CHRYSLER TOWN AND COUNTRY 2004 4.G Warranty Booklet
Manufacturer: CHRYSLER, Model Year: 2004, Model line: TOWN AND COUNTRY, Model: CHRYSLER TOWN AND COUNTRY 2004 4.GPages: 131, PDF Size: 1.07 MB
Page 41 of 131
Odometer Reading
Date
Repair Order No.
DAIMLER CHR YSLER
D EALER STAMP
Signature of authorized DaimlerChrysler Canada dealer
l Change engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate, as required, all steering and suspension components.
l Inspect the engine air cleaner filter and replace if necessary(Sebring, Sebring Convertible, PT Cruiser, SRT-4 and
SX 2.0 only).
l Replace the engine air cleaner filter if required (Pacifica,Minivan, Concorde, Intrepid and 300M only).
l Inspect and replace, if required, the make-up air filter located inside the air cleaner (PT Cruiser and SX 2.0 only).
l Adjust the drive belt tension (Concorde, Intrepid and 300M only).
l Check and retention power steering pump belt (2.4L Minivan only).
l Check the generator belt, replace if necessary (2.4L Minivan only).
l Change the all-wheel-drive power transfer unit fluid.*
INSPECT THE FOLLOWING: l Inspect the brake hoses.
l Check the automatic transaxle fluid level.
l Check the manual transaxle fluid level and fill plug condition (if equipped).
l Check the coolant level, hoses and clamps.
l Inspect the exhaust system.
*All-wheel-drive power transfer unit fluid and overrunning clutch/rear carrier fluid must be changed at more frequent intervals than shown in Schedule B if thevehicle is used for trailer tow, taxi, police or other types of commercial service.
Maint enance Service Sc hedule ÒBÓ
24,0 00 km
2004 Car_Minivan Maint Book 7/24/03 12:42 PM Page 40
Page 42 of 131
Maintenance Service
Sc hedule ÒBÓ
Odometer Reading
Date
29,0 00 km
Dealer copy.
Remove and attach to Repair Order 26-92-06-01 3N.
Maint enance Service Sc hedule ÒBÓ
29,0 00 km
l Change engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate, as required, all steering and suspension components.
l Inspect the engine air cleaner filter and replace if necessary
(Sebring, Sebring Convertible,
Concorde, Intrepid, 300M, Pacifica and Minivan only).
l Rotate tires and check tire pressure.
INSPECT THE FOLLOWING: l Inspect the front and rear brake linings and components (Pacifica, Minivan, Concorde, Intrepid, 300M and SX 2.0 only).
l Inspect the brake hoses.
l Check the automatic transaxle fluid level.
l Check the manual transaxle fluid level and fill plug condition (if equipped).
l Check the coolant level, hoses and clamps.
l Inspect the exhaust system.
2004 Car_Minivan Maint Book 7/24/03 12:42 PM Page 41
Page 43 of 131
Odometer Reading
Date
Repair Order No.
DAIMLER CHR YSLER
D EALER STAMP
Signature of authorized DaimlerChrysler Canada dealer
l Change engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate, as required, all steering and suspension components.
l Inspect the engine air cleaner filter and replace ifnecessary (
Sebring, Sebring Convertible, Concorde,
Intrepid, 300M, Pacifica and Minivan only).
l Rotate tires and check tire pressure.
INSPECT THE FOLLOWING: l Inspect the front and rear brake linings and components (Pacifica, Minivan, Concorde, Intrepid, 300M and SX 2.0 only).
l Inspect the brake hoses.
l Check the automatic transaxle fluid level.
l Check the manual transaxle fluid level and fill plugcondition (if equipped).
l Check the coolant level, hoses and clamps.
l Inspect the exhaust system.
Maint enance Service Sc hedule ÒBÓ
29,0 00 km
2004 Car_Minivan Maint Book 7/24/03 12:42 PM Page 42
Page 44 of 131
Maintenance Service
Sc hedule ÒBÓ
Odometer Reading
Date
34,0 00 km
Dealer copy.
Remove and attach to Repair Order 26-92-07-01 3N.
