Key 18
Remote control 18
Alarm

20
Doors


21
Rear roof flap


25
T

ailgate
26
Central locking


27
Instrument panel


28
Date and time


29
W

arning lamps
32
Fuel gauge


40
Coolant


40
Under-inflation


detection

41
Service indicator


43
Lighting dimmer


44
Steering wheel


adjustment

45
Manual gearbox


45
Gear shift indicator


46
6-speed electronic


gearbox

47
Stop & Start


49
Starting and stopping


52
Hill start assist


53
Driving


recommendations

54Lighting

55
Wipers
58
T
rip computer
60
Cruise control


61
Speed limiter


64
Heating /

Air conditioning
manual

67
digital


69
Demisting and


defrosting

72
Front seats


74
Individual passenger


seat

75
Extenso Cab


76
Configurations


78
Front fittings


79
Courtesy lamps


81
Crew cab


82
Load space


84
Roof bars


86
Mirrors


87
Electric windows


89
Exterior

5
Interior
6 left hand drive


6 right hand drive


7
Instruments and controls


8 left hand drive


8 right hand drive


1

1
Technical data - Maintenance

12
OVERVIEW 4-14
1.
Horn 90
Hazard warning lamps 90
Parking brake

90
Parking sensors


91
Reversing camera


93
Anti-lock braking


system (ABS)

94
EBA 94
ASR and DSC


95
Grip control


96
Active City Brake


98
Seat belts


102
Airbags


104
Carrying children


108
Deactivating the passenger's front


airbag

1
10
Recommended seats

1
13
Installation

1
14
Environment

15
Eco-driving


16
The "V

isual search" (visual
index) section assists
you in finding the controls
and functions and their
associated page numbers
on the schematic outlines of
the vehicle.
Instruments and controls
left hand drive


13 right hand drive


14
READY TO GO SAFETY
EASE OF USE and
COMFORT
18-54
55-8990-116
3.
4. 5.
E
CO
-
DRIVI
n
G
15-17
2.
Contents

8
Berlingo-2-VU_en_Chap01_vue ensemble_ed01-2015
ASR-DSC 95
Parking sensors 91-92
Electric mirrors

87-88Headlamp beam height adjustment 57
Stop & Start
49-51 Starter motor
, ignition switch
52
Wipers

58-59
Automatic wiping

58Windscreen / headlamp wash 59, 128
Trip computer
60
Cruise control

61-63
Speed limiter


64-66
Lighting


55-57
Automatic illumination of headlamps


56
Foglamps


56, 57
InSTRUMEnTS A n D CO n TROLS
Dashboard, passenger
compartment fuses 154-156
Opening the bonnet

124
Parking brake, handbrake


90Instrument panels,


screens, dials
28-29Warning lamps, indicator lamps 32-39
Indicators, gauge
40, 43-44
Setting the time

in the instrument panel

29
Lighting dimmer


44
Gear shift


indicator

46
Steering mounted controls:-


T
ouch screen tablet
172
-


Audio system

233
Steering wheel adjustment


45
Horn


90
6-speed electronic


gearbox

47-48
Location

11
Berlingo-2-VU_en_Chap01_vue ensemble_ed01-2015
Parking brake, handbrake 90 Instrument panels,

screens, dials
28-29Warning lamps, indicator lamps 32-39
Indicators, gauge
40, 43-44
Setting the time

in the instrument panel

29
Lighting dimmer


44
Gear shift


indicator

46 Passenger's front airbag deactivation


107, 1
10
ASR-DSC

95
Parking sensors


91-92
Electric mirrors


87-88Headlamp beam height adjustment 57
Stop & Start
49-51
Starter motor
, ignition switch

52
Wipers


58-59
Automatic wiping


58Windscreen / headlamp wash 59, 128
Trip computer
60
Steering mounted controls: -

T

ouch screen tablet

172
-


Audio system


233
Steering wheel adjustment


45
Horn


90
6-speed electronic


gearbox

47-48
Lighting


55-57
Automatic illumination of headlamps


56
Foglamps


56, 57
Cruise control


61-63
Speed limiter


64-66
1
oVERVIEW
Location

13
Berlingo-2-VU_en_Chap01_vue ensemble_ed01-2015
InSTRUMEnTS AnD COn TROLS
1. Lighting and direction indicator control
stalk.
2.

Instrument panel with screen.
3.


Wiper
, screenwash, trip computer
control stalk.
4.

Ignition switch.
5.


Audio controls.
6.


Driver's front airbag, horn.
7.


Steering wheel height and reach
adjustment.
8.


Cruise control, speed limiter controls.
9.


Switch panel: parking sensors,
headlamp beam adjustment, DSC,
Stop & Start.
10.


Bonnet release lever
.
11 .
Electric door mirror adjustment.
12.


Front electric window switches.
13.


Switch panel: hazard warning
lamps, central locking (passenger
compartment, load space).
14.


