CHRYSLER TOWN AND COUNTRY 2007 4.G Owner's Manual

Three button transmitters will provide basic UNLOCK,
LOCK and PANIC functions.
Six button transmitters will provide functions that allow
the same basic operation as the three button, but may also
be used to Open/Close the optional power liftgate, left
power sliding door, or right power sliding door. Otheroptions of the system allow you to turn ON/OFF the
Sound Horn On Lock, Remote Unlock Driver’s Door 1st,
and Flash Lights On Lock/Unlock features.
Three Button Transmitter
Six Button Transmitter
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 21
2

To unlock the doors and liftgate:
Press and release the UNLOCK button on the transmitter
once to unlock the driver’s door side of the vehicle, or
twice to unlock all doors and liftgate. The illuminated
entry system also turns on.
The Remote Unlock Driver’s Door 1st feature can be
enabled or disabled by performing the following proce-
dure:
1. Press the UNLOCK button for 5 to 10 seconds.
2. While the UNLOCK button is pressed, (after 5 sec-
onds) press the LOCK button. Release both buttons.
The “Remote Unlock Driver’s Door 1st” feature can be
reactivated by repeating the above mentioned procedure
or by performing the procedure in the Electronic Vehicle
Information Center (EVIC), Customer Programmable
Features section on vehicles so equipped. (See page 172
for more information.)
To lock the doors and liftgate:
Press and release the LOCK button on the transmitter to
lock all doors and liftgate. The horn will chirp once to
acknowledge the signal.
If desired, the “Sound Horn On Lock” feature can be
turned on and off by performing the following proce-
dure:
1. Press the LOCK button for 5 to 10 seconds.
2. While the LOCK button is pressed (after 5 seconds),
press the PANIC button. Release both buttons.
The “Sound Horn On Lock” feature can be reactivated by
repeating this procedure or by performing the procedure
in the Electronic Vehicle Information Center (EVIC),
Customer Programmable Features section on vehicles so
equipped. (See page 172 for more information.)
22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

Using The Panic Alarm:
To turn the panic alarm feature ON or OFF, press and
hold the PANIC button on the transmitter for at least one
second and release. When the panic alarm is on, the
headlights and park lights will flash, the horn will pulse
on and off and the interior lights will turn on.
The panic alarm will stay on for 3 minutes unless you
turn it off by pressing the PANIC button a second time or
by turning the ignition switch to the ON position.
NOTE:When you turn off the panic alarm by pressing
the PANIC button a second time, you may have to be
closer to the vehicle due to the radio frequency noises of
the system.
To Program Transmitters:
Refer to SENTRY KEY “Customer Key Programming.”
(See page 17 for more information.)
If you do not have a programmed transmitter, contact
your dealer for details.
To Open/Close Power Liftgate — If Equipped
Press the LIFTGATE button twice within five seconds to
open/close the power liftgate. The liftgate will beep for 2
seconds and then open/close. If the button is pushed
while the liftgate is being power closed, the liftgate will
reverse to the full open position.
If the liftgate is locked and is not equipped with a
powered liftgate, pressing the button twice will result in
the liftgate becoming unlocked for 30 seconds allowing
you to manually access the liftgate area.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 23
2

To Open/Close Left Power Sliding Door — If
Equipped
Press the LEFT button twice within five seconds to
open/close the left power sliding door. If the button is
pushed while the door is being power closed, the door
will reverse to the full open position.
If the vehicle is not equipped with a left power sliding
door and the door is closed and locked, pressing the
button twice will result in the left side doors becoming
unlocked.
To Open/Close Right Power Sliding Door — If
Equipped
Press the RIGHT button twice within five seconds to
open/close the right power sliding door. If the button is
pushed while the door is being power closed, the door
will reverse to the full open position.If the vehicle is not equipped with a right power sliding
door and the door is closed and locked, pressing the
button twice will result in the right side doors becoming
unlocked.
To Turn Off “Flash Lights On Lock/Unlock” — If
Equipped
If desired, the “Flash Lights On Lock/Unlock” feature
can be turned on and off by performing the following
procedure:
1. Press the LOCK button for 5 to 10 seconds.
2. While the LOCK button is pressed, (after 5 seconds)
press the UNLOCK button. Release both buttons.
The “Flash Lights On Lock/Unlock” feature can be
reactivated by repeating this procedure or by performing
the procedure in the Electronic Vehicle Information Cen-
ter (EVIC), Customer Programmable Features section on
24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

vehicles so equipped. The table below explains the Lamp
Flash options. (See page 172 for more information.)
Function Which Turn Signal
LampsNumber of
Flashes
Lock All 1
Unlock 1st
PressLeft Side 2
Unlock All
DoorsAll 2
Left Side Left Side 2
Right Side Right Side 2
Liftgate All 2
General Information
This device complies with part 15 of the FCC rules and
RSS 210 of Industry Canada. Operation is subject to the
following conditions:
•This device may not cause harmful interference.
•This device must accept any interference received,
including interference that may cause undesired op-
eration.
If your Remote Keyless Entry transmitter fails to operate
from a normal distance, check for these two conditions.
1. A weak battery in the transmitter. The expected life of
the battery is a minimum of three years.
2. Closeness to a radio transmitter such as a radio station
tower, airport transmitter, and some mobile or CB radios.
Transmitter Battery Service
The recommended replacement battery is one CR2032
battery.
NOTE:Do not touch the battery terminals that are on
the back housing or the printed circuit board.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 25
2