Maint enance Service Sc hedule ÒBÓ
34,0 00 km
l Change engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate, as required, all steering and suspension components.
l Inspect the engine air cleaner filter and replace if necessary (
Sebring, Sebring Convertible,
Concorde, Intrepid, 300M, Pacifica and Minivan only).
l Change the all-wheel-drive overrunning clutch and rear carrier fluid.*
INSPECT THE FOLLOWING: l Inspect the brake hoses.
l Check the automatic transaxle fluid level.
l Check the manual transaxle fluid level and fill plug condition (if equipped).
l Check the coolant level, hoses and clamps.
l Inspect the exhaust system.
* All-wheel-drive power transfer unit fluid and overrunning clutch/rear carrier fluid must be changed at more frequent intervals than shown in Schedule B if the vehicle is used for trailer tow, taxi, police or other types of
commercial service.
2004 Car_Minivan Maint Book 7/24/03 12:42 PM Page 43
Page 45 of 131
Odometer Reading
Date
Repair Order No.
DAIMLER CHR YSLER
D EALER STAMP
Signature of authorized DaimlerChrysler Canada dealer
l Change engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate, as required, all steering and suspension components.
l Inspect the engine air cleaner filter and replace if necessary (
Sebring, Sebring Convertible, Concorde,
Intrepid, 300M, Pacifica and Minivan only) .
l Change the all-wheel-drive overrunning clutch and rear carrier fluid.*
INSPECT THE FOLLOWING: l Inspect the brake hoses.
l Check the automatic transaxle fluid level.
l Check the manual transaxle fluid level and fill plug condition (if equipped).
l Check the coolant level, hoses and clamps.
l Inspect the exhaust system.
*All-wheel-drive power transfer unit fluid and overrunning clutch/rear carrier fluid must be changed at more frequent intervals than shown in Schedule B if thevehicle is used for trailer tow, taxi, police or other types of commercial service.
Maint enance Service Sc hedule ÒBÓ
34,0 00 km
2004 Car_Minivan Maint Book 7/24/03 12:42 PM Page 44
Page 46 of 131
Maintenance Service
Sc hedule ÒBÓ
Odometer Reading
Date
38,0 00 km
Dealer copy.
Remove and attach to Repair Order 26-92-08-01 3N.
Maint enance Service Sc hedule ÒBÓ
38,0 00 km
l Change engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate, as required, all steering and suspension components.
l Inspect the engine air cleaner filter and replace if necessary (
Sebring, Sebring Convertible,
Concorde, Intrepid, 300M, Pacifica and Minivan only).
l Replace the air conditioning filter (Pacifica and Minivan, if equipped).
l Rotate tires and check tire pressure.
INSPECT THE FOLLOWING: l Inspect the front and rear brake linings and components (Sebring, Sebring Convertible, PT Cruiser and SRT-4 only).
l Inspect the brake hoses.
l Check the automatic transaxle fluid level.
l Check the manual transaxle fluid level and fill plug condition (if equipped).
l Check the coolant level, hoses and clamps.
l Inspect the exhaust system.
2004 Car_Minivan Maint Book 7/24/03 12:42 PM Page 45
Page 47 of 131
Odometer Reading
Date
Repair Order No.
DAIMLER CHR YSLER
D EALER STAMP
Signature of authorized DaimlerChrysler Canada dealer
l Change engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate, as required, all steering and suspension components.
l Inspect the engine air cleaner filter and replace if necessary(
Sebring, Sebring Convertible, Concorde, Intrepid, 300M,
Pacifica and Minivan only).
l Replace the air conditioning filter (Pacifica and Minivan, if equipped).
l Rotate tires and check tire pressure.
INSPECT THE FOLLOWING: l Inspect the front and rear brake linings and components (Sebring, Sebring Convertible, PT Cruiser and SRT-4 only).
l Inspect the brake hoses.
l Check the automatic transaxle fluid level.
l Check the manual transaxle fluid level and fill plugcondition (if equipped).
l Check the coolant level, hoses and clamps.
l Inspect the exhaust system.
