25INSTRUMENTS, CONTROLS and DISPLAYS-
DISPLAY A
This displays the following information:
- the time,
- the date,
- t h e a u d i o s y s t e m d i s p l a y s ,
- a d o o r c h e c k ( e . g . : ' ' l e f t f r o n t d o o r open''),
- w a r n i n g m e s s a g e s ( e . g . ' ' r e m o t e c o n t r o l b a t t e r y fl a t ' ' ) o r i n f o r m a t i o n
m e s s a g e s ( e . g . ' ' e c o n o m y m o d e
a c t i v e ' ' ) , d i s p l a y e d t e m p o r a r i l y . A d j u s t i n g t h e p a r a m e t e r s d i s p l a y A
P r e s s a n d h o l d b u t t o n
A for two sec-
onds to access the settings; the data
fl a s h e s , i n d i c a t i n g i t i s r e a d y t o b e
m o d i fi e d .
T h e n , e a c h p r e s s o f b u t t o n A scrolls
t h r o u g h t h e v a r i o u s d a t a i n t h e f o l l o w -
ing order:
- l a n g u a g e o f i n f o r m a t i o n d i s p l a y e d ,
- h o u r s ( 1 2 t h e n 2 4 h o u r m o d e ) ,
- m i n u t e s ,
- year,
- month,
- d a y .
P r e s s i n g b u t t o n B a l t e r s t h e v a l u e o f
t h e p a r a m e t e r s e l e c t e d . P r e s s a n d
h o l d f o r r a p i d a d v a n c e ( r e t u r n t o s t a r t
a f t e r t h e l a s t p o s s i b l e v a l u e ) .
After 7 seconds with no action, the
s t a n d a r d d i s p l a y r e t u r n s ; t h e m o d i fi e d
d a t a i s n o w r e c o r d e d .
Page 25 of 114
AUDIO EQUIPMENT28 - GENERAL FUNCTIONS AUDIO SETTINGS
Adjusting the loudness
This function automatically empha-sises bass and treble tones. Press button I or J to switch the function on or off.
On/off
With the ignition key in the accessories or ignition position, press button A to switch the set on or off.
The set can operate for 30 minutes without the vehicle ignition being switched on.
Anti-theft system
The audio system is coded in such a way that it can operate only on your v e h i c l e . I t w o u l d n o t f u n c t i o n i f fi t t e d to another vehicle.
The anti-theft system is automatic and requires no action on your part.
ADJUSTING THE VOLUME
Adjusting the bass
Adjusting the treble
When "TREB" is displayed, press button I or J to vary the setting.
- "TREB -9" for a minimum treble setting,
- "TREB 0" for a normal setting,
- "TREB +9" for a maximum treble setting.
Press button H several times in succession to access the bass(BASS) , treble (TREB) , loudness (LOUD) , fader (FAD) , balance (BAL) and automatic volume correction.
Exit from audio mode is automatic after a few seconds without pressing any button, or by pressing button H a f t e r c o n fi g u r a t i o n o f t h e a u t o m a t i c volume correction.
Note: bass and treble settings are s p e c i fi c t o e a c h s o u r c e . I t i s p o s s i -ble to set them differently for radio, cassette (RB3) , CD (RD3) and CD changer.
When "BASS" is dis-played, press button Ior J to vary the setting.
- "BASS -9" for a minimum bass setting,
- "BASS 0" for a normal setting,
- "BASS +9" for a maximum bass setting.
Press button C to in-crease the volume, or button B to decrease it.
Continuous pressure on buttons C and B allows a gradual adjustment of the volume.
Page 26 of 114
29AUDIO EQUIPMENT-
RADIO
Adjusting the front/rear sound distribution (Fader)
When "FAD" is displayed, press but-ton I or J .
Button I increases the volume in the front.
Button J increases the volume in the rear.
Adjusting the right/left sound distribution (Balance)
When "BAL" is displayed, press but-ton I or J .
Button I increases the volume on the right-hand side.