1. With the transmitter buttons facing down, use a thin
coin to pry the two halves of the transmitter apart. Make
sure not to damage the rubber gasket during removal.2. Remove and replace the batteries. Avoid touching the
new batteries with your fingers. Skin oils may cause
battery deterioration. If you touch a battery, clean it with
rubbing alcohol.
3. To reassemble the transmitter case snap two halves
together. Make sure there is an even “gap” between the
two halves. Test transmitter operation.
Separating Transmitter Halves
26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

DOOR LOCKS
Manual Door Locks
Lock the doors by pushing down on the lock plungers on
each door trim panel.If the lock plunger is down when you shut the door, the
door will lock. Therefore, make sure the keys are not
inside the vehicle before closing the door.
WARNING!
•For personal security and safety in the event of an
accident, lock the vehicle doors as you drive as
well as when you park and leave the vehicle.
•When leaving the vehicle always remove the key
from the ignition lock, and lock your vehicle. Do
not leave children unattended in the vehicle, or
with access to an unlocked vehicle. Unsupervised
use of vehicle equipment may cause severe per-
sonal injuries and death.
Door Lock Plunger
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 27
2

Power Door Locks — If Equipped
A power door lock switch is on each front door trim
panel. Use this switch to lock or unlock the doors.
If you press the power door lock switch while the key is
in the ignition, and any front door is open, the powerlocks will not operate. This prevents you from acciden-
tally locking your keys in the vehicle. Removing the key
or closing the door will allow the locks to operate. A
chime will sound if the key is in the ignition switch and
a door is open, as a reminder to remove the key.
If you press the power door lock switch while the sliding
door is open, the sliding door will lock.
Automatic Door Locks — If Equipped
If this feature is enabled, your door locks will lock
automatically when the vehicles speed exceeds 15 mph.
Automatic Door Lock Programming
This feature is enabled when your vehicle is shipped
from the assembly plant and can be disabled by using the
following procedure:
•On electronic vehicle information center (EVIC)
equipped vehicles refer toPersonal Settingsin the
EVIC section of this manual.
Power Door Lock switch
28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

•On non EVIC - equipped vehicles perform the follow-
ing steps:
1. Enter your vehicle and close all doors.
2. Fasten your seat belt (Fastening the seat belt will
cancel any chiming that may confuse you during this
programming procedure).
3. Place the key into the ignition.
4. Within 15 seconds cycle the key from the LOCK
position to the ON/RUN position a minimum of four
times; ending in the LOCK position (Do not start the
engine).
5. Within 30 seconds, press the driver’s door lock switch
in the LOCK direction.
6. A single chime will be heard to indicate the feature has
been disabled.
7. To reactivate this feature, repeat the above steps.8. If a chime is not heard, program mode was canceled
before the feature could be disabled. If necessary, repeat
the above procedure.
You can turn the feature back on by repeating the above
mentioned procedure or by performing the procedure in
the Electronic Vehicle Information Center (EVIC), Cus-
tomer Programmable Features section on vehicles so
equipped.
Auto Unlock On Exit — If Equipped
This feature unlocks all of the doors of the vehicle when
any door is opened. This will occur only after the vehicle
has been shifted into the Park position after the vehicle
has been driven (shifted out of Park and all doors closed).
This feature will not operate if there is any manual
operation of the power door locks (Lock or Unlock).
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 29
2

Auto Unlock On Exit Programming — If Equipped
The doors will unlock automatically on vehicles with
power door locks if:
1. Enter your vehicle and close all doors.
2. Fasten your seat belt (fastening the seat belt will cancel
any chimes that may be confusing during this program-
ming procedure).
3. Insert the key into the ignition.
4. Within 15 seconds, cycle the key from the LOCK
position to the ON/RUN position a minimum of four
times ending in the LOCK position(do not start the
engine).
5. Within 30 seconds, press the driver’s door lock switch
in the UNLOCK direction.
6. A single chime will sound to indicate the feature has
been changed.7. Repeat the above steps to alternate the availability of
this feature.
8. If a chime is not heard, program mode was canceled
before the feature could be changed. If necessary repeat
the above procedure.
The Auto Unlock On Exit feature can be enabled or
disabled by performing the procedure in the Electronic
Vehicle Information Center (EVIC), Customer Program-
mable Features section on vehicles so equipped.
NOTE:Use the Auto Door Locks and Auto Unlock
features in accordance with local laws.
30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
