CHRYSLER TOWN AND COUNTRY 2007 4.G Owners Manual

Security
If you sell your vehicle, be sure to erase the frequencies
by following the “Erasing HomeLink Buttons” instruc-
tions in this section.
This device complies with part 15 of FCC rules and with
RSS-210 of Industry Canada. Operation is subject to the
following conditions:
•This device may not cause harmful interference.
•This device must accept any interference that may be
received including interference that may cause undes-
ired operation.
NOTE:Changes or modifications not expressly ap-
proved by the party responsible for compliance could
void the user’s authority to operate the equipment.
HomeLinkis a trademark owned by Johnson Controls,
Inc.In the event that you are still having programming
difficulties, questions, or comments, contact HomeLink
at:www.homelink.com or 1-800-355-3515.
POWER SUNROOF — IF EQUIPPED
The power sunroof control is located between the sun
visors on the overhead console.
Power Sunroof Controls
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 181
3

Press and hold the switch rearward to fully open the
sunroof. The sunroof can be stopped at any position
between closed and full open. Momentarily pressing the
switch rearward will activate the Express Open Feature,
causing the sunroof to open automatically.
Press and hold the button located to the right of the
sunroof switch, to open the vent. The sunroof can be
stopped at any position between closed and full vent. To
close the sunroof from the vent position, press and hold
the switch forward. Releasing the switch will stop the
movement of the sunroof and the sunroof will remain in
the partial vent position until the switch is pushed
forward again.
Express Open Feature
During the Express Open operation, any movement of
the switch will stop the sunroof and it will remain in a
partial open position. Again, momentarily pressing the
switch rearward will activate the Express Open Feature.To close the sunroof, hold the switch in the forward
position. Again, any release of the switch will stop the
movement and the sunroof will remain in a partial open
condition until the switch is pushed forward again.
The sunshade can be opened manually. It will also open
as the sunroof opens. The sunshade cannot be closed if
the sunroof is open.
WARNING!
NEVER leave children alone in a vehicle. Occupants,
particularly unattended children, can become en-
trapped by the power sunroof while operating the
power sunroof switch. Such entrapment may result
in serious injury or death. Don’t leave the keys in the
ignition. A child could operate power windows,
other controls, or move the vehicle
182 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

WARNING!
In an accident, there is a greater risk of being thrown
from a vehicle with an open sunroof. You could also
be seriously injured or killed. Always fasten your
seat belt properly and make sure all passengers are
properly secured too.
Do not allow small children to operate the sunroof.
Never allow fingers or other body parts, or any
object to project through the sunroof opening. Injury
may result.
Wind Buffeting
Wind buffeting can be described as the perception of
pressure on the ears or a helicopter type sound in the
ears. Your vehicle may exhibit wind buffeting with the
windows down, or the sunroof (if equipped) in certain
open or partially open positions. This is a normal occur-
rence and can be minimized. If the buffeting occurs withthe rear windows open, open the front and rear windows
together to minimize the buffeting. If the buffeting occurs
with the sunroof open, adjust the sunroof opening to
minimize the buffeting or open any window.
Sunroof Maintenance
Use only a non-abrasive cleaner and a soft cloth to clean
the glass panel.
ELECTRICAL POWER OUTLETS — IF EQUIPPED
To the left of the instrument panel cup holder are two 12
volt power outlets. The upper outlet is controlled by the
ignition switch and the lower outlet is connected directly
to the battery. The upper outlet will also operate a
conventional cigar lighter unit (if equipped with an
optional Smoker’s Package).
A third outlet is located on the driver’s side, just to the
rear of the sliding door and is also controlled by the
ignition switch. The lower and rear outlets will not
accommodate a conventional cigar lighter unit.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 183
3

