CHRYSLER TOWN AND COUNTRY 2005 4.G Warranty Booklet

Maintenance Service
Sc hedule “B”
Odometer Reading
Date
Dealer Copy
Remove and attach to Repair Order 26-92-02-01 3N.
2005 Passenger Car • Minivan • Pacifica
Maint enance Service Sc hedule “B”
5,0 00 km
Change engine oil and engine oil filter (or every 3 months).
Inspect and lubricate, as required, all steering and suspension componen\
ts.
Inspect the engine air cleaner filter and replace if necessary (Sebring\
, Pacifica
and Minivan only).
INSPECT THE FOLLOWING:
Inspect the brake hoses.
Check the automatic transaxle fluid level.
Check the manual transaxle fluid level and fill-plug condition (SX 2.0,\
SRT-4
and PT Cruiser only, if equipped).
Check the coolant level, hoses and clamps.
Inspect the exhaust system.
5,0 00 km

DAIMLER CHR YSLER
D EALER STAMP
Signature of authorized DaimlerChrysler Canada dealer
2005 Passenger Car • Minivan • Pacifica

Change engine oil and engine oil filter (or every 3 months).
Inspect and lubricate, as required, all steering and
suspension components.
Inspect the engine air cleaner filter and replace if
necessary (Sebring, Pacifica and Minivan only).
INSPECT THE FOLLOWING:
Inspect the brake hoses.
Check the automatic transaxle fluid level.
Check the manual transaxle fluid level and fill-plug
condition (SX 2.0, SRT-4 and PT Cruiser only,
if equipped).
Check the coolant level, hoses and clamps.
Inspect the exhaust system.
Odometer Reading
Date
Repair Order No.
Maint enance Service Sc hedule “B”
5,0 00 km

2005 Passenger Car • Minivan • PacificaDealer Copy
Remove and attach to Repair Order 26-92-02-01 3N.
Maint enance Service
Sc hedule “B”
Odometer Reading
Date
Maint enance Service Sc hedule “B”
1 0,0 00 km
Change engine oil and engine oil filter (or every 3 months).
Inspect and lubricate, as required, all steering and suspension componen\
ts.
Inspect the engine air cleaner filter and replace if necessary (Sebring\
, Pacifica
and Minivan only).
Rotate tires and check tire pressure.
INSPECT THE FOLLOWING:
Inspect the brake hoses.
Check the automatic transaxle fluid level.
Check the manual transaxle fluid level and fill-plug condition (SX 2.0,\
SRT-4
and PT Cruiser only, if equipped).
Check the coolant level, hoses and clamps.
Inspect the exhaust system.
10,0 00 km

DAIMLER CHR YSLER
D EALER STAMP
Signature of authorized DaimlerChrysler Canada dealer
2005 Passenger Car • Minivan • Pacifica
Odometer Reading
Date
Repair Order No.

Change engine oil and engine oil filter (or every 3 months).
Inspect and lubricate, as required, all steering and
suspension components.
Inspect the engine air cleaner filter and replace
if necessary (Sebring, Pacifica and Minivan only).
Rotate tires and check tire pressure.
INSPECT THE FOLLOWING:
Inspect the brake hoses.
Check the automatic transaxle fluid level.
Check the manual transaxle fluid level and fill-plug
condition (SX 2.0, SRT-4 and PT Cruiser only,
if equipped).
Check the coolant level, hoses and clamps.
Inspect the exhaust system.
Maint enance Service Sc hedule “B”
1 0,0 00 km

Maintenance Service
Sc hedule “B”
Odometer Reading
Date
Dealer Copy
Remove and attach to Repair Order 26-92-02-01 3N.
2005 Passenger Car • Minivan • Pacifica
Odometer Reading
Date
14,0 00 km
Maint
enance Service Sc hedule “B”
14,0 00 km
Change engine oil and engine oil filter (or every 3 months).
Inspect and lubricate, as required, all steering and suspension componen\
ts.
Inspect the engine air cleaner filter and replace if necessary (Sebring\
, Pacifica
and Minivan only).
INSPECT THE FOLLOWING:
Inspect the front and rear brakes and components (Pacifica, Minivan and\
SX 2.0 only).
Inspect the brake hoses.
Check the automatic transaxle fluid level.
Check the manual transaxle fluid level and fill-plug condition (SX 2.0,\
SRT-4
and PT Cruiser only, if equipped).
Check the coolant level, hoses and clamps.
Inspect the exhaust system.

DAIMLER CHR YSLER
D EALER STAMP
Signature of authorized DaimlerChrysler Canada dealer
2005 Passenger Car • Minivan • Pacifica
Odometer Reading
Date
Repair Order No.

