8W-41 HORN/CIGAR LIGHTER/POWER OUTLET
Component Page
Accessory Relay................... 8W-41-3, 4
Body Control Module................. 8W-41-3
Clockspring......................... 8W-41-2
Floor Console Power Outlet............ 8W-41-4
Front Cigar Lighter.................. 8W-41-3
Front Control Module............. 8W-41-2, 3, 4
Fuse 5........................... 8W-41-3, 4
Fuse 6........................... 8W-41-3, 4
Fuse 8............................. 8W-41-2
G102.............................. 8W-41-2
G200............................ 8W-41-3, 4Component Page
G302............................ 8W-41-3, 4
High Note Horn..................... 8W-41-2
Horn Relay......................... 8W-41-2
Horn Switch........................ 8W-41-2
Integrated Power Module.......... 8W-41-2, 3, 4
Low Note Horn...................... 8W-41-2
Power Outlet........................ 8W-41-4
PTC7 ............................. 8W-41-4
Radio............................. 8W-41-3
Rear Power Outlet................... 8W-41-3
RS8W-41 HORN/CIGAR LIGHTER/POWER OUTLET8W-41-1