Button J increases the volume on the left-hand side.
Automatic volume correction
This function enables the volume to be automatically adjusted depending on the level of noise produced by the speed of the vehicle.
Press buttons I or J to switch the function on or off.
Selecting radio mode
Press button R . Notes on radio reception
Your car radio is subject to pheno-mena which do not affect domestic radio sets. Both AM (MW/LW) and FM reception are subject to various forms o f i n t e r f e r e n c e . T h i s i s n o r e fl e c t i o n o n the quality of the equipment, but is due to the nature of the signals and the way in which they are transmitted.
On MW/LW, interference may be noticed when passing under high voltage power lines or bridges, or in tunnels.
On FM, interference may be the re-sult of increasing distance from the t r a n s m i t t e r , d e fl e c t i o n o f t h e s i g n a l s b y obstacles (mountains, hills, buildings, etc.), or of being in an area which is not covered by a transmitter.
Selecting a waveband
B r i e fl y p r e s s b u t t o n R to select the FM1, FM2, FMast and AM wave-bands.
Page 27 of 114
29AUDIO EQUIPMENT-
RADIO
Adjusting the front/rear sound distribution (Fader)
When "FAD" is displayed, press but-ton I or J .
Button I increases the volume in the front.
Button J increases the volume in the rear.
Adjusting the right/left sound distribution (Balance)
When "BAL" is displayed, press but-ton I or J .
Button I increases the volume on the right-hand side.
Button J increases the volume on the left-hand side.
Automatic volume correction
This function enables the volume to be automatically adjusted depending on the level of noise produced by the speed of the vehicle.
Press buttons I or J to switch the function on or off.
Selecting radio mode
Press button R . Notes on radio reception
Your car radio is subject to pheno-mena which do not affect domestic radio sets. Both AM (MW/LW) and FM reception are subject to various forms o f i n t e r f e r e n c e . T h i s i s n o r e fl e c t i o n o n the quality of the equipment, but is due to the nature of the signals and the way in which they are transmitted.
On MW/LW, interference may be noticed when passing under high voltage power lines or bridges, or in tunnels.
On FM, interference may be the re-sult of increasing distance from the t r a n s m i t t e r , d e fl e c t i o n o f t h e s i g n a l s b y obstacles (mountains, hills, buildings, etc.), or of being in an area which is not covered by a transmitter.
Selecting a waveband
B r i e fl y p r e s s b u t t o n R to select the FM1, FM2, FMast and AM wave-bands.
Page 28 of 114
AUDIO EQUIPMENT30 -
B r i e fl y p r e s s b u t t o n L or N to search for the station immediately above or below. By continuing to press the button in the direction selected, you will obtain continuous scrolling of the frequency.
T h e s c r o l l i n g s t o p s a t t h e fi r s t s t a -tion found as soon as the button is released.
If the TA t r a f fi c i n f o r m a t i o n p r o -gramme is selected, only stations broadcasting this type of programme are selected.
S e a r c h i n g f o r a s t a t i o n o c c u r s fi r s t i n "LO" sensitivity (selection of the most powerful transmitters) during scan-ning of the waveband, then in "DX"sensitivity (selection of the weakest and most distant transmitters).
To make a direct search in "DX" sen-sitivity, press button L or N twice.
Manual station search
Press the "MAN" button.
B r i e fl y p r e s s b u t t o n L or N to in-crease or decrease the frequency displayed.
By continuing to press the button in the direction selected, you will obtain continuous scrolling of the frequency.
T h e s c r o l l i n g s t o p s a t t h e fi r s t s t a -tion found as soon as the button is released.
Pressing the "MAN" button again returns you to automatic station search.
Manual storing of stations in the memory
Select the station required.
Press one of the buttons "1" to "6"for more than two seconds.
The sound stops then becomes audible a g a i n , c o n fi r m i n g t h a t t h e s t a t i o n h a s been stored in the memory.