Maint enance Service Sc hedule ÒBÓ
38,0 00 km
2004 Car_Minivan Maint Book 7/24/03 12:42 PM Page 46
Page 48 of 131
Maintenance Service
Sc hedule ÒBÓ
Odometer Reading
Date
43,0 00 km
Dealer copy.
Remove and attach to Repair Order 26-92-09-01 3N.
Maint enance Service Sc hedule ÒBÓ
43,0 00 km
l Change engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate, as required, all steering and suspension components.
l Inspect the engine air cleaner filter and replace if necessary (
Sebring, Sebring Convertible,
Concorde, Intrepid, 300M, Pacifica and Minivan only).
INSPECT THE FOLLOWING: l Inspect the front and rear brake linings and components (Pacifica, Minivan, Concorde, Intrepid, 300M and SX 2.0 only).
l Inspect the brake hoses.
l Check the automatic transaxle fluid level.
l Check the manual transaxle fluid level and fill plug condition (if equipped).
l Check the coolant level, hoses and clamps.
l Inspect the exhaust system.
2004 Car_Minivan Maint Book 7/24/03 12:42 PM Page 47
Page 49 of 131
Odometer Reading
Date
Repair Order No.
DAIMLER CHR YSLER
D EALER STAMP
Signature of authorized DaimlerChrysler Canada dealer
l Change engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate, as required, all steering and suspension components.
l Inspect the engine air cleaner filter and replace ifnecessary (
Sebring, Sebring Convertible, Concorde, Intrepid,
300M, Pacifica and Minivan only).
INSPECT THE FOLLOWING:
l Inspect the front and rear brake linings and components(Pacifica, Minivan, Concorde, Intrepid, 300M and SX 2.0 only).
l Inspect the brake hoses.
l Check the automatic transaxle fluid level.
l Check the manual transaxle fluid level and fill plug condition (if equipped).
l Check the coolant level, hoses and clamps.
l Inspect the exhaust system.
Maint enance Service Sc hedule ÒBÓ
43,0 00 km
2004 Car_Minivan Maint Book 7/24/03 12:42 PM Page 48
Page 50 of 131
Maintenance Service
Sc hedule ÒBÓ
Odometer Reading
Date
48,0 00 km
Dealer copy.
Remove and attach to Repair Order 26-92-10-01 3N.
Maint enance Service Sc hedule ÒBÓ
48,0 00 km
l Ch ange engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate, as required, all steering and suspension components.
lInspect the engine air cleaner filter and replace if necessary (Sebring, Sebring Convertible, PT Cruiser, SRT-4, and SX 2.0 only).
l Replace the engine air cleaner filter if required (all models).
l Replace the spark plugs (PT Cruiser, SRT-4, Sebring, Sebring Convertible, SX 2.0 and 2.4L Minivan only).
l Check and replace, if necessary, the PCV valve.
l Inspect and replace, if required, the make-up air filter located inside the air cleaner (PT Cruiser and SX 2.0 only).
l Adjust the drive belt tension (Concorde, Intrepid and 300M only)
l Adjust the generator belt tension (PT Cruiser and SRT-4 only).
l Adjust the generator belt tension (SX 2.0 only).
l Check and retention power steering pump belt (2.4L Minivan only).
l Check the generator belt, replace if necessary (2.4L Minivan only).
l Change the all-wheel drive power transfer unit fluid.*
l Rotate tires a nd check tire pressure.
INSPECT THE FOLLOWING: l Inspect the tie rod ends and boot seals (Pacifica, Minivan, PT Cruiser, SRT-4 and SX 2.0 only).
l Inspect the brake hoses.
l Check the automatic transaxle fluid level.
l Check the manual transaxle fluid level and fill plug condition (if equipped).
l Check the coolant level, hoses and clamps.
l Inspect the exhaust system.
* All-wheel-drive power transfer unit fluid and overrunning clutch/rear carrier fluid must be changed at more frequent intervals than shown in Schedule B if the vehicle is used for trailer tow, taxi, police or other types of
commercial service.
2004 Car_Minivan Maint Book 7/24/03 12:42 PM Page 49