Cigarette lighter
.
15.

Heating-ventilation controls.
16.


Electronic gearbox control or Grip
control button.
17.


T
ouch screen tablet.
18.

USB port (with electronic gearbox).
19.


USB port (with manual gearbox).
1
OVERVIEW
Presentation

14
Berlingo-2-VU_en_Chap01_vue ensemble_ed01-2015
1. Lighting and direction indicator control
stalk.
2.

Instrument panel with screen.
3.


Wiper
, screenwash, trip computer
control stalk.
4.

Ignition switch.
5.


Audio controls.
6.


Driver's front airbag, horn.
7.


Steering wheel height and reach
adjustment.
8.


Cruise control, speed limiter controls.
9.


Switch panel: parking sensors,
headlamp beam adjustment, DSC,
Stop & Start, alarm.
10.


Bonnet release lever
.
11 .
Electric door mirror adjustment.
12.


Front electric window switches.
13.


Switch panel: hazard warning
lamps, central locking (passenger
compartment, load space).
14.


Cigarette lighter
.
15.

Heating-ventilation controls.
16.


Electronic gearbox control or Grip
control button.
17.


T
ouch screen tablet.
18.

USB port (with electronic gearbox).
19.


USB port (with manual gearbox).
InSTRUMEnTS AnD CO n TROLS
Presentation

18
BERLInGO-2-VU_En_CHAP03_PRET-A-PARTIR_ED01-2015
KEY
This locks and unlocks the vehicle's
doors, opens and closes the fuel filler
cap, as well as starting and stopping
the engine.
Security of use
R
EMOTE

CO
n
TROL
Unlocking the cab or the vehicle Unlocking the load spaceLocking
Press this button to lock the
vehicle completely.
The direction indicators flash once.
If one of the doors is open
(transportation of long loads) or is not
closed correctly, the central locking will
not work.
Deadlocking
A second press on the closed padlock
on the remote control within five
seconds after locking changes the
locking to deadlocking.
This is confirmed by fixed lighting
of the direction indicators for
approximately two seconds.
Deadlocking renders the exterior
and interior door opening handles
inoperative: do not leave anyone inside
the vehicle when it is deadlocked.
If deadlocking is activated from inside
the vehicle using the remote control, it
will change to normal locking when the
vehicle is started.
To unlock the load space only:
Press this control to unlock
the load space, the front
doors alone remain locked. Press this control to lock the
vehicle completely. Press this button to unlock all
of the rear doors.
Press this button once to
unlock the front doors.
Press this button again
to unlock your vehicle
completely.
The direction indicators flash twice.
Access

32
BERLInGO-2-VU_En_CHAP03_PRET-A-PARTIR_ED01-2015BERLInGO-2-VU_En_CHAP03_PRET-A-PARTIR_ED01-2015
WARn I n G LAMPS
Warning lamp is indicatesSolution - action
STOP on, associated
with another
warning
lamp and
accompanied
by a message
in the screen. major faults linked with
the "Brake fluid level",
"Engine oil pressure and
temperature", "Coolant
temperature", "Electronic
brake force distribution"and
"Power steering" warning
lamps.
You must stop as soon as it is safe to do
so. Park and switch off the ignition. Have it
checked by a CITROË
n dealer or a qualified
workshop.
Parking
brake
/ Brake
fluid level /
EBFD on.
that the parking brake is applied
or has not been released fully.Releasing the parking brake switches off the
warning lamp.
on. low brake fluid level. Top up using a fluid recommended by CITROËN.
remaining on even
though the level
is correct and
associated with the
ABS warning lamp.
a fault with the electronic
brake force distribution. You must stop as soon as it is safe to do so.
Park and switch off the ignition.
Have it checked by a CITROË
n dealer or a
qualified workshop.
Engine oil
pressure and
temperature on while
driving.
low pressure or a high
temperature. Park and switch off the ignition then allow to cool.
Visually check the level.
Chapter 7, "Levels" section.
remaining on,
even though
the level is
correct. a major fault.
Have it checked by a CITROËN dealer or a
qualified workshop.
Each time the vehicle is started: a series of warning lamps comes on applying a self-test check. They go off almost
immediately.
Engine running: the lamp becomes a warning if it remains on continuously or flashes.
This initial warning may be accompanied by an audible signal and a message in the screen.
Do not ignore these warnings.
Instruments and controls