Automatic station search Automatic storing of FM stations in the memory (autostore)
Press and hold but-ton R for more than two seconds.
Your radio automatically stores the 6 stations with the strongest signal in FM . These stations are stored in the FMast waveband.
I f i t i s n o t p o s s i b l e t o fi n d 6 s t a t i o n s , the remaining memories are empty.
Recalling stations stored in the memory
F o r e a c h w a v e b a n d , b r i e fl y p r e s s buttons "1" to "6" to recall the cor-responding station.
Page 29 of 114
31AUDIO EQUIPMENT-
RDS
T r a f fi c i n f o r m a t i o n p r o g r a m m e Regional following mode (REG)
RDS station following
The display indicates the name of the station selected. The radio is conti-nually searching for the station which has the best reception and which is transmitting the same programme.
Press the "TA" button to switch the function on or off.
The multi-function display will show:
- "TA" if the function is selected,
- "(TA)" if the function is selected but not available.
A n y t r a f fi c i n f o r m a t i o n fl a s h w i l l b e given priority, whatever source you are listening to (radio, cassette, CD or CD changer).
If you wish to interrupt a message, press the "TA" button; this switches the function off.
B r i e fl y p r e s s t h e "RDS" button to switch the function on or off.
The multi-function display will show:
- "RDS" if the function is selected.
- "(RDS)" if the function is selected but not available.
When they are part of a network, certain stations broadcast re-gional programmes in the various areas they serve. With re-gional following mode you can keep listening to the same programme.
Press the "RDS" button for more than two seconds to switch the REGfunction on or off.
Using the RDS (Radio Data System) function on FM
Radio Data System allows you to continue listening to the same sta-tion, whatever frequency it is using for the region you are going through.
N o t e : t h e v o l u m e o f t r a f fi c i n f o r m a -tion announcements is indepen-dent of the volume of normal radio listening. You can adjust it using the volume button. The setting will be stored and will be used when the next messages are broadcast.
Page 30 of 114
AUDIO EQUIPMENT32 -
EON system
This connects stations which are part of the same network. It enables the b r o a d c a s t o f t r a f fi c i n f o r m a t i o n , b y a station that is part of the same net-work as the station to which you are listening.
This service is available when you have selected the TA t r a f fi c i n f o r m a t i o n p r o -TAgramme or the PTY function. PTY
PTY function
This allows you to listen to stations broad- c a s t i n g a s p e c i fi c t y p e o f p r o g r a m m e (news, culture, sport, rock, etc.).
To search for a PTY programme: PTY
With FM selected, press the "TA" but-ton for more than two seconds to switch this function on or off.
- select the PTY function, PTY
- b r i e fl y p r e s s b u t t o n L or N to scroll down the list of the various types of programmes offered.
- when the programme of your choice is displayed, keep button L or N pressed for more than two seconds to carry out an automatic search (after an automatic search the PTY function is switched off). PTY
In PTY mode the different types of PTYprogrammes can be stored in the memory. To do this, press the prese-lection buttons "1" to "6" for more t h a n t w o s e c o n d s . B r i e fl y p r e s s t h e corresponding button to recall the type of programme stored in the memory.
Page 72 of 114
DRIVING72 -
SPEED LIMITER
T h e o p e r a t i n g a c t i o n s m u s t b e
c a r r i e d o u t w h e n s t a t i o n a r y , w i t h
t h e e n g i n e r u n n i n g , o r w i t h t h e v e -
h i c l e m o v i n g . The status of the function is displayed
on the instrument panel in accordance
with the following sequences:
Function selected,
displaying of the "Speed
Limiter" symbol.
Function deactivated,
last programmed speed - OFF (example at 66 mph
(107 km/h)).
Function activated
(example at 66 mph (107 km/h)).
Vehicle speed above
66 mph (107 km/h),
the programmed speed is
d i s p l a y e d fl a s h i n g .
Operating fault detected,
O F F - t h e d a s h e s fl a s h .
S e l e c t i n g t h e f u n c t i o n
Place the dial in the LIMIT position.
