51SEATS-
ADVICE ON CHILD SEATS
The incorrect installation of a
child seat in a vehicle com-
promises the child's protection in the
event of an accident.
Remember to fasten the seat belts or
the child seat harnesses keeping the
slack in relation to the child's body to
a minimum, even for short journeys.
For optimum installation of the "for-
ward facing" child seat, ensure that
the back of the child seat is in contact
with the back of the vehicle's seat
and that the head restraint does not
cause any discomfort.
If the head restraint has to be re-
moved, ensure that it is stored or
attached securely to prevent it from
being thrown around the vehicle in
the event of sharp braking. Children under the age of 10 must not
travel in the "forward facing" position
on the front passenger seat, unless
the rear seats are already occupied
by other children, cannot be used or
are absent.
Deactivate the passenger airbag
when a "rear facing" child seat is in-
stalled on the front seat. Otherwise,
the child would risk being seriously
injured or killed if the airbag were to
i n fl a t e .
As a safety precaution, do not leave:
- one or more children alone and
unsupervised in a vehicle,
- a child or an animal in a vehicle which is exposed to the sun, with
the windows closed,
- the keys within reach of children inside the vehicle.
Installing a booster seat
The chest part of the seat belt must
be positioned on the child's shoulder
without touching the neck.
Ensure that the lap part of the seat
belt passes correctly over the child's
thighs.
CITROËN recommends the use of a
b o o s t e r s e a t w h i c h h a s a b a c k , fi t t e d
with a seat belt guide at shoulder level. To prevent accidental
opening of the doors, use
the "Child lock".
Take care not to open the
rear windows by more than
one third.
To protect young children from the
r a y s o f t h e s u n , fi t s i d e b l i n d s o n t h e
rear windows.
Page 52 of 123
SEATS52-
SEAT BELTS
Locking the seat belts
Pull the strap, then insert the end into
the buckle.
Check that the seat belt is fastened
correctly by pulling the strap.
Unfastening the seat belts
Press the button on the buckle.
Front seat belts
with pre-tensioner
Safety in the event of frontal impacts
has been improved by the introduc-
tion of pre-tensioning seat belts for
the front seats.
Depending on the seriousness of the
impact, the pre-tensioning system
instantly tightens the seat belts and
pulls them against the bodies of the
occupants.
The pre-tensioning seat belts are
armed when the ignition is on.
Seat belt height adjustment
To lower or raise: slide the control
downwards or upwards. Rear seat belts
(5 seat version)
T h e r e a r s e a t s a r e fi t t e d w i t h t h r e e
three-point inertia reel seat belts
(two-part rear seat, 1/3 - 2/3).
Rear seat belts
(7 seat version)
In row 2
T h e r e a r s e a t s a r e fi t t e d w i t h t w o
three-point inertia reel seat belts.
In row 3
T h e r e a r s e a t s a r e fi t t e d w i t h t h r e e
three-point inertia reel seat belts.
Page 53 of 123
53SEATS-
The driver must ensure that
the passengers use the seat
belts correctly and that they
are all properly restrained
before setting off.
Wherever you are seated in the ve-
hicle, always fasten your seat belt,
even for short journeys.
Do not invert the seat belt buckles as
t h e y w i l l n o t f u l fi l t h e i r r o l e f u l l y .
If the seats have armrests * , the lap
part of the seat belt must always
pass under the armrest.
T h e s e a t b e l t s a r e fi t t e d w i t h a n i n -
ertia reel permitting automatic adjust-
ment of the length of the strap to your
size. The seat belt is stored automat-
ically when not in use.
Before and after use, ensure that the
seat belt is reeled in correctly.
The lower part of the strap must be
positioned as low as possible on the
pelvis.
The upper part must be positioned in
the hollow of the shoulder.
T h e i n e r t i a r e e l s a r e fi t t e d w i t h a n a u -
tomatic locking device which comes
into operation in the event of a colli-
sion, on emergency braking or if the
vehicle rolls over. You can release
the device by pulling rapidly on the
strap and releasing it. In order to be effective, a seat belt:
- must be tightened as close to the
body as possible,
- must restrain one adult only,
- must not bear any trace of cuts or fraying,
- must be pulled in front of you with a smooth movement, checking
that it does not twist,
- m u s t n o t b e t r a n s f o r m e d o r m o d i fi e d to avoid altering its performance.