33
BERLInGO-2-VU_En_CHAP03_PRET-A-PARTIR_ED01-2015BERLInGO-2-VU_En_CHAP03_PRET-A-PARTIR_ED01-2015
Warning lamp is indicatesSolution - action
Coolant
temperature
and level on with needle
in the red
zone.
an abnormal increase in
temperature.
Park and switch off the ignition then allow to cool.
Visually check the level.
flashing. a drop in the coolant level. Chapter 7, "Levels" section.
Contact a CITROËN
dealer or a qualified
workshop.
Service on temporarily. minor faults or warnings.
Consult the alert log in the display or screen.
If your vehicle is equipped with a trip computer or
a screen: refer to the "Steering mounted controls"
section in Chapter 4.
Contact a CITROËN dealer or a qualified workshop.
remaining on. major faults.
Seat belt not
fastened on then
flashing.
the driver and/or front
passenger has not fastened
their seat belt.
Pull the strap then insert the tongue in the buckle.
accompanied
by an audible
signal then
remains on. the vehicle is moving with
the driver's and/or front
passenger's seat belt not
fastened.
Check that the seat belt is fastened by pulling the
strap.
Chapter 5, "Seat belts" section.
ECO on.
The Stop & Start
system
has put the engine in STOP
mode following a vehicle
stop (red light, traffic jam,
etc...). As soon as you want to move off, the warning
lamp goes off and the engine restarts
automatically in START mode.
flashes for a
few seconds,
then goes off. STOP mode is temporarily
unavailable.
or
START mode has been
invoked automatically.
Chapter 3, "Stop & Start" section.
READY TO GO
3
Instruments and controls

49
BERLInGO-2-VU_En_CHAP03_PRET-A-PARTIR_ED01-2015BERLInGO-2-VU_En_CHAP03_PRET-A-PARTIR_ED01-2015
STOP & START
The Stop & Start system puts the
engine temporarily on standby - ST OP
mode - during stops in the traffic (red
lights, traffic jams, or other...). The
engine restarts automatically - START
mode - as soon as you want to move
off. The restart takes place instantly,
quickly and silently.
Perfect for urban use, the Stop & Start
system reduces fuel consumption and
exhaust emissions as well as the noise
level when stationary.
Operation
Going into engine STOP mode
The "ECO" warning lamp comes
on in the instrument panel and
the engine goes into standby:
- with a manual gearbox , at speeds
below 12 mph (20 km/h), when you
put the gear lever into neutral and
release the clutch pedal,
-

with the 6-speed electronic gear
control gearbox

, at a speed below
5 mph (8 km/h), when you press
the brake pedal or put the gear
lever into position
n .If your vehicle is fitted with the system,
a time counter calculates the sum of
the periods in STOP mode during a
journey. It rests itself to zero every time
the ignition is switched on with the key.
With the automatic gearbox
system, for your comfort during
parking manoeuvres, STOP mode
is not available for a few seconds after
coming out of reverse gear.
STOP mode does not affect the
functionality of the vehicle, such as
braking, power steering, for example.
Never refuel with the engine in
STOP mode; you must switch off
the ignition with the key. Special cases: STOP mode
unavailable
STOP mode is not invoked when:
-
the driver's door is open,
-

the driver's seat belt is not
fastened,
-

the vehicle has not exceeded

6 mph (10 km/h) since the last
engine start using the key,
-
the engine is needed to maintain
a comfortable temperature in the
passenger compartment,
-

demisting is on,
-

some special conditions (battery
charge, engine temperature,
braking assistance, ambient
temperature...) where the engine
is needed to assure control of a
system.
In this case, the
"ECO"
warning lamp flashes for a
few seconds, then goes off.
This operation is perfectly normal.
READY TO GO
3
Stop & Start

50
BERLInGO-2-VU_En_CHAP03_PRET-A-PARTIR_ED01-2015BERLInGO-2-VU_En_CHAP03_PRET-A-PARTIR_ED01-2015
Going into engine START mode
The "ECO" warning lamp
goes off and the engine starts:
-

with a manual gearbox
, when you
fully depress the clutch pedal,
-

with the 6-speed electronic gear
control gearbox

:
●

gear lever in position
A or M,
when you release the brake
pedal,
●

or gear lever in position
n and
the brake pedal released, when
you move the gear lever to posi-
tion A or M,
●

or when you engage reverse
gear

.
With a manual gearbox in STOP
mode, if a gear is engaged without
fully depressing the clutch pedal, a
warning lamp comes on or a message
is displayed asking you to depress the
clutch pedal to restart the engine. Special cases: START invoked
automatically
For your safety and comfort, START is
invoked automatically when:
-

you open the driver's door
,
-

you unfasten the driver's seat belt,
-


the speed of the vehicle exceeds
15 mph (25 km/h) with a manual
gearbox or 7 mph (1

1 km/h) with
the 6-speed electronic gearbox
system,
-

some special conditions (battery
charge, engine temperature,
braking assistance, ambient
temperature...) where the engine
is needed to assure control of a
system.In this case the

"ECO"
warning lamp flashes for few
seconds, then goes off.
This operation is perfectly normal.Deactivation
At any time, press the "ECO
OFF" switch to deactivate the
system.
This is confirmed by the switch warning
lamp coming on accompanied by a
message in the screen.
If the system has been deactivated
in STOP mode, the engine restarts
immediately.
Stop & Start