The limiter is selected but is not yet
active. The display indicates dashes
or the last programmed speed.
Programming a speed
A speed can be programmed without
activating the limiter but with the en-
gine running.
A brief or extended press of the
SET - button decreases the speed.
A brief or extended press of the
SET + button increases the speed.
A c t i v a t i o n / d e a c t i v a t i o n ( o f f )
When you have programmed your
speed, pressing this button once acti-
vates the limiter and the programmed
speed is displayed, pressing the button
again deactivates it (OFF).
Page 73 of 114
73DRIVING-
E x c e e d i n g t h e p r o g r a m m e d
speed
Pressing the accelerator pedal in order
to exceed the programmed speed
will have no effect unless you press
the pedal fi r m l y beyond the p o i n t o f
resistance .
The limiter is deactivated temporarily
and the programmed speed which is
s t i l l d i s p l a y e d fl a s h e s .
F l a s h i n g o f t h e s p e e d
T h e s p e e d fl a s h e s :
- following forcing of the accelerator point of resistance,
- when the limiter cannot prevent an increase in the vehicle speed
d u e t o t h e p r o fi l e o f t h e r o a d o r o n
a steep descent,
- in the event of sharp acceleration. In any event, the speed limiter
cannot replace the need to ob-
serve speed limits, nor can it
replace the need for vigilance
and responsibility on the part
of the driver.
The driver must always pay attention
t o t h e p r o fi l e o f t h e r o a d , t a k e c a r e
on sharp acceleration and remain in
perfect control of his vehicle.
To prevent the mat from becoming
trapped under the pedals:
- e n s u r e t h a t t h e m a t a n d i t s fi x i n g s are positioned correctly,
- n e v e r fi t o n e m a t o n t o p o f a n o t h e r .
S w i t c h i n g t h e f u n c t i o n o f f
Place dial in position 0 or switch
off the ignition to switch the
system off. The last programmed
speed remains in the memory.
O p e r a t i n g f a u l t
In the event of a limiter malfunction,
a message is displayed on the multi-
function display accompanied by an
audible signal.
The programmed speed is cleared and
t h e d a s h e s fl a s h f o r a f e w s e c o n d s .
Contact a CITROËN dealer to have
the system checked.
To return to the limiter function, re-
duce your speed to the programmed
speed or below.
Page 74 of 114
DRIVING74 -
CRUISE CONTROL
The cruise control maintains a con-
stant vehicle speed programmed by
the driver.
In order for it to be programmed or
activated, the vehicle speed must be
greater than 25 mph (40 km/h) with
at least fourth gear engaged.
I f t h e v e h i c l e i s fi t t e d w i t h a s p e e d
limiter and cruise control, these func-
tions cannot be activated at the same
time. The status of the function is displayed
on the instrument panel in accord-
ance with the following sequences:
Function selected,
displaying of the
"Cruise Control" symbol.
Function deactivated,
OFF (example at 66 mph
(107 km/h)).
Function activated (example at 66 mph (107 km/h)).
Vehicle speed above
(e.g. 73 mph (118 km/h)),
the programmed speed is
d i s p l a y e d fl a s h i n g .
Operating fault detected,
O F F - t h e d a s h e s fl a s h .
S e l e c t i n g t h e f u n c t i o n
Place the switch in the CRUISE
position. The cruise control is
selected but is not yet active and
no speed has been programmed. First activation/programming a
speed
Reach the chosen speed by
pressing the accelerator.
Press the SET - or SET + button.
This programmes the reference
speed and the vehicle will maintain
this speed.
T e m p o r a r y e x c e e d i n g o f t h e
speed
It is possible to accelerate and drive
momentarily at a speed greater than
the programmed speed. The value
p r o g r a m m e d fl a s h e s .
When the accelerator pedal is re-
leased, the vehicle will return to the
programmed speed.
The cruise control has a display on
the instrument panel to indicate the
programmed reference speed.