In accordance with current safety
regulations, all repairs and checks
must be carried out by a CITROËN
dealer who guarantees that the work
is carried out correctly.
Have your seat belts checked regu-
larly by a CITROËN dealer and par-
ticularly if the straps show signs of
damage.
Clean the seat belt straps with soapy
water or a textile cleaning product,
sold by CITROËN dealers.
* According to model.
Recommendations for children:
- use a suitable child seat if the pas-
senger is less than 12 years old or
s h o r t e r t h a n o n e m e t r e fi f t y ,
- do not use the strap-guide * when a child seat is installed.
- never use the same seat belt to secure more than one person,
- never allow a child to travel on your lap.
Depending on the nature and se-
riousness of the impacts , the pre-
tensioning device may be triggered
before and independently of the air
bags. Triggering of the pre-tensioners
is accompanied by a slight emission
of harmless smoke and a noise, due
to the activation of the pyrotechnic
cartridge incorporated in the system.
In all cases, the airbag warning lamp
comes on.
Following an impact, have the seat
belts system checked, and if neces-
sary replaced, by a CITROËN dealer.
After folding or moving a
seat or rear bench seat,
ensure that the seat belt
is positioned and rolled up
correctly.
Page 54 of 123
ACCESS and STARTING54 -
KEYS
The keys allow you to switch on the
ignition and operate the passenger
air bag disarming switch as well as to
independently operate the locks on
t h e d o o r s a n d t h e f u e l fi l l e r c a p . Locating your vehicle
To locate your vehicle, if you have
locked it, in a car park:
press button A , the courtesy lamps
come on and the direction indica-
t o r s fl a s h f o r a f e w s e c o n d s . Changing the battery of the
remote control
C R 2 0 1 6 / 3 v o l t b a t t e r y .
T h e i n f o r m a t i o n " b a t t e r y fl a t " i s g i v e n
by an audible signal accompanied
by the message
"Remote control
b a t t e r y fl a t " o n t h e s c r e e n .
To change the battery, unclip the
c a s i n g u s i n g a c o i n a t t h e r i n g .
If the remote control does not work
after the battery has been changed,
r e - p r o g r a m m e t h e r e m o t e c o n t r o l .
Reinitialising the remote
control
S w i t c h o f f t h e i g n i t i o n .
S w i t c h t h e i g n i t i o n o n a g a i n .
Press button A immediately for a
f e w s e c o n d s .
Switch off the ignition and remove
the remote control key from the
i g n i t i o n l o c k . T h e r e m o t e c o n t r o l
i s n o w w o r k i n g a g a i n .
Remote control
Central locking
From the front doors, the keys allow
you to lock and unlock the doors and
t a i l g a t e .
If one of the doors or the tailgate is
open, the central locking does not
w o r k .
The remote control performs the
same functions at a distance. Locking
Press button
A t o l o c k t h e v e h i c l e .
T h i s i s c o n fi r m e d b y fi x e d l i g h t i n g o f
t h e d i r e c t i o n i n d i c a t o r s f o r a p p r o x i -
m a t e l y t w o s e c o n d s .
Unlocking
Press button B t o u n l o c k t h e v e h i c l e .
T h i s i s c o n fi r m e d b y r a p i d fl a s h i n g o f
t h e d i r e c t i o n i n d i c a t o r s .
Note : if the vehicle is locked and
unlocking is activated inadvertently,
unless the doors are opened within
30 seconds, the vehicle will lock au-
t o m a t i c a l l y .
Page 55 of 123
55ACCESS and STARTING-
ELECTRONIC ENGINE IMMOBILISER
This locks the engine control sys-
tem as soon as the ignition has been
switched off and therefore prevents
starting of the vehicle by anyone who
d o e s n o t h a v e t h e k e y .
The ignition key has an electronic
c h i p w h i c h h a s a s p e c i a l c o d e . W h e n
the ignition is switched on, the code
must be recognised for the vehicle to
s t a r t .