The outlets include tethered caps labeled with a key or
battery symbol indicating the power source. The lower
instrument panel outlet is powered directly from the
battery, items plugged into this outlet may discharge the
battery and/or prevent engine starting.The lower outlet is protected by an automatic reset circuit
breaker. The automatic circuit breaker restores power
when the overload is removed. The circuit breaker also
supplies power to the outlet in the removable floor
console, when in the front position. Refer to section 3
“Removable Floor Console” in this manual.
NOTE:If desired, all of the power outlets can be
converted by your authorized dealer to provide power
with the ignition switch in the OFF position.
Rear Power Outlet
184 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Electrical Outlet Use With Engine Off
CAUTION!
•Many accessories that can be plugged in draw power from
the vehicle’s battery, even when not in use (i.e. cellular
phones, etc.). Eventually, if plugged in long enough, the
vehicle’s battery will discharge sufficiently to degrade
battery life and/or prevent engine starting.
•Accessories that draw higher power (i.e. coolers, vacuum
cleaners, lights, etc.), will degrade the battery even more
quickly. Only use these intermittently and with greater
caution.
•After the use of high power draw accessories, or long
periods of the vehicle not being started (with accessories
still plugged in), the vehicle must be driven a sufficient
length of time to allow the alternator to recharge the
vehicle’s battery.
•Power outlets are designed for accessory plugs only. Do not
hang any type of accessory or accessory bracket from the
plug. Improper use of the power outlet can cause damage.
CONVENIENCE TRAY DRAWER AND CUP
HOLDERS
Instrument Panel Cup Holders
The instrument panel cupholders are located in a pull out
drawer just below the climate controls.
Front Cupholders
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 185
3

When the drawer is pulled out firmly, the arms of the
cupholders will spring out. Place the container to be held
into one of the cupholders and then push the arm toward
the container until the container is held stable. There are
adjustable positions for the arm so the cupholder can
accommodate a wide variety of container types and sizes,
including those with handles. The arms of the cupholder
can be adjusted in or out without damaging the detent
mechanism.
NOTE:Be sure the drawer is pulled out completely,
otherwise the adjustable arm detents will not engage and
the container will not be held stable.
Convenience Tray And Optional Smoker’s
Package Kit
Located between the instrument panel cupholders is a
convenience tray that has been designed to hold miscel-
laneous small items.NOTE:The convenience tray should never be used for
ashes without the optional ash receiver in place. Perma-
nent burn marks may result.
With the optional dealer installed Smoker’s package, a
removable ash receiver is inserted into the convenience
tray location. To install the ash receiver, slide the forward
edge into the convenience tray opening and push down
to lock it into position. For cleaning of the ash receiver, its
removal is accomplished by inserting the end of a key in
the pry slot that is molded into the rear edge of the ash
receiver and then twisting the key slightly.
186 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Rear Cupholders
There are dual stationary cupholders located in the
passenger side rear trim panel and a single stationary cup
holder on the driver side rear trim panel.
There are also dual underseat cupholders for the 2nd seat
passengers. With a bench seat in the 2nd seat position
these cupholders slide out from under the center of the
seat.
If your vehicle is equipped with quad seats in the 2nd
seat position, these cupholders are located on the out-
board side of the seat pedestal.
NOTE:
•The quad seat cupholders will remain upright if the
seat is tilted forward.
Quad Seat Cupholder
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 187
3

•The quad seat cupholders are designed to break away
if stepped on. To return the cupholder to its normal
position, simply push the cupholder up to snap it into
place.
•The floor mat must be in position for optimum cup-
holder operation.
There are also two cupholders and a flat tray on the seat
back of the quad seats. These can be used when the seat
back is folded forward.
STORAGE
Front Seat Storage Bin — If Equipped
The storage bin is located under the front passenger’s
seat. If equipped with a lock, it can be locked with the
ignition key.Second Row Seat Storage bins — If Equipped
The Seat Storage Bins are located on the floor in front of
the second row seats, the area below the covers can be
used for storage when the second row seat is in the
upright position.
Front Seat Storage Bin
188 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Pull up on the storage bin latch to open the cover. Slide
the storage bin locking mechanism to theUnlocked
position to allow greater access to the storage bin.
CAUTION!
NOTE: The storage bin cover must be locked and flat
to avoid damage from contact with the front seat
tracks, which have minimal clearance to the cover.
WARNING!
In an accident, serious injury could result if the seat
storage bin covers are not properly latched. Do not
drive the vehicle with the storage bin cover open.
Keep the storage bin cover closed and latched while
the vehicle is in motion. Do not operate the storage
bin cover while the vehicle is in motion.
Storage Bin Cover Lock Release
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 189
3

Overhead Rail System — If Equipped
The overhead rail system contains provisions for three
movable and removable overhead storage bins. The
storage bins may be placed anywhere on the overhead
rail system.
CAUTION!
Do not load objects over 1.5 lbs (0.68 kg) in the
storage bins. Failure to follow this could cause
damage to the Overhead Rail System.
To Remove Storage Bins
1. Support the bin with one hand and pull the latch
handles out.2. Twist the latch handles a
14turn and pull outward to
disengage the bin from the rail.
190 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
