Cooling system
Only use the fluid recommended by the manufacturer.
Otherwise,
  you   risk   seriously   damaging
your

  engine.
When the engine is warm, the
temperature of the coolant is controlled
by
  the   engine   fan.
As
  this   fan   can
operate

  with   the   ignition   key   removed
and because the cooling system is
pressurised, wait for at least one hour
after the engine has stopped before
carrying

  out   any   work.
Slacken
  the   cap   by   1/4   of   a   turn   to
release the pressure to prevent any
risk

  of   scalding.   When   the   pressure
has dropped, remove the cap and top
up

  the   level   with   coolant.
If
  fluid   has   to   be   added   frequently,
this indicates a fault which must be
checked

  by   a   CITROËN   dealer   as
soon

  as   possible.
Power steering fluid level
The vehicle must be parked on level ground  with   the   engine   cold.   Unscrew
the cap integrated with the gauge and
check

  the   level   which   must   be   between
the

  MIN   and   MAX   marks. In
  order   to   regenerate   the   filter,   you  are advised to drive at a speed higher
than
  40   mph   (60   km/h)   for   at   least   five  minutes as soon as possible, when
traffic
  conditions   permit   (until   the
message disappears and the service
warning

  lamp   goes   off).
During regeneration of the particle
emission
  filter,   the   noise   of   a   relay
operating may be heard under the
dashboard.
If the message is still displayed and
if the service warning lamp remains
on, contact a CITROËN dealer or a
qualified

  workshop.
Topping up
The level must be between the MIN
and

MAX

marks

on

the

expansion

bottle.


If

more

than

1

litre

of

fluid

is

required to top up the level, have the
system


checked

by

a

CITROËN

dealer

or


a

qualified

workshop.
Screenwash level
For best quality cleaning and for your
safety, we would advise that you use
products   of   the   CITROËN   range.
For optimum cleaning and to avoid
freezing,
  this   fluid   must   not   be   topped
up

  or   replaced   with   plain   water.
Capacity
  of   the   screenwash   reservoir:
approximately

  3   litres.
Diesel additive level
(Diesel with particle
filter)
Topping up
This additive must be topped up by
a  CITROËN   dealer   or   a   qualified
workshop

  without   delay.
Waste products
Avoid prolonged contact of used oil
with  the   skin.
Brake
  fluid   is   harmful   to   health   and
very

  corrosive.
Do
  not   dispose   of   used   oil,   brake   fluid
or coolant into drains or into the ground
but into the containers dedicated to this
use at a CITROËN dealer (France) or
an

  authorised   waste   disposal   site.
The minimum level of this additive
is indicated by lighting of the service
warning lamp, accompanied by an
audible signal and a message in the
screen.
When this occurs with the engine
running it is due to the start of
saturation

of

the

particle

filter

(exceptionally prolonged urban type
driving


conditions:

low

speed,

long

traffic


jams,

...).
Levels

187
Berlingo2VP_en_Chap08_Aide-rapide_ed02-2016Berlingo2VP_en_Chap08_Aide-rapide_ed02-2016
CHANGING A FUSE
The fuseboxes are located:
-
in the lower dashboard on the left-
hand side (behind the cover),
-


under
  the   bonnet   (near   the   battery).
The information given concerns only
those fuses which can be changed by
the user using the tweezer, located
behind the dashboard storage
compartment
  on   the   right-hand   side.
For

  any   other   work,   visit   a   CITROËN
dealer

  or   a   qualified   workshop.
Removing and fitting a fuse
Always replace a failed fuse with a
fuse of the same rating.
Motor

trade

technicians:

for

complete information on the fuses
and relays, refer to the "Repair
Manual" diagrams via the dealer
network.
CITROËN will not accept responsibility
for the cost incurred in repairing
your vehicle or for rectifying the
malfunctions resulting from the
installation of accessories not
supplied and not recommended by the
CITROËN


network

and

not

installed

in accordance with its instructions,
in particular when the combined
consumption of all of the additional
equipment connected exceeds
10 millia

mperes. Before replacing a fuse, the cause of
the
  incident   must   be   identified   and
rectified.
●


Use
  the   tweezer.
QUICK HELP
8
Changing a fuse

189
Berlingo2VP_en_Chap08_Aide-rapide_ed02-2016Berlingo2VP_en_Chap08_Aide-rapide_ed02-2016
Passenger compartment fuses
Fuses F Amperes
A Allocation
1 - Not used
2 20 Heated seats
3 - Not used
4 15 Folding mirrors relay
5 15 Refrigeration
  equipment   socket   relay
QUICK HELP
8
Changing a fuse