If the system does not function
correctly, the central locking button
indicator light, situated in the centre
o f t h e f a s c i a , fl a s h e s r a p i d l y w h e n t h e
ignition is switched on (2nd notch),
accompanied by an audible signal
a n d a m e s s a g e o n t h e d i s p l a y .
In this case your vehicle will not
s t a r t .
Contact a CITROËN dealer as soon
a s p o s s i b l e .
Key in ignition
A buzzer sounds on opening the
driver's door, if the key has been left
i n t h e i g n i t i o n . Make a careful note of the
n u m b e r o f e a c h k e y . T h i s
number is coded on the label
a t t a c h e d t o t h e k e y .
The high frequency remote control is
a sensitive system; do not operate it
while it is in your pocket as there is a
possibility that it may unlock the vehi-
c l e , w i t h o u t y o u b e i n g a w a r e o f i t .
The remote control does not operate
when the key is in the ignition, even
when the ignition is switched off,
e x c e p t f o r r e p r o g r a m m i n g .
Driving with the doors locked may
make access to the passenger com-
partment by the emergency services
m o r e d i f fi c u l t i n a n e m e r g e n c y .
As a safety precaution (with children
on board), remove the key from the
ignition when you leave the vehicle,
e v e n f o r a s h o r t t i m e .
Do not repeatedly press the buttons
of your remote control out of range of
y o u r v e h i c l e .
You run the risk of stopping it from
working and the remote control would
h a v e t o b e r e p r o g r a m m e d .
W h e n p u r c h a s i n g a s e c o n d - h a n d v e -
hicle, have the key codes memorised
by a CITROËN dealer, to ensure that
the keys in your possession are the
o n l y o n e s w h i c h c a n s t a r t t h e v e h i c l e .
D o n o t m a k e a n y m o d i fi c a t i o n s t o t h e
e l e c t r o n i c e n g i n e i m m o b i l i s e r s y s t e m . If the keys are lost
Visit a CITROËN dealer with the vehi-
c l e ' s V 5 r e g i s t r a t i o n c e r t i fi c a t e a n d y o u r
p e r s o n a l i d e n t i fi c a t i o n d o c u m e n t s .
The CITROËN network will be able to
retrieve the key code and the trans-
ponder code to order a replacement
k e y .
A h e a v y o b j e c t ( k e y f o b . . . ) , a t t a c h e d
to the key and weighing down on
its shaft in the ignition switch, could
c a u s e a m a l f u n c t i o n .
Page 56 of 123
ACCESS and STARTING54 -
KEYS
The keys allow you to switch on the
ignition and operate the passenger
air bag disarming switch as well as to
independently operate the locks on
t h e d o o r s a n d t h e f u e l fi l l e r c a p . Locating your vehicle
To locate your vehicle, if you have
locked it, in a car park:
press button A , the courtesy lamps
come on and the direction indica-
t o r s fl a s h f o r a f e w s e c o n d s . Changing the battery of the
remote control
C R 2 0 1 6 / 3 v o l t b a t t e r y .
T h e i n f o r m a t i o n " b a t t e r y fl a t " i s g i v e n
by an audible signal accompanied
by the message
"Remote control
b a t t e r y fl a t " o n t h e s c r e e n .
To change the battery, unclip the
c a s i n g u s i n g a c o i n a t t h e r i n g .
If the remote control does not work
after the battery has been changed,
r e - p r o g r a m m e t h e r e m o t e c o n t r o l .
Reinitialising the remote
control
S w i t c h o f f t h e i g n i t i o n .
S w i t c h t h e i g n i t i o n o n a g a i n .
Press button A immediately for a
f e w s e c o n d s .
Switch off the ignition and remove
the remote control key from the
i g n i t i o n l o c k . T h e r e m o t e c o n t r o l
i s n o w w o r k i n g a g a i n .
Remote control
Central locking
From the front doors, the keys allow
you to lock and unlock the doors and
t a i l g a t e .
If one of the doors or the tailgate is
open, the central locking does not
w o r k .