Change engine oil and engine oil filter (or every 3 months).
Inspect and lubricate, as required, all steering and
suspension components.
Inspect the engine air cleaner filter and replace if
necessary (Sebring, Pacifica and Minivan only).
INSPECT THE FOLLOWING:
Inspect the front and rear brakes and components (Pacifica,
Minivan and SX 2.0 only).
Inspect the brake hoses (PT Cruiser).
Check the automatic transaxle fluid level.
Check the manual transaxle fluid level and fill-plug
condition (SX 2.0, SRT-4 and PT Cruiser only, if equipped).
Check the coolant level, hoses and clamps.
Inspect the exhaust system.
Maint enance Service Sc hedule “B”
14,0 00 km

2005 Passenger Car • Minivan • PacificaDealer Copy
Remove and attach to Repair Order 26-92-02-01 3N.
Maint enance Service
Sc hedule “B”
Odometer Reading
Date
19,0 00 km
Maint
enance Service Sc hedule “B”
1 9,0 00 km
Change engine oil and engine oil filter (or every 3 months).
Inspect and lubricate, as required, all steering and suspension componen\
ts.
Inspect the engine air cleaner filter and replace if necessary (Sebring\
, Pacifica
and Minivan only).
Replace the air conditioning filter (Pacifica and Minivan if equipped)\
.
Rotate tires and check tire pressure.
INSPECT THE FOLLOWING:
Inspect the front and rear brakes and components (Sebring, PT Cruiser a\
nd SRT-4 only). Inspect the brake hoses.
Check the automatic transaxle fluid level.
Check the manual transaxle fluid level and fill-plug condition (SX 2.0,\
SRT-4
and PT Cruiser only, if equipped).
Check the coolant level, hoses and clamps.
Inspect the exhaust system.

DAIMLER CHR YSLER
D EALER STAMP
Signature of authorized DaimlerChrysler Canada dealer
2005 Passenger Car • Minivan • Pacifica
Odometer Reading
Date
Repair Order No.

Change engine oil and engine oil filter (or every 3 months).
Inspect and lubricate, as required, all steering and
suspension components.
Inspect the engine air cleaner filter and replace
if necessary (Sebring, Pacifica and Minivan only).
Replace the air conditioning filter (Pacifica and Minivan
if equipped).
Rotate tires and check tire pressure.
INSPECT THE FOLLOWING:
Inspect the front and rear brakes and components
(Sebring, PT Cruiser and SRT-4 only).
Inspect the brake hoses.
Check the automatic transaxle fluid level.
Check the manual transaxle fluid level and fill-plug
condition (SX 2.0, SRT-4 and PT Cruiser only,
if equipped).
Check the coolant level, hoses and clamps.
Inspect the exhaust system.
Maint enance Service Sc hedule “B”
1 9,0 00 km

2005 Passenger Car • Minivan • PacificaDealer Copy
Remove and attach to Repair Order 26-92-02-01 3N.
Maint enance Service
Sc hedule “B”
Odometer Reading
Date
24,0 00 km
Maint
enance Service Sc hedule “B”
24,0 00 km
Change engine oil and engine oil filter (or every 3 months).
Inspect and lubricate, as required, all steering and suspension componen\
ts.
Inspect the engine air cleaner filter and replace if necessary (Sebring\
, PT Cruiser, SRT-4
and SX 2.0 only).
Replace the engine air cleaner filter if required (Pacifica and Minivan\
only).
Inspect and replace, if required, the make-up air filter located inside \
the air cleaner
(PT Cruiser, SRT-4 and SX 2.0 only).
Change the all-wheel-drive power transfer unit fluid.*
INSPECT THE FOLLOWING:
Inspect the brake hoses.
Check the automatic transaxle fluid level.
Check the manual transaxle fluid level and fill-plug condition
(SX 2.0, SRT-4 and PT Cruiser only, if equipped).
Check the coolant level, hoses and clamps.
Inspect the exhaust system.
*The all-wheel-drive power transfer unit fluid and overrunning clutch/re\
ar carrier
fluid must be changed at more frequent intervals than shown in schedule \
B if the
vehicle is used for trailer tow, taxi, or other type of commercial servi\
ce.

DAIMLER CHR YSLER
D EALER STAMP
Signature of authorized DaimlerChrysler Canada dealer
2005 Passenger Car • Minivan • Pacifica
Odometer Reading
Date
Repair Order No.

Change engine oil and engine oil filter (or every 3 months).
Inspect and lubricate, as required, all steering and
suspension components.
Inspect the engine air cleaner filter and replace if
necessary (Sebring, PT Cruiser, SRT-4 and SX 2.0 only).
Replace the engine air cleaner filter if required
(Pacifica and Minivan only).
Inspect and replace, if required, the make-up air filter
located inside the air cleaner (PT Cruiser, SRT-4 and
SX 2.0 only).
Change the all-wheel-drive power transfer unit fluid.*
INSPECT THE FOLLOWING:
Inspect the brake hoses.
Check the automatic transaxle fluid level.
Check the manual transaxle fluid level and fill-plug
condition (SX 2.0, SRT-4 and PT Cruiser only,
if equipped).
Check the coolant level, hoses and clamps.
Inspect the exhaust system.
*The all-wheel-drive power transfer unit fluid and overrunning
clutch/rear carrier fluid must be changed at more frequent intervals
than shown in schedule B if the vehicle is used for trailer tow, taxi,
or other type of commercial service.
Maint enance Service Sc hedule “B”
24,0 00 km
