parts
Automatic Transmission MoparATF+4 Automatic Transmission Fluid.
Brake Master Cylinder MoparDOT 3 and SAE J1703 should be used. If DOT 3 brake fluid is not
available, then DOT 4 is acceptable. Use only recommended brake fluids.
Power Steering Reservoir MoparATF+4 Automatic Transmission Fluid.
MAINTAINING YOUR VEHICLE 329