The remote control performs the
same functions at a distance. Locking
Press button
A t o l o c k t h e v e h i c l e .
T h i s i s c o n fi r m e d b y fi x e d l i g h t i n g o f
t h e d i r e c t i o n i n d i c a t o r s f o r a p p r o x i -
m a t e l y t w o s e c o n d s .
Unlocking
Press button B t o u n l o c k t h e v e h i c l e .
T h i s i s c o n fi r m e d b y r a p i d fl a s h i n g o f
t h e d i r e c t i o n i n d i c a t o r s .
Note : if the vehicle is locked and
unlocking is activated inadvertently,
unless the doors are opened within
30 seconds, the vehicle will lock au-
t o m a t i c a l l y .
Page 57 of 123
55ACCESS and STARTING-
ELECTRONIC ENGINE IMMOBILISER
This locks the engine control sys-
tem as soon as the ignition has been
switched off and therefore prevents
starting of the vehicle by anyone who
d o e s n o t h a v e t h e k e y .
The ignition key has an electronic
c h i p w h i c h h a s a s p e c i a l c o d e . W h e n
the ignition is switched on, the code
must be recognised for the vehicle to
s t a r t .
If the system does not function
correctly, the central locking button
indicator light, situated in the centre
o f t h e f a s c i a , fl a s h e s r a p i d l y w h e n t h e
ignition is switched on (2nd notch),
accompanied by an audible signal
a n d a m e s s a g e o n t h e d i s p l a y .
In this case your vehicle will not
s t a r t .
Contact a CITROËN dealer as soon
a s p o s s i b l e .
Key in ignition
A buzzer sounds on opening the
driver's door, if the key has been left
i n t h e i g n i t i o n . Make a careful note of the
n u m b e r o f e a c h k e y . T h i s
number is coded on the label
a t t a c h e d t o t h e k e y .
The high frequency remote control is
a sensitive system; do not operate it
while it is in your pocket as there is a
possibility that it may unlock the vehi-
c l e , w i t h o u t y o u b e i n g a w a r e o f i t .
The remote control does not operate
when the key is in the ignition, even
when the ignition is switched off,
e x c e p t f o r r e p r o g r a m m i n g .
Driving with the doors locked may
make access to the passenger com-
partment by the emergency services
m o r e d i f fi c u l t i n a n e m e r g e n c y .
As a safety precaution (with children
on board), remove the key from the
ignition when you leave the vehicle,
e v e n f o r a s h o r t t i m e .
Do not repeatedly press the buttons
of your remote control out of range of
y o u r v e h i c l e .
You run the risk of stopping it from
working and the remote control would
h a v e t o b e r e p r o g r a m m e d .
W h e n p u r c h a s i n g a s e c o n d - h a n d v e -
hicle, have the key codes memorised
by a CITROËN dealer, to ensure that
the keys in your possession are the
o n l y o n e s w h i c h c a n s t a r t t h e v e h i c l e .
D o n o t m a k e a n y m o d i fi c a t i o n s t o t h e
e l e c t r o n i c e n g i n e i m m o b i l i s e r s y s t e m . If the keys are lost
Visit a CITROËN dealer with the vehi-
c l e ' s V 5 r e g i s t r a t i o n c e r t i fi c a t e a n d y o u r
p e r s o n a l i d e n t i fi c a t i o n d o c u m e n t s .
The CITROËN network will be able to
retrieve the key code and the trans-
ponder code to order a replacement
k e y .
A h e a v y o b j e c t ( k e y f o b . . . ) , a t t a c h e d
to the key and weighing down on
its shaft in the ignition switch, could
c a u s e a m a l f u n c t i o n .
Page 58 of 123
ACCESS and STARTING56 - * A c c o r d i n g t o c o u n t r y .
THE ALARM SYSTEM *
The alarm offers two types of protection:
- exterior protection: the alarm
sounds if a door, the boot or the
bonnet is opened ;
- interior protection: the alarm
sounds if there is a variation in
the volume inside the vehicle
(breaking of a window or move-
ment inside the vehicle) .
Setting the alarm
Switch the ignition off and get out of
t h e v e h i c l e .
