Fig. 67 SUSPENSION RETAINERS AND REINFORCEMENTS - LEFT
23 - 168 BODY STRUCTURERS
WELD LOCATIONS (Continued)
ProCarManuals.com

Fig. 68 FLOOR PAN REINFORCEMENTS - SIDE RAILS
RSBODY STRUCTURE23 - 169
WELD LOCATIONS (Continued)
ProCarManuals.com

Fig. 69 REAR SUSPENSION BRACKETS
23 - 170 BODY STRUCTURERS
WELD LOCATIONS (Continued)
ProCarManuals.com

Fig. 70 FLOOR PAN CROSS MEMBERS
RSBODY STRUCTURE23 - 171
WELD LOCATIONS (Continued)
ProCarManuals.com

Fig. 71 SEAT REINFORCEMENTS - LONG WHEEL BASE ONLY
23 - 172 BODY STRUCTURERS
WELD LOCATIONS (Continued)
ProCarManuals.com

Fig. 72 STRIKER REINFORCEMENTS - LONG WHEEL BASE ONLY
RSBODY STRUCTURE23 - 173
WELD LOCATIONS (Continued)
ProCarManuals.com

Fig. 73 FUEL TANK MOUNTING/REAR SEAT AND SUSPENSION
23 - 174 BODY STRUCTURERS
WELD LOCATIONS (Continued)
ProCarManuals.com

Fig. 74 REAR SUSPENSION HANGER BRACKETS - LONG WHEEL BASE
RSBODY STRUCTURE23 - 175
WELD LOCATIONS (Continued)
ProCarManuals.com

Fig. 75 FRONT SEAT CROSS MEMBER
23 - 176 BODY STRUCTURERS
WELD LOCATIONS (Continued)
ProCarManuals.com

Fig. 76 FLOOR PAN SIDE RAIL REINFORCEMENT
RSBODY STRUCTURE23 - 177
WELD LOCATIONS (Continued)
