CHRYSLER SEBRING SEDAN 2007 3.G Owners Manual

Miles 78,000 81,000 84,000 87,000 90,000
(Kilometers ) (130 000) (135 000) (140 000) (145 000) (150 000)
Change engine oil and oil filter,or at 3 months,
whichever comes first.X X XXX
Replace engine air cleaner filter.X
Rotate tires. X X X
Check spare tire for proper pressure and correct
stowage.XXX
Inspect brake linings.X
Replace Spark Plugs:2.4L EngineX
SCHEDULE “B” 341
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 93,000 96,000 99,000 102,000 105,000
(Kilometers) (155 000) (160 000) (165 000) (170 000) (175 000)
Change engine oil and oil filter,or at 3 months,
whichever comes first.X X XXX
Replace engine air cleaner filter.X
Rotate tires. X X
Check spare tire for proper pressure and correct
stowage.XX
Replace Spark Plugs:2.7L and 3.5L Engines X
Flush and replace engine coolantif not done at 60
months. (Flush and replace engine coolant at 60
months, or 102,000 miles (170 000 km) whichever
comes first.X
342 SCHEDULE “B”
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 108,000 111,000 114,000 117,000 120,000
(Kilometers) (180 000) (185 000) (190 000) (195 000) (200 000)
Change engine oil and oil filter,or at 3 months,
whichever comes first.X XXXX
Replace engine air cleaner filter.X
Rotate tires. X X X
Check spare tire for proper pressure and correct
stowage.XXX
Inspect brake linings. X
Change Automatic Transaxle Fluid and Filter.X
Replace Spark Plugs:2.4L EngineX
Replace the accessory drive belt every 120,000
miles (200 000 km).X
SCHEDULE “B” 343
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Schedule “A”
Miles 6,000 12,000 18,000 24,000 30,000
(Kilometers) (10 000) (20 000) (30 000) (40 000) (50 000)
[Months] [6] [12] [18] [24] [30]
Change engine oil and oil filter.X X XXX
Replace engine air cleaner filter.X
Rotate tires. X X X X X
Check spare tire for proper pressure and correct
stowage.X X XXX
Inspect brake linings. X
Replace Spark Plugs:2.4L EngineX
344 SCHEDULE “A”
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 36,000 42,000 48,000 54000 60,000
(Kilometers) (60 000) (70 000) (80 000) (90 000) (100 000)
[Months] [36] [42] [48] [54] [60]
Change engine oil and oil filter.X X XXX
Replace engine air cleaner filter.X
Rotate tires. X X X X X
Check spare tire for proper pressure and correct
stowage.X X XXX
Inspect brake linings. X X
Flush and replace engine coolantat 60 months, if
not replaced at 102,000 miles (170 000 km).X
Replace Spark Plugs:2.4L EngineX
SCHEDULE “A” 345
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 66,000 72,000 78,000 84,000 90,000
(Kilometers) (110 000) (120 000) (130 000) (140 000) (150 000)
[Months] [66] [72] [78] [84] [90]
Change engine oil and oil filter.XXXXX
Replace engine air cleaner filter.X
Rotate tires. X X X X X
Check spare tire for proper pressure and correct
stowage.XXXXX
Inspect brake linings. X X
Replace Spark Plugs:2.4L EngineX
346 SCHEDULE “A”
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 96,000 102,000 108,000 114,000 120,000
(Kilometers) (160 000) (170 000) (180 000) (190 000) (200 000)
[Months] [96] [102] [108] [114] [120]
Change engine oil and oil filter.XXXXX
Replace engine air cleaner filter.X
Rotate tires. X X X X X
Check spare tire for proper pressure and correct
stowage.XXXXX
Inspect brake linings. X
Change Automatic Transaxle Fluid and Filter.X
Flush and replace engine coolant,102,000 miles
(170 000 km) if not done at 60,000 milesX
Replace Spark Plugs:2.4L EngineX
Replace Spark Plugs:2.7L and 3.5L Engines X
Replace the accessory drive belt every 120,000
miles (200 000 km).X
SCHEDULE “A” 347
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Inspection and service should also be performed anytime
a malfunction is observed or suspected. Retain all re-
ceipts.WARNING!
You can be badly injured working on or around a
motor vehicle. Do only that service work for which
you have the knowledge and the right equipment. If
you have any doubt about your ability to perform a
service job, take your vehicle to a competent me-
chanic.
348 SCHEDULE “A”
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

IF YOU NEED CONSUMER ASSISTANCE
CONTENTS

Suggestions For Obtaining Service For
Your Vehicle
..........................350
▫Prepare For The Appointment............350
▫Prepare A List........................350
▫Be Reasonable With Requests.............350

If You Need Assistance..................350

Warranty Information (U.S. Vehicles Only)...352

MoparParts.........................352

Reporting Safety Defects.................353
▫In Canada..........................353

Publication Order Forms.................353

Department Of Transportation Uniform Tire
Quality Grades
........................354
▫Treadwear..........................355
▫Traction Grades......................355
▫Temperature Grades...................355
9

SUGGESTIONS FOR OBTAINING SERVICE FOR
YOUR VEHICLE
Prepare For The Appointment
If you’re having warranty work done, be sure to have the
right papers with you. Take your warranty folder. All
work to be performed may not be covered by the
warranty, discuss additional charges with the service
manager. Keep a maintenance log of your vehicle’s
service history. This can often provide a clue to the
current problem.
Prepare A List
Make a written list of your vehicle’s problems or the
specific work you want done. If you’ve had an accident,
or work done that is not on your maintenance log, let the
service advisor know.
Be Reasonable With Requests
If you list a number of items, and you must have your
vehicle by the end of the day, discuss the situation with
the service advisor and list the items in order of priority.
At many dealers, you may obtain a rental vehicle at aminimal daily charge. If you need a rental, it is advisable
to make these arrangements when you call for an ap-
pointment.
IF YOU NEED ASSISTANCE
The manufacturer and its dealers are vitally interested in
your satisfaction. We want you to be happy with our
products and services.
Warranty service must be done by an authorized
Chrysler, Dodge, or Jeep dealer. We strongly recommend
that you take your vehicle to your selling dealer. They
know you and your vehicle best, and are most concerned
that you get prompt and high quality service. The
manufacturer’s dealers have the facilities, factory-trained
technicians, special tools, and the latest information to
assure your vehicle is fixed correctly and in a timely
manner.
This is why you should always talk to your dealer’s
service manager first. Most matters can be resolved with
this process.
350 IF YOU NEED CONSUMER ASSISTANCE