A c t i v a t e t h e a l a r m w i t h i n fi v e m i n u t e s
f o l l o w i n g y o u r e x i t f r o m t h e v e h i c l e ,
by locking using the remote control
key (the red indicator light on the
switch 1 , which can be seen from the
o u t s i d e , fl a s h e s o n c e a s e c o n d ) . Warning
If, on setting the alarm, a door, the
boot or the bonnet are not closed
correctly, the siren sounds for a mo-
m e n t .
Close the vehicle correctly to set the
a l a r m .
If the interior protection alarm is trig-
gered ten times in succession, it is
d i s a r m e d a u t o m a t i c a l l y . I t m u s t b e
set again in order for it to operate
c o r r e c t l y .
W h e n t h e a l a r m i s t r i g g e r e d , t h e s i r e n
sounds and the direction indicators
fl a s h f o r t h i r t y s e c o n d s .
After it has been triggered, the alarm
b e c o m e s o p e r a t i o n a l a g a i n .
Note: if you wish to lock your vehicle
without setting the alarm, lock it using
t h e k e y i n t h e d o o r l o c k .
Disarming the alarm
Unlock the vehicle using the remote
control key (the red indicator light on
the switch 1 g o e s o u t ) .
Note: i f t h e w a r n i n g l i g h t fl a s h e s , i t i s
a sign that the alarm has been trig-
g e r e d i n y o u r a b s e n c e .
T o s t o p i t , s w i t c h o n t h e i g n i t i o n .
Note: when the alarm is set, but the
remote control no longer works:
unlock the doors using the key
and open the door; the alarm is
triggered;
switch the ignition on within ten
s e c o n d s ; t h e a l a r m i s d i s a r m e d .
To set the alarm with exterior
protection only
If, while you are away from the vehicle,
you wish to leave a window partially
open or a pet inside the vehicle, you
n e e d t o s e l e c t e x t e r i o r p r o t e c t i o n o n l y :
Page 59 of 123
57ACCESS and STARTING-
FRONT DOORS AND SLIDING SIDE DOORS
Front doors
Side doors Front doors
The driver's door opening control
permits complete unlocking of the
v e h i c l e .
Side doors
Opening the doors from inside
Opening the doors from outside
Sliding side doors
If the fuel tank cap is removed,
the right-hand side door can-
n o t b e o p e n e d .
Locking Unlocking from the inside
Front doors
To lock, lower button
A .
The closing control of one of the front
doors permits complete locking of
t h e v e h i c l e .
To unlock and open, lift button A and
p u l l t h e h a n d l e t o w a r d s y o u .
The driver's door opening control
permits complete unlocking of the
v e h i c l e . From the inside, the sliding
side door is opened and
c l o s e d u s i n g t h e h a n d l e .
A point of resistance at the
end of the opening travel
secures the door in the
o p e n p o s i t i o n . The side door opening/closing
control only controls the door
c o n c e r n e d .
To close, push the control
B forwards
a n d s l i d e t h e d o o r .
To open, pull the control B rearwards
a n d s l i d e t h e d o o r .
Page 60 of 123
ACCESS and STARTING58 - Locking from the inside
Lower or raise control C to lock or unlock
f r o m t h e i n s i d e .
Locking from the inside
Pressing control D operates the
central locking, when the doors are
c l o s e d . Automatic central locking
Your vehicle can lock automatically
while driving (speed greater than
6 m p h ( 1 0 k m / h ) ) . Y o u c a n a c t i v a t e o r
d e a c t i v a t e t h i s f u n c t i o n .
Unlocking from the inside
Press control D .
It is still possible to open the doors
f r o m t h e i n s i d e . Activation
Press and hold control
D .
Activation of the function is accom-
panied by an audible signal and a
m e s s a g e o n t h e d i s p l a y .
Deactivation
Press and hold control D .
Deactivation of the function is accom-
p a n i e d b y a n a u d i b l e s i g n a l .
Notes:
- doors locked and ignition off: the i n d i c a t o r l i g h t fl a s h e s ,
- doors locked and ignition on: the i n d i c a t o r l i g h t r e m a i n s o n .
